- Page 1 EN - Installation, use and maintenance manual H20 V SHAPE H25 V SHAPE...
- Page 2 Dear Customer. Thank you for choosing a product from our range. You are invited to read this manual carefully before using it, to take full advantage of all its features, in complete safety. This manual contains information necessary for correct installation, start-up, use, cleaning and maintenance of the product.
-
Page 3: Manual Index
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” MANUAL INDEX 1 Introduction 9 Menu browsing Symbols Planned use 10 First start-up instructions Improper use 10.1 Date and time setting Importance of the manual 10.2 Probe adjustment General safety warnings 10.3... -
Page 4: Importance Of The Manual
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” INTRODUCTION 1.3 IMPROPER USE The product by Nobis was designed and manufactured The product must be intended for the use for which it in compliance with the reference standards for the was expressly designed;... -
Page 5: Legal Warranty
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” • The product can be used by children over • all parts resulting as being faulty due to 8 years of age and people with reduced negligence or careless use, wrong... -
Page 6: Identification Plate
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” CHARACTERISTICS OF THE PELLETS SPARE PARTS Wood pellets are fuel made of pressed sawdust, of- Only use original spare parts. ten recovered from carpentry processing waste. The... -
Page 7: Installation
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” INSTALLATION The air intake is not necessary for installation of the hermetic appliances that take air All local and national legislation and European directly from outside. Check and... -
Page 8: Chimney Flue
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 3.3 CHIMNEY FLUE 3.5 HERMETIC PRODUCT INSTALLATION In the event of installation of a hermetic product, When installing the chimney flue, the following provi- you can execute one of the following types of con- sions must be applied. -
Page 9: Examples Of Correct Installation
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 3.6 EXAMPLES OF CORRECT INSTALLATION installation of the product (A) necessary for the hori- zontal section for connection to an existing chimney flue. Based on a slope of 3-5%, to reduce ash deposit in the horizontal pipe section which must not be over 3m (1). - Page 10 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 3.7 DOCUMENTATION TO ISSUE When installation is concluded, the installation tech- nician must deliver to the user: • the use and maintenance booklet of the appliance supplied by the manufacturer;...
- Page 11 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Fig.2 3.10 COVERING MAJOLICA ASSEMBLY LOWER SIDE MAJOLICA ASSEMBLY (fig.1C) fig.1B Use a M8 wrench to unscrew the 8 screws on the RH and LH side of the structure, where the upper and lower side majolica will be later fa- stened (fig.
-
Page 12: Hydraulic Connection
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” HIGHER SIDE MAJOLICA ASSEMBLY (fig.2) 3.11 HYDRAULIC CONNECTION Take the RH higher side majolica from the In this section of the manual all the steps to perform... -
Page 13: System Cleaning
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” If, while operating, system pressure happens to drop In order to remove any residues and deposits, wash (during evaporation of gases dissolved in the water) the entire system before connecting the product. - Page 14 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” EXAMPLES OF HYDRAULIC DIAGRAMS...
- Page 15 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE”...
- Page 16 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE”...
- Page 17 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE”...
-
Page 18: Product Maintenance
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” TECHNICAL DATA OF THE PRODUCT It is compulsory for the system to be grounded and have a differential switch in compliance with legis- This chapter issues to the end user all the information lation in force. -
Page 19: Product Configuration
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” PRODUCT CONFIGURATION 6.3 DIMENSIONS Revisioni Area Rev. Descrizione Data Approvata Once all the installation, covering assembly (where RILASCIO PROGETTO 07/08/2019 R.A. present as a kit) and electrical connection are in place, with utmost attention, access the rear part of the product to power it. -
Page 20: Pellet Loading
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Select the language, using the keys that you 7.2 CONFIGURATION OF EXT THERMOSTAT want to use as the display standard. Press the key If you want to manage the appliance from a differ- to confirm and go to the next screen. -
Page 21: Description Of Remote Controls
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” In the event of malfunctioning of the remote com- munication between the handheld device and the receiver, or if the batteries are flat, use the emer- gency cablesupplied, to restore communication between the remote devices. - Page 22 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 8.3 DESCRIPTION OF THE HANDHELD DEVICE DISPLAY The handheld device display is as follows: STAND-BY SCREEN From STAND-BY mode, pressing allows to obtain an overview of the actual and active device status,...
-
Page 23: Menu Browsing
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 8.5 CONCISE ICONS DIAGRAM MEANING MEANING START O STANDBY MAX. WORKING POWER FAULT PRESSURE SENSOR FAULTY FLAME READOUT PROBE MIN. WORKING POWER HANDHELD DEVICE BATTERIES IN SANITARY MODE... - Page 24 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 10 FIRST START-UP INSTRUCTIONS By pressing , scroll down entries to select SETTINGS Access the menu by pressing This chapter highlights a series of operations to carry out during the first start-up phase of the appliance.
-
Page 25: Saving Mode
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 11 WORKING PHASE Each time the appliance is turned on, it ALWAYS turns on at maximum power to guarantee the Products in the range include a working phase with 2 greatest amount of heat to the heating system. -
Page 26: Operating Procedure
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Delta restart OPERATING PROCEDURE: MENU >> SET USER >> AIR CON. COMFORT Access the menu by pressing key Scroll the items to SET USER with the key... -
Page 27: Description Of The Menu Functions
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 12 DESCRIPTION OF THE MENU FUNCTIONS 11.3 H O STANDBY This chapter describes the user menu functions, useful “H O Standby” mode is activated when water tem- to improve some comfort related aspects of the user perature reaches 85°C;... - Page 28 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Access the menu by pressing key Edit the switch on and switch off times, as well as enabling the days of the week, keys Scroll the items to AUGER LOADING, key...
-
Page 29: Stove Status
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Scroll the items to SET USER with the key Edit the pellet setting with the keys Access the menu by pressing key The values vary from -5: reduction in pellet load in %... - Page 30 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Scroll the items to SETTINGS with the key Access the menu by pressing key The first item on the menu, ENABLE T.EXT. Tick using the key if you want to manage the...
-
Page 31: Firmware Version
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Access the menu by pressing key 12.10 ANTICONDENSATION (exhaust fumes temperature) Scroll the items to SETTINGS with the key This function ensures that the temperature Access the menu by pressing key of exhaust gases remains higher than condensing temperature. - Page 32 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” The DHW storage is managed by the appliance thanks To go back to the STAND-BY screen, press button to a contact or immersion probe (not provided) to be repeatedly connected on the back side of the product.
- Page 33 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” STAND-BY SCREEN 13.2 DIAGRAM 02 (TECHNICAL H O STORAGE TANK) In this type of circuit, technical H2O storage tank is managed by the product thanks to a contact or im- mersion probe (not provided) to be connected to the back side of the appliance.
-
Page 34: Functions Overview
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 14 PHASES OVERVIEW 15 FUNCTIONS OVERVIEW PHASE DESCRIPTION PHASE DESCRIPTION -The resistor preheating phase Room temperature set on MAN starts and pellet begins to fall into the mode. -
Page 35: Description Of Alarms
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” ANOMALIES OVERVIEW The anomalies, differing from alarms, are signals which automatically reset, once the cause that FASE DESCRIZIONE generated them has been eliminated. Furthermore, the signalling does not cause the ap-... - Page 36 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” ALARM CODE REASON ALARM CODE REASON Combustion in the brazier is not optimal as it No power supply or power supplied by elec- is clogged or the inner passages of the ap- tronic control unit not pliance are clogged.
- Page 37 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” MANUAL RESET THERMAL SWITCH POSITION ALARM CODE REASON Combustion in the brazier is not optimal as the brazier is clogged or the inner passages of the appliance are clogged.
-
Page 38: Cleaning The Appliance
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” Ogni condizione di allarme causa l’immediato spegnimento dell’apparecchio. Premere il tasto di accensione P3 per resettare l’allarme. prima di riaccendere l’apparecchio, verificare che la segnalazione sia stata risolta. -
Page 39: Cleaning The Glass Door
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 19.2 CLEANING THE GLASS DOOR To clean the glass, use a cotton cloth or kitchen paper. You are advised to clean the glass using a damp cloth with... - Page 40 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” OPERATING PROCEDURE: CLEANING CYCLES TABLE Below, the control and/or maintenance intervention Open the door positioned under the fire door, as in are summarised which are indispensable for the figure below: correct appliance operation.
-
Page 41: Wiring Diagram
ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” 20 WIRING DIAGRAM S. BOILER FLUX NTCm S. PUF.H NTCr T.EXT/PUF.L F N NO NC LEGENDA: SAFETY REMOTE UNIT SELECTION PRESSURE SENSOR SMOKE EXTRACTOR VACUUM SWITCH UPGRADE FW KEY... - Page 42 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” DATE NOTE...
- Page 43 ENGLISH Use and Maintenance Manual model “H20 V SHAPE - H25 V SHAPE” DATE NOTE...
- Page 44 NOBIS srl Via Palazzolo N.11 25037 - Pontoglio - BS www.nobisfire.it Nobis Srl cannot be held in any way liable for any errors in this manual and considers itself free to change the features of its products without prior warning.
