24" 720p, 60Hz, LED Roku TV
NS-24DR220NA18/NS-24DR220CA18
Before using your new product, please read these instructions to prevent any damage.
Illustrations in this guide are provided for
reference only and may differ from actual
product appearance. Product design and
specification may be changed without notice.
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-24DR220CA18 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Insignia NS-24DR220CA18

Summary of Contents for Insignia NS-24DR220CA18

  • Page 1 USER GUIDE 24" 720p, 60Hz, LED Roku TV NS-24DR220NA18/NS-24DR220CA18 Illustrations in this guide are provided for reference only and may differ from actual product appearance. Product design and specification may be changed without notice. Before using your new product, please read these instructions to prevent any damage.

  • Page 2: Table Of Contents

    Contents Contents CHILD SAFETY ............. . . 4 Important Safety Instructions .
  • Page 3 Legal notices ............. . . 45 One-year limited warranty - Insignia Televisions ......49...

  • Page 4: Child Safety

    CHILD SAFETY PROPER TELEVISION PLACEMENT MATTERS THE CONSUMER ELECTRONICS INDUSTRY CARES Manufacturers, retailers and the rest of the consumer electronics industry are committed to making home entertainment safe and enjoyable. As you enjoy your television, please note that all televisions - new and old - must be supported on proper stands or installed according to the manufacturer's recommendations.

  • Page 5: Important Safety Instructions

    Important Safety Instructions 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use CAUTION caution when moving the cart/apparatus combination to RISK OF ELECTRIC SHOCK avoid injury from tip-over.

  • Page 6: Caution

    NS-24DR220NA18 / NS-24DR220CA18 Handling the LCD panel Outdoor antenna grounding • Your TV’s screen is made of glass. Do not drop your If an outside antenna or cable system is connected to TV or hit, jolt, or press hard against the LCD panel. If your TV, make sure that the antenna or cable system is the screen breaks, be careful of broken glass.
  • Page 7 End of life directives Non-active pixels Your TV may contain materials that are regulated for The LCD panel contains almost 3 million thin film environmental reasons. Your TV also contains transistors, which provide exceptionally sharp video materials that can be recycled and reused. To help quality.

  • Page 8: Welcome

    NS-24DR220NA18 / NS-24DR220CA18 24" 720p, 60Hz, LED Roku TV Welcome Congratulations on the purchase of your new TV! Discover the joy of endless entertainment. After it's set up, you'll be able to access a world of streaming content channels that may include Netflix, YouTube, Crackle, CNET, and literally thousands more.

  • Page 9: Accessibility (U.s. Models Only)

    24" 720p, 60Hz, LED Roku TV 6 Send your personal media to the big screen • Send personal photos, videos, and music from your compatible smartphone or tablet to the TV screen in just a few taps. Plus, with certain channels, such as Netflix and YouTube, send movies, shows, sport highlights, and more directly to your TV.

  • Page 10: Installing The Stand Or Wall-Mount Bracket

    NS-24DR220NA18 / NS-24DR220CA18 Installing the stand or wall-mount bracket • If you want to place your TV on a table or in an entertainment center, go to Installing the stand. • If you want to mount your TV on a wall, go to Installing a wall-mount bracket.

  • Page 11: Installing A Wall-Mount Bracket

    24" 720p, 60Hz, LED Roku TV Installing a wall-mount bracket Warnings • Your TV has four VESA mounting holes on the back. If you attach a wall-mount bracket to the back of your TV, the bracket must be securely attached, using all four holes. If you do not use all four mounting holes, your TV may fall and cause property damage or personal injury.
  • Page 12 NS-24DR220NA18 / NS-24DR220CA18 3 Attach the wall-mount bracket to your TV using either the four provided M4 × 10 mm screws (the short screws) or the screws that came with the wall-mount bracket. See instructions that came with the wall-mount bracket for information about which screws to use and how to correctly hang your TV.

  • Page 13: Tv Components

    24" 720p, 60Hz, LED Roku TV TV components Side jacks Your TV has built-in controls for adjusting basic settings and several sets of jacks for connecting devices to your TV. This section contains information about: • Package contents • Front features •...

  • Page 14: Back Jacks

    NS-24DR220NA18 / NS-24DR220CA18 Back jacks # Item Description —Press to turn on your TV when your TV is off (in standby mode). Press and hold to turn off your TV when TV is on. Warning: When your TV is off, power still flows through it.

  • Page 15: Remote Control

    24" 720p, 60Hz, LED Roku TV Remote control Button Description —Moves the highlight up one item. —Moves the highlight down one item. —Moves the highlight left, if possible (if a < hint appears). When watching TV, displays your channel list. When playing most streaming videos, skips backward in the video.
  • Page 16 NS-24DR220NA18 / NS-24DR220CA18 Button Description Button Description When playing streaming video that supports this feature, or Turns volume up one setting with each press. Press and hold broadcast TV if Live TV Pause is enabled: to turn volume up rapidly. A volume indicator shows the...

  • Page 17: What Connection Should I Use

    24" 720p, 60Hz, LED Roku TV What connection should I Connection type and Cable connector use? jack Your TV has several connection types for connecting Digital optical devices to your TV. audio output For the best video quality, you should connect a device to the best available connection.

  • Page 18: Connecting A Cable Or Satellite Box

    NS-24DR220NA18 / NS-24DR220CA18 Connecting a cable or satellite box Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 17.

  • Page 19: Av (Composite Video) (Good)

    24" 720p, 60Hz, LED Roku TV AV (composite video) (good) Notes Cables are often color-coded to match color-coded jacks. Cable wall jack Side of TV On your TV AV cable AV cable Audio cable connector connectors Cable or satellite box Analog AV jack audio jacks...

  • Page 20: Coaxial (Good)

    NS-24DR220NA18 / NS-24DR220CA18 Coaxial (good) Cable or Cable satellite box wall jack On your TV Coaxial cable Coaxial cable connector ANT/CABLE IN jack Back of TV 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off.

  • Page 21: Connecting An Antenna Or Cable Tv (No Box)

    24" 720p, 60Hz, LED Roku TV Connecting an antenna or cable TV (no box) Antenna or cable TV (no box) On your TV Coaxial cable connector Coaxial cable ANT/CABLE IN jack Back of TV 1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off. 2 Connect a coaxial cable (not provided) to the ANT/CABLE IN jack on the back of your TV and to the antenna or cable TV wall jack.

  • Page 22: Connecting A Dvd Or Blu-Ray Player

    NS-24DR220NA18 / NS-24DR220CA18 Connecting a DVD or Blu-ray player Many DVD or Blu-ray players have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 17.

  • Page 23: Av (Composite Video) (Good)

    24" 720p, 60Hz, LED Roku TV AV (composite video) (good) Note Cables are often color-coded to match color-coded jacks. Side of TV On your TV DVD or Blu-ray player AV cable Audio cable connector connectors AV cable AV jack Analog audio jacks 1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off.

  • Page 24: Connecting A Game Console

    NS-24DR220NA18 / NS-24DR220CA18 Connecting a game console Many game consoles have more than one connection type. To get the best video, you should use the best connection type available. For more information, see What connection should I use? on page 17.

  • Page 25: Av (Composite Video) (Good)

    24" 720p, 60Hz, LED Roku TV AV (composite video) (good) Note Cables are often color-coded to match color-coded jacks. Side of TV On your TV Game console AV cable Audio cable connector connectors Console-specific AV cable AV jack Analog audio jacks 1 Make sure that your TV’s power cord is unplugged and the game console is turned off.

  • Page 26: Connecting A Computer

    NS-24DR220NA18 / NS-24DR220CA18 Connecting a computer You can use an HDMI® jack on your TV to connect to a computer. Computer On your TV HDMI® cable connector HDMI® cable HDMI® jack Back of TV 1 Make sure that your TV’s power cord is unplugged and the computer is turned off.

  • Page 27: Connecting A Usb Flash Drive

    24" 720p, 60Hz, LED Roku TV Connecting a USB flash drive You can use the USB jack on your TV to view photos and videos and listen to music stored on a USB flash drive. Side of TV USB flash drive 1 Plug a USB flash drive into the USB port on the side of your TV.

  • Page 28: Connecting Headphones

    NS-24DR220NA18 / NS-24DR220CA18 Connecting headphones When you connect headphones, your TV speakers are muted and sound only plays through the headphones. Warning Loud noise can damage your hearing. When using headphones, use the lowest volume setting on your headphones that still lets you hear the sound.

  • Page 29: Connecting External Speakers Or A Soundbar

    24" 720p, 60Hz, LED Roku TV Connecting external speakers or a soundbar When you connect external speakers or a soundbar, sound plays through your TV speakers and the external speakers or soundbar. You can connect external speakers or a soundbar using: •...

  • Page 30: Digital Audio Using The Arc Jack

    NS-24DR220NA18 / NS-24DR220CA18 Digital audio using the ARC jack Your TV can send sound to an ARC device, like an AV receiver, to create a home theater that uses two or more speakers. When you connect external speakers or a soundbar, sound plays through the external speakers or soundbar.

  • Page 31: Analog Audio

    24" 720p, 60Hz, LED Roku TV Analog audio When you connect an analog system or soundbar to the jack, your TV speakers are muted. Analog speaker system On your TV Soundbar Audio cable connector Audio cable jack Back of TV 1 Make sure that your TV’s power cord is unplugged and the analog speaker system or soundbar is turned off.

  • Page 32: Connecting A Home Theater System With Multiple Devices

    NS-24DR220NA18 / NS-24DR220CA18 Connecting a home theater system with multiple devices You can connect an AV receiver and your devices to create a home theater. Cable or satellite box DVD or Blu-ray player AV receiver Antenna or cable TV connected directly to the wall jack The connections you make depend on the video and audio jacks available on your devices.

  • Page 33: Connecting Power

    24" 720p, 60Hz, LED Roku TV Connecting power You should connect devices before you connect the power cord. When you are adding devices, make sure that the power cable is unplugged from the power outlet. 1 Connect the AC power cord to the AC IN connector on the back of your TV. 2 Connect the other end of the cord to a power outlet.

  • Page 34: Installing Remote Control Batteries

    NS-24DR220NA18 / NS-24DR220CA18 Installing remote control batteries Open the back of your TV remote control and insert two AAA batteries, observing the proper orientation. Reattach the back cover. Remote control on page explains how to use the remote control in each of your TV’s operating modes.

  • Page 35: Setting Up Your Tv

    24" 720p, 60Hz, LED Roku TV Setting up your TV When you turn on your TV for the first time, Guided Setup starts. During Guided Setup: • Your TV automatically detects your wireless network, so have your network name and password handy and follow the easy on-screen instructions.

  • Page 36: Troubleshooting

    For the latest answers to Frequently Asked Questions, visit General Support & FAQs under the Support and Service section of the Insignia TV support website (www.insigniaproducts.com) and the Support section of the Roku website (www.roku.com). Video and audio...
  • Page 37 24" 720p, 60Hz, LED Roku TV Symptom Possible cause Try this... • Try another channel. The station may be experiencing Broadcast TV may be problems. experiencing problems • If you are using an antenna and the signal strength is low, or may not be set up adjust the antenna or use a highly directional outdoor antenna or set-top antenna with a built-in amplifier.
  • Page 38 NS-24DR220NA18 / NS-24DR220CA18 Symptom Possible cause Try this... • Make sure that the antenna or cable TV is connected correctly and securely. See Connecting a cable or satellite box page Connecting an antenna or cable TV (no box) Cables may not be page 21.

  • Page 39: Remote Control

    24" 720p, 60Hz, LED Roku TV Symptom Possible cause Try this... Light in the viewing area • Make sure that the room is not too bright. Light reflecting off may be interfering the screen can make the picture difficult to see. Poor picture A connected camera or •...

  • Page 40: General

    NS-24DR220NA18 / NS-24DR220CA18 General Symptom Possible cause Try this... • Make sure that the power cord is correctly connected to both your TV power connector and power outlet. See Connecting power on page 33. You should see an LED in the front of your Power cord may not be TV panel when a button on the remote is pressed.

  • Page 41: Roku

    24" 720p, 60Hz, LED Roku TV Symptom Possible cause Try this... • You may have Set up for store mode when you set up your TV. Store use mode is for retail environments only. In Store use mode, some of your TV’s features are missing or limited. If you Some features The wrong TV mode may selected Set up for store use and you want to change to Set...

  • Page 42: Cec-Compatible Devices

    NS-24DR220NA18 / NS-24DR220CA18 CEC-compatible devices Symptom Possible cause Try this... • Make sure that the HDMI® cable is connected securely to your Cables may not be TV and the device. connected correctly • Make sure that the device is connected to your TV with an HDMI®...
  • Page 43 24" 720p, 60Hz, LED Roku TV Symptom Possible cause Try this... Connected device may • Make sure that the device is a CEC device. See the not be a CEC device documentation that came with the device. The device does •...

  • Page 44: Specifications

    NS-24DR220NA18 / NS-24DR220CA18 Specifications Audio Number: 2 Speakers Specifications are subject to change without notice. Watts per channel: 3W Audio enhancement DTS Sound Dimensions and weight Power 13.1 × 21.8 × 3.3 in. (33.2 × 55.3 × 8.3 cm) Without stand H × W × D 5.3 lbs.

  • Page 45: Legal Notices

    After your Roku Account is created, you can link your Insignia Roku INSIGNIA ROKU TV FOR THE FIRST TIME. TV to your account. By using the Insignia Roku TV, you agree to the Overview following disclaimer. For the avoidance of doubt, the content disclaimer set forth herein shall refer to all content and channels This End User License Agreement (“EULA”) between you and Roku,...
  • Page 46 NS-24DR220NA18 / NS-24DR220CA18 Changes to This EULA Software Updates Roku may amend this EULA at any time in its discretion. Such in its sole discretion, ROKU MAY PROVIDE UPDATES TO YOUR amendments shall be effective immediately upon posting of the...
  • Page 47 800-778-7879. For If You desire to contact Insignia, please send your correspondence Claims between You and Roku of $75,000 or less, you will by mail to be responsible for the initial arbitration filing fee, up to the...
  • Page 48 NS-24DR220NA18 / NS-24DR220CA18 FCC Statement Dolby License Notice and Trademark Acknowledgement Note: This equipment has been tested and found to comply with Manufactured under license from Dolby the limits for a class B digital device, pursuant to part 15 of the FCC Laboratories.

  • Page 49: One-Year Limited Warranty - Insignia Televisions

    Insignia repair center or store personnel, LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS Insignia will (at its sole option): (1) repair the Product with new or WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND rebuilt parts;...
  • Page 50 For product inquiries or accessibility assistance, please contact us with the information below: 1-877-467-4289 www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2017 Best Buy. All rights reserved.
