- Page 1 RANGE HOOD USER'S MANUAL PEC 5406W PEC 6406W PEC 5507IX PEC 6507IX...
- Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user's manual.
-
Page 3: Table Of Contents
CONTENTS PART 1: IMPORTANT SAFETY INSTRUCTIONS ....................2 PART 2: DESCRIPTION OF THE APPLIANCE ....................4 PART 3: INSTALLATION ............................ 5 Unpacking ........................................5 Dimensions of the appliance ................................5 Supplied accessories ....................................7 Placement ........................................8 Installation .........................................8 Carbon fi lter......................................11 Ventilation ....................................... 12 PART 4: OPERATION ............................ -
Page 4: Part 1: Important Safety Instructions
PART 1: IMPORTANT SAFETY INSTRUCTIONS Recommendation: Carefully read these instructions before installing and operating this range hood. Write down the serial number found on the rating label of the range hood in the space below. It is essential that you store this user's manual in a safe place so that you can use it in the future. If you intend to sell the appliance, give it to another owner, or if you move, always make sure that the user's manual is attached to the appliance, so that the new owner can also learn about the operation of the appliance and the relevant warnings. - Page 5 If a chimney is connected to the exhaust of the range hood, use pipes with a diameter of 150 or 120 mm. The pipe connection should be as short as possible. Keep packaging materials out of children's reach. They could suff er injury or suff ocation. ...
-
Page 6: Part 2: Description Of The Appliance
PART 2: DESCRIPTION OF THE APPLIANCE Control panel Filter Lighting EN - 4 Copyright © 2012, Fast ČR, a. s. 04/2012... -
Page 7: Part 3: Installation
PART 3: INSTALLATION Unpacking After unpacking remove all packaging and advertising labels from the appliance. Check that the appliance has not been damaged and that the package includes all the items described in this user's manual. If the appliance was damaged during transport, contact authorised service centre. ... - Page 8 IMPORTANT: Before installing or using the appliance, please fi rst read all instructions and check that the voltage and frequency values on the rating label correspond to the voltage and frequency in your electricity grid. We recommend that the appliance be connected by a service technician or another qualifi ed person in compliance with local codes and regulations.
-
Page 9: Supplied Accessories
Supplied accessories (depending on the model) Short fl ap Use if the range hood will be used without an exhaust duct (it is necessary to purchase a carbon fi lter). Long fl ap Use if the range hood will be used with an exhaust duct. This accessory is not attached to the range hood. Exhaust plug It serves to block the air outfl ow opening when the range hood is used without an exhaust duct. -
Page 10: Placement
Placement Install the range hood at a height of at least 65 cm above an electric cooktop or at a height of 75 cm above a gas cooktop. Installation Suspended under a cabinet Drill 4 holes under the cabinet to which you wish to mount the range hood according to the distances on the installation diagram. - Page 11 Wall-mounted Drill 2 holes into a wall using a bit with a diameter of 6 mm at a distance of points E, F (see part "Dimensions of the Appliance"). Insert 2 dowels (included) into the drilled holes. Insert the hooks into the dowels. Ensure that they are properly and fi rmly inserted into the dowels. Now hang the range hood on the hooks.
- Page 12 Place the exhaust fl ange on to the range hood. Attach one end of the aluminium fl ue pipe to the range hood fl ange and the other end to the air outlet. Check that both ends are fi rmly attached and secured in place. Bends and deviations in the aluminium fl ue pipe reduce the exhaust performance, so it is essential that the pipe is bent as little as possible.
-
Page 13: Carbon Fi Lter
Carbon fi lter If you are using the range hood without an air exhaust, it is necessary to use a carbon fi lter. The carbon fi lter is not included. Contact your vendor or an authorised service centre to purchase this fi lter. ... -
Page 14: Ventilation
Ventilation To ensure proper ventilation, leave windows closed while the appliance is turned on. WARNING! Pay increased attention if you are using the appliance together with another appliance that uses air or fuel for its operation (e.g. heating fan, fan, etc.) or that uses gas, coal or wood, as its operation may negatively aff ect the performance of the range hood because it expels air out of the room. -
Page 15: Part 4: Operation
PART 4: OPERATION Remove the protective foil from the control panel. Exhaust power selection This range hood is equipped with 3 levels of exhaust power. Select the power level based on the use of the stove and the amount steam that the pots emit. Press the respective button on the control panel. -
Page 16: Part 5: Maintenance And Cleaning
PART 5: MAINTENANCE AND CLEANING WARNING! Before cleaning, regular or other maintenance, installation or removal, check that the appliance is turned off and disconnected from the power socket or that the respective circuit breaker is turned off . Changing a light bulb ... -
Page 17: Part 6: Before You Call The Service Centre
PART 6: BEFORE YOU CALL THE SERVICE CENTRE If the appliance is not working as it should check the following recommendations for resolving the most common problems. If the problem persists or it is not included in the table below, turn off the appliance and disconnect it from the power socket and contact an authorised service centre. -
Page 18: Part 7: Technical Specifications
PART 7: TECHNICAL SPECIFICATIONS NOTE: All the here mentioned data is subject to change. EN - 16 Copyright © 2012, Fast ČR, a. s. 04/2012... - Page 19 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
