SOL paragliders SPEEDUP Manual

Paramotor wing/2 lines technology
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
DGAC
Version 2 5 / 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPEEDUP and is the answer not in the manual?

Questions and answers

Related Manuals for SOL paragliders SPEEDUP

Summary of Contents for SOL paragliders SPEEDUP

  • Page 1 Manual DGAC Version 2 5 / 2023...

  • Page 2: Table Of Contents

    Landing with paramotor .............. 28 Symbols ..................4 Landing with paratrike ..............28 IMPORTANT NOTES ..................5 FAST DESCENT MANEUVERS ..............29 SPEEDUP - THE PROJECT ................6 B-Stall ................... 29 Big ears ..................29 Recommendation ................6 Positive spiral ................30 Certification ...................

  • Page 3: Welcome To The Sol Team

    We hope your paraglider SPEEDUP will provide you with many nice flights and that you’re - When practicing the sport of paragliding, the pilot of this equipment assumes sole experiencing moments that will last forever in your memory.

  • Page 4: Speedup - The Project

    - The glide is exceptional, even with open trimmer and little acceleration the wing stabilizes with low rpm variation. Recommendation The SPEEDUP is a paramotor wing designed for experienced or intermediate level pilots who want an excellent performance, safety, durability and ease of use. Certification The SPEEDUP has a DGAC certification.

  • Page 5: Tecnologias

    Tecnologias...

  • Page 6: Overview Paraglider

    Overview paraglider Overview risers 1. Trailing edge 1. Riser A. 2. Top 2. Riser A'. 3. Leading edge 3. Riser B. 4. Bottom 4. Brake lines. 5. Stabilo 5. Auxiliary brake lines. 6. Lines 6. Brakehandle connection. 7. Risers 7. Brakehandle. 8.

  • Page 7: Line Plan

    Never and under no circumstances the line length can be altered! life. During all consideration and calculation, security always is our first goal.. The used material mix for the lines of the SPEEDUP forms an ideal combination: long life with little deformation and aerodynamic drag.

  • Page 8: The Paraglider - Information

    Tow release take off Harness The SPEEDUP can be used for towed flight. The used equipment must be certified, the The regulated distance between the large clips (adjustable at the chest) is 45 cm for the team handling the equipment must be licensed and you must have done a workshop SPEEDUP.

  • Page 9: Connecting Paramotor Wing And Harness

    Check if the carabiners are really looked and closed! Accelerator The SPEEDUP risers are equiped with trimme and speed system. It can be used in different configurations. It’s very important pay attention for the best performance and safety that you wish.
  • Page 10 Step 7. Closed the loop. Step 8. Pass the main line Step 9. Close the node inside the pulley with main auxiliary line. Confirm that both sides are symmetric. Make the necessary readjustments and fill the glider on the ground to make sure that the brakes are working fine before flying with your power glider.

  • Page 11: Commands With Reflex Profile

    Less speed, brakes are easier, more passive security in case of collapse. The SPEEDUP has an auxiliary command, this double command is used to make curves more open or closed in all conditions of use, regardless of the position of the trimmer.

  • Page 12: Flight

    FLIGHT Take Off Check List - Helmet closed? - Carabiners looked and closed? - Harness all looks closed? - Carabiner distance OK.? - Risers A in hands? Normal turn - Pull one commands Closed turn – Pull one commands vertically downwards. downwards close to your body.

  • Page 13: Forward Take Off

    The pilot, ready to take off, must hold the black lines (AR3) of the red riser (A), together with the toggles. The arms must be held at the side, as if they were an extension of the rods (A). Sol Paragliders does not recommend using the engine force to inflate the paramotor wing.

  • Page 14: Climbing

    The pilot can use the double command to make more closed turns. the SPEEDUP is than more sensitive to deformation and closing. The pilot must remember that the higher the speed, the more dynamic the collapse response or symmetric closing will be.

  • Page 15: Landing With Paramotor

    After killing the glider pull him back to you using the B risers. SPEEDUP is not designed to perform B-Stoll. In case of a B-Stoll attempt, the paramotor wing may go into Full Stall.

  • Page 16: Positive Spiral

    EXTREME FLIGHT SITUATIONS Positive spiral A positive spiral has a high sink rate. But the high acceleration, G-Force, impedes Front-stall to fly this maneuver for a long time. The G-Force may cause that the pilot looses his consciousness and spirals until he crashes the ground. The same high energy is Normally the paramotor wing opens on his own after a front-stall.

  • Page 17: Lateral Closing

    Exactly at this stage of The SPEEDUP has a long way on the brakes before he enters a full-stall. A full-stall pendulum effect under the canopy, it is important that the pilot controls carefully the happens if the brakes are pulled symmetrically and excessively downwards.

  • Page 18: Negative Spiral

    Negative spiral Line Over The SPEEDUP has a long way on the brakes and difficulties to enter in a negative spiral. If the tip of the wing is trapped in lines it could cause a positive spiral, which is difficult But if one of the brakes is extremely pulled downwards it can happen.

  • Page 19: Packing Your Paramotor Wing

    We are recommending the (Origami Method) and the use of a folding cover (see below). Link: how to pack your SPEEDUP Storing Most part of the paramotor wing fabric is Nylon. As all other synthetic materials it suffers and deteriorates under the influence of ultraviolet radiation (UV).

  • Page 20: Tips For Care

    TIPS FOR CARE INSPECTION Your paramotor wing has strictly to follow the required inspection intervals. The first - Over-stressing of individual lines, more than normal load in flight, should be avoided. inspection check is mandatory completing 24 months or 100 hours flights, whichever An excessive deformation is irreversible and can’t be undone.

  • Page 21: Warranty

    We fly so that we can feel more alive. We wish you good and safe flights with your new paraglider. SOL Paragliders Team !! ENVIRONMENT AND RECYCLING Please be aware of our environment: don’t toss your garbage into nature, respect the animals.

  • Page 22: Technical Data

    TECHNICAL DATA Weight, measure and data Model 145 - XXS 160 - XS 175 - S 190 - M 205 - L 220 - XL Cells Real Surface 14,5 16,0 17,5 19,0 20,5 22,0 m² Real Span 10,2 10,6 11,0 11,4 Real A/R Projected Surface...

  • Page 23: Parts And Materials

    Parts and materials WTX 40 PU + Silicon 40 gr/sm - WTX 29 PU + Silicon 29 gr/sm Bottom WTX 40 PU + Silicon 40 gr/sm - WTX 29 PU + Silicon 29 gr/sm Profiles/Diagonal tapes Pro-Nyl High Tenacity Nylon rip-stop Hard finish 36 gr/sm Reinforcements Nylon Maxfio 2,5 mm Reinforcements inside/outside...

  • Page 24: Line Lengths

    Line lengths SPEEDUP 145 - XXS SPEEDUP 175 - S 5290 5311 5092 5798 5821 5614 5334 5358 5115 5845 5871 5639 5491 5498 5192 6014 6022 5724 5539 5549 5249 6066 6077 5788 5602 5610 5313 6133 6142 5859...
  • Page 25 SPEEDUP 205 - L 6260 6286 6089 6310 6339 6117 6492 6500 6211 6547 6558 6283 6619 6629 6361 6699 6706 6659 6750 6736 6749 6810 6664 6719 6699 6715 6780 6691 6732 6711 6728 6796 6753 6792 6768 6785...

  • Page 26: Line Lengths Individually

    Line lengths individually SPEEDUP 145 - XXS SPEEDUP 145 - XXS Name Line reference Diameter / mm Length / mm Number of lines Name Line reference Diameter / mm Length / mm Number of lines Cousin vectran 12100 Cousin vectran...
  • Page 27 SPEEDUP 160 - XS SPEEDUP 160 - XS Name Line reference Diameter / mm Length / mm Number of lines Name Line reference Diameter / mm Length / mm Number of lines Cousin vectran 12100 Cousin vectran 16330 Cousin vectran...
  • Page 28 SPEEDUP 175 - S SPEEDUP 175 - S Name Line reference Diameter / mm Length / mm Number of lines Name Line reference Diameter / mm Length / mm Number of lines Cousin vectran 12100 Cousin vectran 16330 Cousin vectran...
  • Page 29 SPEEDUP 190 - M SPEEDUP 190 - M Name Line reference Diameter / mm Length / mm Number of lines Name Line reference Diameter / mm Length / mm Number of lines Cousin vectran 12100 Cousin vectran 16330 Cousin vectran...
  • Page 30 SPEEDUP 205 - L SPEEDUP 205 - L Name Line reference Diameter / mm Length / mm Number of lines Name Line reference Diameter / mm Length / mm Number of lines Cousin vectran 12100 Cousin vectran 16330 Cousin vectran...
  • Page 31 SPEEDUP 220 - XL SPEEDUP 220 - XL Name Line reference Diameter / mm Length / mm Number of lines Name Line reference Diameter / mm Length / mm Number of lines Cousin vectran 12100 Cousin vectran 16330 Cousin vectran...
  • Page 32 Référence manuel d'entretien Surface à plat Référence manuel d'utilisation Référence manuel d'entretien Surface à plat minimale d'ancrage minimale d'ancrage Manuel d’ utilisation SPEEDUP Manuel d’ utilisation SPEEDUP 14,50 m² 750 daN Manuel d’ utilisation SPEEDUP Manuel d’ utilisation SPEEDUP 16 m²...
  • Page 33 Surface à plat Résistance minimale d'ancrage Référence manuel d'utilisation Référence manuel d'entretien Surface à plat minimale d'ancrage Manuel d’ utilisation SPEEDUP Manuel d’ utilisation SPEEDUP 17,50 m² 750 daN Manuel d’ utilisation SPEEDUP Manuel d’ utilisation SPEEDUP 19 m² 750 daN Limitations du constructeur de la DISTANCE ENTRE LES POINTS DE FIXATION DES ÉLÉVATEURS: 45CM + - 5CM...
  • Page 34 Référence manuel d'entretien Surface à plat Référence manuel d'utilisation Référence manuel d'entretien Surface à plat minimale d'ancrage minimale d'ancrage Manuel d’ utilisation SPEEDUP Manuel d’ utilisation SPEEDUP 20,50 m² 750 daN Manuel d’ utilisation SPEEDUP Manuel d’ utilisation SPEEDUP 22 m²...
  • Page 35 Tél. 01 58 09 43 21 - Fax : 6 fiches d'identification ULM. Objet Madame, Monsieur, Je vous prie de bien vouloir trouver ci-joint les fiches d'identification pour les ULM suivants : SPEEDUP 145 XXS B101SF04041E SPEEDUP 160 XS B101SF04042E SPEEDUP 175 S...
  • Page 36 Sol Sports Ind. e Com. Ltda. Rua Walter Marquardt, 1180 cp 370 89259-565 Jaraguá do Sul, SC BRAZIL Telefone (+55) 47 3275 7753 E-mail: info@solsports.com.br www.solparagliders.com.br facebook: solparagliders instagram @solparamotorsofficial...
