Summary of Contents for Synergy Global Technology MIL1U17-03
- Page 2 LCD Drawer User Manual MIL1U17-03 w/ Trackball - 1 -...
- Page 3 This manual, covering various aspects of the equipment such as installation, setup and cascade, will help you make full use of this LCD KVM Drawer. Please read this manual carefully and install and operate the equipment according to the manual to avoid damage to this product its accessories.
-
Page 4: Table Of Contents
Table of Contents Introduction …………………………………………………………………………-4- 1.1Overview…………………………………………………………………...…. -4- 1.2 Functions & Features…………………………………… ……………...…..-4- 1.3 Hardware Requirement……………………………………………..….……-4- 1.3.1 Host Requirement………………………………………………..… -4- 1.3.2 Cables…………………………………………………………...….… -4- 1.4 Product Specifications………………………………………………..….…..-5- 1.5 LCD Specifications………………………………………………….…..……-5- 1.6 Front View………………………………………………………….…..……. -6- 1.7 Rear View……………………………………………………………..….…...-7- Installation……………………………………………………………………...……-8- 2.1 Rack Installation……………………………………………………………… -8- 2.2 Standard Installation……………….………………………………….……... -
Page 5: Introduction
1 Introduction 1.1 Overview The model integrates keyboard, LCD display and trackball mouse in a drawer type worktable and provides a convenient space-saving operation mode for KVM switch technology. The cover is an LCD display, while the base is keyboard and trackball. The model is a control device integrating 17.3”... -
Page 6: Product Specifications
1.4 Product Specifications 17.3"-Military-Grade-LCD-console Model 300cd/m2 Brightness 700:1 Contrast Angle of visibility 178°(H),178°(V) 262K Color display IP65 silicone keyboard Keyboard Trackball mouse Mouse Local Control Keyboard/Mouse USB 2.0 Terminal 24 pin DVI-D female connector DVI-D HD-15 female connector USB 2.0 For USB peripheral device Video resolution 1920 x 1200 @75Hz... -
Page 7: Front View
Front View Part Function Description Handle to adjust screen opsition LCD display IP65-silicone-keyboard Trackball LCD button to control Screen Display position and LCD OSD button image setting. Mounting bracket Install into rack cabinet Lock button Auto lock / release when lcd pull up and down USB2.0 HUB port for USB peripheral device Thumbscrews for locking the LCD in closed position - 6 -... -
Page 8: Rear View
Rear View Component Function Description 100-240V AC 50/60Hz via 4 pins lock connector AC Power port Power Switch Rock switch, turn on/off equipment main power. Connect to server or KVM. VGA port Connect to server or KVM. USB port DVI port Connect to server or KVM. -
Page 9: Installation
2 Installation 2.1 Rack Installation Step 1 Attach the two rear slide rails to the rear vertical mounting rails of the rack cabinet using standard M6 cage nuts and screws ( 3 ) (4pcs). Back VIEW Step 2 Attach the two front slide rails to the front vertical mounting rails of the rack cabinet using standard M6 cage nuts and screws ( 3 ) -
Page 10: Standard Installation
2.2 Standard Installation Please follow the installation drawing and instructions below for standard installation: * Please Shutdown the Power of Equipment Needs to be Connected * Please Pay Attention to Earthing of Equipment The standard installation is completed, and LCD KVM console can be powered on. Then power on connected hosts. -
Page 11: Lcd Kvm Console And Kvm Cascade Installation
2.3 LCD KVM Console and KVM Cascade Installation LCD KVM console port can be directly connector to another KVM Switch as cascade to Perform unified management all connected hosts. Please follow the installation drawing and instructions for standard installation: (1) Make sure to power off all equipment to be connected and existing equipment. (2) Switching slide switch on USB position (3) Use an USB / VGA cable to connected the LCD and KVM switch console port. -
Page 12: Lcd Osd Menu Setup
2.4 LCD OSD Menu Setup OSD Control buttons LCD OSD can establish and setup LCD display. Setup instructions of four buttons are as follows: Button Functions POWER Turn on or off the LCD Display Activate OSD menu, select a menu and press MENU key to confirm the MENU selection and enter the submenu. -
Page 13: Certificates
The company reserves the right to modify product speciÞ cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2022 Synergy Global Technology Inc. All rights reserved. - 12 - www.RackmountMart.com...
