PARTS MANUAL 4165108
36 HYDRO MID-16HP KAW FS
36 HYDRO MID-18HP ES KAW FS
48 HYDRO MID-18HP KAW FS
48 HYDRO MID-18HP ES KAW FS
54 HYDRO MID-20HP KAW FS
54 HYDRO MID-20HP ES KAW FS
933305G
933307G
934306G
934307G
935308G
935309G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOB-CAT 933305G and is the answer not in the manual?

Questions and answers

Summary of Contents for Schiller BOB-CAT 933305G

  • Page 1 933305G 36 HYDRO MID-16HP KAW FS 933307G 36 HYDRO MID-18HP ES KAW FS 934306G 48 HYDRO MID-18HP KAW FS 934307G 48 HYDRO MID-18HP ES KAW FS 935308G 54 HYDRO MID-20HP KAW FS 935309G 54 HYDRO MID-20HP ES KAW FS PARTS MANUAL 4165108...
  • Page 2 CALIFORNIA WARNING Proposition 65 Warning Diesel engine exhaust and some The engine exhaust from this product of its constituents are known to the contains chemicals known to the State State of California to cause cancer, of California to cause cancer, birth birth defects and other reproductive defects or other reproductive harm.
  • Page 3: Table Of Contents

    Your safe use of this Schiller Grounds Care, Inc. product is one of our prime design objectives. Many safety features are built in, but we also rely on your good sense and care to achieve accident-free operation. For best protection, study the manuals thoroughly.
  • Page 4: Safety

    Schiller of hazard seriousness. These words appear in this Grounds Care, Inc. Engineering Department. Any manual and on the safety labels attached to Schiller Schiller Grounds Care, Inc. product that is altered, Grounds Care, Inc. machines. For your safety and...
  • Page 5: Labels

    LABELS Hydro Midsize Manufactured under one or more of the following U.S. patents: 5,343,678 5,415,059 5,651,241 4165666...
  • Page 6 LABELS Hydro Midsize For use on: 933307G, 934307G, 935309G For use on: 933305G, 934306G, 934308G...
  • Page 7 LABELS Hydro Midsize...
  • Page 8: General Instructions

    GENERAL INSTRUCTIONS Hydro Midsize Before using machine for the first time, check engine Never operate the equipment in wet grass. Always and hydraulic fluid levels and lubricate all points. be sure of your footing; keep a firm hold on the handle and walk;...
  • Page 9 GENERAL INSTRUCTIONS Hydro Midsize Stop the engine: slopes, rests with the operator. • whenever you leave the mower; • Use lower speeds and exercise extreme caution • before refuelling. on slopes and especially in sharp turns to prevent tipping and loss of control. Use extra caution when s) Shut the engine (motor) off and wait until the blades changing direction on slopes.
  • Page 10: Controls

    CONTROLS Hydro Midsize SPEED SELECTOR (E) The speed selector levers in the center of the control panel set the maximum forward and reverse speeds. The further the levers are moved forward, the faster the maximum preset speed. The levers must be moved forward for both forward and reverse speeds.
  • Page 11 CONTROLS Hydro Midsize TRACTION CONTROL LEVERS (G) TRACTION LOCKS (H) The traction locks provide a neutral position when pulled back and locked with traction control levers. To release: pull the traction control levers up enough to push forward on the locks. NOTE: •...
  • Page 12: Machine Operation

    MACHINE OPERATION Hydro Midsize BEFORE STARTING THE ENGINE: • Disengage cutterdeck drive. • Traction levers are positively locked in neutral. • Parking brake is on and speed selector is in neutral. 1. Check the engine oil level and add if necessary. Open the fuel valve under the fuel tank. Set the traction levers in the neutral position and the PTO switch to the off position.
  • Page 13 MACHINE OPERATION Hydro Midsize DRIVING THE MACHINE IN TRANSPORT 1. With the PTO switch disengaged, and the operator present controls depressed, move the speed selector lever to give the required forward speed. 2. Release the traction lever locks and gradually engage both traction control levers together. NOTE: Engaging only one traction lever will cause the machine to turn to one side.
  • Page 14 MACHINE OPERATION Hydro Midsize PUSHING THE MACHINE WITH THE ENGINE STOPPED: Open dump valve V on each pump by turning counter clockwise two revolutions. Move the machine and close dump valve V by turning clockwise until valve is firmly seated.
  • Page 15: Height Of Cut

    HEIGHT OF CUT Hydro Midsize Make all adjustments with the engine shut off, spark 2. CUTTERDECK BLADE SPINDLES plug wire disconnected and mower drive disengaged. NOTE: See MAINTENANCE section of the Setup, FIXED CUTTERDECK HEIGHT OF CUT Parts & Maintenance manual for blade removal and replacement procedures.
  • Page 16 HEIGHT OF CUT Hydro Midsize SETTING CUTTERDECK HEIGHT CUTTERDECK POSITION 1. Support rear of power unit. 2. Place blocks under both outside edges of cutter- deck at B. See Block chart below. " 5 " 5 " " " 5 "...
  • Page 17 HEIGHT OF CUT Hydro Midsize FIXED CUTTERDECK HEIGHT OF CUT 4109861 A(1/8") NUMBER OF SPACERS BETWEEN SPINDLE B(1/4") AND BLADE (1/4" THICK) C(1/2") CUTTING HEIGHT UPPER BOLT POSITION 1.375 1.625 1.875 2.125 2.375 2.625 2.875 3.125 3.375 3.625 3.875 4.125 4.375 4.625 NOTE: Use only these combinations of settings.
  • Page 18: Belt Replacement

    BELT REPLACEMENT Hydro Midsize PTO BELT 1. Rotate idler arm using a 3/8" ratchet or breaker bar and remove belt. CUTTERDECK BELT 1. Remove PTO belt. 2. Rotate idler arm using a 3/8" ratchet or breaker bar and remove belt. 3.
  • Page 19: Adjustments

    ADJUSTMENTS Hydro Midsize TRACTION DRIVE HYDROSTAT ADJUSTMENTS: The following adjustments must be done in order. STEP 1 - Set Neutral Neutral is set at the factory. If it should require adjustment, raise the wheels off the ground by setting the machine on jackstands or blocks. Disconnect the traction control rod A and speed control rod R at each pump end.
  • Page 20 ADJUSTMENTS Hydro Midsize Speed Control Lever Friction The speed control lever is held where set by friction pads. If the setting will not hold, tighten nuts E to increase friction on the speed control lever. Adjust Knob D to get machine to track in a straight line.
  • Page 21 ADJUSTMENTS Hydro Midsize Make all adjustments with the engine shut off, spark plug wire disconnected and mower drive disengaged. OPERATOR PRESENT CONTROLS The operator present (OP) controls should be ad- justed to control the operation of the plunger of the operator present switch (located under the right side of the control panel).
  • Page 22 ADJUSTMENTS Hydro Midsize TRACK WIDTH ADJUSTMENT The track width originally set from the factory can be increased an additional 3-1/4" overall by performing the following steps. 1. Loosen wheel lug nuts on both drive tires. 2. Raise rear of unit so that drive tires are off the ground.
  • Page 23: Specifications

    SPECIFICATIONS Hydro Midsize POWER UNITS CUTTERDECKS CONTROLS: CONSTRUCTION: Throttle, choke, PTO switch, speed selector levers, 10 and 7 gauge steel deck welded single unit, baffled key switch, operator present, traction levers (1 per for high velocity air flow, large discharge opening with wheel), parking brake.
  • Page 24 SPECIFICATIONS Hydro Midsize , 5G , 6G , 8G " 7 " 5 " 4 " 5 " 8 " 5 " 5 " 5 " 5 " 8 " 5 " 8 t f i t f i t f i t f i t f i t f i...
  • Page 25 SPECIFICATIONS Hydro Midsize ENGINES 933307G, MODEL NUMBER 933305G 934306G 935308G 935309G 934307G, MANUFACTURER KAWASAKI KAWASAKI KAWASAKI KAWASAKI KAWASAKI MODEL FS481VV FS541V FS541V FS600V FS600V CYLINDERS COOLING FUEL Gasoline Gasoline Gasoline Gasoline Gasoline 2.9" X 2.8" 2.9" X 2.8" 2.9" X 2.8" 2.9"...
  • Page 26 SCHILLER GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.schillergc.com ©Schiller Grounds Care, Inc. 2010...
