TS series Handbook supplement.
This supplement provides additional information about the Astra
three door City and SRi models.
This supplement should be kept together with the Owner1S Handbook,
in the glovebox of your car.
HOLDEN
holden .com
www.
.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Astra City 2001 and is the answer not in the manual?

Questions and answers

Related Manuals for HOLDEN Astra City 2001

Summary of Contents for HOLDEN Astra City 2001

  • Page 1 TS series Handbook supplement. This supplement provides additional information about the Astra three door City and SRi models. This supplement should be kept together with the Owner1S Handbook, in the glovebox of your car. HOLDEN holden .com www.
  • Page 2 © 2001 Holden Ltd. Reproduction of this booklet in whole or part is prohibited without written approval from Holden Ltd. A.C.N. 006 893 232 Part No. 92107040...

  • Page 3: Table Of Contents

    Contents Engine oil level - SRi ....... Manual transmission ....... . . Shift speeds - SRi .

  • Page 4: Engine Oil Level - Sri

    Engine oil level - SRi The engine oil dipstick is located at the front of the engine. Oil level should be maintained between the 'Min' and 'Max' markings on the dipstick. For further information on checking the oil level, refer to page of the Manual transmission door models with...

  • Page 5: Shift Speeds- Sri

    Shift speeds- SRi Manual transmission change speeds The chart shows the Gear recommended change change Economy Normal speeds at which gear c h a n g e s should 1 st,..., 2 nd 15 km/h 20 km/h m a d e during n o rmal driving for SRi models.

  • Page 6: Rear Seat Access

    Rear seat access To gain access to the rear seat, a lever is provided at the outer side of each front seat. Pull up the lever; tilt the seat-back forwards and then slide the whole seat forwards. To reposition the seat, first push seat...

  • Page 7: Front Electric Windows - Sri

    Front electric windows - SRi To avoid risk to children (through incorrect use of electric windows), the driver should remove the key from the ignition when leaving the car. The main switches for the windows are located in the driver's door. An individual switch located on the passenger...

  • Page 9: Isovin

    ISOVIN The ISOVIN is explained in Chapter 8 of your Astra Handbook. However, please note that as part of the ISOVIN, your car carries a different code for the body style which is applicable to all 3 door models. Weights CARRYING CAPACITY The recommended carrying capacity of your car is 445 kg, which includes 5 occupants and luggage.

  • Page 10: Dimensions

    Dimensions City Overall length 4,110 mm 4,110 mm Overall width, 1,967 mm 1,967 mm - including mirrors Overall height, 1,429 mm 1,429 mm - at curb Track 1,464 mm -Front 1,484 mm 1,452 mm - Rear 1,472 mm Wheel base -at curb 2,614 mm 2,614 mm -atGVM...

  • Page 11: Extreme Operating Conditions- Sri

    Holden Dealer. Change automatic transmission fluid @ 60,000 km or 4 years (whichever comes first)

  • Page 12: Petrol Requirements - Ron

    A3. Viscosity grade 15W-40 or 15W-50. Refill oil capacity 5 litres approximately (inc. filter) Power steering fluid type Hydraulic fluid Holden specification number HN2305 (Pentosin CHF 11 S Hydraulic fluid). Fuel tank capacity 52 litres Coolant capacity 6.8 litres approximately...
