DPP310
Instruction Manual
Pet Friendly PIR Detector
www.pima-alarms.com
Key Features
• 35kg Pet Friendly
• 15 Metre Range
• Grade 2
• Multi Height Optics
• 2.0m - 2.2m Mounting Height
• Selectable EOL Resistors
• Slide to Fit Front Cover
• Remote LED Control
• Sealed Optics
• True Creep Zones
†
• Digital Pulse Count
• Temperature Compensation
• Advanced Signal Processing
†
• RFI Immunity up to 2.7GHz
†
• Optional Tamper Proof Bracket
†
Patent Pending
Location
1
Mounting
Location
Height
Warning
2.2m
Max
2.0m
Recommended
Note: For maximum detection range, especially
at high temperatures, mount at 2.0m.
Detector Setup
3
Note the jumper settings for
Installation with FORCE.
For Double Pole Wiring
A-Zone
T-Zone
12V
0V
•ALARM
TAMPER•
LED
For EOL Wiring
EOL Zone
12V
0V
•ALARM
TAMPER•
LED
Alarm Resistor
Tamper Resistor
O/C
O/C
1K0
1K0
2K2
2K2
4K7
4K7
5K6
5K6
6K8
Coverage Pattern (m)
15m
0
2
4
6
8
10
12
14
16
12
10
8
6
4
2
0
2
4
6
8
10
12
0
2
4
6
8
10
12
14
16
15m
2.0m
0
2
4
6
8
10
12
15m
Do Not
Touch
Mounting
2
without bracket
Seal all holes
Use No. 6 countersunk screws
LED
On
LED = NC/
12V
Rem\Off
LED = 0V
LED
Pulse Count
1
2
Pulse
Pulse
