Schiller BOB-CAT PREDATOR PRO GVT990 Operator's Manual

Hide thumbs Also See for BOB-CAT PREDATOR PRO GVT990:

Advertisement

Quick Links

Download this manual
PREDATOR PRO GVT990 GEN W/61" SIDE DISCHARGE
PREDATOR PRO GVT990 GEN W/72" SIDE DISCHARGE
PREDATOR PRO FX921V KAW W/61" SIDE DISCHARGE
PREDATOR PRO FX1000V-DFI KAW W/61" SIDE DISCHARGE
PREDATOR PRO FX1000V-DFI KAW W/72" SIDE DISCHARGE
PREDATOR PRO FX921V KAW W/72" SIDE DISCHARGE
OPERATOR'S MANUAL 4168254
942512J
942513J
942514J
942515J
942516J
942519J
www.bobcatturf.com

Advertisement

loading

Related Manuals for Schiller BOB-CAT PREDATOR PRO GVT990

Summary of Contents for Schiller BOB-CAT PREDATOR PRO GVT990

  • Page 1 942512J PREDATOR PRO GVT990 GEN W/61” SIDE DISCHARGE 942513J PREDATOR PRO GVT990 GEN W/72” SIDE DISCHARGE 942514J PREDATOR PRO FX921V KAW W/61” SIDE DISCHARGE 942515J PREDATOR PRO FX1000V-DFI KAW W/61” SIDE DISCHARGE 942516J PREDATOR PRO FX1000V-DFI KAW W/72” SIDE DISCHARGE 942519J PREDATOR PRO FX921V KAW W/72”...
  • Page 2 CALIFORNIA Proposition 65 Warning WARNING Diesel engine exhaust and some The engine exhaust from this product of its constituents are known to the contains chemicals known to the State State of California to cause cancer, of California to cause cancer, birth birth defects and other reproductive defects or other reproductive harm.
  • Page 3 Your safe use of this Schiller Grounds Care, Inc.product is one of our prime design objectives. Many safety features are built in, but we also rely on your good sense and care to achieve accident-free operation.
  • Page 4 Schiller of hazard seriousness. These words appear in this Grounds Care, Inc.Engineering Department. Any manual and on the safety labels attached to Schiller Schiller Grounds Care, Inc.product that is altered, Grounds Care, Inc.machines. For your safety and...
  • Page 5 ASSEMBLY AND SETUP PREDATOR-PRO SERIES TOOLS REQUIRED FOR ASSEMBLY Wrecking bar Claw hammer Ratchets: 3/8” Drive Sockets: 9/16”, 3/4" Wrenches: 3/8", 9/16", 3/4"” Straight edge Tire pressure gauge Blocks (for deck leveling) NOTE: All references below to the “right” or “left” are with respect to an operator at the controls. 1.
  • Page 6 ASSEMBLY AND SETUP PREDATOR-PRO SERIES 5. COUNTERBALANCE SPRINGS a) Raise the cutterdeck all the way. b) Adjust the spring A with nut B: Approximately 1" of threads should be extending past the spring mounting bracket at nut B. The springs may be tightened or loosened from this point according to personal preference.
  • Page 7 ASSEMBLY AND SETUP PREDATOR-PRO SERIES 7. FINAL PREPARATIONS Check the engine and hydraulic oil levels. Top up with the correct oil if necessary. Use SAE 10W30 motor oil for the engine. Use fresh, clean SAE 15W40 or SAE 20W50 motor oil or SAE 15W50 synthetic motor oil for the hydraulic system.
  • Page 8 MAINTENANCE CHART PREDATOR-PRO SERIES t l i t l i...
  • Page 9 MAINTENANCE RECORD PREDATOR-PRO SERIES NOTES ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ & & r i f , l i t l i...
  • Page 10 MAINTENANCE PREDATOR-PRO SERIES CHECK DAILY Operator Presence Interlock System - Start Operation For the engine to crank, the parking brake must be on, the PTO (blades) off and traction levers in the neutral lock position. Sit in the seat and check, one by one, if the engine will crank with the parking brake off, the blades on, and either traction lever out of neutral lock.
  • Page 11 MAINTENANCE PREDATOR-PRO SERIES LUBRICATION Every 50 hours of operation, lubricate the following points (1-4) with grease: 1. Deck lift rockshaft (1 point) 2. Deck lift pivots (6 points) 3. Brake lever pivot (1 point) 4. Push arms (2 points located at rear of cutterdeck under each fuel tank) 5.
  • Page 12 MAINTENANCE PREDATOR-PRO SERIES HYDRAULIC SYSTEM Fluid level in the hydraulic system should be checked after the first 5 hours of operation, and every 100 hours thereafter, or when a leak has occurred. If the fluid is low, check all components for leaks. To check, remove reservoir cap M.
  • Page 13 MAINTENANCE PREDATOR-PRO SERIES ENGINE OIL Do not perform engine maintenance without the engine off, spark plug wires disconnected and PTO disengaged. AFTER FIRST FIVE (5) HOURS While the engine is warm: 1. Release the oil drain hose assembly from the engine clip J.
  • Page 14 MAINTENANCE PREDATOR-PRO SERIES ENGINE COOLING Continued operation with a clogged cooling system will cause severe overheating and can result in en- gine damage. Daily: Clean air intake screen S on air cooled engines. Every 100 hours: Clean cooling fins beneath blower housing H with reference to information in the engine manufacturer's manual.
  • Page 15 MAINTENANCE PREDATOR-PRO SERIES CLEANING MACHINE Clean the machine after use. Compressed air is recommended. Do not use a pressure washer. The machine will run cooler and last longer if kept free of clippings and other debris. A clean machine also re- duces the risk of fire due to accumulation of combus- tible debris and chaff.
  • Page 16 MAINTENANCE PREDATOR-PRO SERIES BLADE REMOVAL BLADE BALANCE Follow these instructions to prevent injury during Blade balance must be maintained at 5/8 oz-in blade removal: (19.4 g-cm) or less. Failure to keep blades balanced 1. Loosen with a box wrench or a socket and long causes excess vibration, wear, and shortened life of breaker bar.
  • Page 17 ADJUSTMENTS PREDATOR-PRO SERIES DECK LEVELING FORWARD PITCH SHOWN a) Park the machine on a smooth, level surface. Raise the deck to the transport position. b) Lower the deck onto a pair of equal height blocks A under the rear corners of the deck. Place another pair of adjustable blocks B under the front of the deck so that the deck top is pitched forward 1/8”.
  • Page 18 ADJUSTMENTS PREDATOR-PRO SERIES HEIGHT OF CUT The height of cut is set by moving height of cut pin C to the hole designated for the height of cut desired. To change the height of cut: 1. Lift the deck to the highest position. 2.
  • Page 19 ADJUSTMENTS PREDATOR-PRO SERIES CONTROL LEVERS There are two mounting positions for the control levers, upper and lower. The lower position works well for most people. Taller operators may need the upper position. To adjust the height of the control levers: Remove bolts A and nuts B.
  • Page 20 ADJUSTMENTS PREDATOR-PRO SERIES TRACKING HANDLES An adjustment is provided to allow the operator to adjust machine tracking during operation. 1. Turn knob W clockwise to shorten control lever travel. 2. Turn knob W counter-clockwise to increase con- trol lever travel. DAMPERS Different damper mounting holes have been provided for various operator preferences with control lever...
  • Page 21 ADJUSTMENTS PREDATOR-PRO SERIES HYDROSTAT ADJUSTMENTS A turnbuckle-style hydrostat neutral adjustment is provided. Neutral: 1. Support the machine with the rear wheels off the ground. Use jackstands or equivalent sup- port. Do not rely only on mechanical or hydraulic jacks. 2. Move the traction levers out into the neutral lock position and raise the seat.
  • Page 22 PREDATOR-PRO SERIES Note: Always use Schiller Grounds Care, Inc.replacement belts, not general purpose belts. Schiller Grounds Care, Inc.belts are specially designed for use on commercial mow- ers and will normally last longer. CUTTERDECK BELT 1. Tilt floorplate all the way forward.
  • Page 23 SPECIFICATIONS PREDATOR-PRO SERIES POWER UNITS ENGINES: CONTROLS: Construction: Aluminum block with cast-in cast iron sleeves. Aluminum head. Throttle; choke; power takeoff (PTO) clutch switch; Configuration: 4-stroke, vertical shaft, V-twin cylin- traction levers; parking brake lever; lift lever. der, overhead valve, air-cooled. FUEL SYSTEM: DRIVE SYSTEM: One tank on each side of operator.
  • Page 24 SPECIFICATIONS PREDATOR-PRO SERIES ENGINES MODEL NUMBERS 942512J, 942513J 942515J, 942516J 942514J, 942519J MANUFACTURER Generac Kawasaki Kawasaki MODEL GTV990 FX1000V FX921V CYLINDERS COOLING 3.54 X 3.07" 3.5 X 3.2" 3.5 X 3.2" BORE/STROKE (90 X 78mm) (89.2 X 80mm) (89.2 X 80mm) DISPLACEMENT 60 cu.
  • Page 25 SPECIFICATIONS PREDATOR-PRO SERIES & & r i f , l i t l i...
  • Page 26 SPECIFICATIONS PREDATOR-PRO SERIES CUTTERDECKS 942512J, 942514J 942513J, 942516J MODEL NUMBER 942515J 942519J TYPE Side Discharge Side Discharge CUTTING WIDTH 61" (155 cm) 71.5" (181 cm) WIDTH WIDTH 62" (157 cm) 72.5" (184 cm) (CHUTE UP) WIDTH 73" (185 cm) 84.0" (213 cm) (CHUTE DOWN) high lift high lift...
  • Page 27 PARTS SECTION PREDATOR-PRO SERIES PARTS SECTION...
  • Page 28 GENERAC UPPER ENGINE DECK ASSY PREDATOR-PRO SERIES FIGURE 1 INCLUDED W/ENGINE 18 31...
  • Page 29 GENERAC UPPER ENGINE DECK ASSY PREDATOR-PRO SERIES FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165867 ENGINE-3GTV990 GENERAC 1 64141-6 NUT-WLF 5/16-18 64229-08 LOCKNUT NYLON 5/16-24 *2198147-01 ELEMENT 64268-02 NUT-FL NYLON LOCK 5/16-18 2 *4135662 AIR FILTER SECONDARY 64192-06 SETSCR SQHD 5/16-18X3/4 *4135663...
  • Page 30 KAW UPPER ENGINE DECK ASSY PREDATOR-PRO SERIES FIGURE 2 18 31...
  • Page 31 KAW UPPER ENGINE DECK ASSY PREDATOR-PRO SERIES FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4164254 ENGINE-37 HP DFI KAW 4167705 ENGINE-37 HP DFI 64141-6 NUT-WLF 5/16-18 4165719 ENGINE-34 KAW NON DFI 64229-08 LOCKNUT NYLON 5/16-24 64268-02 NUT-FL NYLON LOCK 5/16-18 2 4152953 S-AIR FILTER PRIMARY 64192-06...
  • Page 32 LOWER ENGINE DECK ASSY/CLUTCH PREDATOR-PRO SERIES FIGURE 3 ENGINE PUMP PUMP BELT DETAIL...
  • Page 33 LOWER ENGINE DECK ASSY/CLUTCH PREDATOR-PRO SERIES FIGURE 3 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4157180 PULLEY-PUMP 64151-26 NUT-7/16-20 NYLN INST. 64164-29 KEY-MET 3/16X3/4 64164-12 4165508 PULLEY- 5.25 OD X 1.126 (USED ON KAW ENGINES ONLY) 4165507 PULLEY-ENGINE (USED ON GENERAC ENGINES ONLY) 4165709 CLUTCH-ELECTRIC, 225 (USED ON KAW ENGINES ONLY)
  • Page 34 BUMPER PREDATOR-PRO SERIES FIGURE 4...
  • Page 35 BUMPER PREDATOR-PRO SERIES FIGURE 4 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4167906 S-ENG DECK W/LABS 4165491.7 BRKT-BUMPER, TOP (NOT USED ON KOHLER MODELS) 4165490.7 WRAPPER-BUMPER 4165492.7 STRAP-BUMPER 64262-012 BLT-FLG HD 3/8-16 X 1-1/4 64268-03 NUT-FL NYLON LOCK 3/8-16 QTY 12 ON 61"...
  • Page 36 NON-DFI FUEL TANKS/CONTROL PANEL PREDATOR-PRO SERIES FIGURE 5 7 11 13 ENGINE TO ENGINE...
  • Page 37 FUEL TANKS/CONTROL PANEL PREDATOR-PRO SERIES FIGURE 5 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165428 TANK-FUEL LH (INCLUDES ITEMS 15, 31-33, 35, 36, 38) 4165429 TANK-FUEL RH (INCLUDES ITEMS 15, 31-33, 35, 36, 38) 4165930 S-CONTROL PANEL 4167906 S ENG DECK W/LABS 4165291 CAP-FUEL, RATCHET TYPE 2 64123-50...
  • Page 38 DFI FUEL TANKS/CONTROL PANEL PREDATOR-PRO SERIES FIGURE 6 CONTROL PANEL 47 39 ENGINE TO ENGINE...
  • Page 39 DFI FUEL TANKS/CONTROL PANEL PREDATOR-PRO SERIES FIGURE 6 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165428 TANK-FUEL LH 4165429-03 TUBE -FUEL PICK UP (INCLUDES ITEMS 15, 31-33, 35, 36, 49) 34* 970391 KIT-LIGHT ACCESSORY 35* 4166704 CLAMP-FUEL 4165429 TANK-FUEL RH 4165471 KIT-DFI THROTTLE LEVER (INCLUDES ITEMS 15, 31-33, 35, 36, 49)
  • Page 40 BRAKES/REAR WHEEL PREDATOR-PRO SERIES FIGURE 7 TORQUE TO 225 FT/LBS...
  • Page 41 BRAKES/REAR WHEEL PREDATOR-PRO SERIES FIGURE 7 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4167906 S-ENGINE DECK W/LABS (USED ON 61" DECKS ONLY) 4165701.7 WLDMT-BRAKE ARM LH 64189-22 BLT-HEX SOC 1/2-13 X 6 4165700.7 WLDMT-BRAKE ARM RH (USED ON 72" DECKS ONLY) 128102 SPRING,EXTENSION 4165449.7...
  • Page 42 OIL COOLER PREDATOR-PRO SERIES FIGURE 8 TO PUMP CASE DRAIN...
  • Page 43 OIL COOLER PREDATOR-PRO SERIES FIGURE 8 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4167906 S ENGINE DECK W/LABS 4166416.7 BRKT-COOLER FRONT (USED ON KAWASAKI MODELS) 4166418.7 BRKT-COOLER FRONT (USED ON GENERAC MODELS) 64262-002 BLT-FLG HD 1/4-20 X 3/4 2720891.7 SCREEN-OIL COOLER 2188173 COOLER-OIL 4167655...
  • Page 44 AIR COOLED HYDRAULICS PREDATOR-PRO SERIES FIGURE 9...
  • Page 45 AIR COOLED HYDRAULICS PREDATOR-PRO SERIES FIGURE 9 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4167655 S HYD RESERVOIR W/LAB 2720396 FILTER 25 MICRON 4167240 CAP-RESERVOIR 4160243 PLUG-HYDRAULIC TANK 158058-04 FTG-90 BRB 9/16-18X.38 108205-03 ELBOW-MALE 45 37-ORB 69053-05 3/8 HIGH TEMP HSE (69053-05 IS A SERVICEABLE LENGTH OF 55") LH PUMP PORT A-HOSE KAW MODEL 2188157-02...
  • Page 46 HYDROGEAR PUMP PREDATOR-PRO SERIES FIGURE 10...
  • Page 47 HYDROGEAR PUMP PREDATOR-PRO SERIES FIGURE 10 ITEM HYDROGEAR PART NO. CGC, INC. PART NO. DESCRIPTION 71019 4157242-001 PUMP SHAFT KIT-TAPERED 2000038 4157242-002 RETAINING RING 2000023 4157242-003 SPACER 51092 4157242-004 LIP SEAL 70739 4157242-005 TRUNNION SEAL/RETAINER 2000014 4157242-006 TRUNNION ARM 2000015 188059-09 SLOT GUIDE 70738...
  • Page 48 NON-DFI WIRE HARNESS PREDATOR-PRO SERIES FIGURE 11 CLUTCH ELECTRIC WIRE COLORS WHITE ENGINE GROUND STARTER WHITE W/ BLACK STRIPE PURPLE ORANGE ORANGE W/ BLACK STRIPE PURPLE W/ ORANGE STRIPE ORANGE W/ PURPLE STRIPE DARK BLUE BLACK GREEN BATTERY BATTERY YELLOW YELLOW W/ BLACK STRIPE RED W/ WHITE STRIPE GREEN W/ YELLOW STRIPE...
  • Page 49 NON-DFI WIRE HARNESS PREDATOR-PRO SERIES FIGURE 11 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165575 HARNESS-WIRING MAIN 148082-20 FUSE-20 AMP 108061-13 CABLE-BATTERY 36 BLACK 4124009 SWITCH-SEAT, NO 4143068 JUMPER-SEAT SWITCH 4165120 METER-HOUR 2722227-02 CABLE-BATT W/CONDUIT (INCLUDES ITEMS 20 & 21) 128010 KEY-SWITCH 2722325...
  • Page 50 DFI WIRING HARNESS PREDATOR-PRO SERIES FIGURE 12 BATTERY BATTERY (RED) (BLACK) ENGINE BLOCK SOLENOID (GROUND) SOFT START MODULE SOFT START HARNESS 87 NO RELAY SCHEMATIC...
  • Page 51 DFI WIRE HARNESS PREDATOR-PRO SERIES FIGURE 12 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165599 HARNESS-WIRING MAIN 148082-20 FUSE-20 AMP 108061-13 CABLE-BATTERY 36 BLACK 1 158135-01 SWITCH-SEAT, NO 158136 WIRE-SEAT SWITCH 4165120 METER-HOUR 2722227-02 CABLE-BATT W/CONDUIT 128010 KEY-SWITCH 2722325 RELAY-40AMP SEALED 2188154 MODULE-DELAY...
  • Page 52 SEAT ASSEMBLY PREDATOR-PRO SERIES FIGURE 13 BRACKET ON ENGINE DECK WELDMENT...
  • Page 53 SEAT ASSEMBLY PREDATOR-PRO SERIES FIGURE 13 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4167820 SEAT-SUSPENSION (INCLUDES ITEMS 2-12, 21, 25, 26, 28) 4165316-07 UPPER SEAT ASSEMBLY 4165316-10 CUSHION-COVER BACK 4165316-11 CUSHION COVER 4165316-06 PROTECTOR-BACK 4165316-02 PAD-ARM SINGLE 4165316-05 ARM KIT-LH 4165316-04 ARM KIT-RH 4124009...
  • Page 54 FOLDING ROPS PREDATOR-PRO SERIES FIGURE 14...
  • Page 55 FOLDING ROPS PREDATOR-PRO SERIES FIGURE 14 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4168257 S-ROPS W/ LABELS (INCLUDES ITEMS 2-13) 64123-31 BOLT-1/2-13 X 3 64151-7 LOCKNUT- 1/2-13 4162880 LANYARD-NYLON 64262-011 BLT-FLG HD 3/8-16X1 4160347 LABEL-WARNING ROPS 64268-03 NUT-FL NYLN LOCK 3/8-16 8 64168-1 PIN-COTTER 4160343...
  • Page 56 STEERING/DECK LIFT PREDATOR-PRO SERIES FIGURE 15...
  • Page 57 STEERING/DECK LIFT PREDATOR-PRO SERIES FIGURE 15 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 85010N ZERK, 1/4-28 STR SELF TH 11 4167906 S ENGINE DECK W/LABS 64221-04 E-RING .875 4163746 SPRING 64175-05 NUT-PUSH 1/2 4165962 ZERK-90 DEGREE 64188-36 PIN, CLEVIS 7/16X1-1/4 64123-50 BLT-HEX 3/8-16X1 4165466...
  • Page 58 CRADLE ASSEMBLY PREDATOR-PRO SERIES FIGURE 16 KICKPLATE...
  • Page 59 CRADLE ASSEMBLY PREDATOR-PRO SERIES FIGURE 16 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165610 LABEL-WARNING 2182356.7 BRACKET-SHAFT HANGER 2188127 CHAIN-6.35 (.250) 5 LINKS QTY 4 USED ON 61" DECKS QTY 2 USED ON 72" DECK 2722454 CHAIN-6.35 (.250) 3 LINKS QTY 2 USED ON 72"...
  • Page 60 CRADLE & CASTER ASSEMBLY PREDATOR-PRO SERIES FIGURE 17...
  • Page 61 CRADLE & CASTER ASSEMBLY PREDATOR-PRO SERIES FIGURE 17 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 48043-03C CUP, OUTER BEARING 4165278 ASSY-WHL 13X6.5-6 (INCLUDES ITEM 7) 4167970 ASSY-WHL HIGH CROWN (OPTIONAL WHEEL ASSY) DECK/W LABS 64123-223 BOLT-3/4-10 X 10 2722452.7 WLDMT-CASTER YOKE 2722230-03 SPANNER...
  • Page 62 61" SIDE DISCHARGE PREDATOR-PRO SERIES FIGURE 18...
  • Page 63 61" SIDE DISCHARGE PREDATOR-PRO SERIES FIGURE 18 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4166118 S-DECK W/ LABELS 61" ZT2 1 64229-01 NUT-NYLON LOCK 1/4-20 4165456.7 BELT COVER-RH 4168642.7 BAFFLE-FRONT,CNTR 61IN 1 4165455.7 BELT COVER-LH 4165968.7 BAFFLE-FRONT,LH 61IN 38524 KNOB-4 PRONG 3/8-16 521438 GREASE SEAL...
  • Page 64 72" SIDE DISCHARGE PREDATOR-PRO SERIES FIGURE 19...
  • Page 65 72" SIDE DISCHARGE PREDATOR-PRO SERIES FIGURE 19 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165943 SPRING-EXTENSION 4166120 S-DECK W/ LABELS 72" ZT2 1 64163-93 WSHR-.635 X 1.12 X.062 4165564.7 GUARD-BELT RH 548138 BRG NDL.88 1.12 1.00 4165563.7 GUARD-BELT LH 64018-7 BLT-CRG 3/8-16X1-1/4 38524...
  • Page 66 BELTS-CUTTERDECK PREDATOR-PRO SERIES FIGURE 20...
  • Page 67 BELTS-CUTTERDECK PREDATOR-PRO SERIES FIGURE 20 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165617 BELT-DECK 72" GENERAC 1 4165645 BELT-DECK 72" KAWASAKI 4165644 BELT-DECK 61" GENERAC 4169463 BELT-DECK 61" KAWASAKI...
  • Page 68 DECALS-POWER UNIT PREDATOR-PRO SERIES FIGURE 21 BACK OF ENGINE DECK DOCUMENT TUBE LOCATED UNDER FOOTPLATE UNDER SEAT LOCATED BEHIND SEAT ON OIL COOLER LOCATED UNDER FOOTPLATE...
  • Page 69 DECALS-POWER UNIT PREDATOR-PRO SERIES FIGURE 21 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4165866 LABEL-PREDATOR-PRO 4158401 LABEL-BOB-CAT, 10.5" 2000735 LABEL-OPER MAN 2000590 LABEL, WARN BATTERY 4165722 LABEL - HYDR OIL FILL 4165639 LABEL-CONTROL PANEL (USED ON NON-DFI MODELS) 4165638 LABEL-CONTROL PANEL (USED ON DFI MODEL ONLY) 2000693...
  • Page 70 DECALS-CUTTERDECKS PREDATOR-PRO SERIES FIGURE 22...
  • Page 71 DECALS-CUTTERDECKS PREDATOR-PRO SERIES FIGURE 22 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4164269 LABEL-WARNING BLADES 1 2000577 LABEL-WARNING...
  • Page 72 KAW DFI DUAL FUEL PUMP PARTS PREDATOR-PRO SERIES FIGURE 23...
  • Page 73 KAW DFI DUAL FUEL PUMP PARTS PREDATOR-PRO SERIES FIGURE 23 ITEM KAW P/N DESCRIPTION 130AA0614 BOLT-FLANGED ELECTRIC PUMP 32154-7020 PIPE-PULSE 130AA0616 BOLT-FLANGED RESERVOIR 23062-7020 BRACKET-COMP FUEL PUMP 311AA0600 NUT-HEX ELECTRIC PUMP 42036-0723 SLEEVE-450MM VENT TUBE 42036-7022 SLEEVE-300 SUPPLY TUBE 42036-7012 SLEEVE-125MM INTAKE &...
  • Page 74 SCHILLER GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.schillergc.com ©Schiller Grounds Care, Inc. 2010...
