Pico Macom TSV-2 Specifications

DISTRIBUTION
Passive Components
Broadband 5-1000MHz
frequency range
Vertical port design allows close
mounting in lock boxes for easy
access of cable connections
1-inch centered 1 / ˝ long precision
2
machined F-connector threads
ensure improved port-to-connector
interface and accommodate external
security devices
Standard TSB-series splitters feature
an epoxy-sealed back cover that
provides effective EMI-RFI shielding
>-90dB reducing signal ingress
TSB-SB-series feature a solder-back
cover-plate providing maximum
EMI-RFI shielding >-130dB and
eliminating signal ingress to guar-
antee distortion-free pictures
Silver-coated zinc-alloy diecast
housing ensures excellent ground
bonding and long corrosion-free
service life in indoor/outdoor
applications
Capacitor coupling circuitry at all
ports provides effective DC voltage
blocking
Internal seizing pins provide
improved connectivity to connector
center lead
Mounting tabs with provided
mounting screws enables easy
installation
Cast-in integrated ground block
with convenient 3-way mounting
screws (Slotted, Hex, Phillips)
enables cost-effective installations
Performance tests conducted con-
forming with SCTE standards IPS
TP-201, 202, 203, 406
www.picomacom.com
1GHz 90dB/130dB EMI CATV Vertical Splitters
TSV-2
TSV-2SB
TSV-4
TSV-4SB
TSV
Series
1GHz 90dB/130dB EMI CATV Vertical Splitters
Manufactured to high performance standards, TruSpec's TSV-series 1GHz professional-
grade CATV splitters provide excellent performance rivaling competitors' equivalent
models. Applications range from residential to MDU installations in international and
domestic cable distribution systems. The vertical-port design ideally suits these splitters
for applications where limited space is available such as lock boxes and utility closets.
Our advanced printed board circuitry includes special ferrite core material guaranteeing
minimal insertion loss, optimal isolation and return loss to 1GHz ensuring high-quality
analog or digital signal transfer. TSV series F-port threads are precision machined,
ensuring easy connector installation and removal, and improved port-to-connector
interface. The silver-plated zinc alloy cast case features mounting tabs and cast-in
ground block enabling easy and cost efficient installations. TSV series are optionally
available in >90dB epoxy-backed or >130dB solder-backed versions. Each TSV splitter
is individually tested at the factory to comply with precise quality standards.
