PRECAUTIONS
‰ Shut off all power going to header before attempting any wiring procedures.
‰ Maintain a clean and safe environment when working in public areas.
‰ Constantly be aware of pedestrian traffic around the door area.
Always stop pedestrian traffic through the doorway when performing tests that may result in unexpected reactions
‰
by the door.
‰ ESD (electrostatic discharge): Circuit boards are vulnerable to damage by electrostatic discharge. Before handling any
board, ensure you dissipate your body's ESD charge.
‰ Always check placement of all wiring before powering up to ensure that moving door parts will not catch any wires
and cause damage to equipment.
‰ Ensure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation.
‰ DO NOT attempt any internal repair of the components. All repairs and/or component replacements must be
performed by BEA, Inc. Unauthorized disassembly or repair:
FCC
FCC APPROVAL
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
*this device may not cause harmful interference, and
*this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
*Reorient or relocate the receiving antenna
*Increase the separation between the equipment and receiver
*Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
*Consult the dealer or an experienced radion/TV technician for help
WARNING: CHANGES OR MODIFICATIONS TO THIS EQUIPMENT NOT EXPRESSLY APPROVED BY BEA INC. MAY VOID THE FCC
AUTHORIZATION TO OPERATE THIS EQUIPMENT.
PREINSTALLATION CHECK
9 When wiring multiple devices together to create a system configuration, it is best to ensure that each
device works independently. This will reduce troubleshooting if a discrepancy occurs.
9 Prior to installing any equipment in either new or existing circuits, verify correct line voltage and line
stability. Always remember to shut off the power before performing circuit wiring.
1
INSTALLATION
Gang Box
(metal/plastic)
Depending on the door installation, the weather-resistant
foam gasket or plastic adapter ring may be used. The
weather resistant gasket is used as a protective barrier
against the elements. The plastic adapter ring is designed
to enable the double-gang face plate to attach to various
plastic and metal gang boxes.
Page 2 of 4
1. May jeopardize personal safety and may expose one to the risk of electrical shock.
2. May adversely affect the safe and reliable performance of the product resulting in a voided warranty.
MS08
Assembly
The Touchless Actuator may be mounted in
conventional metal or plastic electrical gang boxes.
Ensure that the unit sensor does not come in contact
with the metal gang box to avoid shorting out the
unit.
Do not place the sensor in the door's opening range,
where the sensor may see door movement.
Do not place moving objects in front of the sensor.
Gang Box
(metal/plastic)
Adapter Ring
Foam Gasket
MS08
Assembly
75.5265.05 MS08 20180913
