- Page 2 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com...
-
Page 3: Table Of Contents
3.2.1 Connecting to a Wi-Fi network........15 5.2.1 How do I get a SIP account?........28 3.2.2 Connecting to a wired network........16 5.3 Other theoretical definitions......29 3.2.3 Connecting to a 4G/5G network.........16 5.4 TECHNICAL SPECIFICATIONS......30 3.3 SIP CALLS............16 www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting... - Page 4 About this manual review, May 2023 review, May 2023 Solidyne® All rights reserved. No part of this manual may be re- produced, copied or transmitted in any form or by any means, electronic or mechanical: either in whole or in part.
-
Page 5: Features
MX2200 has two stereo LINE inputs: an analog line input (TRS) and the USB port for direct audio trans- Solidyne MX-2200 is a portable mixer-console and fer from a computer. IP audio CODEC for live remotes. It’s an all in one... -
Page 6: General Working Diagram
Studio takes the call (or vice versa). An Internet server (CLOUD SERVICE) con- nects both ends (1 and 2) and when the MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 7: Audio Operation
(USB or analog) to generate the program signal. The level should Pressing and holding for 1 second cancels any be maintained around 0 VU (-10 dBFS). changes made to an option or value. www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting... -
Page 8: Main Channels
MIC 3+4. The microphone gains are automatic, varying de- 3. SETUP pending on the position of the fader. This auto- matic adjustment simplifies operation, maintaining an optimal signal-to-noise ratio and preventing preamplifiers from saturating. MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 9: Dynamic Compressor
To cue the signal (POTS) and one mobile phone, linked via Blue- USB/LINE IN (with fader closed) press the button tooth. Both can be used as: CUE located over the fader. www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting... -
Page 10: Using The Phone Lines For "On-Air" Calls
TALK mic is not sent to the Studio. line, using the built-in microphone. • To avoid any inadvertent broadcasting of the talk-back microphone while utilizing the phone line as a studio link, it is crucial P 10 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 11: Using A Bluetooth Cell Phone
(ID) of 1. Turn on Bluetooth on MX2200 by pressing the MX-2200, and this procedure only needs to be BTL until the LED lights up (approx 5 secs). performed once for the same mobile phone. -
Page 12: Volume Adjustment
CUE/ abled on the phone. Re-connection is auto- PGM button to the CUE position (button re- matic in some cases, while in others, the user P 12 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 13: Generate The Call On The Mobile
BLT button on the console (it can also be will be heard in the headphones, and the vol- ended from the mobile). ume of the tone can be regulated with the www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting P 13... -
Page 14: Recordings
The recording date is displayed in the local time 100 hours of audio. of the computer on which it is being viewed. The audio files can be downloaded from the right-clic menu (to the browsers default folder). P 14 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 15: Link With The Studios
The ways to connect MX2200 to the Internet are main at zero. In this case, the procedure the following: should be repeated from Step 4. Remember: to cancel and exit any screen, press and hold for 1 second. www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting P 15... -
Page 16: Connecting To A Wired Network
At the Studios, an operator receives the call on a computer. From the Studios, the op- erator can also call the MX2200. Technical details for this process are available in Section 4 of this user manual." P 16 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 17: Making A Sip Call
To establish the RTP connection (once the net- work has been configured and the IP accesses have been obtained) proceed as follow. www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting P 17... -
Page 18: Return From The Studio On The Console
2. Press to navigate the options. Select HTTP PCM16@44.1Khz or one of the MP3 modes. STREAM and press. These formats allow for direct playback in VLC Player. However, if the OPUS CODEC is used, a P 18 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 19: Reception Of Mx2200 In The Studios
LINES” in the operation section. tional telephone hybrids. In the Studios the call is received using conven- All of the Solidyne line of consoles have the ability tional telephone hybrids. to connect to standard telephone lines and Blue- tooth interfaces to link mobile phones. - Page 20 P 20 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com...
-
Page 21: Setup And Connections
4 Setup and connections 4 Setup and connections 4.1 GENERAL DIAGRAM 4.2 REAR PANEL Ilustración 7: Vista trasera de MX-2200 4.2.1 POWER SUPPLY The unit can also be powered by connecting an ex- ternal 12 VDC battery to DC IN. Take special care The unit includes the switching power source. -
Page 22: Microphones
3. The person who answers the call should re- monitor speakers, and when an air light is plugged main silent, or activate the MUTE function if available. in, it is detected by the console. Whenever the air P 22 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 23: Stereo Auxiliary Input
The options related to the Internet links can be ac- to the PGM output and re-enter the processed sig- cessed in the following ways: nal to the MX-2200 via the "Stream-In" jack, so that the processed audio can be streamed. 1. From the onboard screen, using the rotary command or encoder. -
Page 24: Setup → Wi-Fi
DEM dongles (subject to compatibility). ized technical personnel. Modern dongles act as an Ethernet adapter and its operation is plug & play: after a few seconds of P 24 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 25: Setup Sip Account
SIP CONTACTS changes to the MX2200 hardware. To edit a SIP contact: 1. Select the contact you want to modify Displays the SIP contact book stored in MX2200. from the list. www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting P 25... -
Page 26: Setup Power Info
→ 4.3.10 SETUP TIME ZONE The time zone setting is required for proper nam- ing during recording. It is normally set only once. Time synchronization is done through public NTP servers. P 26 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 27: Technical Notes
When one of the parties decides to terminate the com- munication, a 'BYE' message is sent, and the other party sip:studioRadio@sipserver.com. responds with an 'OK' to confirm and end the communi- cation." www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting P 27... -
Page 28: How Do I Get A Sip Account
When you get a SIP account the provider will give you the following connection details: P 28 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com... -
Page 29: Other Theoretical Definitions
Interactive Connectivity Establishment (ICE): A Protocol for The gateway (GATEWAY) between the external Internet and Network Address Translator (NAT) Traversal the LAN is carried out by a device called a router, which is as- https://datatracker.ietf.org/doc/html/rfc8445 www.SOLIDYNEPRO.com MX-2200 audio mixer-codec for remote broadcasting P 29... -
Page 30: Technical Specifications
DIMENSIONS AND WEIGHT 12 V / 120ma LED Tally Light Wide= 274 mm // Deep= 270 mm Front high= 25 mm // Rear High: = 71 mm Weight = 1,9 Kg P 30 MX-2200 audio mixer-codec for remote broadcasting www.SOLIDYNEPRO.com...
