3
Vorbereitung / Preparation
3
Vorbereitung
3.1
Lieferumfang
3.1.1
Geberrad je nach Version
Geberrad für Schraubmontage oder Heiß-
1
schrumpfmontage
(MHGE 100 x5 G)
Inkrementalspur
1.1
Nullimpulsspur
1.2
Nullimpulsmarkierung
1.3
6x Befestigungsbohrung ø4,5 mm
1.4
3x Abdrückgewinde M4
1.5
5
3
3.1
3.1.1
1
1.4
1.3
1.5
Baumer_MHGE100-T2_DE_EN_202210_MI_11121631 (22A1)
Preparation
Scope of delivery
Encoder wheel depending on version
1.1
1.2
Encoder wheel for screw mounting or
1
shrink fit mounting
(MHGE 100 x5 G)
Incremental track
1.1
Zero pulse track
1.2
Zero pulse marker
1.3
6x fixing bore ø4.5 mm
1.4
3x jack-screw thread M4
1.5
MB200T2 - 11121631
