Cutout & Product Dimensions
PREPARE SITE
Your U-Line product has been designed for either free-
standing or built-in installation. When built-in, your unit
does not require additional air space for top, sides, or
rear. However, the front grille must NOT be obstructed,
and clearance is required for an electrical connection in
the rear.
CAUTION
!
Unit can NOT be installed behind a closed cabinet
door.
If you would like to align the face of the unit with
other adjacent cabinet doors, you may need to
alter the wall just behind the drain connection on
the unit to accommodate the drain.
CUTOUT DIMENSIONS
Preferred location
for electrical outlet
is in adjacent
cabinet.
33 7⁄8"
24"
(860 mm)
(610 mm)
to
34 7⁄8"
(886 mm)
7"
(178 mm)
4"
(102 mm)
PRODUCT DIMENSIONS
REAR
Water In & Drain
7 ⁄ "
(200 mm)
Cutout & Product Dimensions
5⁄8"
(16 mm)
17 7⁄8"
(454 mm)
8 ⁄ "
(222 mm)
5 ⁄ "
(143 mm)
Power Cord
1 ⁄ "
(48 mm)
FRONT
TOP
SIDE
8
17 ⁄ "
(451 mm
28"
(711 mm
21 ⁄ "
(537 mm
1 ⁄
"
(48 mm
20 ⁄ "
(511 mm
25 ⁄ "
(657 mm
24"
(610 mm
12 ⁄ "
(306 mm
4 ⁄ "
(117 mm
