Insignia NS-24D310NA17 Quick Setup Manual

INCLUDED ACCESSORIES
Remote control and
two AAA batteries
A
A
TV stands
M3 screws (10 mm length) (2 pcs.)

FEATURES

WALL MOUNT ACCESSORIES
M4 screws (10 mm length) (4 pcs.)
Note: The wall-mount screws are in the VESA
mounting holes on the back of your TV.
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, then click
Support & Service.
Enter NS-24D310NA17/ NS-24D310MX17
in the box under Manual, Firmware, Drivers &
Product Information, then click ►.
STOP
Do not plug your power cord in until all other
devices have been connected.
Before using your new product, please read these
instructions to prevent any damage.

START HERE

1
How do I attach the stand to my TV? (not for wall mounting)
You'll need: Soft surface and Phillips screwdriver
Place your TV face-down on a cushioned, B Align the screw holes on the TV stands with the holes on the
clean surface. bottom of your TV, then secure each stand to your TV with the
provided screws.
B
Remote control sensor
Power indicator
AV IN ANT/CABLE
VIDEO L R IN
- AUDIO -
M3 screws (10 mm length)

MAKING CONNECTIONS

2
How do I watch TV (cable, satellite, or antenna) or connect a device, such as a DVD or Blu-ray disc player, game console, or tablet?
WHICH CABLES
DO YOU HAVE?
HDMI (BEST)
Best video quality
AV
(GOOD)
COAXIAL
(GOOD)
AV IN
VIDEO
Quick Setup Guide | NS-24D310NA17/ NS-24D310MX17

WALL MOUNT

How do I prepare my TV for wall mounting?
(not for use with a TV stand)
You'll need: Soft surface and Phillips screwdriver
A Carefully place your TV face-down on a cushioned, clean surface.
OR B See the instructions that came with your wall mount for more information
about how to correctly mount your TV.
C Your TV has wall-mount screws installed in the VESA mounting holes on the
back of your TV.
Remove the screws, place the wall-mount bracket (not included) over the
screws holes, then replace the screws to secure the bracket to your TV.
A
B
Your TV has four VESA mounting holes on the back. If you attach a wall-mount
bracket to the back of your TV, the bracket must be securely attached, using
all four holes. If you do not use all four mounting holes, your TV may fall and
cause property damage or personal injury. See the documentation that came
with your wall-mount for complete mounting instructions.
Multi-purpose jacks: You can plug any device that uses HDMI into either HDMI jack.
However, certain devices must be connected to the ARC jack. See the instructions
that came with your ARC device for more information.
AV IN ANT/CABLE
VIDEO L - AUDIO - R IN
ANT/CABLE
IN
L - AUDIO - R
24" 720p 60Hz • LED TV
C
AUDIO/VIDEO OUT
CABLE
