Page 3: Table Of Contents
Weekly checks 7 Checking fluids and tyre pressures. Engine specs, fluid specs, transmission specs, dimensions, identification plates. After sales 9 Warranty, Ro B: dside Assistance, Holden Dealers, Customer Assistance. Towing 10 Loading information, towing, towing precautions. Cleaning 11 Interior cleaning, exterior cleaning, list of cleaning materials.
Page 4 We thank you for choosing Holden and want to assure you of our continuing interest in your motoring pleasure and satisfaction and compliment you on your choice. This handbook applies to the current Zafira model. Due to different options, you may find reference in this Handbook to some equipment not installed in your own car.
Page 5 Please fill in the form below if you have changed your name, address, bought the car second-hand, or have become the new driver. Holden requires these details in order to contact the operator in the event of a safety recall and to keep the initial year Roadside Assistance details up to date (refer Chapter 9).
Page 6 Place in an envelope and mail to: The Manager - Warranty Administration Service Department Holden Limited Box 5480, G.P.O. Melbourne Victoria, 3001...
Page 7 Please fill in the form below if you have changed your name, address, bought the car second-hand, or have become the new driver. Holden requires these details in order to contact the operator in the event of a safety recall and to keep the initial year Roadside Assistance details up to date (refer Chapter 9).
Page 8 Place in an envelope and mail to: The Manager Warranty Administration Service Department Holden Limited Box 5480, G.P.O. Melbourne Victoria, 3001...
Page 9 Please fill in the form below if you have changed your name, address, bought the car second-hand, or have become the new driver. Holden requires these details in order to contactthe operator in the event of a safety recall and to keep the initial year Roadside Assistance details up to date (refer Chapter 9).
Page 10 Place in an envelope and mail to: The Manager - Warranty Administration Service Department Holden Limited Box 5480, G.P.O. Melbourne Victoria, 3001...
Page 11 The following page illustrates the dash board, identifying the gauges, warn ing l i g h ts , c o ntrols a n d switches. Page reference numbers are listed next to each item. Horn ···· Gauges Bonnet release Ignition switch Cruise control...
Page 12 Chapter 1 DASHBOARD LAYOUT Page Page Storage compartment with 1-12 Side vents 6-25 fuse panel behind 6-16 Front passenger air bag 1-20 Bonnet release 1-12 Centre vents 1-21 Ignition lock 1-10 Hazard flasher switch Tilt/telescopic steering 1-11 Radio Cigarette lighter 1-17 1-18 Info display...
Page 13 Chapter 1 DASHBOARD TILT STEERING AND HORN Tilt/reach steering The lock lever is located directly beneath the ignition lock. Move the lock lever downwards. Grasp the steering wheel and move as required. It can be moved up or down, pulled towards you or pushed away from you.
Page 14: Dashboard
Chapter 1 DASHBOARD GAUGES Odometer/Tripmeter/Service reminder Reset knob Speedometer The speedometer indicates vehicle speed in kilometres per hour. Odometer I trip meter I service reminder A small window in the speedometer is used for the odometer, the tripmeter, and the service reminder.
Page 15 Chapter 1 DASHBOARD GAUGES Engine temperature gauge NEEDLE IN ZONE AT LEFT= Engine has not reached operating temperature. NEEDLE BETWEEN ZONES = Normal operating temperature. NEEDLE ZONE RIGHT Temperature too high. Stop the car as soon as it is safe to do so. Refer Chapter 6 for further information.
Page 16 If it lights up during driving then the battery is not being charged (engine cooling may also be affected). You should see a Holden Dealer as soon as possible. Brakes, hydraulic clutch Lights up for a few seconds when ignition is switched ON. It will go out after a few seconds unless the park brake is applied and/or the brake /clutch fluid levels are low.
Page 17 ABS (Anti-lock Brake System). The car's brake system remains operational but without ABS assistance, refer Chapter 4. You should consult your Holden Dealer as soon as possible. Traction control Lights up for a few seconds when the ignition is switched on and goes out a few seconds after the system has performed a self-test.
Page 18 Chapter 1 DASHBOARD WIPERS & WASHERS Wipers and washers are operational when the ignition is ON. Windscreen wipers Move the lever upwards. fast slow intermittent 7725 u Windscreen washer Never operate with wipers on dry glass, as this will damage the rubber. To spray washer fluid onto the windscreen pull the lever toward you.
Page 19 Chapter DASHBOARD EXTERIOR LIGHTS Light switch �cE parking lights �D headlights and parking lights J:J.· pull the light switch outwards to turn on the interior light Turn the thumb wheel to adjust instrument illumination. High/low beam When the headlights are switched on, push the lever away from you, until you feel a click, then release.
Page 20 Chapter 1-10 DASHBOARD EXTERIOR LIGHTS cont. Rear fog lights The push button for the rear fog lights is located below the headlight switch. Push the button to switch on or off. The symbol in the instrument panel glows when the fog lights are working. Check your State's Laws regarding use of fog lights when driving.
Page 21 Chapter 1 11 DASHBOARD Radio The radio will stay ON until the key is removed from the ignition. Therefore, remember to remove the key when leaving the car for any length of time. or you may flatten the Refer to audio leaflet for operating instructions about your audio system. Mobile phones and CB radios Mobile phones and CB radio equipment which use an integrated antenna, may temporarily affect the car's electronics when used inside the car, due to the interference...
Page 22 Chapter 1 1-12 DASHBOARD VENT/LA TION The car features a flow through ventilation system for your comfort. Under reasonable conditions it shouldn't be necessary to open the windows at any time. Outside air is drawn into the car through the opening at the base of the windscreen. Do not allow this opening to become clogged with debris, such as leaves or snow.
Page 23 Chapter 1 13 DASHBOARD • VENT/LA TION AND HEATING Front temperature dial Anticlockwise cool Clockwise warm Front fan dial OFF plus four fan speeds are provided. Note that the rate of air flow is determined by car speed, as well as by the fan. Front vent dial �...
Page 24 Chapter 1-14 DASHBOARD VENT/LA TION AND HEATING Air intake button Push the button to switch between re circulated and outside air. The light in the switch glows when re-circulate is selected. When following another car on dusty roads, or to prevent exhaust fumes or odours entering your car, press the button to the re-circulation position (light in switch showing).
Page 25 Chapter 1 15 DASHBOARD AIR CONDITIONING Air conditioning not only cools the air but also removes moisture. If the temperature dial is moved away from extreme cold, the air will then be reheated before entering the cabin. The air conditioner is switched on by pushing the button with the snowflake symbol. A light in the switch will glow when the air conditioner is operating.
Page 26 Chapter 1-16 DASHBOARD OEM/STING Windscreen demisting air conditioning switch ON • air intake button to fresh • Note: air intake will automatically switch from re-circulation to fresh air when vents dial is rotated to demist mode. temperature dial to hot •...
Page 27 Chapter 1 17 DASHBOARD CIGARETTES Cigarette lighter When the ignition is on, press the cigarette lighter in. When the element is heated, the lighter pops out, ready for use. Ashtrays Ash trays should only be used for ash, not for combustible rubbish. Front The cover opens when pressed at the top.
Page 28 Chapter 1 1-18 DASHBOARD INFORMATION DISPLAY Display shows time, date and outside temperature when the ignition is ON. When the radio is playing the date display is replaced by radio display. As with the instrument lighting, the brightness of the display can be adjusted when the park/head lights are ON, by turning the thumb knob located below the light switch.
Page 29 3° when the temperature drops below "--.-° C" on the display indicates a fault in the system and you should see your Holden Dealer. Note that a fall in temperature is indicated immediately, and a rise in temperature after a short delay.
Page 30 Chapter 1 1-20 DASHBOARD BONNET From inside the car, pull the lever towards you. This allows the bonnet to release but is prevented from opening by the safety catch. To open completely, pull the tab forwards while lifting the bonnet. Fully open the bonnet.
Page 31 Chapter 1 21 DASHBOARD IGNITION Ignition LOCK: Ignition off. Steering locked, • when key is removed. OFF: Steering unlocked, ignition off. ON: Ignition on. START: Start the engine. 10536 T To release steering column lock: To release the lock, move the steering wheel slightly and turn the key to position I. To lock steering column: Withdraw the key in position •...
Page 32 Chapter 1 1-22 DASHBOARD CRUISE CONTROL The cruise control maintains your car's speed without you having your foot on the accelerator pedal and works at speeds over 30 km/h. The cruise control lever is on the left side of the steering column. The lever has two switches.
Page 33 Chapter 1 23 DASHBOARD CRUISE CONTROL cont. RESUMING THE STORED SPEED: Tap button "R" at a speed above 30 km/h: the speed selected before the cruise control was switched off is resumed. The stored speed is erased when the ignition is switched off. WARNING: Do not use the cruise control when road or driving conditions could require varying speeds.
Page 34: Locks
Locks Page Keys Free-turning door locks 2 - 2 Child safety rear door switch 2 -3 Electric locks 2- 3 Dead locks 2 -5 The remote control Tailgate...
Page 35 Car Pass (a card containing information about the engine immobilizer) away from your car. Then, if your key is lost, replacements can be ordered through a Holden Dealer by quoting the key code number and providing proof of ownership.
Page 36 Chapter 2 LOCKS DOOR LOCKS AND DEADLOCKING Locking the car: Press the rear button of remote control or turn the key in driver's door. This locks the doors, tailgate and fuel tank filler. To deadlock all doors, press the rear button on the remote control again within 1 0 seconds after locking.
Page 37 Chapter LOCKS ELECTRIC DOOR LOCKS cont. Closing electric windows: electrically operated windows can be closed from outside the car by holding the key in the door locking position until the 'vVindmvs are fully closed. Emergency - flat battery Unlocking and locking the driver's door in the event of malfunction of the central locking system (e.g.
Page 38 Chapter 2 LOCKS ELECTRIC DOOR LOCKS. THE REMOTE CONTROL The remote control The remote control is powered by a • battery inside the key head. A weakening battery is indicated by a progressive "loss of range", which means you must be closer to the car when pressing the key.
Page 39 Chapter 2 LOCKS TAILGATE The central locking system cannot be switched on or off from the tailgate lock. Provided that the key slot is horizontal, the taiigate wiii iockiuniock when the doors are locked/unlocked. To keep hatch lid permanently locked (regardless of door lock position) turn the key slot to the vertical position.
Page 40 Chapter 2 LOCKS Notes...
Page 41 Page 3- 2 Front seat adjustment Head restraints 3 -3 Second row seat 3- 4 Third row seats Luggage compartment cover Luggage compartment enlargement Accessory socket 3-10 Seat belts Child restraints 3-13 Drink holders 3-15 Mirrors 3-16 Windows 3-17 Park brake 3-18 Interior light 3-18...
Page 42 Chapter 3 KNOW YOUR CAR FRONT SEAT ADJUSTMENT Front seat forward/rearward Pull the handle at the front of the seat then slide the seat forward or backward. After releasing the handle try to move the seat back and forth to check that the catch has locked in position.
Page 43 Chapter KNOW YOUR CAR HEAD RESTRAINTS Height Adjust the height as required. The upper edge of the head restraint should be approximately at eye level - never at neck level. If this is not possible for very tall passengers, the restraint should be set at its highest position.
Page 44 Chapter KNOW YOUR CAR Moving seats Push the handle on the side of the seat and move the seat row forward or back. Release the handle and ensure the seat locks into position. For increased comfort, when the centre seat is unoccupied, the centre armrest can by pulled down by lifting the flap then tugging on the strap.
Page 45 Chapter KNOW YOUR CAR THIRD ROW SEATS Lowering the seats into the floor Before lowering the third row seats, move the second row seats forward by pushing the handle on the side of the seat and moving the second row forward until the marking on the seat is level with the marking on the floor, as per the illustration.
Page 46 Chapter 3 KNOW YOUR CAR THIRD ROW SEATS cont. Push the seat belt buckles into the recess in the floor and close the cover. The second row seats can then be moved back, as required. To reposition the third row seats: Move the second row seats forward until •...
Page 47 Chapter 3 KNOW YOUR CAR LUGGAGE COMPARTMENT COVER Opening and closing When the third row seats are folded into the floor, the lu gg a g e compartment cover can be used to hide objects placed in the rear. Before usin g , the seat belts must be tucked behind the hook, as shown.
Page 48 Chapter 3 KNOW YOUR CAR LUGGAGE COMPARTMENT ENLARGEMENT For transporting large objects Lower one or both of the third row seats into the vehicle floor, see previous pages and additionally, fold up the second row seats: push handle 1 down and pull up the seat •...
Page 49 Chapter 3 KNOW YOUR CAR ACCESSORY SOCKET In the side trim on the right, there is a storage compartment with an accessory socket. To open the side trim, rotate the fasteners 90 degrees; to close, rotate the fasteners all the way back again. Whe n objects stowed...
Page 50 Actuation may also be indicated by yellow tabs on the belt buckles. If the belt tensioners have been activated they must be replaced bv a Holden nea!er. The seat belts remain operational even when the 9886T belt tensioners have been actuated.
Page 51: Now Your Car
Chapter 3 3 11 KNOW YOUR CAR SEAT BELTS Seat belt height adjust (if fitted) do not adjust height while driving, • pull belt out somewhat, • press button down or push belt guide up • to desired height, allow anchorage to lock audibly into •...
Page 52 Chapter 3-12 KNOW YOUR CAR SEAT BELTS cont. Lap belts On the centre seat in the second row: to adjust the belt length, tilt the latch plate and pull the belt side'vvays. Seat belts in 3rd row seats Open the cover in the floor between the seats and swivel up the belt buckles.
Page 53 Only approved child restraint harnesses should be used on anchorage points. See your Holden Dealer for advice about the various types of approved child restraints available. INFANTS UNABLE TO SIT BY THEMSELVES should be carried in an approved child seat restraint.
Page 54 Chapter 3-14 KNOW YOUR CAR CHILD RESTRAINTS Three anchor fittings for child restraints are provided behind the 2nd row seats, as shown. A chiid restraint iviUST ONLY be attached • to the anchor provided directly behind it. It MUST NOT be attached to anything else, forinstance to the luggage hooks or cargo barrier, as they are not designed to take the load.
Page 55 Chapter 3 3 15 KNOW YOUR CAR DRINK HOLDERS Drink holders Drink holders are provided in the front, underneath the ashtray and in the front door pockets. Other drink holders are provided in the centre armrest in the second row. Fold down the centre armrest and pull out the drink holders.
Page 56 Chapter 3-16 KNOW YOUR CAR MIRRORS Internal rear view mirror Grasp the mirror and swivel to adjust height. Swivel the lever on the lower edge of the mirror to reduce dazzle at night. 9832 T Electric exterior mirrors Switch the. top, 'rocker' switch to either left mirror or right mirror as required.
Page 57 Chapter 3 17 KNOW YOUR CAR WINDOWS Manual windows Turn the handle on the door to raise or close the windows. Front electric windows To avoid risk to children (through incorrect use of electric windows), the driver should remove the key from the ignition when leaving the car.
Page 58 Chapter 3 3-18 KNOW YOUR CAR PARK BRAKE AND INTERIOR LIGHTS Park brake To apply, pull the lever straight up. To release, pull the lever slightly upwards, push in the release button on the end of the lever and whilst depressed, lower the lever all the way down.
Page 59 Chapter 3 3 19 KNOW YOUR CAR E-TAG Some road systems require electronic devices (E-tags to be fitted to cars in order to bill the road users. Your car is fitted with a special heat reflective windscreen which uses metallic oxide.
Page 60 Safety Manual transmission Driving precautions Snow chains Traction control...
Page 61: Driving4
Chapter 4 DRIVING ENGINE STARTING Apply the park brake firmly and release only after you have started the engine and are ready to drive off. MANUAL: Depress the clutch pedal and shift the gear lever to Neutral position. The clutch pedal can nO\'V be released.
Page 62 Chapter 4 DRIVING SAFETY Before entering the car Check that windows, mirrors and lights are clean. Check tyre are not flat. Before driving off Be sure that all doors are secured. Position your seat for comfortable driving. 3. Adjust rear vision mirrors. FASTEN SEAT BELTS.
Page 63 Chapter 4 DRIVING AUTOMATIC TRANSMISSION To move out of P position, switch on the ignition, depress the brake pedal and push in the button on the side of the T- ..LIQI, Push in the button when t"...
Page 64 (in the gauges) is illuminated, then a fault is indicated in the transmission. You should use the T-bar to manually shift through the gears ("1 ", "2", "3", "D"). Consult a Holden Dealer as soon as possible. NEUTRAL IDLE CONTROL. This feature is designed to reduce fuel consumption •...
Page 65 Chapter 4 DRIVING MANUAL TRANSMISSION This system has 5 forward gears and a reverse gear. The shift pattern illustrated, is found on the top of the gear shift lever. When selecting fifth gear you must shift the gear lever sideways against light spring pressure in order to pass into the gear.
Page 66 Chapter 4 DRIVING DRIVING PRECAUTIONS Brakes Power assisted brakes, which are fitted to your car, utilise vacuum from the engine • when it is running. Never let the car run down steep grades without the engine running. Never coast with the engine switched off. Driving through water may affect performance.
Page 67 ABS. The car's brake system remains operational but without ABS assistance. You should consult your Holden Dealer as soon as possible. The braking effect is regulated by the ABS every millisecond during braking.
Page 68 If the TC warning light does not light up, or if it comes on during driving, a fault is indicated in the system and traction control will no longer be operational. You should contact your Holden Dealer.
Page 70: Fuel
-whenever a change is noticed in the sound of the exhaust system, -whenever the exhaust system, underbody or rear of the car is damaged. Take the car to your Holden Dealer if you think your car needs inspecting for any of the above reasons.
Page 71 Chapter 5 FUEL PETROL CAUTION: Petrol should be regarded as extremely flammable and highly explosive. • Always turn off the engine and any mobile phones when refuelling. • • If petrol fumes are smelt while driving, the cause should be found and •...
Page 72 Chapter 5 FUEL PETROL Tank capacity= 56 litres Petiol fillei nozzle ieStiictoi To help the atmosphere, your car has been designed to operate on UNLEADED PETROL. A petrol nozzle restrictor is fitted to ensure that only UNLEADED petrol is used. This allows the thinner, unleaded petrol nozzle to open the hinged flap, so that petrol can be added to the tank.
Page 73 Maintenance schedule in Chapter 12. It is recommended that the necessary servicing be performed by an authorised Holden Dealer who has the specialised servicing equipment and trained personnel available...
Page 74 Chapter 5 FUEL REDUCING FUEL CONSUMPTION Engine Maintain the engine in peak mechanical condition by having it serviced regularly in accordance with the Maintenance schedule in Chapter 12. This will ensure items such �c: thA c:n�rk nh 1nc: �ir f'IA�nAr Atf' �rA m�int�inArl frw minim11m f11AI 11c:�nA �nrl no!:�...
Page 75 Chapter 5 FUEL Notes...
Page 76 Flat tyre Towing a disabled Zafira Towing a disabled car with a 6-10 Zafira 6-11 Auto trans with a flat battery Engine overheating 6-12 6-14 Flat battery, jump starting Air bags 6-16 6-18 Fuses 6-25...
Page 77 Chapter EMERGENCIES ACCIDENTS All motorists are advised to learn what to do at the scene of an accident, particularly where persons are injured. Injured people can choke to death if their air passages are not cleared. They can bleed to death unless the bleeding is stopped. They may require mouth-to mouth resuscitation or may have to be moved, even thouqh badly iniured.
Page 78 Chapter 6 EMERGENCIES ACCIDENTS Part 3. Medical assistance This information is basic first aid information which is intended as a guide only and may not be applicable in all situations. You should always defer to a trained medical officer or other person with first aid knowledge. Protective equipment, such as rubber gloves are recommended.
Page 79 Chapter 6 EMERGENCIES FLATTYRE CAUTION: Use the jack only for lifting the car when changing wheels. • �Jever get beneath the car \AJhen it is on!y supported by the jack. Do not start or run the engine while the car is only supported by the jack. •...
Page 80 Chapter 6 EMERGENCIES FLATTYRE Remove the spare wheel (which is stowed underneath the car: Use the wheel bolt wrench in the tool kit to undo the bolt in the stowage compartment floor. Lift the spare wheel holder. Unhook the catch and lower the spare wheel.
Page 81 Chapter EMERGENCIES FLATTYRE Remove the wheel trim: Steel wheel (if fitted) • using the tool in the car tool kit, remove the full wheel trim. Alloy wheel (if fitted) • remove the centre cap and individual wheel bolt caps. Loosen (but do not remove) the wheel bolts with wheel bolt wrench.
Page 82 Chapter 6 EMERGENCIES FLAT TYRE cont. Depressions on the lower edge of the car indicate the points where the jack is to the used. CAUTION: Failure to position the jack as described above could result in serious personal injury or car damage caused by the car slipping off the jack. 9.
Page 83 Chapter 6 EMERGENCIES FLAT TYRE cont. 12. Remove the wheel from the car and change it over with the spare. 13. Replace the wheel bolts and tighten by hand. Then, with the wheel wrench, lightly tighten in a crisscross sequence. 14.
Page 84 Chapter EMERGENCIES TOWING A DISABLED ZAFIRA Proper lifting or towing equipment is necessary to prevent damage during any towing operation of the car. State and Local laws must be followed. In an emergency, your car may be towed on all four wheels in the following manner: The towing eye is located in the bag •...
Page 85 Chapter 6 6-10 EMERGENCIES TOWING A DISABLED CAR WITH A ZAFIRA The towing eye is located in the bag containing ja c k tools underneath stowage compartment in the rear floor. Open the cover concealing the hole for • the towing eye (located at the rear of the car on the right hand side) by disengaging the cover at the bottom and pulling downwards.
Page 86 Chapter 6-11 EMERGENCIES AUTO TRANS WITH FLAT BATTERY For safety, the transmission has an electric PARK lock so that the key must be in the ignition (in the ON position) before the T-bar can be moved away from the "P" position. If the car's battery is flat the T -bar cannot be moved, as required for towing.
Page 87 Chapter 6 6-12 EMERGENCIES ENGINE OVERHEATING CAUTION: Immediate action is required if the engine overheats. This can be indicated by the temperature gauge needle moving to the red zone, by steam escaping from under the bonnet, a loss of power or a loud knocking or pinging noise.
Page 88 Note that with this type of sealed, pressurised cooling system there should be very little loss of coolant. If the surge tank is low a leak is indicated. Therefore you should see your Holden Dealer as soon as possible to fix the leak. The engine may temporarily operate at high temperatures during more demanding operating conditions, especially on very hot days.
Page 89 Chapter 6-14 EMERGENCIES FLAT BATTERY CAUTION: DO NOT attempt to "push start" or "tow start" this car, as it is fitted with a catalytic converter and if un-combusted fuel were to reach the catalytic converter and ignite, the converter could overheat or be destroyed by backfire. If your car will not start due to a flat battery, it can often be started by using energy from a battery in another car- a procedure called...
Page 90 Chapter 6 6-15 EMERGENCIES FLAT BATTERY The battery of your car has a negative earth and a 12 volt rating. The battery in the • other car must be the same voltage and also have a negative earth. The battery capacity of the charged battery must not be substantially lower than that of the discharged battery.
Page 91 If the light rollovers ..always wear a seat belt. show when the ignition is switched to ON, or if it comes on when driving, you should contact your Holden Dealer, as they may not function correctly, especially in an accident.
Page 92 After use the whole air bag system will have to be replaced. It is recommended that the work be done by your Holden Dealer. The system should also be inspected by a Holden Dealer if the steering wheel or dash board area is scratched, cracked or damaged. Remember that the horn pad must not be covered with adhesive or any other material, as this may hinder air bag operation.
Page 93 However, because headlight aiming is a safety item it is recommended that you have it carried out by your Holden Dealer. On cars fitted with headlight range adjustment, the headlight aiming must be carried out with the switch in...
Page 94 Chapter 6-19 EMERGENCIES BULB REPLACEMENT cont. Headlights, low beam Open bonnet and engage support. Grip bulb holder on plug connector, rotate anti-clockwise. Remove bulb holder from reflector. Detach bulb from bulb holder. Insert new bulb into bulb holder, without touching the glass. Insert new bulb so that the three lugs on the bulb holder engage in the recesses in the reflector.
Page 95 Chapter 6-20 EMERGENCIES BULB REPLACEMENT cont. Headlights, high beam . Open bonnet and engage support. Grip bulb holder on plug connector, rotate anti-clockwise. Remove bulb holder from reflector. Raise lug and detach connector from bulb holder. Insert new bulb into bulb holder, without touching the glass.
Page 96 Rotate bulb holder anti-clockwise and disengage. Press bulb into holder slightly, turn anti clockwise and remove. Insert new bulb and engage holder in reflector by turning. High mounted stop light and instrument lighting The work should preferably be carried out by a Holden Dealer.
Page 97 Chapter 6 6 22 EMERGENCIES BULB REPLACEMENT cont. Tail, brake, rear turn signal, reverse lights, rear fog lights Disengage and remove the cover. Detach plug connector from bulb holder. Grip the lens from the outside and unscrew the two nuts. Detach the lens from the car body.
Page 98 Chapter 6-23 EMERGENCIES BULB REPLACEMENT cont. Number plate light Open luggage compartment. Unscrew both screws on the underside of the tailgate handle and remove the bulb holder. Press bulb slightly towards spring clip and remove. Insert new bulb and re-install bulb holder.
Page 99 Chapter 6-24 EMERGENCIES BULB REPLACEMENT cont. Rear courtesy light (if fitted), glovebox light and load area light Before removal, close the doors or make surethatthe contactswitc h is kept depressed so that the light is not live. Lightly prise light out of recess, using a screwdriver.
Page 100 Chapter 6 6-25 EMERGENCIES FUSES CAUTION: Electronic i g n i t i o n systems use a very high voltage. Do not touch the ignition system The fuses are located behind a cover, to the right of the steering wheel. To access the fuses, detach the cover.
Page 101 Chapter 6 6-26 EMERGENCIES FUSES cont. Before replacing a fuse, turn off the respective switch and remove the ignition key. Slot the fuse gripping tool onto the fuse and withdraw. A defective fuse can be recognised by its melted wire. A new fuse should only be installed after the cause of the trouble has been located and eliminated.
Page 102 Chapter 6 6-27 EMERGENCIES Notes...
Page 103 Miscellaneous checks 7 - 3 Engine oil level Engine coolant level 7 -5 Brake fluid level 7 - 5 7 -5 Power steering fluid level Washer fluid level Battery Tyres...
Page 104 Chapter 7 WEEKLY CHECKS MISCELLANEOUS CHECKS As well as taking your car to be serviced (refer Chapter there are a few simple, weekly checks that the owner/operator is required to make. These are shown on the following pages. The following checks should also be regularly done to ensure proper safety and dependability of your car.
Page 105: Weekly Checks
, m a y detrimental to the operation o f your car and may void your New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of your Holden vehicle.
Page 106 -30°C, provided the correct concentration is maintained. If you regularly have to top up the cooling system, you should see your Holden Dealer. CAUTION: Corrosion inhibitors and antifreeze fluids are poisonous.
Page 107 If the master cylinder requires constant topping up it could indicate that a malfunction exists and you should immediately see your Holden Dealer. Automatic transmission fluid level (if fitted) The fluid level for automatic transmission will be checked for you when your car is taken...
Page 108 To fill, open the flip top cap. For a crystal clear windscreen, use a small amount of Optikleen (available from your Holden Dealer) can be added. Do not use ordinary soap or detergent as these not only froth up but will also damage the wiper rubbers.
Page 109 Out-of-balance wheels and tyres can cause annoying vibration and uneven tyre wear such as cupping and flat spots. If you have any reason to suspect that either of the above problems exist then have a wheel alignment and balance check done by your Holden Dealer.
Page 110 Tyre condition will be checked for you when you take your car to be serviced by your Holden Dealer, who will be able to diagnose any unusual signs of wear. If the tyres are rotated it is recommended that the balance be checked at the same time.
Page 111 Chapter 7 WEEKLY CHECKS TYRES cont. Tyre replacement and repair CAUTION: Do not mix different tyre construction types, such as radial and cross ply, on your car except in emergencies, because your car's handling could be affected and may result in loss of control. When replacing tyres you should use the same size, load rating and construction type as the original tyres on your car.
Page 112 Chapter 7 7 1 0 WEEKLY CHECKS Notes...
Page 113 Chapter 7 7 11 WEEKLY CHECKS Notes...
Page 114 Specifications Page Engine specifications Transmission specifications Dimensions Battery Identifications plates...
Page 115 ACEA service classification A2 or A3. viscosity grade 15W-40 or 15W-50. 5 litres approx. (including filter) Refill oil capacity Power steering fluid type Hydraulic fluid to Holden specification number HN2305 (Pentosin CHF 11 S Hydraulic fluid). Fuel tank capacity 56 litres Coolant capacity 7 litres approx.
Page 116 GENERAL SPEC/FICA TIONS Transmission 4 speed auto 5 speed manual transmission transmission Gear oil, meeting Auto trans fluid Fluid type Holden spec. no. meeting Holden HN2354 (Castrol spec. no. HN2287 SMX-0 or (Esso JWS 3305G) equivalent) Clutch fluid Heavy duty...
Page 117 The TYRE PLACARD is located on the inside of the fuel filler flap. Holden Identification Plate The Holden Identification Plate is located on the driver's side of the radiator support panel. The Holden number is used for warranty identification, Roadside assist identification etc.
Page 118 Chapter SPECIFICATIONS /DENT/FICA TION LABELS Vehicle identification number (I.S.O.V.I.N.) The individuaii.S.O.V.I.N. Number (example below) appears on the Safety Compliance Plate. This number is used for identification of parts. WOL 0 equent1al Production enal umber Assembly Plant Code, can be alpha or numeric Model Year Code: 1=2001,2=2002, 3=2003 Bodystyle...
Page 119 New Vehicle Warranty 9- 8 Customer Assistance 9-1 0 For New Zealand Holden owners 9-11 Australian Holden Dealers 9-12 New Zealand Holden Dealers 9-28 Note: Dealership names and details may change after the p rinting of this Handbook. The list contains both...
Page 120 Subject to the exclusions shown on the following page, this Warranty covers the correction, during the Warranty Period, of any vehicle defect related to materials or workmanship and advised to a Holden Dealer or Authorised Service Outlet, by repair or at Holden's option by replacement. Warranty Period...
Page 121 (c) failure to carry out proper maintenance services, (d) use of incorrect types and grades of fuel, oil or lubricants, (e) alteration of the vehicle by anyone not authorised by Holden, (f) fitting of parts or accessories not marketed by Holden, (g) any work carried out on the vehicle by anyone except a Holden Dealer or authorised Service Outlet.
Page 122: After Sales
• Parts and Accessories purchased at trade or retail and installed by other than a Holden Dealer or authorised Service Outlet are warranted for 1 year from the date of purchase. Please keep a receipt to support warranty claims. The Warranty does not cover the labour costs of removal I reinstallation of Parts and Accessories when installed or rectified by other than a Holden Dealer or authorised Service Outlet.
Page 123 Vehicle Warranty) is required to enable your vehicle to be operated safely and it is not practical for you to go to an Authorised Holden Dealer, the service (to the extent that it is necessary to enable your vehicle to be operated safely) may be performed by any other qualified mechanic or repairer.
Page 124 Chapter AFTER SALES WARRANTY QUESTIONS Willi have to pay for maintenance costs during the Warranty Period? Maintenance costs are not covered by the Holden New Vehicle Warranty. The Maintenance Schedule in Chapter specify the minimum maintenance required for your vehicle operating under normal conditions.
Page 125 Holden Dealer it is your responsibility to deliver your vehicle to the servicing Holden Dealer's premises. If, as a result of a defect which is covered by the Holden New Vehicle Warranty, your vehicle cannot be driven safely and you arrange for the nearest Authorised Holden Dealer to carry out the required Holden Warranty service, Holden will accept reasonable towing costs to move your vehicle to the nearest Holden Dealer's premises.
Page 126 Australia wide. We hope the need never arises, but if it does, we'll be there to help through Holden Roadside Assistance. How does Holden Roadside Assistance work? Holden Roadside Assistance is provided by Holden Ltd., and delivered by the...
Page 127 Holden Roadside Assistance stays with the vehicle, so if you sell your vehicle during the 36 month period, it is still eligible for the balance of the Holden Roadside Assistance. The new owner simply registers for the service by using the change of ownership form supplied in the Roadside Assistance booklet.
Page 128 Manager or Service Manager - go to the General Manager or to the Dealer Principal. By now you should have satisfaction. If not, the Holden Customer Assistance office is at your disposal. The Australian Holden Customer Assistance representatives can be telephoned from anywhere within Australia for only the cost of a local call.
Page 129 AFTER SALES FOR NEW ZEALAND HOLDEN OWNERS The information in this Owner's Handbook applies primarily to Australian Holden vehicles and there may be some differences to the Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
Page 130 Cnr Hume Hwy/Waterloo Rd RYDE (02) 9642 0233 (02) 9642 7798 Fax: Hunter Holden DEE WHY 603-605 Victoria Road Peninsula Holden Dee Why (02) 9808 9123 (02) 9809 6592 Fax: Cnr May & Mooramba Roads SPRINGWOOD (02) 9982 1311 (02) 9982 3755 Fax:...
Page 131 Chapter 9-13 AFTER SALES AUSTRALIAN HOLDEN DEALERS CONT. ST. MARY'S BOOROWA John Young Holden Boowowa Auto Repairs Cnr Glossop & Harris Streets Marsden Street (02) 9673 2111 (02) 9673 4932 (02) 6385 3305 Fax: SUTHERLAND BREWARRINA McGrath Holden Sutherland Lukas Holden...
Page 132 Chapter 9 14 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. COOTAMUNDRA GLEN INNES Glen Severn Holden Jenkins Garage Wallendoon Street Grey Street (02) 6942 2522 (02) 6942 1493 (02) 6732 2888 (02) 6732 3394 Fax: Fax: COWRA GOSFORD Waugoola Motors Pty Ltd...
Page 133 Chapter 9-15 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. KANDOS MORUYA Chrisfield Holden Surfair Holden Angus Street Vulcan Street Fax: (02) 6379 4204 Fax: (02) 6379 4606 (02) 4474 2555 (02) 4474 2129 KATOOMBA MOSS VALE Katoomba Holden Moss Vale Holden...
Page 134 Chapter 9 9 16 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. PARKES TWEED HEADS Broderick Motors Holden Tweed Motors Cnr Mitchell & Clarinda Sts 75-79 Pacific Highway P: (02) 6862 2266 Fax: (02) 6862 1406 P: (07) 5536 3411 Fax: (07) 5536 4490...
Page 135 Chapter 9-17 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. WYONG Vic. Metropolitan Barry Robertson Holden BERWICK Pacific Highway Barry Bourke Holden (02) 4351 2588 (02) 4352 1759 Fax: Princes Highway YASS (03) 9707 2222 (03) 9707 3091 Fax: Bill Nesbitt Holden...
Page 136 (03) 9784 4444 (03) 9784 441 9 (03) 9627 3333 (03) 9682 6888 Fax: Fax: GEELONG SOUTH YARRA R & B Smith Holden Penfold Holden 51 0 Moorabool Street Chapel Street (03) 5222 2888 (03) 5221 31 1 4 (03) 9827 2272...
Page 137 Chapter 9 9-19 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. BIRCHIP EUROA R.L. & C.J. Bales Parker Bros Auto Co. Euroa 38 Cumming Avenue 37-41 Clifton Street P:(03) 5795 2702 Fax: (03) 5795 1288 P: (03) 5492 2543 BOORT FOSTER Jaron Motors...
Page 138 Chapter 9 9 20 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. MARYBOROUGH SALE Graham Jacka Holden Sam Gould Holden 35 Nolan Street 273 York Street P: (03) 5461 1011 Fax: (03) 5461 4789 P: (03) 5144 3944 Fax: (03) 5144 6289...
Page 139 Chapter 9 9-21 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. WARRACKNABEAL INDOOROOPILL Y Amor Motors Aubrey Truck Sales Westpoint Holden 33 Woolcock Street 440 Moggill Road P: (03) 5394 1 055 Fax: (03) 5398 1904 P: (07) 3878 0440 Fax: (07) 3878 1340...
Page 140 Chapter 9 9 22 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. CROWS NEST Qld. Country Dennis Nissen Motors ATHERTON 14 William Street Redding Motors Pty Ltd P: (07) 4698 1300 Fax: (07) 4698 1495 2 Cook Street DALBY P: (07) 4091 1344 Fax: (07) 4091 2039...
Page 141 Chapter 9-23 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. LONG REACH ROCKHAMPTON Lawrence's Longreach Motors Swan Street Richardson Road (07) 4658 1700 (07) 4658 1857 (07) 4930 5111 (07) 4930 5112 Fax: Fax: MACKAY ROMA Pioneer Holden Maranoa Multi Agencies Cnr Gordon & Wellington Streets...
Page 142 Chapter 9 9 24 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. KATHERINE S.A. Country Kittles Holden BALAKLAVA 441 Victoria Highway Balaklava Motors P: (08) 8972 1788 Fax: (08) 8971 0209 4 Wallace Street P: (08) 8862 1 030 Fax: (08) 8862 2000...
Page 143 Chapter 9-25 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. KINGSTON RENMARK Lecornu's Service Garage Rosenthal Motors Pty Ltd Agnes Street Ral Ral Avenue (08) 8767 2424 (08) 8767 2533 (08) 8586 6626 (08) 8586 4040 Fax: Fax: LOXTON ROXBY DOWNS Hayes Augusta Motors...
Page 144 Chapter 9 9 26 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. GOSNELLS BROOKTON Gibbons Holden Coote Motors 2325 Albany Highway 1 Robinson Road P: (08) 9398 2211 Fax: (08) 9398 5683 P: (08) 9642 11 08 Fax: (08) 9642 1 003...
Page 145 Chapter 9 9-27 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. PORT HEDLAND KALGOORLIE Golden City Holden Moxham Motors 114 Boulder Road 15 Anderson Street P:(08) 9173 3660 Fax: (08) 9144 1258 P: (08) 9021 1699 Fax: (08) 9021 5737 WAGIN KARRATHA...
Page 146 Chapter 9 28 AFTER SALES NEW ZEALAND HOLDEN DEALERS DARGA VILLE Auckland Metropolitan Marcel Motors Limited HENDERSON Victoria Street West City Holden (09) 439 7399 (09) 439 7399 Fax: Great North Road (09) 836 0097 (09) 837 5291 Fax: (1992)
Page 147 Chapter 9-29 AFTER SALES NEW ZEALAND HOLDEN DEALERS cont. NAPIER TAUMARANUI Turaki Motors Limited Karamu Holden Cnr Wellesley Rd & Thakeray St Hakiaha Street (06) 87 4 3033 (06) 834 1454 (07) 895 7009 (07) 895 8909 Fax: Fax: NELSON...
Page 149 Chapter 10 10 2 TOW & LOAD LOADING THE CAR Overloading is a safety hazard and could also shorten the life of your car or its parts. The recommended carrying capacity of your car is: 600 kg (including 7 occupants and luggage).
Page 150: Towing
Holden will not accept liability for defects occurring in towing equipment not marketed by Holden or for defects in the car arising from the use of such equipment. The use of such equipment may void your New Vehicle Warranty, to the extent that Holden considers the non-recommended equipment affects the specifications or quality of your Holden vehicle.
Page 151 Chapter 10 10 4 TOW & LOAD • TOWING cont. Safe towing tips Your car will handle differently when towing. It's a good idea to make a couple of short distance trips with the trailer/caravan before you set off on the big one. Have your car correctly maintained and serviced.
Page 152 Chapter 10 10-5 TOW & LOAD LOADING Lashing eyes Do not leave loose articles or luggage in the passenger compartment. Whenever possible, stow loads in the luggage compartment . Four lashing eyes are provided in the luggage compartment to tie down loads. 9940T Storage tray A storage tray is provided under the front...
Page 153: Cleaning
Cleaning Page INTERIOR CLEANING 11-2 Upholstery 11-2 Vinyl (P.V.C.) fabrics Cloth fabrics 11-3 11-3 Carpet 1 1-3 Seat belts 11-3 Interior glass EXTERIOR CLEANING Paint inspection Washing Grease, oil & tar spots Polishing Wheels 11-7 Exterior glass 11-8 Cleaning products...
Page 154 Using lukewarm water and soap, or Holden Velour Fabric and Vinyl Cleaner, work up thick suds on a piece of cheesecloth, and apply to the surface. A soft bristle brush can be used to remove stubborn stains or dirt embedded in the grain of the material.
Page 155 Do not bleach or dye seat belts since this may severely weaken them. Cleaning interior glass The interior glass area of the car should be cleaned using Holden Glass Cleaner with a clean soft cloth. Care must be taken when cleaning inside the rear window so as not to damage the demister.
Page 156 Chapter 11 11-4 CLEANING CARING FOR PAINT To help preserve that shiny new car finish, special attention should be given to correctly treating those conditions that can damage the paint. Road bloom: If, over a long period of time, oils, dirt, exhaust and other pollutants are allowed to build up, they may combine to affect the paint finish.
Page 157 PVC coating should be checked and if necessary, restored to perfect condition. Commercial bitumen and rubber materials can damage PVC coating. Have all work on the underbody performed by a Holden Dealer, as it requires knowledge of the specified materials and experience concerning their application.
Page 158 New tyre look can be restored using Holden Tyre and Bumper Shine. Alloy wheels To preserve the original appearance of alloy wheels, keep them clean and free from build up of road dirt. Holden Wheel Cleaner can be used for cleaning alloy wheels. Do not use abrasive cleaners on alloy wheels.
Page 159 The blades can be cleaned by lifting them off the windscreen and cleaning with Holden Optikleen and a clean cloth.
Page 160 Chapter 11 11-8 CLEANING CLEANING PRODUCTS HOLDEN PART ·SIZE DESCRIPTION USAGE NUMBER 92141386 500 ml Polymer glaze Seals in a deep, lustrous glazed finish. polish Long lite protection from oxidation, salt and weather damage. Velour fabric and Cleans and deodorises velour, most...
Page 161 Chapter 11 11-9 CLEANING Notes...
Page 162 12-2 Service intervals 12-4 12-6 12-8 Service charges 12-9 Service coupons...
Page 163 • SERVICE INTERVALS When it comes to service, remember that your Holden Dealer has the trained personnel and specialised equipment to correctly service your vehicle. Your Dealer invites you to return for all your service needs both during and after the warranty period.
Page 164 Chapter 12 12 3 SERVICING SERVICE LIGHT A small window in the speedometer is used for the odometer, tripmeter and the service reminder. The service reminder will show "lnSP" (inspection required) for a few seconds when the ignition is turned ON if the car is within 500 km or one week of the next service.
Page 165 If at any time it is considered that the above items or other items should be more frequently serviced due to the type of operation or before a long trip, discuss the situation with the service manager of your Holden Dealer. Change automatic transmission fluid @ 60,000km...
Page 166 Chapter 12 5 SERVICING EXTREME OPERATING CONDITIONS SPECIAL SERVICE FOR EXTREME SPECIAL SERVICE FOR EXTREME OPERATING CONDITIONS OPERATING CONDITIONS Date ....km ......Date ....km ......Items performed: ........ . Items performed: ........ Servicing Servicing Dealer ..........Dealer ..........
Page 167 Chapter 12 12 6 SERVICING MAINTENANCE SCHEDULE 1,000 1.5 15 30 45 60 75 90 Use odometer reading 1 05 120 135 150 165 180 or years, whichever 1/12 occurs first or years SERVICE ITEMS %1/12 COOLANT- check level, check coolant COOLANT - replace DRIVE BELTS check...
Page 168 Chapter 12 12 7 SERVICING MAINTENANCE SCHEDULE cont. 1.5 15 30 45 60 75 90 1 05 120 135 150 165 180 Use odometer reading 1,000 km or years, whichever 1/12 occurs first or years SERVICE ITEMS HEADLIGHT ADJUSTMENT check BODY/UNDERBODY check corrosion 1/12...
Page 169 The repair or replacement of any part found faulty during a service check and not covered by Holden Warranty will be added to the charges. Where any deficiencies are noted, such items should be reported to the owner/ operator so that the extra work required can be authorised.
Page 170 Chapter 12 12 g SERVICING 1,500km or 1 month INSPECTION .£ + Holden invites the new owner of this car to return to the selling Dealer for a free service inspection at 1,500 km. � Owner's Mrs.-------------------------------------------------------------------- Name Miss. Other...
Page 171 Chapter 12 1 SERVICING COOLANT- check fluid level, check coolant% ENGINE OIL- check fluid level POWER STEERING -check fluid level WASHER- check fluid level BRAKE AND CLUTCH FLUID- check fluid level LEAKAGE - visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT- check BODY/UNDERBODY- check corrosion protection BRAKE PIPES, BRAKE PRESSURE HOSES, FUEL LINES,...
Page 172 Chapter 12 12 11 SERVICING I authorise performance of the services 15,000 km specified on the rear of this coupon. I understand I will be charged for the following year hours of labour: SERVICE COUPON 1.1 hours • "0 Also, that there will be a charge for all "2 lubricants, filters and parts used as a result of checks and additional services performed...
Page 173 Chapter 12 SERVICING 0 COOLANT - replace coolant 0 DRIVE BELTS - check 0 ENGINE OIL AND FILTER - replace 0 POWER STEERiNG -check fluid level 0 LEAKAGE- visual check of engine and trans. 0 LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT- check WINDSCREEN WIPE/WASH system -check fluid level and blade condition...
Page 174 Chapter 12 13 SERVICING I authorise performance of the services 30,000 km specified on the rear of this coupon. I understand I will be charged for the following 2 years hours of labour: SERVICE COUPON hours labour • hours if brake/clutch fluid "'0 •...
Page 175 Chapter 12 14 SERVICING COOLANT- check level, check coolant% POLLEN FILTER (if fitted)- replace DRIVE BELTS - check FUEL FILTER- replace ENGINE OIL AND FIL TEA- replace POWER STEERING -check fluid level AUTO TRANS - check fluid level. LEAKAGE -visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check WINDSCREEN WIPE/WASH system - check fluid level...
Page 176 Chapter 12 15 SERVICING I authorise performance of the services 45,000 km specified on the rear of this coupon. I understand I will be charged for the following 3 years hours of labour: SERVICE COUPON hours labour • hours if brake/clutch fluid •...
Page 177 Chapter 12 16 SERVICING • COOLANT- check level, check coolant% DRIVE BELTS - check ENGINE OIL AND FILTER -replace POWER STEERING -check lfluid evel LEAKAGE - visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check WINDSCREEN WIPE/WASH system - check fluid level and blade condition DOOR HINGES, DOORSTOP, BONNET LOCK, TAILGATE...
Page 179 Chapter 12 18 SERVICING COOLANT- check level, check coolant% POLLEN FILTER (if fitted)- replace DRIVE BELTS - check AIR CLEANER paper element- replace SPARK PLUGS- replace FUEL FILTER- replace ENGINE OIL AND FILTER- replace POWER STEERING - check fluid level AUTO TRANS - check fluid level.
Page 180 Chapter 12 12 19 SERVICING I authorise performance of the services 75,000 km specified on the rear of this coupon. I understand I will be charged for the following 5 years hours of labour: SERVICE COUPON 1.8 hours labour • add 0.2 hours if brake/clutch fluid •...
Page 181 Chapter 12 12 20 SERVICING COOLANT -replace DRIVE BELTS -check ENGINE OIL AND FILTER - replace POWER STEERING -check fluid level LEAKAGE -visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT -check WINDSCREEN WIPE/WASH system -check fluid level and blade condition DOORHINGES, DOORSTOP, BONNET LOCK,TAILGATE HINGES -lubricate...
Page 182 Chapter 12 12 21 SERVICING I authorise performance of the services 90,000 km specified on the rear of this coupon. I understand I will be charged for the following 6 years hours of labour: SERVICE COUPON 1.6 hours labour • add 0.2 hours if brake/clutch fluid •...
Page 183 Chapter 12 22 SERVICING COOLANT- check level, check coolant% POLLEN FILTER (if fitted)- replace DRIVE BELTS - check FUEL FIL TEA- replace ENGINE OIL AND FIL TEA- replace POWER STEERING- check fluid level AUTO TRANS - check fluid level. LEAKAGE- visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT- check WINDSCREEN WIPE/WASH system - check fluid level...
Page 184 Chapter 12 23 SERVICING I authorise performance of the services 105,000 km specified on the rear of this coupon. I understand I will be charged for the following 7 years hours of labour: SERVICE COUPON hours labour • "0 hours if brake/clutch fluid •...
Page 185 Chapter 2 24 SERVICING • COOLANT - check level, check coolant% DRIVE BELTS -check ENGINE OIL AND FILTER -replace POWER STEERING -check fluid level LEAKAGE -visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT -check WINDSCREEN WIPE/WASH system - check fluid level and blade condition DOOR H I NGES, DOOR STOP, BON N ET...
Page 187 Chapter 12 26 SERVICING COOLANT - check level, check coolant POLLEN FILTER (if fitted) -replace DRIVE BELTS - check AIR CLEANER paper element-replace SPARK PLUGS- replace FUEL FILTER- replace ENGINE OIL AND FILTER- replace POWER STEERING -check fluid level AUTO TRANS check fluid level.
Page 188 Chapter 12 27 SERVICING I authorise performance of the services 135,000 km specified on the rear of this coupon. I understand I will be charged for the following 9 years hours of labour: SERVICE COUPON hours labour • hours if brake/clutch fluid •...
Page 189 Chapter 12 28 SERVICING • COOLANT - check level, check coolant% DRIVE BELTS - check ENGINE OIL AND FILTER - replace POWER STEERING -check fluid level LEAKAGE- visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT- check WINDSCREEN WIPE/WASH system - check fluid level and blade condition DOOR HINGES, DOOR STOP, BONNET...
Page 190 Chapter 12 12 29 SERVIC I authorise performance of the services 150,000 km specified on the rear of this coupon. I understand I will be charged for the following years hours of labour: SERVICE COUPON 1.9 hours labour • add 0.2 hours if brake/clutch fluid •...
Page 191: Servicing
Chapter ·12 3Q SERVICING COOLANT - replace POLLEN FILTER (if fitted)-replace DRIVE BELTS - check FUEL FILTER-replace ENGINE OIL AND FILTER-replace POWER STEERING-check fluid level AUTO TRANS check fluid level. LEAKAGE -visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT- check WINDSCREEN WIPE/WASH system -check fluid level and blade condition...
Page 192 Chapter 12 12 31 SERVICING I authorise performance of the services 165,000 km specified on the rear of this coupon. I understand I will be charged for the following 11 years hours of labour: SERVICE COUPON 1.5 hours labour • add 0.2 hours if brake/clutch fluid "0 •...
Page 193 Chapter 12 32 SERVICING COOLANT -check level, check coolant DRIVE BELTS -check ENGINE OIL AND FILTER- replace POWER STEERING -check fluid level LEAKAGE -visual check of engine and trans LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARKBRAKE ADJUSTMENT-check WINDSCREEN WIPE/WASH system - check fluid level and blade condition DOOR HINGES, DOOR STOP, BONNET LOCK, TAILGATE HINGES-lubricate...
Page 194 Chapter 12 33 SERVICING I authorise performance of the services 180,000 km specified on the rear of this coupon. I understand I will be charged for the following 12 years hours of labour: SERVICE COUPON hours labour • hours if brake/clutch fluid •...
Page 195 Chapter 12 34 SERVICING COOLANT - check level, check coolant% POLLEN FILTER (if fitted)- replace DRIVE BELTS check AIR CLEANER paper element- replace SPARK PLUGS- replace FUEL FILTER- replace ENGINE OIL AND FILTER- replace POWER STEERING - check fluid level AUTO TRANS - check fluid level.
Page 196 ..........Dealers (Authorised Holden) 9-12 .
Page 198 INDEX Locks Paintwork cleaning 11-4 ....Bonnet 1-20 Park brake lever 3-18 ........
Page 199 INDEX Speedometer Warning lights ............. Sporty drive Warranty Certificate .

This manual is also suitable for:

Zafira 2001

HOLDEN TT 2001 Series Owner's Handbook Manual

Quick Links

Need help?

Questions and answers

Related Manuals for HOLDEN TT 2001 Series

Summary of Contents for HOLDEN TT 2001 Series

This manual is also suitable for:

Table of Contents
