SOPHIA
MULTI-ZONE
INVERTER
SPLIT AIR CONDITIONER
WITH HEAT PUMP
INSTALLATION MANUAL
OUTDOOR UNIT
Models:
CH-HYP19MSPH-230VO
CH-HYP28MSPH-230VO
CH-HYP36MSPH-230VO
CH-HYP48MSPH-230VO
IMPORTANT NOTE:
•
Read this manual carefully before installing or operating your new air
conditioning unit. Make sure to save this manual for future reference.
•
This manual only describes the installation of the outdoor unit. When installing
the indoor unit, refer to the installation manual of the indoor unit.
HYPER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cooper & Hunter SOPHIA CH-HYP19MSPH-230VO
Summary of Contents for Cooper & Hunter SOPHIA CH-HYP19MSPH-230VO
- Page 1 SOPHIA HYPER MULTI-ZONE INVERTER SPLIT AIR CONDITIONER WITH HEAT PUMP INSTALLATION MANUAL OUTDOOR UNIT Models: CH-HYP19MSPH-230VO CH-HYP28MSPH-230VO CH-HYP36MSPH-230VO CH-HYP48MSPH-230VO IMPORTANT NOTE: • Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference. •...
-
Page 2: Table Of Contents
Table of Contents INSTALLATION MANUAL Accessories ............................3 Safety Precautions ........................... 4 Installation Summary ........................5 Installation Diagram ........................6 Specifications ........................... 7 Outdoor Unit Installation ....................... 8 1. Select installation location ...........................8 2. Install drain joint ..............................9 3. Anchor outdoor unit ...............................9 Refrigerant Piping Connection ..................... -
Page 3: Accessories
Accessories The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and fire, or cause the equipment to fail. The items not included with the air conditioner must be purchased separately. -
Page 4: Safety Precautions
Safety Precautions Read safety precautions before installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. WARNING Failure to observe a warning may result in death. The appliance must be installed in accordance with national regulations. -
Page 5: Installation Summary
Installation Summary Installation Order Install the outdoor unit Connect the refrigerant pipes Connect the wires (Page 8) (Page 11) (Page 14) Perform a test run Evacuate the refrigeration (Page 24) system (Page 21) Page 5... -
Page 6: Installation Diagram
Installation Diagram Installation Diagram Mounting screw More than More than More than 5,9 in (15 cm) ST3.9 x 25-C-H 4,7in (12cm) 4,7in (12cm) Air-break Installation plate Switch Clip anchor Air-break Switch Remote controller Drainage holder Pipe 5 4 3 More than 11.8in (30 cm) More than 4,7in (12cm) Outdoor Unit... -
Page 7: Specifications
Specifications Indoor units that can be used in Number of connected 1-5 units combination units Compressor stop/start frequency Stop time 3 minutes or more Voltage fluctuation within ±10% of rated voltage Power source voltage Voltage drop during start within ±15% of rated voltage Interval unbalance within ±3% of rated voltage Unit: ft/m... -
Page 8: Outdoor Unit Installation
Outdoor Unit Installation Install the unit by following local codes and DO NOT install unit in the following locations: regulations, which may differ slightly from Near an obstacle that will block air inlets and region to region. outlets Near a public street, crowded areas, or where noise from the unit will disturb others ... -
Page 9: Install Drain Joint
Step 2: Install drain joint IN COLD CLIMATES (Heat pump unit only) Before bolting the outdoor unit in place, you In cold climates, make sure that the drain hose must install the drain joint at the bottom of the is as vertical as possible to ensure swift water unit. - Page 10 1. Determine the location of the wall hole based on the location of the outdoor unit. 2. Using a 2.5 in (65 mm) core drill, drill a hole in the wall. NOTE: When drilling the wall hole, make sure to avoid wires, plumbing, and other sensitive components.
-
Page 11: Refrigerant Piping Connection
Refrigerant Piping Connection When connecting refrigerant piping, do not let DO NOT DEFORM PIPE substances or gasses other than the specified WHILE CUTTING refrigerant enter the unit. The presence of other gasses or substances will lower the Be extra careful not to damage, dent, or unit’s capacity, and can cause abnormally high deform the pipe while cutting. -
Page 12: Connect Pipes
4. Remove PVC tape from ends of pipe when ready to perform flaring work. 5. Clamp flare form on the end of the pipe. The end of the pipe must extend beyond the flare form. 3. Tighten the flare nut as tightly as possible by hand. - Page 13 NOTE: DO NOT intertwine signal cable with NOTE On Minimum Bend Radius other wires. While bundling these items togeth- Carefully bend the tubing in the middle er, do not intertwine or cross the signal cable according to the diagram below. DO NOT bend with any other wiring.
-
Page 14: Wiring
Wiring 11. If the unit has an auxiliary electric heater, BEFORE PERFORMING it must be installed at least 1 meter (40in) ANY ELECTRICAL WORK, away from any combustible materials. READ THESE REGULATIONS 12. To avoid getting an electric shock, never 1. -
Page 15: Outdoor Uint Wiring
Outdoor Unit Wiring Air switch (purchased seperately) WARNING Indoor & Outdoor Outdoor unit power wires connective wires (purchased seperately) BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE MAIN Outdoor unit POWER TO THE SYSTEM. Indoor unit 1. Prepare the cable for connection A. -
Page 16: Wiring Figure
3. Connect the u-lugs to the terminals Match the wire colors/labels with the labels on the terminal block, and firmly screw the u-lug of each wire to its corresponding terminal. 4. Clamp down the cable with designated cable clamp. 5. Insulate unused wires with electrical tape. Keep them away from any electrical or metal parts. 6. - Page 17 L(A) N(A) S(A) L(B) N(B) S(B) N L( 1) SUPPLY Model E Model F Model G NOTE: Use the magnetic ring (not supplied, optional part) to hitch the connective cable of indoor and outdoor units after installation. One magnetic ring is used for one cable. L(A) N(A) S(A) L(B) N(B) S(B) S(2)
- Page 18 Model D Model E Model F L(A) N(A) S(A) L(B) N(B) S(B) L(C) N(C) S(C) TO A TO C TO B SUPPLY Model G One-four models: Model A Model B Model C Model D Page 18...
- Page 19 L(A) N(A) S(A) L(B) N(B) S(B) L(C) N(C) S(C) L(D) N(D) S(D) TO A TO B TO A TO B SUPPLY Model E Model F 1(C) 2(C) 3(C) 1(D) 2(D) 3(D) 1(C) 2(C) 3(C) 1(D) 2(D) 3(D) L1(A) L2(A) S(A) L1(B) L2(B) S(B) 1(A) 2(A) 3(A) 1(B) 2(B) 3(B) TO B TO A...
- Page 20 CAUTION After the confirmation of the above conditions, prepare the wiring as follows: • Never fail to delegate an individual power circuit specifically for the air conditioner. For the method of wiring, use the circuit diagram posted on the inside of the control cover as a guide. •...
-
Page 21: Air Evacuation
Air Evacuation 4. 4. Turn on the vacuum pump to evacuate the Safety Precautions system. CAUTION 5. 5. Run the vacuum for at least 15 minutes, or until the compound meter reads -76 cmHG • Use a vacuum pump with a gauge reading (-1x105 Pa). -
Page 22: Note On Adding Refrigerant
Note on Adding Refrigerant CAUTION • Refrigerant charging must be performed after wiring, vacuuming, and the leak test. • DO NOT exceed the maximum allowable quantity of refrigerant or overcharge the system. • Doing so may damage or impact the unit’s function. •... - Page 23 water or a liquid neutral detergent to the indoor or outdoor unit connections. If bubbles come out, there is leakage. 2. Leak detector Use the leak detector to check for leakage. NOTE: The illustration is for explanation purposes only. The actual order of A, B, C, D and E on the machine may be slightly different from the unit you purchased.
-
Page 24: Test Run
Test Run c) Double check to see if the room Before Test Run temperature is being registered correctly. A test run must be performed after the entire d) Ensure the indicators on the remote system has been completely installed. Confirm control and the display panel on the indoor the following points before performing the test: unit work properly. -
Page 25: Function Of Automatic Wiring/Piping Correction
Function of Automatic Wiring/Piping Correction Automatic Wiring/Piping Correction Function The new product is able to automatically correct a wiring/piping error. Press the “check switch” on the outdoor unit PCB board for 5 seconds until the LED display shows “CE. ” This means the function is working.
