- Page 1 EN - Installation, use and maintenance manual A9 V / C ZENITH A10 V / C PLUS ZENITH...
- Page 2 Dear Customer. Thank you for choosing a product from our range. You are invited to read this manual carefully before using it, to take full advantage of all its features, in complete safety. This manual contains information necessary for correct installation, start-up, use, cleaning and maintenance of the product.
-
Page 3: Manual Index
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 8 Menu browsing MANUAL INDEX 1 Introduction 9 First start-up instructions Symbols Date and time setting Planned use Calibration of handheld device probe 18 Improper use User/auto management Importance of the manual Ambient temperature setting General safety warnings... -
Page 4: Importance Of The Manual
Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” INTRODUCTION 1.3 IMPROPER USE The product by Nobis was designed and manufactured The product must be intended for the use for which it in compliance with the reference standards for the was expressly designed;... -
Page 5: Legal Warranty
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” • The product can be used by children over • all parts resulting as being faulty due to 8 years of age and people with reduced negligence or careless use, wrong physical, sensor or mental capacity, or without maintenance, non-conforming installation experience or the necessary know-how, provided... -
Page 6: Identification Plate
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” CHARACTERISTICS OF THE PELLETS SPARE PARTS Wood pellets are fuel made of pressed sawdust, of- Only use original spare parts. ten recovered from carpentry processing waste. The Do not wait for the components to wear from use be- material used cannot contain any foreign substance fore replacing them. -
Page 7: Installation
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” The air intake is not necessary for INSTALLATION installation of the hermetic appliances that take air directly from outside. Check and All local and national legislation and European comply with the ventilation requirements for simul- standards must be met when installing and using the taneous operations with other combustion devices... -
Page 8: Chimney Flue
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 3.3 CHIMNEY FLUE 3.5 HERMETIC PRODUCT INSTALLATION When installing the chimney flue, the following provi- In the event of installation of a hermetic product, sions must be applied. you can execute one of the following types of con- •... -
Page 9: Examples Of Correct Installation
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 3.6 EXAMPLES OF CORRECT INSTALLATION installation of the product (A) necessary for the hori- zontal section for connection to an existing chimney flue. Based on a slope of 3-5%, to reduce ash deposit in the horizontal pipe section which must not be over 3m (1). - Page 10 Position the equipment and proceed with its connection to the chimney flue. Find, NOBIS SRL cannot be held in any way liable in the using the 4 adjustment feet, the right level so that event of non-compliance with the installation and smoke discharge and the pipe are connected start-up standards of its products.
-
Page 11: Cover Assembly
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” Remove the right rear side. Make the electrical connection of the fan using the CANAL appendix, already present in the original wiring of the product. Live and Neutral can be Remove the pre-drilled blank from the sheet metal inverted, unlike the earth connection (yellow / with the assistance of a suitable tool (e.g. -
Page 12: Electrical Connection
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” When finished, replace the ceramic top. Below the final result. Repeat both operations for mounting the opposite side. LOWER FRONT PANEL ASSEMBLY 3.11 ELECTRICAL CONNECTION Open the door that hides the ash drawer and remo- ve the lower front panel and 4 screws (M5x12) from The product power supply cable must only be con- the packaging. -
Page 13: Product Maintenance
5.1 PRODUCT DATA SHEET PRODUCT DATA SHEET EU 2015/1186 Nobis Brand MAINTENANCE A9V/C ZENITH A10 V/C PLS ZENITH Model The maintenance operations, excluding routine... -
Page 14: Product Configuration
- remove the batteries in case of prolonged not use of command, risk of oxidation and liquid leakage; Nobis srl declares that the type of “Handheld” radio device complies with Directive 2014/53 / EU. The full text of the EU declaration of conformity is available at the following Internet address: https://www.nobisfire.it/wp-content/uploads/2019/04/DoC-Palmare-Radio-Nobis-1.pdf... -
Page 15: Pellet Loading
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” Select the language, using the keys that you 6.2 CONFIGURATION OF T.EXT THERMOSTAT want to use as the display standard. Press the key If you want to manage the appliance from a differ- to confirm and go to the next screen. -
Page 16: Description Of Remote Control
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” DESCRIPTION OF REMOTE CONTROL Before connection using the emergency cable, re- move the batteries from the handheld device Before switching on the appliance, you are advised from the specific compartment. DANGER OF FIRE to read the following chapter carefully relating to use of the receiver and the handheld device, 7.2 DESCRIPTION OF HANDHELD DEVICE KEYS... - Page 17 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” Icon indicating the status of the appliance 7.5 ICONS CONCISE DIAGRAM (see “Concise icons diagram”). MEANING Indicates the work power set. Furthermore, by pressing the scroll key , it allows the power setting SWITCH ON to be displayed, which can be edited using the two...
-
Page 18: Menu Browsing
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” FIRST START-UP INSTRUCTIONS MENU BROWSING This chapter highlights a series of operations to carry To access the menu, press the key on the stand- out during the first start-up phase by screen to display the selection items, of the appliance. - Page 19 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” Scroll the items to SETTINGS with the key This setting inhibits manual management of the op- tional fan, with the exception of Access the menu by pressing key the fan setting on OFF.
-
Page 20: Saving Mode
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” The appearance is highlighted of the “flame” sym- Screen in SAVING mode: bol with the writing ON, without displaying the work power. Prolonged pressing of the key accompanied by acoustic signalling causes switching off of the prod- uct, as well as resetting of any alarms. - Page 21 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 10.3 POWERFUL FUNCTION Edit the value with the keys The function described in the paragraph, once acti- vated, allows heating of the ambient, taking advan- tage of the maximum speed of the fan. The scope is to supply the maximum heat to the det- riment of a minor acoustic comfort.
-
Page 22: Description Of The Menu Functions
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” OPERATING PROCEDURE 2: 10.4 VENTILATION MANAGEMENT (if optional) MENU >> SET USER >> SETTINGS >> POWERFUL The products of the range with optional ventilation, taking advantage of the natural convection system Access the menu by pressing key which guarantees a considerable amount of heat in Scroll the items to SET USER, key... - Page 23 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” OPERATING PROCEDURE: During editing, remember that: • to return to the previous data, without saving MENU >> SET USER >> THERMOSTAT TIMER the last data changed, press the key Access the menu by pressing key •...
- Page 24 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” During editing, remember that: 11.3 EXTRACTION/PELLET MIX • to return to the previous data, without saving The PELLET-EXTRACTION mix setting the last data changed, press the key allows you to change, with immediate effect, the •...
- Page 25 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” To return to the SET USER screen. 11.6 LANGUAGE press the key Based on the destination country or the user acquir- To return to the STAND-BY screen, use the ing the product, this function includes a , repeating the operation multiple times.
-
Page 26: Firmware Version
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” Edit the data highlighted using the keys Scroll the items to SETTINGS with the key Confirm the data changed using the key Access the menu by pressing key Scroll the items to ANTICONDENSA with the key To return to the STAND-BY screen, use the , repeating the operation multiple times. - Page 27 Access the menu by pressing key thermostat. provided on request of (not supplied). Key Nobis s.r.l. First item in the “CHANNELLING” menu, key confirm. (not supplies as standard) The screen appears with setting of channelling, If the flag is enabled for “channelling” temperature as in the figure.
- Page 28 The screen appears with setting of channelling, of the external thermo- provided on request of as in the figure. stat. Nobis s.r.l.(not supplies as (not supplied). Key standard) confirm. Having confirmed setting of the RH channelling, confirm with the key...
- Page 29 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 13 PHASES CONCISE DIAGRAM PHASE DESCRIPTION - The phase starts to pre-heat the re sistor and the pellet starts to fall in the brazier. Edit the data highlighted using the keys - The pellet switches on by taking ad Confirm the data changed using the key SWITCH ON...
- Page 30 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” ANOMALIES CONCISE DIAGRAM PHASE DESCRIPTION PHASE DESCRIPTION Management was chosen of the ambient temperature The appliance signals a malfunc- using an external thermostat (not tion of the sensor controlling correct supplied by the manufacturer) THERMOSTAT combustion.
-
Page 31: Description Of Alarms
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” DESCRIPTION OF ALARMS ALARM CODE REASON ALARM CODE REASON No power supply to the smoke extractor No power during the work phase The smoke extractor is blocked SOLUTION FAULTY SMOKE SOLUTION... - Page 32 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” ALARM CODE REASON ALARM CODE REASON The cleaner has not completed During the pellet loading phase of movement and is not found in the the product, the tank door was not closed correct position or the fire door is not closed properly.
-
Page 33: Cleaning The Appliance
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” Each alarm condition causes the appliance to immediately switch off. Press the switch on key P3 to reset the alarm. Before switching back on the appliance, check signalling is resolved. -
Page 34: Cleaning The Glass Door
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 18.2 CLEANING THE GLASS DOOR To clean the glass, use a cotton cloth or kitchen paper. You are advised to clean the glass using a damp cloth with water and combustion ash (with an abrasive function), avoiding use of products with additives that could, over time, wear the seals, glass and paint. - Page 35 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” CLEANING CYCLES TABLE OPERATING PROCEDURE: Below, the control and/or maintenance intervention Open the door positioned under the fire door, as in the figure below: are summarised which are indispensable for correct appliance operation.
-
Page 36: Wiring Diagram
ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” 19 WIRING DIAGRAM R/RH R/RH LEGEND: SAFETY REMOTE UNIT SELECTION PRESSURE SENSOR SMOKE EXTRACTOR VACUUM SWITCH STROKE COUNTER UPGRADE FW KEY VENTILATION MANUAL RESET THERMAL MECHANICAL CLEANER (technical support only) FRONT SWITCH... - Page 37 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” MAINTENANCE DATE INTERVENTION CARRIED OUT...
- Page 38 ENGLISH Use and Maintenance Manual model “A9 V/C - A10 V/C PLUS ZENITH” NOTE...
- Page 40 NOBIS srl Via Palazzolo N.11 25037 - Pontoglio - BS www.nobisfire.it Nobis Srl cannot be held in any way liable for any errors in this manual and considers itself free to change the features of its products without prior warning.
