- Page 1 SCAN COMBIFLEX 450 / 450NS MANUAL V2023-06...
- Page 2 Scanmaskin Sweden AB Box 187 SE-437 22 Lindome / Gothenburg Sweden Telephone: +46 (0) 31 99 49 70 www.scanmaskin.com scanmaskin.com...
- Page 3 Scanmaskin Sweden AB Per-Anders Bardh IMPORTANT INFORMATION! This User Guide only concerns the floor grinding machines “Scan Combiflex 450” and “Scan Combiflex 450NS” hereby referred to as “SC-450”. For information that only concerns Scan Combiflex 450NS, that machine is called “SC-450NS”. SC-450 may only be used for grinding horizontal surfaces approved by Scanmaskin Sweden AB.
-
Page 4: Table Of Contents
4.14. Grinding ........4.15. Changing tools ......scanmaskin.com... - Page 5 8. EC DECLARATION ........32 CONTACT INFORMATION ......33 scanmaskin.com...
-
Page 6: Specifications
2,2kW motor / NS model. Maximum current for the fuses used in the power source (i.e. the distribution box). This is the standard inlet used. Machines sold outside of EU will be shipped either with a local standard inlet or an adapter. scanmaskin.com... -
Page 7: Tools
Scan Combiflex 450 / Scan Combiflex 450NS Dimensions of SC-450 Width 460 mm 18.1” Height 1030 mm 40,6” Depth 850 mm 31,9” Dimensions of shipping box Width 610 mm 24,0” Height 1430 mm 56,3” Depth 810 mm 31,9” Ambient temperature during operation: -20 °C to +40 °C... -
Page 8: Range Of Application
Machines sold outside of Europe will be either equipped with a local standard connector for the power inlet or the mating connector will be included and fitted at the main power inlet. Read ”2.6 Electrical safety” before connecting any included connectors. scanmaskin.com... -
Page 9: Overview
Scan Combiflex 450 / Scan Combiflex 450NS 1.6. OVERVIEW Figure 1.4 SC-450 overview Figure 1.5 SC-450NS overview Item Description Reference Item Description Reference Control device 4.3 Control device Electrical cabinet Handle Power inlet Dust collector Dust collector hose holder connection... -
Page 10: Safety Regulations
Don’t use the machine if there are any foreign objects stuck into the surface. Such objects must be removed prior to operation of machine. Read ”2.3 Organizational measures” and ”2.5 Safety regarding operation of machine” thoroughly before operation! scanmaskin.com... -
Page 11: Organizational Measures
Scan Combiflex 450 / Scan Combiflex 450NS 2.3. ORGANIZATIONAL MEASURES The user guide is to be kept near the location where the machine is being operated and must be within reach at all times. • In addition to this user guide general and legal regulations regarding accident prevention and environmental protection must be complied with as per local regulations. -
Page 12: Personnel Selection And Qualification
• To perform maintenance work correctly it is imperative to be equipped with the proper tools for the task in question. • Repairs may only be made by Scanmaskin Sweden AB certified service technicians. • Some grinding work may generate sparks under certain circumstances. -
Page 13: Safety Regarding Operation Of Machine
Scan Combiflex 450 / Scan Combiflex 450NS 2.5. SAFETY REGARDING OPERATION OF MACHINE Do not allow any method of working that impairs safety! • Recognized official procedures must be used to ensure the machine is operated in safe and best conditions. -
Page 14: Electrical Safety
• Only start work after you are familiar with the electrical engineering regulations that apply to the local area. • Only use voltage seekers that comply with the regulations when troubleshooting. From time-to-time check voltage seekers to ensure that they are operationally efficient. scanmaskin.com... -
Page 15: Definition Of The "Safety Off Position
Scan Combiflex 450 / Scan Combiflex 450NS 2.6.1. Cables Only use cables that are marked and rated according to the specifications in “1.1 Electrical specifications”. Don’t use excessive length of the cables. If a very long cable is needed, we recommend that you use a cable rated for more current and connect it to a distribution central near the machine. -
Page 16: Safety Regarding Maintenance
These activities may only be undertaken by qualified personnel. The machine must not be connected to any power source while cleaning. See ”5.5 Cleaning the machine” for further information. scanmaskin.com... -
Page 17: Safety Regarding Transport
Scan Combiflex 450 / Scan Combiflex 450NS 2.9. SAFETY REGARDING TRANSPORT Always remove the tools before transport. The tools may fall of or damage the surface the machine is transported along. 2.9.1. Manual transport When transporting the machine manually be observant about ramps and/or edges. -
Page 18: Transportation
On each side of the grinding head / motor assembly there is two pins, each fastened by a locking clip. To separate the machine, disconnect the motor cable; remove the locking clips and the pins. Take extra care to prevent the frame from falling backwards. scanmaskin.com... -
Page 19: Inside Vehicles
Scan Combiflex 450 / Scan Combiflex 450NS 3.5. INSIDE VEHICLES • Detach the tools according to the instruction in ”4.15 Changing tools”. • Secure the machine inside the vehicle. Secure the machine according to local transport safety regulations before transporting the machine inside a vehicle. -
Page 20: Machine Functions
Wait at least 15 minutes before operating the machine again if this occurs. 4.3. CONTROL DEVICE SC-450 1. Stop 2. Start Figure 4.2 SC-450 control device. Item Function Description Stop Stops the SC-450 Start Starts the SC-450 Table 4.1 Description of control device. scanmaskin.com... -
Page 21: Start Up
Scan Combiflex 450 / Scan Combiflex 450NS 4.4. START UP SC-450 Se ”4.1 Precautions” before starting the machine. How to start the machine: 1. Make sure that the machine is equipped with the right “Scan on” tools. 2. Make sure that the main power and hoses for the dust collector are connected to the machine. -
Page 22: Control Device
To empty the water tank before lying down transport, increase the water flow to a maximum and let the water pour out. Make sure the tank is empty before lying down transport. Empty the tank before long time storage. See The range of the speed selection knob is described in ”1.2 Mechanical specifications” . scanmaskin.com... -
Page 23: Start Up The Sc-450Ns
See ”4.1 Precautions” before starting the machine. How to start the machine: 1. Make sure that the machine is equipped with the correct tools from Scanmaskin. 2. Make sure that the power plug and hoses for dust collector and water (if water supply is used) are connected to the machine. -
Page 24: Grinding Speed Sc-450Ns
3. The segment is now fit on the Scan-On plate. To make sure that the tool is secured, use a small plastic hammer and slightly hit the tool outwards. In reverse this technique can be used to loosen tools that are stuck. scanmaskin.com... -
Page 25: Maintenance
Scan Combiflex 450 / Scan Combiflex 450NS MAINTENANCE 5.1. PRECAUTIONS Set the machine into the Safety off position before beginning any work on the machine. See ”2.7 Definitions of the ”Safety off positions””. Read ”2.6 Electrical safety” before beginning any maintenance work. -
Page 26: Maintenance And Inspection List
• The grinding speed • Lower the speed is to high The machine vibrates a lot • The tools are damaged • Inspect the tools • Change the tools if needed Table 01 Common faults See access table ”Table 04” scanmaskin.com... - Page 27 Scan Combiflex 450 / Scan Combiflex 450NS 5.5.2. Alarm- and fault codes SC-450NS Alarm codes starts with “A” and fault codes starts with “F”. The machine will be operational if an alarm code is present but not when an fault code is present.
- Page 28 • One of the three phases is missing Table 02 Alarm- and fault codes SC-450NS. The following table describes the access for the task. Abbreviation Person Machine Operator Electrician Scanmaskin certified service technician Table 04 Access rights for different persons scanmaskin.com...
-
Page 29: Spare Parts
Scan Combiflex 450 / Scan Combiflex 450NS SPARE PARTS See details in Scanmaskin service manual, scan the QR code or go to the following link: https://drive.google.com/file/d/1foH7q4tmIL6VCrDjTeEk0Bgy0Dtiaxf9/view?usp=drive_link scanmaskin.com... -
Page 30: Warranty
If the product does not function satisfactorily during this period, Scanmaskin will return the product to full working order for normal use which the product is intended for – with no charge for labor or spare parts, according to the following conditions: 1. - Page 31 7. All warranty repairs must be carried out by Scanmaskin or by a Scanmaskin accredited repair workshop. Costs for repairs, carried out by an unauthorised workshop, will not be reimbursed by Scanmaskin.
-
Page 32: Ec Declaration
Manufacturer Scanmaskin Sweden AB Address Heljesvägen 10 427 36 Lindome / Gothenburg Sweden Product Grinding machine Product name Scan Combiflex 450 Scan Combiflex 450NS Serial number _______________ The product conforms with the following directives: Machine directives 2006/42/EC 2014/30/EU 2014/35/EU Harmonized standards EN ISO 12100:2010 EN ISO 60204–1... -
Page 33: Contact Information
Scan Combiflex 450 / Scan Combiflex 450NS CONTACT INFORMATION Sweden (Head Office) Heljesvägen 10 Box 187 SE-437 22 Lindome Phone: +46 (0) 31 99 49 70 E-mail: info@scanmaskin.se Website: www.scanmaskin.se Denmark Torvegade 22 DK-7330 Brande Phone: +45 97 18 00 58 Fax: +45 97 18 45 58 E-mail: info@scanmineral.dk... - Page 34 NOTES scanmaskin.com...
- Page 35 Scan Combiflex 450 / Scan Combiflex 450NS scanmaskin.com...
- Page 36 SCANMASKIN SWEDEN AB Huvudkontor / Head office Box 187 SE-437 22 Lindome Phone: +46 (0)31- 99 49 70 Email: info@scanmaskin.com Besöksadress / Visiting address Heljesvägen 10 SE-437 36 Lindome www.scanmaskin.com...
