  • Page 1 Blunami Digital Sound Decoder ™ Electric User’s Guide Software Release 1.0 Rev. B 02/11/23...
  • Page 2 The information in this document is subject to change without notice. SoundTraxx (Throttle Up! Corp.) shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damage resulting from the furnishing, performance or use of this material.

  • Page 3: Table Of Contents

    Contents All Aboard! ..................4 Overview ......................4 Using Blunami ...................... 5 CV Programming Tutorial ................... 10 Introduction to Programming ................13 Basic Programming ..............17 Configuring the Address ..................17 Configuring the Decoder ..................18 Configuring Throttle and Braking ................ 20 Configuring Lighting Outputs ................

  • Page 4: All Aboard

    Overview Congratulations on purchasing your SoundTraxx Blunami Digital Sound Decoder (DSD) for electric locomotives and trolleys! Blunami is the newest wave of SoundTraxx innovation and builds upon the previous generation of Tsunami2 to offer the highest quality sound for model railroading.

  • Page 5: Using Blunami

    All Aboard! Using Blunami The Blunami Digital Sound Decoder is designed to enhance your model railroading experience by giving you a wide variety of innovative features and incredibly realistic sound for your models. Some of the features discussed in this user’s guide include Dynamic Digital Exhaust for electric locomotives, Hyperdrive2 advanced motor control, Flex-Map function mapping technology, two volume mixers, independent and train brake functions and Motorman Omura sound effects.
  • Page 6 All Aboard! Ring the Bell Turn on F1 to ring the bell. Press F1 again to stop ringing the bell. The bell is generally rung before moving the locomotive, when approaching crossings, to alert people or equipment near the track, and as a warning signal when necessary. Blow the Airhorn Signaling can make your operating sessions more fun! Engineers signal to notify passengers, crew, and other trains of common locomotive movements, such as stopping, moving forward,...
  • Page 7 F10 twice. When the trolley begins to move in the reverse direction, ring the trolley bell three times. Configure automatic trolley bell signals with SoundTraxx’ Flex-Map technology. Refer to “Configuring Function Mapping” for more information.
  • Page 8 All Aboard! Use Switching Mode To improve throttle control for switching operations, turn on F14 to override all momentum CVs and reduce the current throttle setting by 50%. Press F14 again to reset locomotive speed to the prior speed step and reactivate all momentum CV settings. For more information about momentum CVs, refer to “Configuring Throttle and Braking.”...
  • Page 9 All Aboard! Automatic Sound Effects Blunami plays a variety sound effects automatically. Automatic sound effects respond prototypically to aspects of operation, such as certain functions, speed settings, and motor load changes. Traction Motors With the pantograph extended, the whine of the tractions motors is automatically adjusted by auto-notching and Dynamic Digital Exhaust as you operate.

  • Page 10: Cv Programming Tutorial

    All Aboard! CV Programming Tutorial What is a CV? Configuration Variable (CV) is the industry-adopted term for a decoder’s user-adjustable memory locations. CVs allow you to adjust various decoder properties and customize your operating experience. The address, audio settings, motor control, lighting effects, and function assignments are just some of the properties you can adjust with CVs.
  • Page 11 All Aboard! CV. As the bit variables can take on only one of two values (0 or 1), they are usually used to control features that are either OFF or ON (i.e., disabled or enabled). Tip: Think of bits as light switches to turn ON or OFF various features. Each bit (0-7) carries a “weight”...
  • Page 12 All Aboard! Example Let’s assume we would like to set CV 29 (Configuration Data 1) so that 28/128 speed-step mode and extended (long) addressing are enabled. We would use the following steps to calculate the value: 1. To configure these features we see that bit 1 (F0) and bit 5 (EAM) should both be ON (set to 1), with all other bits OFF (set to 0).

  • Page 13: Introduction To Programming

    All Aboard! Introduction to Programming Configuration Variable Control CVs This section details CV programming modes, reading CVs, CV 8: Manufacturer ID accessing indexed CVs, resetting CVs to factory defaults, CV 15: CV Unlock Code and locking and unlocking CVs. Due to the varying CV CV 16: CV Lock ID programming methods used by DCC systems, we cannot CV 30: Error Information...
  • Page 14 All Aboard! Indexed CVs The term “indexed CVs” tends to cause confusion and consternation. Simply put, indexed CVs are located on ‘pages’ to help manage the total number of CVs. This is required by the NMRA DCC Standard and works like this: Indexed CVs are accessed with the use of two CVs: CV 31 enables indexing when set to a value of 16 (the default value) and CV 32 selects the desired indexed page.
  • Page 15 The CVs can be quickly reset to their factory default values. Follow the steps below to perform either a full or partial CV reset: 1. Turn on track power to the decoder. If you have a SoundTraxx CurrentKeeper ™...
  • Page 16 If you still can’t identify the lock code, there may be a problem with the installation, programming track, or decoder. Contact SoundTraxx Customer Support if this occurs. If you do not have access to a programming track with read-back capabilities (or are uncertain...

  • Page 17: Basic Programming

    The Primary address is commonly referred to as the “short” or “2-digit” address. Enter a value from 1 to 127 into CV 1 to set the primary address. All SoundTraxx decoders are set to primary address 3 by default. When selecting the locomotive with your DCC throttle, only enter “3” into the method used to select locomotives.

  • Page 18: Configuring The Decoder

    Basic Programming Configuring the Decoder CV 29 controls a variety of important settings. It determines Decoder Configuration CVs locomotive direction, speed-step mode, alternate power source, CV 29: Configuration Data 1 speed tables, and the decoder address. Configuring CV 29 This is the first CV that you’ll encounter which will need to be programmed by the bits. Refer to the “CV Programming Tutorial”...
  • Page 19 Basic Programming Table C. CV 29 Reference Address Type Speed Table Analog Mode Speed Steps Direction CV Value Primary “Short” (CV1) Normal Primary “Short” (CV1) Reversed Primary “Short” (CV1) 28/128 Normal Primary “Short” (CV1) 28/128 Reversed Primary “Short” (CV1) Normal Primary “Short”...

  • Page 20: Configuring Throttle And Braking

    Basic Programming Configuring Throttle and Braking Throttle and Braking Control CVs You can use throttle and braking control CVs to customize CV 2: Vstart the decoder’s throttle and braking settings to your operating CV 3: Baseline Acceleration Rate preferences. This section details setting acceleration and CV 4: Baseline Deceleration Rate deceleration rates, automatically calibrating Dynamic Digital CV 5: Vhigh...
  • Page 21 Basic Programming Calibrating DDE Load Compensation Blunami features a cutting-edge new version of our already revolutionary Dynamic Digital Exhaust! We highly recommend you automatically calibrate Dynamic Digital Exhaust settings before adjusting throttle and braking control CVs. This will create an amazingly accurate representation of prototypical operation.
  • Page 22 Basic Programming Set the Independent Brake Rate The independent brakes on prototype locomotives are applied separately from the rest of the train, generally during switching operations and to control slack between units. CV 117 determines the deceleration rate that will bring the locomotive to a stop when the independent brake function is turned on.
  • Page 23 Basic Programming Setting the 3-Point Speed Curve By default, track voltage is distributed to the decoder with no variation in a straight line and the decoder responds instantly to the throttle setting. You can designate the amount of voltage applied at the first, middle, and last speed step with CV 2 (Vstart), CV 5 (Vhigh), and CV 6 (Vmid) to compensate for track power or throttle control inefficiencies.
  • Page 24 Basic Programming Setting the Custom Speed Table Blunami offers a custom speed table with 28 Table D. 28-Point Speed Table Settings adjustable speed points. The 28-point custom Value % of Throttle speed table is disabled by default. However, you can enable it with CV 25 (Speed Table Enable) and CV 29 (Configuration Data 1), and then adjust each speed point with CVs 67-94 (Custom Speed Table).
  • Page 25 Basic Programming Setting Motor Trim CV 66 (Forward Motor Trim) and CV 95 (Reverse Motor Trim) are used to “trim” the forward and reverse drive voltages when the 28-point custom speed table is enabled. Setting motor trim can help compensate for speed differences between forward and reverse directions. For instance, if the throttle setting is the same in both directions and the locomotive appears to be moving faster in reverse, you can use CVs 66 and 95 to correct the speed difference.

  • Page 26: Configuring Lighting Outputs

    Basic Programming Lighting Output Control CVs Configuring Lighting Outputs CV 49: Headlight Configuration CV 50: Backup Light Configuration CV 51: FX3 Configuration Blunami provides up to eight lighting outputs (depending on CV 52: FX4 Configuration the board format). Lighting output control CVs allow you to CV 53: FX5 Configuration* enable Hyperlight effects, Grade-Crossing Logic, phase offset, CV 54: FX6 Configuration*...
  • Page 27 Basic Programming Double-Flash Strobe The xenon double-flash strobe effect emits two rapid flashes of light during each flash rate timing cycle. CV 59 is used to modify the flash rate timing cycle. Western-Cullen D312 Rotary Beacon The Western-Cullen D312 Rotary Beacon effect follows a revolving reflector and bulb assembly flash-pattern.
  • Page 28 Basic Programming Phase Offset Add a value of 32 to the value of flashing Hyperlight effects to set the corresponding lighting output to Phase B from Phase A. Flashing effects set to Phase B will flash opposite of flashing effects set to Phase A, i.e., Phase A turns off when Phase B turns on, and Phase A turns on when Phase B turns off.
  • Page 29 Basic Programming Adjusting Lighting Output Settings After configuring Hyperlight effects and features with CVs 49-56, adjust CV 57 (Forward Direction Enable), CV 58 (Reverse Direction Enable), CV 59 (Hyperlight Flash Rate), CV 61 (Brightness Register 1), CV 62 (Brightness Register 2), CV 63 (Dimmer Level), and CV 64 (Master Brightness Register) to customize lighting output direction, the Hyperlight flash rate, and brightness levels.
  • Page 30 Basic Programming Example: Alternating Ditch Lights This example details using CV 51 (FX3 Configuration) and CV 52 (FX4 Configuration) to enable alternating ditch lights for Grade-Crossing Logic. Follow the steps below to set ditch lights to the FX3 and FX4 lighting outputs and allow them to alternate during the crossing hold timer countdown after Grade-Crossing Logic is activated: 1.

  • Page 31: Configuring Sound Effects

    Basic Programming Configuring Sound Effects Sound control CVs allow you to fully customize the decoder’s sound effects to fit your preferences. All sound effects included in Blunami are recordings from actual locomotives and simulate the reality of operating an electric locomotive. Sound Control CVs This section shows you how to: CV 113: Quiet Mode Time-Out Period...
  • Page 32 Basic Programming Select the Bell Each decoder version has a selection of bells with pre-configured ring rates. Refer to the Blunami Electric Sound Selection Reference for your decoder to determine the range of values. For each bell, a range of up to 4 values is available. Within that range, higher values correspond to faster ring rates.
  • Page 33 Note: Be sure that your speaker is rated to match the audio amplifier of your decoder. Ratings for each format are available on the packaging and at www.soundtraxx.com. Failure to do so could cause severe damage to your speaker.
  • Page 34 Basic Programming Table H. Primary Mixer Volume Levels Sound Effect Default Value Airhorn Bell Contactor Camshaft Air Compressor Pantograph Blower Fans Generator Traction Motor Coupler Train Brake Apply/Release Independent Brake Apply Independent Brake Release Trolley Bell Stop Request Bell Poppet Valve Steam Generator Cab Doors Trolley Doors...
  • Page 35 Basic Programming Adjust Alternate Mixer Volume Levels Blunami includes an alternate volume mixer that can be selected in place of the primary volume mixer. This allows you to set two volume levels for each sound effect. This can be useful if you need quieter or louder volume settings for different operating situations, such as one group of settings for your home layout and another for your club layout.
  • Page 36 Basic Programming Table I. Alternate Mixer Volume Levels Sound Effect Default Value 2.289 Airhorn 2.290 Bell 2.291 Contactor Camshaft 2.292 Air Compressor 2.293 Pantograph 2.294 Blower Fans 2.295 Generator 2.296 Traction Motor 2.297 Coupler 2.298 Train Brake Apply/Release 2.299 Independent Brake Apply 2.300 Independent Brake Release 2.301...
  • Page 37 Basic Programming Configuring Automatic Sounds With corresponding automatic sound CVs, you Automatic Sound CVs can configure auto-effects for DCC and analog CV 193: Auto-Bell On Set Point mode operation. Auto-sound CVs can help CV 194: Auto-Bell On Time compensate for lack of function control in analog CV 195: Coach Door Count CV 196: Brake Sensitivity mode.
  • Page 38 Basic Programming Modifying Automatic Sound Effects Sound control CVs additionally allow you to modify automatic sound effects, such as the coach door slams that occur after the conductor’s “all aboard!” announcement, the release rate of the poppet valve, the clickety-clack rate, and the various Motorman Omura tasks that occur when the locomotive is stopped.
  • Page 39 Basic Programming slower scale speeds and reduce the clickety-clack frequency. Enter a value from 1 to 255 into CV 3.258 to adjust the scale speed from 0.01ft/s to 2ft/s. A value of 0 will disable the clickety-clack sound effects. You can also use the equation below to calculate scale speed: Scale Speed (ft/s) = (Speed Step ×...
  • Page 40 Basic Programming Sound Configuration Example The following example details using sound control CVs to customize electric sound effects to fit your operating preferences. Example: Modifying Electric Sound Effects This example shows you how to customize sound effects, such as the airhorn, bell, air compressor, coupler, coach door slams, and poppet valve, with the following sound control CVs: CV 114: Engine Exhaust Control CV 124: Air Compressor Select...
  • Page 41 Basic Programming 6. You can adjust the number of coach door slams that occur with the all aboard/coach doors function (F23 by default) with CV 195. Entering a value from 1 to 15 into CV 195 will set the coach door count from 1 to 15. To simulate eight coach doors, enter a value of 8 into CV 195.

  • Page 42: Advanced Programming

    Advanced Programming Advanced Programming Configuring Audio Control Audio Control CVs CVs 161-192: FX Bus Mixer CV 224: High-Pass Filter Cutoff Frequency Blunami features a high-pass filter and 7-band CV 225: Equalizer Control Register equalizer, allowing you to adjust frequency responses CV 226: 62Hz Cut/Boost according to your installation.
  • Page 43 Advanced Programming Setting EQ Frequency Levels CV 225 (Equalizer Control Register) is used primarily for setting the frequency levels of the equalizer to accommodate a range of speaker sizes. Enter a value from 1 to 4 into CV 225 to select preset cut/boost levels to match the diameter of your speaker diaphragm (smaller than 1”...
  • Page 44 Advanced Programming Table L. CV 225: EQ Control Register *Cut/boost values for CVs 226-232 shown in red 62Hz 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz CV Value Description CV 226 CV 227 CV 228 CV 229 CV 230 CV 231 CV 232 Flat Micro Speaker -12dB...
  • Page 45 Advanced Programming Setting Reverb The reverb effect allows you to add a bit of ‘presence’ to sound effects. CV 233 (Reverb Control Register) allows you to choose between preset reverb options for sound effects or select user- adjustable reverb. CV 234 (Reverb Output Level), CV 235 (Reverb Delay Time), and CV 236 (Reverb Feedback Gain Level) are used to set up reverb for the sound effects assigned to CVs 161-192 (Reverb Mixer).
  • Page 46 Advanced Programming CVs 161-192: Reverb Mixer Sound Effect Default Value Airhorn Bell Contactor Camshaft Air Compressor Pantograph Blower Fans Generator Traction Motor Coupler Train Brake Apply/Release Independent Brake Apply Independent Brake Release 173* Trolley Bell 174* Stop Request Bell Poppet Valve Steam Generator Cab Doors Trolley Doors...
  • Page 47 Advanced Programming Adjust Reverb Control CVs Setting up the reverb involves a bit of trial and error and is best done while the sounds are playing, using Operations Mode programming to make the adjustments. Start by setting CV 233 to 7 to enable the user-adjustable reverb. Next, set CVs 234-236 to a nominal value. We like to start with the settings of 64 for CV 234, 255 for CV 235, and 64 for CV 236.

  • Page 48: Configuring Dynamic Digital Exhaust

    Advanced Programming Configuring Dynamic Digital Exhaust Dynamic Digital Exhaust (DDE) is one of the DDE Control CVs most fun effects featured in Blunami. CV 2.503: DDE Load Offset CV 2.504: DDE Load Slope When the locomotive encounters a grade. DDE CV 2.507: DDE Traction Motor Low Volume Limit responds to this by elevating the volume of the CV 2.508: DDE Traction Motor High Volume Limit...
  • Page 49 Advanced Programming 6. Increase the throttle to an appropriate moderate speed for your layout (generally between speed-step 25 and speed-step 40). 7. When your locomotive is on level track, enter a value of 255 into CV 504 (DDE Load Slope) to automatically calibrate the nominal high-speed load level. Note: If, after the calibration is complete, you feel the need to increase or decrease the sensitivity, you can do this with CV 2.512.
  • Page 50 Advanced Programming CV 2.512 (DDE Load Sensitivity) is used to adjust the correlation between motor load and traction motor sound effects. As the motor is impeded during operation, the DDE processor and back-EMF circuitry will adjust the volume of traction motor sound effects according to the value of CV 2.512.

  • Page 51: Configuring Function Mapping

    Advanced Programming Configuring Function Mapping Function mapping CVs allow you to reassign any Function Mapping CVs effect to any function key, enable effects to CV 31: CV Index 1 respond automatically to direction and movement CV 32: CV Index 2 changes, map an effect to the emergency stop CVs 33-46: Function Status CVs CVs 1.257-1.385: Effect Map Registers...
  • Page 52 Advanced Programming Table M. CVs 1.257-1.384 Table N. Default Function Assignments Effect Map Registers F0-F28 Effect Value CV 1.257: Headlight F0(f) Headlight 1.257 CV 1.258: Backup Light F0(r) Backup Light 1.258 CV 1.259: FX3 Effect Bell 1.298 CV 1.260: FX4 Effect Airhorn 1.297 CV 1.261: FX5 Effect...
  • Page 53 Advanced Programming Enabling Automatic Effects To provide more versatility, Flex-Map function mapping CVs allow you to configure automatic effects that respond to direction and movement. Follow the steps below to enable automatic effects with CVs 1.385-1.512 (Effect Auxiliary Map Registers): 1.
  • Page 54 Advanced Programming Table P. CVs 1.385-1.512 Table Q. CVs 1.385-1.512 Defaults Effect Auxiliary Map Registers Value CV 1.385: Headlight CV 1.449: E-Brake App. CV 1.386: Backup Light CV 1.387: FX3 Effect CV 1.388: FX4 Effect CV 1.389: FX5 Effect CV 1.390: FX6 Effect CV 1.391: FX7 Effect CV 1.392: FX8 Effect CVs 1.393-1.400: Reserved...
  • Page 55 Advanced Programming Flex-Map Function Mapping Examples The following examples detail using CVs 1.257-1.512 for function mapping, enabling automatic effects, and mapping an effect to the emergency stop button. Before accessing CVs 257-512, ensure CV 31 is set to a value of 16, and enter a value of 1 into CV 32. Example: Mapping Electric Functions You may want to use CVs 1.257-1.384 to map the grade-crossing signal to F4 and stop request bell to F9.
  • Page 56 Advanced Programming NMRA Legacy Function Mapping CVs 33-46 (Function Status CVs) are function mapping CVs stated in the NMRA Standards for DCC Configuration Variables (S-9.2.2). CVs 35-46 are used to assign effects to function keys F1-F12, and CVs 33 and 34 are used to assign effects to the F0 function key. If the same effect is selected for both reverse and forward F0 functions, that effect will turn on when the F0 function key is turned on regardless of locomotive direction.

  • Page 57: Configuring Hyperdrive2

    Advanced Programming Configuring Hyperdrive2 Advanced Motor Control CVs CV 10: EMF Feedback Cutout Blunami features Hyperdrive2 advanced motor control, CV 119: Max Engine Recovery Speed providing high-frequency pulse-width modulation (PWM) for CV 209: PID Kp Parameter silent motor control and a back-electromotive force (back- CV 210: PID Ki Parameter EMF) sensor to improve low-speed operation and maintain CV 211: Low-Speed Compensation...
  • Page 58 Advanced Programming Control Loop Coefficients Blunami compensates for load changes in response to back-EMF voltage readings that compare motor load to locomotive speed. When a variation between them occurs, a proportional-integral (PI) control loop adjusts the motor voltage to compensate for the difference so that the locomotive’s speed remains consistent.
  • Page 59 CV 215 may be programmed with any value from 60 to 255 to set the back-EMF reference Voltage from 6 to 25.5 volts. If you are planning to consist the model with other models equipped with SoundTraxx decoders (such as Tsunami or MC1 and MC2 DCC Mobile Decoders), make sure that the value entered in CV 215 is equal to the observed voltage of the track output from your command station, so that the reference voltage is identical to your other decoders.
  • Page 60 Advanced Programming Example: Motor Speed Step Deadband and Automatic Whistle Signals Refer to the following example to configure automatic forward-driving and reverse-driving whistle signals using CV 216: 1. To enable automatic forward-driving whistle signals, set CV 1.407 (Forward Whistle Signal Auxiliary Map Register) to a value of 1.

  • Page 61: Configuring Advanced Consist Operation

    Advanced Programming Configuring Advanced Consist Operation Advanced Consist CVs A consist is made up of several units that are coupled CV 19: Consist Address together to operate as a complete train. In model railroading, CV 21: Consist Function Enable 1 “Advanced Consisting”...
  • Page 62 Advanced Programming Consist Function Enable 1-4 The following procedure details enabling effects mapped to F0(f), F0(r), and F1-F28 for advanced consist operation: 1. Circle the CV values associated with your preferred F0-F28 function keys. 2. For each CV, add the values together and record the sum in the space provided. You should have four total CV values for enabling your preferred function keys when finished.
  • Page 63 Advanced Programming Setting Consist Momentum Rates CVs 23 (Consist Acceleration Rate) and 24 (Consist Deceleration Rate) are used to set the acceleration and deceleration rates for consists when a valid consist address is active. Like CVs 3 (Baseline Acceleration Rate) and 4 (Baseline Deceleration Rate), CVs 23 and 24 are used to determine the time it will take the consist to accelerate to full speed from a stop and come to a stop from full speed.

  • Page 64: Miscellaneous Features

    Miscellaneous Features Miscellaneous Features Configuring Analog Mode Operation Analog Mode CVs Although Blunami is designed to be operated with a CV 12: Alternate Power Source DCC system, you can still use it with a conventional CV 13: Analog Mode Function Enable 1 powerpack on a DC layout.
  • Page 65 Miscellaneous Features Analog Mode Function Enable 1-4 The following procedure details enabling effects mapped to F0(f), F0(r), and F1-F28 for analog mode operation: 1. Circle the CV values associated with your preferred effects mapped to function keys F0-F28. 2. For each CV, add the values together and record the sum in the space provided. You should have four total CV values for enabling your preferred function keys when finished.
  • Page 66 Miscellaneous Features Enabling Analog Mode Automatic Effects To provide more versatility, CV 243 (Analog Mode Function Enable 5) can be used in conjunction with Flex-Map function mapping CVs to allow automatic effect configuration for analog mode operation. Automatic effects will respond to direction and movement when enabled.

  • Page 67: Operating With A Currentkeeper

    If your model has limited electrical pick-up or you desire to add more energy storage to the installation, a SoundTraxx CurrentKeeper can be used with any Blunami decoder to provide added reliability. Refer to the Blunami Installation Guide for more information about how to connect a CurrentKeeper to the various styles of decoders.

  • Page 68: Troubleshooting

    Troubleshooting Troubleshooting Sorting Out Decoder Difficulties If you have any difficulties operating your Blunami Digital Sound Decoder, refer to this section first before doing anything else. We find that most problems are caused by errant CV values and can be easily corrected. We suggest you perform your diagnostics with the decoder on the programming track.
  • Page 69 Troubleshooting The locomotive is sitting and both headlights are flashing Refer to the following section, “Error Codes.” • Sound works for a while, and then stops working • The amplifier is overheating. Lower the volume and verify that properly rated speakers are installed.
  • Page 70 Error 5: EEROM Checksum Failure Error 6: EEROM Data Integrity Failure If you’re still having difficulties, please contact our customer service department: SoundTraxx Customer Support Department 141 Burnett Drive Durango, CO 81301, USA Phone: (970) 259-0690 Email: support@soundtraxx.com...

  • Page 71: Appendix A: Decimal-Hex-Binary Conversions

    Appendix A: Decimal-Hex-Binary Conversions Appendix A: Decimal-Hex-Binary Conversions Blunami Electric User’s Guide...

  • Page 72: Appendix B: Elecric Cv Reference

    Appendix B: Blunami Electric CV Reference Appendix B: Elecric CV Reference Primary CVs Sound Control CVs CV 1: Primary Address CV 113: Quiet Mode Time-Out Period CV 2: Vstart CV 114: Engine Exhaust Control CV 3: Baseline Acceleration Rate CV 117: Independent Brake Rate CV 4: Baseline Deceleration Rate CV 118: Train Brake Rate CV 5: Vhigh...

  • Page 73: Appendix C: License Agreement

    SoundTraxx provides the computer software/firmware embedded within the Blunami Digital Sound Decoder and any modifications, updates, revisions or enhancements received by you from SoundTraxx or its dealers and licenses its use within the terms set below: A. You are granted a nonexclusive, nontransferable license to use the software/firmware included with your Blunami sound system only with the Blunami sound system hardware that you purchased.

  • Page 74: Appendix D: Service And Warranty Policy

    SoundTraxx will cover the repair under the conditions of our Safety-Net Service Warranty. If you damage the Digital Sound Decoder or it fails to operate within the first ninety (90) days, SoundTraxx will repair or replace the product free-of- charge under the following conditions: A.

  • Page 75: Appendix E: Declaration Of Conformity

    Appendix E: Declaration of Conformity Appendix E: Declaration of Conformity Declaration of Conformity We, Throttle Up! Corp., dba SoundTraxx, 141 Burnett Drive, Durango, Colorado USA, declare in sole responsibility that the following products: Product Description Blunami Digital Sound Decoder Model Numbers...
