Summary of Contents for Pico Macom XSV
- Page 1 Sub Band to High Band Block Converter Installation and Operation Manual Operation Ph:800-421-6511 www.picomacom.com Manual Rev. 05/03...
-
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the XSV Converter, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. - Page 3 11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appli- ance dealer or local power company. 12.
- Page 4 (5.75MHz) to VHF (174-216MHz). The unit’s excellent frequency stability makes the XSV ideal for headend or other return signals to the forward channel line up, Pico Macom’s BPF band pass filters and XBS strip amplifiers provide improved selectivity and automatic gain control.
-
Page 5: Specifications
Channels: 7 Channels (T7-T13) Frequency Range: 7-49 MHz Input Level: 5-30 dBmV Output Channels: 7 Channels (T7-T13) Frequency Range: 174-216 MHz Insertion Loss 4 dB ± 5 KHz Frequency Accuracy: Oscillator Leakage: 20 dBmV Specifications Sub Band to High Band Block Converter General Dimensions: Power Supply:... - Page 6 3. Connect the source cable (The one containing the sub band channel) to the RF input connector of the XSV. 4. Connect a cable between the RF output of the XSV and the RF input of a signal level meter or television.
- Page 7 3. Connect the source cable (The one containing the sub band channel) to the RF input connector of the XSV. 4. Connect a cable between the RF output of the XSV and the RF input of the demodulator or channel processor.
-
Page 8: Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
