POWER OFF STATE
Hold on button, then press again for 2 seconds, then you can find the WIFI symbol twinkling.
℃
28
When the wifi symbol
Connection can start
ROOM
TEMP
When wifi symbol twinkling slowly: It means Off Line
℃
0:01
22
SET TEMP
When twinkling Stops: Connection succesfully.
At this time, wifi symbol will be twinkling quickly and frequently.
It means, you can connect thermostat with phone now.
When wifi symbol stop twinkling, it means thermostat is successfully connected with
your phone.
Phone part setting
During the WIFI symbol twinkling,
Open "Beok AC" APP on your phone, you can see APP welcome page.
1.When the thermostat Wifi Symbol
you can start the configure on your Phone App.
My Thermostat
Edit
HVAC-A
34:ea:34:c8:84:7a
Press Configure key
Search Configure
2.Enter your wifi name and password, then press start connection at below.
When connection successfully, it will appear "Connection Success".
< Add a new device
Add a new device to WIFI network
WIFI Name:________
WIFI Password:_____
Display password
<<Possible cause of wifi connection faliure>>
Start Connection
Attention: Only when the WIFI symbol twinkling continuely, thermostat connection
with phone will be succefully. If wifi twinkling stops but connection didn't finish,
enter into Advanced setting to adjust wifi symbol again.
Step 5
twinkling quickly and frequently:
twinkling fast and continuely,
3.After connection success, you need press "Search " key.
My Thermostat
Edit
HVAC-A
34:ea:34:c8:84:7a
Press Search key Press Search key
Search Configure
4.Then it will appear your wifi thermostat HVAC. HVAC is the factory setting name,
when you have more than 2 thermostats, you can change it to any name you want.
My Thermostat
Edit
HVAC-A
34:ea:34:c8:84:7a
Delet current thermostat
Search Configure
a. Long press HVAC for 5 seconds, it will appear Edit Thermostat page.
(IOS phone: slide to left, to edit.)
b. Press Modify Current Thermostat.
c. For examples:.
You can change HVAC to room 1, Bedroom Bath room, or anything you like.
APP Interface on the Phone
My Thermostat
Edit
HVAC-A
"<", back to the device opens
34:ea:34:c8:84:7a
and configure panel
Valve On
Search Configure
Increase or decrease temp.
Clock/Current Time
Time synchronous with phone
Fan speed
Key Lock
Time on/off setting
Power on/off
Working mode
Advanced setting
Thermostat Setting through Phone Operation
1. Clock
Press to make the thermostat time synchronize with the current time
(your phone time). You will see the words"Time sync success"
2. Fan Speed Setting
Press to select the fan speed(Low speed, Medium speed, High speed, Auto)
3. Key Lock
Press in the App interface, to lock the button of thermostat.
(Go into Advanced setting, you will find 3 locking way.
Unlock; Lock all button except power button; Lock all button)
Edit Thermostat
34:ea:34:c8:84:7a
Modify current thermostat
Lock current thermostat
< My Thermostat
TEMP.SET.TO
19
14:03 Monday
8:00 11:31 12:32 17:03
Power
Mode
28
Senior
3
