Vision Sensor
FZ2-30_-10/FZ2-35_-10/FZ2-50_-10/FZ2-55_-10
FZD-50_-10/FZD-55_-10
INSTRUCTION MANUAL
Thank you for selecting the FZ Series Vision Sensor.
This manual explains how to use the FZ Series Vision Sensor.
When using the FZ Series Vision Sensor, make sure to observe the
following:
• The FZ Series Vision Sensor must be operated by personnel
knowledgeable in electrical engineering.
• To ensure correct use, please read this manual thoroughly to deepen your
