Page 1 XC Series Owner’s Handbook www.holden.com.au...
Page 3: Table Of Contents
Specifications 8 8 8 8 8 Engine specs, transmission specs, dimensions, vehicle identification number, identification plates and labels. After Sales 9 9 9 9 9 Warranty, Roadside Assistance, Holden Dealers, Customer Assistance. Loading 10 Loading information, towing recommendation. Cleaning 11 Interior cleaning, exterior cleaning, list of cleaning materials.
Page 4 We thank you for choosing Holden and want to assure you of our continuing interest in your motoring pleasure and satisfaction and compliment you on your choice. This handbook applies to all the current Barina models. Therefore, due to different models and...
Page 5 Holden requires these details in order to contact the operator in the event of a safety recall and to keep the initial 3 year Roadside Assistance details up to date (refer Chapter 9).
Page 6 Place in an envelope and mail to: The Manager - Warranty Administration Service Department Holden Limited Box 548D, G.P.O. Melbourne Victoria, 3001...
Page 7 Holden requires these details in order to contact the operator in the event of a safety recall and to keep the initial 3 year Roadside Assistance details up to date (refer Chapter 9).
Page 8 Place in an envelope and mail to: The Manager - Warranty Administration Service Department Holden Limited Box 548D, G.P.O. Melbourne Victoria, 3001...
Page 9 Holden requires these details in order to contact the operator in the event of a safety recall and to keep the initial 3 year Roadside Assistance details up to date (refer Chapter 9).
Page 10 Place in an envelope and mail to: The Manager - Warranty Administration Service Department Holden Limited Box 548D, G.P.O. Melbourne Victoria, 3001...
Page 11 Dashboard The following page illustrates the dashboard, identifying gauges, warning lights, controls and switches. Page reference numbers are listed next to each item. Page Dashboard layout Tilt steering Horn Gauges Warning/reminder lights Wipers and washers Exterior lights 1-11 Radio / CD player 1-12 Ventilation and heating 1-15...
Page 12 Chapter 1 DASHBOARD LAYOUT Page Page 1 Side vents 1-12 13 Bonnet release 1-19 2 Front passenger's air bag 6-14 14 Audio switches, right side 1-11 3 Audio system 1-11 15 Ignition switch 1-20 4 Hazard warning flasher 1-10 16 Steering tilt adjustment 5 Triple info display 1-18 17 Driver's air bag...
Page 13 Chapter 1 DASHBOARD TILT STEERING AND HORN Tilt steering (if fitted) The lock lever is located directly beneath the ignition lock. Move the lock lever downwards. Grasp the steering wheel and move as required. It can be moved up or down. When in position, move the lock lever back up as far as it will go.
Page 14 Chapter 1 DASHBOARD GAUGES Speedometer The speedometer indicates vehicle speed in kilometres per hour. Odometer / tripmeter / service reminder A small window in the speedometer is used for the odometer, the tripmeter, and the service reminder. The odometer and the tripmeter can be made to appear for a few seconds when the ignition is OFF by pressing the reset knob.
Page 15 Chapter 1 DASHBOARD GAUGES cont. Engine temperature gauge NEEDLE IN ZONE AT LEFT = Engine has not reached operating temperature. NEEDLE BETWEEN ZONES = Engine is at normal operating temperature. NEEDLE IN ZONE AT RIGHT = Engine temperature is too high. Stop the car as soon as it is safe to do so.
Page 16 If it lights up during driving then the battery is not being charged properly (engine cooling may also be affected). You should see a Holden Dealer as soon as possible. Brakes, hydraulic clutch Lights up for a few seconds when ignition is switched on.
Page 17 If illuminated during driving, immediately stop the car and switch off the engine. Check the engine oil level. Do not drive with this light showing. If the oil level is normal, have the system checked at your nearest Holden Dealer. Starting-off aid (automatic transmission only) Lights up when the starting-off aid is switched on, refer to Chapter 4.
Page 18 Chapter 1 DASHBOARD WIPERS AND WASHERS Wipers and washers are operational when the ignition is ON. Windscreen wipers Move the lever upwards. fast slow intermittent Setting intermittent wipe interval between 2 and 15 seconds: • Set lever to intermittent • Set lever to off •...
Page 19 Chapter 1 DASHBOARD EXTERIOR LIGHTS Light switch parking lights headlights and parking lights press the light switch to turn on and off the interior light turn the thumb wheel to adjust instrument illumination High/low beam When the headlights are switched on, push the lever away from you, then release.
Page 20 Chapter 1 1-10 DASHBOARD EXTERIOR LIGHTS cont. Rear fog lights The push button for the rear fog lights is located below the headlight switch beside the instrument dimming switch. Push the button to switch on or off. The symbol in the instrument panel glows when the fog lights are working.
Page 21 Chapter 1 1-11 DASHBOARD RADIO / CD PLAYER Radio / CD player operation The radio will stay ON until the key is removed from the ignition. Therefore, remember to remove the key when leaving the car for any length of time or you may flatten the battery.
Page 22 Chapter 1 1-12 DASHBOARD VENTILATION Ventilation air inlet The car features a flow through ventilation system for your comfort. Under reasonable conditions, it shouldn’t be necessary to open the windows at any time. Outside air is drawn into the car through the opening at the base of the windscreen.
Page 23 Chapter 1 1-13 DASHBOARD VENTILATION AND HEATING Temperature dial Anti-clockwise = cool Clockwise = warm Fan dial OFF plus four fan speeds are provided. Note that the rate of air flow is determined by car speed, as well as by the fan. Vent dial air from demist vents air from demist and foot vents...
Page 24 Chapter 1 1-14 DASHBOARD VENTILATION AND HEATING cont. Air intake button Push the button to switch between re- circulated and outside air. The light in the switch glows when recirculate is selected. When following another car on dusty roads, or to prevent exhaust fumes or odours entering your car, press the button to the recirculation position (light in switch showing).
Page 25 Chapter 1 1-15 DASHBOARD AIR CONDITIONING (if fitted) Air conditioning not only cools the air but also removes moisture. If the temperature dial is moved away from extreme cold, the air will then be reheated before entering the cabin. The air conditioner is switched on by pushing the button with the snowflake symbol. A light in the switch will glow when the air conditioner is operating.
Page 26 Chapter 1 1-16 DASHBOARD DEMISTING Windscreen demisting • air conditioning switch ON (if fitted) • air intake button to fresh Note: air intake will automatically switch from recirculation to fresh air when vents dial is rotated to demist mode. • temperature dial to hot •...
Page 27 Chapter 1 1-17 DASHBOARD ASHTRAYS AND CIGARETTE LIGHTER Cigarette lighter The cigarette lighter works when the ignition is switched on. Push the cigarette lighter inwards to heat. The lighter will automatically pop out when heated and ready to use. Front ashtray To open, lift the front of the cover upwards.
Page 28 3° C. "--.-° C" or an "F" on the display indicates a fault in the system and you should see your Holden Dealer. Note that a fall in temperature is indicated immediately, and a rise in temperature after...
Page 29 Chapter 1 1-19 DASHBOARD BONNET RELEASE From inside the car, pull the lever towards you. This allows the bonnet to release but is prevented from opening by the safety catch. To open completely, locate the bonnet lever on the right-hand side and lift it upwards while lifting the bonnet.
Page 30 Chapter 1 1-20 DASHBOARD IGNITION SWITCH Ignition • LOCK: Ignition off, steering locked when key is removed. OFF: Steering unlocked, ignition off. ON: Ignition on. START: Start the engine. Release steering column lock To release the lock, move the steering wheel slightly and turn the key to position I. Lock steering column •...
Page 31 Chapter 1 1-21 DASHBOARD NOTES...
Page 32 Chapter 1 1-22 DASHBOARD...
Page 33 Locks Page Keys and locks Child safety rear door switch Electric door locks Door locks and deadlocking The remote control Tailgate...
Page 34 If you have problems contact your Holden Dealer. Remember that your car is covered for the first 3 years by Roadside Assist, refer to Chapter 9.
Page 35 Chapter 2 LOCKS ELECTRIC DOOR LOCKS Emergency – flat battery Unlocking and locking the driver's door in the event of malfunction of the central locking system (e.g. if the car's battery is flat). (A) To unlock: Turn key in driver's door lock towards front of car, turning it beyond its resistance point until it will not move any further.
Page 36 Chapter 2 LOCKS DOOR LOCKS AND DEADLOCKING Locking the car Press the rear button of remote control or turn the key in driver's door. This locks the doors, tailgate and fuel tank filler flap. The light-emitting diode (LED) in the remote control lights up and the hazard warning lights flash briefly to show that the remote control is operational.
Page 37 Chapter 2 LOCKS DOOR LOCKS AND DEADLOCKING cont. Unlocking the driver's door only Direct the remote control towards car, press the front button on the remote control unit once, alternatively, turn the key in driver's door once towards the front of the car, then turn it back to the vertical position and remove.
Page 38 Chapter 2 LOCKS THE REMOTE CONTROL The remote control • The remote control is powered by a battery inside the key head. A weakening battery is indicated by a progressive "loss of range", which means you must be closer to the car when pressing the key.
Page 39 Chapter 2 LOCKS THE REMOTE CONTROL cont. Synchronizing the remote control In the event of malfunctions, synchronise the remote control: • Switch on ignition; system will then remain in synchronising mode for 30 seconds. • Briefly press any button on the remote control unit while the key is in the ignition.
Page 40 Chapter 2 LOCKS TAILGATE The central locking system cannot be switched on or off from the tailgate lock. Provided that the key slot is horizontal, the tailgate will lock/unlock when the doors are locked/unlocked. To keep tailgate permanently locked (regardless of door lock position) turn the key slot to the vertical position.
Page 41 Know your Page Front seat adjustment Head restraint adjustment Seat folding – front and rear seats Seat belts Child restraints 3-10 Park brake 3-10 Dome (Interior) light 3-10 Reading lights 3-11 Luggage compartment light 3-12 Mirrors 3-12 Windows 3-13 Transporting objects 3-14 Convenience features...
Page 42 Chapter 3 KNOW YOUR CAR FRONT SEAT ADJUSTMENT Forward/rearward Pull the handle up at the front of the seat then slide the seat forward or backward. After releasing the handle try to move the seat back and forth to check that the catch has locked in position.
Page 43 Chapter 3 KNOW YOUR CAR HEAD RESTRAINT ADJUSTMENT Head restraint adjustment To adjust the head restraint height hold the restraint firmly at the top, tilt it forwards, lift up or push down and then release. Head restraint height The upper edge of the head restraint should be approximately level with the top of the head –...
Page 44 Chapter 3 KNOW YOUR CAR SEAT FOLDING Front seat folding (2 Door) To allow easy entry and exiting of the rear seating positions, fold the front seat forward by pulling the lever upward. Rear seat backrest folding To avoid injury from passing traffic, don't stand on the road side of the car when converting the rear seat.
Page 45 Chapter 3 KNOW YOUR CAR SEAT FOLDING cont. Luggage compartment enlargement As shown on the previous page, place the tongues of the seat belts into the holders provided on the side trim. Remove the rear seat from the floor by grasping at the front edge in the areas indicated by the arrows and pulling it upwards.
Page 46 Actuation may also be indicated by yellow tabs on the belt buckles. If the belt pre-tensioners have been activated they must be replaced by a Holden Dealer. The seat belts remain operational even when the belt pre-tensioners have been actuated.
Page 47 Chapter 3 KNOW YOUR CAR SEAT BELTS cont. Seat belt height adjustment of front seat belt upper anchorage points: Do not adjust height while driving • tilt belt guide inward at top • slide belt guide to desired height and release •...
Page 48 Only approved child restraint harnesses should be used on anchorage points. See your Holden Dealer for advice about the various types of approved child restraints available. INFANTS UNABLE TO SIT BY THEMSELVES should be carried in an approved child seat restraint.
Page 49 Then, install an additional anchor fitting, using the bolt, spacers and washer supplied with a child seat, as per the illustration below. Ensure that the bolts (inner or outer positions) are securely tightened, to 15~25 Newton metres, if unsure refer to your Holden Dealer.
Page 50 Chapter 3 3-10 KNOW YOUR CAR PARK BRAKE AND INTERIOR LIGHTS Park brake To apply, pull the lever straight up. To release, pull the lever slightly upwards, push in the release button on the end of the lever and whilst depressed, lower the lever all the way down.
Page 51 Chapter 3 3-11 KNOW YOUR CAR PARK BRAKE AND INTERIOR LIGHTS cont. Rear reading light (4 Door) Switch to left = Off Switch to right = On Switch to centre = Comes on when a rear door is opened. Luggage compartment light On the passenger side of the luggage compartment, a light comes on when the tailgate is opened.
Page 52 Chapter 3 3-12 KNOW YOUR CAR MIRRORS AND WINDOWS Internal rear view mirror Grasp the mirror and swivel to adjust height. Swivel the lever on the lower edge of the mirror to reduce dazzle at night. Exterior mirrors Grasp the lever inside the car and move the mirror up/down and in/out as required.
Page 53 Chapter 3 3-13 KNOW YOUR CAR TRANSPORTING OBJECTS Long objects and tall objects Transporting long objects can be done by folding the rear seat backrests forward as previously described in this Chapter. Bulky objects that cause the tailgate to be open or ajar should not be transported as exhaust fumes may enter the car.
Page 54 Chapter 3 3-14 KNOW YOUR CAR CONVENIENCE FEATURES Glasses holder (if fitted) Above the driver's door, a holder is provided to store sun-glasses or reading glasses. Fold down to open. Coin holder Slots for storing six coins are provided below the ashtray on the centre console. Glovebox with pen holder To open the glovebox, pull the opener upwards.
Page 55 Chapter 3 3-15 KNOW YOUR CAR CONVENIENCE FEATURES cont. Floor tray (if fitted) A floor tray is provided under the front passenger's seat. To open, lift the tray by grasping recessed edge and pull forwards. To close, push the tray all the way in to lock in place.
Page 56 Chapter 3 3-16 KNOW YOUR CAR...
Page 57 Driving Page 4-2 Engine starting 4-2 Running-in 4-3 Safety 4-4 Automatic transmission 4-7 Manual transmission 4-8 Driving precautions 4-8 Snow chains...
Page 58 Chapter 4 DRIVING ENGINE STARTING 1. Apply the park brake firmly and release only after you have started the engine and are ready to drive off. 2. MANUAL: Depress the clutch pedal and shift the gear lever to Neutral position. The clutch pedal can now be released.
Page 59 Chapter 4 DRIVING SAFETY Before entering the car 1. Check that windows, mirrors and lights are clean. 2. Check tyres are not flat. Before driving off 1. Be sure that all doors are secured. 2. Position your seat for comfortable driving. 3.
Page 60 Chapter 4 DRIVING AUTOMATIC TRANSMISSION T-bar selector position indicator When the ignition is on, the current T-bar position is displayed on the instrument cluster below the tachometer. The engine will not start unless the T-bar selector is in “P” or “N”. To move out of P position, switch on the ignition, depress the brake pedal and raise the gear selection release under...
Page 61 Chapter 4 DRIVING AUTOMATIC TRANSMISSION cont. Starting-off aid (slippery conditions) In the event of starting-off difficulties in slippery conditions, press the button shown. The T-bar must be in P,R,N,D or 3. If the starting-off programme is selected, the indicator light on the instrument cluster will be illuminated.
Page 62 Fault Mode. In Fault Mode the gears are as follows: 1 = 1st gear 2 = 3rd gear 3 = 4th gear D = 4th gear N = Neutral R = Reverse gear P = Park Consult a Holden Dealer as soon as possible if a fault is indicated.
Page 63 Chapter 4 DRIVING MANUAL TRANSMISSION This system has 5 forward gears and a reverse gear. The shift pattern illustrated, is found on the top of the gear shift lever. When selecting fifth gear you must shift the gear lever sideways against light spring pressure in order to pass into the gear.
Page 64: Driving 4 4 4 4
Chapter 4 DRIVING DRIVING PRECAUTIONS Brakes • Power assisted brakes, which are fitted to your car, utilise vacuum from the engine when it is running. Never let the car run down steep grades without the engine running. Never coast with the engine switched off. •...
Page 65 Chapter 4 DRIVING NOTES...
Page 66 Chapter 4 4-10 DRIVING...
Page 67 Fuel Page Carbon monoxide caution Petrol filling Fuel tank capacity Emission control Reducing fuel consumption...
Page 68 – whenever a change is noticed in the sound of the exhaust system, – whenever the exhaust system, underbody or rear of the car is damaged. Take the car to your Holden Dealer if you think your car needs inspecting for any of the above reasons.
Page 69 Chapter 5 FUEL PETROL cont. CAUTION: • Petrol should be regarded as extremely flammable and highly explosive. • Always turn off the engine and any mobile phones when refuelling. • Do not smoke or allow open flames or sparks near the car when refuelling. •...
Page 70 Chapter 5 FUEL PETROL cont. Tank capacity = 45 litres Petrol filler nozzle restrictor To help the atmosphere, your car has been designed to operate on UNLEADED PETROL. A petrol nozzle restrictor is fitted to ensure that only UNLEADED petrol is used.
Page 71 Maintenance schedule in Chapter 12. It is recommended that the necessary servicing be performed by an authorised Holden Dealer who has the specialised servicing equipment and trained personnel available to ensure that the adjustments and services specified are carried out.
Page 72 Chapter 5 FUEL REDUCING FUEL CONSUMPTION Engine Maintain the engine in peak mechanical condition by having it serviced regularly in accordance with the Maintenance schedule in Chapter 12. This will ensure items such as the spark plugs, air cleaner, etc. are maintained for minimum fuel usage and peak engine performance.
Page 73 Emergencies Page Accidents Medical assistance Flat tyre Towing a disabled car 6-10 Engine overheating 6-12 Flat battery 6-14 Air bags 6-16 Bulb replacement 6-24 Fuses Your new car is covered for 3 years by 24 hour Roadside Assistance, refer Chapter 9.
Page 74 Chapter 6 EMERGENCIES ACCIDENTS All motorists are advised to learn what to do at the scene of an accident, particularly where persons are injured. Injured people can choke to death if their air passages are not cleared. They can bleed to death unless the bleeding is stopped. They may require mouth-to-mouth resuscitation or may have to be moved, even though badly injured.
Page 75 Chapter 6 EMERGENCIES ACCIDENTS cont. Part 3. Medical assistance This information is basic first aid information which is intended as a guide only and may not be applicable in all situations. You should always defer to a trained medical officer or other person with first aid knowledge. Protective equipment such as rubber gloves are recommended.
Page 76 Chapter 6 EMERGENCIES FLAT TYRE If using a jack other than the one supplied with the car, refer to Chapter 7 for lifting positions. CAUTION: • Use the jack only for lifting the car when changing wheels. • Never get beneath the car when it is only supported by the jack. •...
Page 77 Chapter 6 EMERGENCIES FLAT TYRE cont. 5. Chock the wheel diagonally opposite the flat tyre by placing wedge blocks, any available blocks of wood or rocks behind and in front of it. 6. Remove the wheel trim. Steel wheels (if fitted): For cars with wheels covers, remove by hand, using the tool provided in the car tool kit.
Page 78 Chapter 6 EMERGENCIES FLAT TYRE cont. 8. Depressions on the lower edge of the vehicle underbody indicate the points where the jack is to be placed. CAUTION: Failure to position the jack as described above could result in serious personal injury or car damage caused by the car slipping off the jack. 9.
Page 79 Chapter 6 EMERGENCIES FLAT TYRE cont. 12. Remove the wheel from the car and change it over with the spare. 13. Replace the wheel bolts and tighten by hand. Then, with the wheel wrench, lightly tighten in a crisscross sequence. 14.
Page 80 Chapter 6 EMERGENCIES TOWING A DISABLED BARINA Proper lifting or towing equipment is necessary to prevent damage during any towing operation of the car. State and Local laws must be followed. In an emergency, your car may be towed on all four wheels in the following manner: •...
Page 81 Chapter 6 EMERGENCIES TOWING A DISABLED BARINA cont. Barina with automatic transmission For safety reasons, the transmission has an electric PARK lock so that the key must be in the ignition (in the ON position) before the T-bar can be moved away from the "P"...
Page 82 Chapter 6 6-10 EMERGENCIES ENGINE OVERHEATING CAUTION: Immediate action is required if the engine overheats. This can be indicated by the temperature gauge needle moving to the red zone, by steam escaping from under the bonnet, a loss of power or a loud knocking or pinging noise. Continued driving EVEN FOR A SHORT TIME could cause a fire or car damage.
Page 83 If the surge tank is low a leak is indicated. Therefore you should see your Holden Dealer as soon as possible to fix the leak. The engine may temporarily operate at high temperatures during more demanding operating conditions, especially on very hot days.
Page 84 Chapter 6 6-12 EMERGENCIES FLAT BATTERY CAUTION: DO NOT attempt to "push start" this car, as it is fitted with a catalytic converter and if un-combusted fuel were to reach the catalytic converter and ignite, the converter could overheat or be destroyed by backfire. If your car will not start due to a flat battery, it can often be started by using energy from a battery in another car - a procedure called "jump starting".
Page 85 Chapter 6 6-13 EMERGENCIES FLAT BATTERY cont. • The battery of your car has a negative earth and a 12 volt rating. The battery in the other car must be the same voltage and also have a negative earth. The battery capacity of the charged battery must not be substantially lower than that of the discharged battery.
Page 86 ON, or if it comes on when driving, you rollovers...always wear a seat belt. should contact your Holden Dealer, as they may not function correctly, especially in an accident.
Page 87 After use the whole air bag system will have to be replaced. It is recommended that the work be done by your Holden Dealer. The system should also be inspected by a Holden Dealer if the steering wheel or dash board area is scratched, cracked or damaged. Remember that the horn pad must not be covered with adhesive or any other material, as this may hinder air bag operation.
Page 88 However, because headlight aiming is a safety item it is recommended that you have it carried out by your Holden Dealer. On cars fitted with headlight range adjustment, the headlight aiming must be carried out with the switch in position 0.
Page 89 Chapter 6 6-17 EMERGENCIES BULB REPLACEMENT cont. Headlights, low beam 1. Open bonnet and engage support. 2. Rotate bulb holder anti-clockwise and remove from reflector. 3. Detach bulb from bulb holder and install new bulb without touching the glass. 4. Install holder into reflector ensuring that the two lugs on the holder engage in the recesses of the reflector.
Page 90 Chapter 6 6-18 EMERGENCIES BULB REPLACEMENT cont. Headlights, high beam 1. Open bonnet and engage support. 2. Rotate headlight cap anti-clockwise and remove from headlight housing. 3. Remove bulb connector from bulb. 4. Disengage spring wire clip from retaining lugs by moving it sideways and swivelling downwards.
Page 91 Chapter 6 6-19 EMERGENCIES BULB REPLACEMENT cont. Front turn signal lights 1. Open bonnet and engage support. 2. Rotate bulb holder anti-clockwise and disengage. 3. Press bulb into holder slightly, turn anti-clockwise and remove. 4. Insert new bulb and engage holder in reflector by turning.
Page 92 Chapter 6 6-20 EMERGENCIES BULB REPLACEMENT cont. Tail, brake, rear turn signal, reverse lights 1. Unscrew the two screws from the rear lens assembly using a screwdriver. 2. Pull the lens assembly rearward to disengage it from its locking elements. 3.
Page 93 Chapter 6 6-21 EMERGENCIES BULB REPLACEMENT cont. Number plate light 1. Insert screwdriver vertically into the side of the lens on right-hand side, press towards the right and disengage spring. 2. Remove the number plate light downwards and clear of the rear bumper.
Page 94 Chapter 6 6-22 EMERGENCIES BULB REPLACEMENT cont. Rear reading light (if fitted), and luggage compartment light Before removal, close the doors or make sure that the contact switch is kept depressed so that the light is not live. 1. Carefully prise light out of trim, using a screwdriver.
Page 95 2. Remove bulb from socket. 3. Insert new bulb. 4. Mount lens and engage into position. Bulb replacement procedures for the following lights should be carried out by a Holden Dealer: • Centre high mounted stop light • Fog lights •...
Page 96 Chapter 6 6-24 EMERGENCIES FUSES The fuses are located between the passenger side headlight and the coolant surge tank. To open the fuse compartment, press the retaining clip towards the compartment lid and lift the lid upwards. Remove the lid completely to access the fuses.
Page 97 Chapter 6 6-25 EMERGENCIES FUSES cont. To help in replacing fuses, there is a special fuse gripping tool (white) located beside the spare fuses in the fuse box. Before replacing a fuse, turn off the respective switch and remove the ignition key.
Page 98 Chapter 6 6-26 EMERGENCIES FUSES cont. 35 Radio Central control unit 7.5A 36 Dipped beam (left) Engine control unit 7.5A 37 Dipped beam (right) Instruments, horn, 38 Park and tail lights (left) information display, 39 Park and tail lights (right) hazard warning flashers 7.5A 40 –...
Page 99 Chapter 6 6-27 EMERGENCIES FUSES cont.
Page 100 Chapter 6 6-28 EMERGENCIES...
Page 101: Weekly Checks 7 7 7 7
Weekly checks Page Miscellaneous checks Engine oil level Engine coolant level Brake fluid level Auto transmission fluid level Washer fluid level Battery Tyres...
Page 102 Chapter 7 WEEKLY CHECKS MISCELLANEOUS CHECKS As well as taking your car to be serviced (refer to Chapter 12) there are a few simple, weekly checks that the owner/operator is required to make. These are shown on the following pages. The following checks should also be regularly done to ensure proper safety and dependability of your car.
Page 103 New Vehicle Warranty, to the extent that Holden considers the non-recommended fluid to have affected the specifications or quality of your Holden vehicle.
Page 104 -30°C, provided the correct concentration is maintained. If you regularly have to top up the cooling system, you should see your Holden Dealer. CAUTION: Corrosion inhibitors and antifreeze fluids are poisonous. Use extreme care when handling.
Page 105 The fluid level for automatic transmission will be checked for you when your car is taken to your Holden Dealer for servicing, refer to Chapter 12. The automatic transmission fluid level does not require checking by the driver in between these...
Page 106 To fill, open the flip top cap. For a crystal clear windscreen, a small amount of Optikleen (Part No. 92140005 from your Holden Dealer) can be added. Do not use ordinary soap or detergent. These not only froth up but will also damage the wiper rubbers and may also block the washer jets.
Page 107 Out-of-balance wheels and tyres can cause annoying vibration and uneven tyre wear such as cupping and flat spots. If you have any reason to suspect that either of the above problems exist then have a wheel alignment and balance check done by your Holden Dealer.
Page 108 Tyre condition will be checked for you when you take your car to be serviced by your Holden Dealer, who will be able to diagnose any unusual signs of wear. If the tyres are rotated it is recommended that the balance be checked at the same time.
Page 109 Chapter 7 WEEKLY CHECKS TYRES cont. Tyre replacement and repair CAUTION: Do not mix different tyre construction types, such as radial and cross ply, on your car except in emergencies, because your car’s handling could be affected and may result in loss of control. When replacing tyres you should use the same size, load rating and construction type as the original tyres on your car.
Page 110 Chapter 7 7-10 WEEKLY CHECKS...
Page 111: Specifications 8 8 8 8
Specifications Page Engine specifications Transmission specifications Dimensions Battery Identification labels Tyre placard...
Page 112 Chapter 8 SPECIFICATIONS SPECIFICATIONS Engine type Z14XE, 16 valve DOHC Piston displacement 1,389 cc Compression ratio 10.5:1 Bore 77.6 mm Stroke 73.4 mm Power * 66 kW @ 6,000 r.p.m. (91 R.O.N. fuel) Torque * 120 Nm @ 4,000 r.p.m. (91 R.O.N. fuel) Oil specification ACEA service classification A3-98/ B3-98 Viscosity grade 5W-40 or 10W-50...
Page 113 4 speed auto transmission transmission Fluid capacity 1.6 litres 5 litres (total) Fluid type Gear oil, meeting Auto trans fluid Holden spec. meeting Holden No. HN2354 spec. No. HN2287 (Castrol SMX-O (Esso JWS or equivalent) 3305G) Clutch fluid Heavy duty...
Page 114 Chapter 8 SPECIFICATIONS IDENTIFICATION LABELS Vehicle identification number (I.S.O.V.I.N.) A unique I.S.O.V.I.N. Number (example below) has been allocated to your car. This number can be used for model identification when purchasing parts. W0L 0 XC F08 1 4 000201 Sequential Production Serial Number Assembly Plant Code, can be alpha or numeric Model Year Code: 1=2001, 2=2002, 3=2003 Body Style: F08=2 door, F68=4 door...
Page 115 The SAFETY COMPLIANCE plate is located inside the engine bay, attached to the firewall on the driver's side. Holden identification plate The HOLDEN IDENTIFICATION plate is located on the passenger's side of the radiator support panel. The Holden number is used for warranty identification, Roadside Assistance identification etc.
Page 116 Chapter 8 SPECIFICATIONS...
Page 117: After Sales 9 9 9 9
New Vehicle Warranty Parts and Accessories Warranty Warranty Questions & Answers Roadside Assistance 9-10 Customer Assistance 9-11 For New Zealand Holden Owners 9-12 Australian Holden Dealers 9-26 New Zealand Holden Dealers Note: Dealership names and details may change after the printing of this Handbook.
Page 118 AFTER SALES NEW VEHICLE WARRANTY CERTIFICATE New Vehicle Warranty application This Warranty is given by Holden Ltd, A.C.N. 006 893 232, ("Holden"). The Warranty applies to the vehicle identified on the inside front cover of this Owner's Handbook. It is provided to the original and subsequent owners/operators driving the vehicle within Australia during the Warranty Period.
Page 119 (c) failure to carry out proper maintenance services, (d) use of incorrect types and grades of fuel, oil or lubricants, (e) alteration of the vehicle by anyone not authorised by Holden, (f) fitting of parts or accessories not marketed by Holden, (g) any work carried out on the vehicle by anyone except a Holden Dealer or authorised Service Outlet.
Page 120 Purchased at retail or trade Parts and Accessories purchased at trade or retail and installed by other than a Holden Dealer or authorised Service Outlet are warranted for 1 year from the date of purchase. Please keep a receipt to support warranty claims.
Page 121 Vehicle Warranty) is required to enable your vehicle to be operated safely and it is not practical for you to go to an Authorised Holden Dealer, the service (to the extent that it is necessary to enable your vehicle to be operated safely) may be performed by any other qualified mechanic or repairer.
Page 122 Q 5. Will I have to pay for maintenance costs during the Warranty Period? Maintenance costs are not covered by the Holden New Vehicle Warranty. The Maintenance Schedule in Chapter 12 specify the minimum maintenance required for your vehicle operating under normal conditions.
Page 123 Holden Dealer it is your responsibility to deliver your vehicle to the servicing Holden Dealer’s premises. If, as a result of a defect which is covered by the Holden New Vehicle Warranty, your vehicle cannot be driven safely and you arrange for the nearest Authorised Holden Dealer to carry out the required Holden Warranty service, Holden will accept reasonable towing costs to move your vehicle to the nearest Holden Dealer’s premises.
Page 124 Australia wide. We hope the need never arises, but if it does, we’ll be there to help through Holden Roadside Assistance. How does Holden Roadside Assistance work? Holden Roadside Assistance is provided by Holden Ltd., and delivered by the...
Page 125 Holden Roadside Assistance stays with the vehicle, so if you sell your vehicle during the 36 month period, it is still eligible for the balance of the Holden Roadside Assistance. The new owner simply registers for the service by using the change of ownership form supplied in the Roadside Assistance booklet.
Page 126: Customer Assistance
Manager or Service Manager - go to the General Manager or to the Dealer Principal. By now you should have satisfaction. If not, the Holden Customer Assistance office is at your disposal. The Australian Holden Customer Assistance representatives can be telephoned from anywhere within Australia for only the cost of a local call.
Page 127 AFTER SALES FOR NEW ZEALAND HOLDEN OWNERS The information in this Owner's Handbook applies primarily to Australian Holden vehicles and there may be some differences to the Warranty and Owner Assistance provisions for New Zealand. Applicable details for New Zealand are set out in the Holden Warranty and Owner Assistance Information booklet enclosed in the New Zealand glovebox wallet.
Page 128 P: (02) 9642 0233 Fax: (02) 9642 7798 Springwood Holden 15 Ferguson Road DEE WHY P: (02) 4751 1911 Fax: (02) 4751 2481 Peninsula Holden Dee Why Cnr May & Mooramba Roads ST LEONARDS P: (02) 9982 1311 Fax: (02) 9982 3755 Hunter Holden...
Page 129 Chapter 9 9-13 AFTER SALES AUSTRALIAN HOLDEN DEALERS CONT. WINDSOR CARDIFF Hawkesbury Valley Holden Brian Kelly Holden 18 Macquarie Street 35~39 MacQuarie Road P: (02) 4577 4077 Fax: (02) 4577 2592 P: (02) 4954 7733 Fax: (02) 4954 9407 CASINO N.S.W.
Page 130 Chapter 9 9-14 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. DUNGOG Turner Holden Royce Curtis Motors 248 Dowling Street 168 Lachlan Street P: (02) 4992 1816 Fax: (02) 4992 1833 P: (02) 6993 1503 Fax: (02) 6993 2212 EDEN HOLBROOK Ron Doyle...
Page 131 Chapter 9 9-15 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. MAITLAND PARKES Heritage Holden Broderick Motors Holden Cnr New England Hwy & Bungaree St Cnr Mitchell & Clarinda Sts P: (02) 4932 0779 Fax: (02) 4932 0473 P: (02) 6862 2266 Fax: (02) 6862 1406...
Page 132 Chapter 9 9-16 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. WAGGA WAGGA A.C.T. Wagga Motors Pty Ltd 32 Dobney Avenue BELCONNEN P: (02) 6925 3411 Fax: (02) 6925 3283 Gerald Slaven Holden 2 Josephson Street WALCHA P: (02) 6251 5111 Fax: (02) 6253 1298...
Page 133 681 Chapel Street P: (03) 9784 4444 Fax: (03) 9784 4419 P: (03) 9827 2272 Fax: (03) 9826 5328 GEELONG SUNBURY R & B Smith Holden Sunbury Holden 510 Moorabool Street 93~95 Horne Street P: (03) 5222 2888 Fax: (03) 5221 3114...
Page 134 Chapter 9 9-18 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. COLAC Vic. Country Parker Bros. Motor Co ALEXANDRA 224 Murray Street Alexandra Total Automotive Services P: (03) 5231 5533 Fax: (03) 5231 3853 120 Grant Street DAYLESFORD P: (03) 5772 1588 Fax: (03) 5772 1978 K.R.
Page 135 Chapter 9 9-19 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. KYNETON RUTHERGLEN Mollison Motors Pty Ltd Jasper Bros Pty Ltd 167 Mollison Street 62 Main Street P: (03) 5422 3377 Fax: (03) 5422 3501 P: (02) 6032 8404 Fax: (02) 6032 8156...
Page 136 Chapter 9 9-20 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. WARRAGUL MOOROOKA Vin Rowe Holden John Sivyer Holden 3 Endeavour Street 1060 Ipswich Road P: (03) 5623 1362 Fax: (03) 5623 4314 P: (07) 3892 3344 Fax: (07) 3848 8866 WARRNAMBOOL MT.
Page 137 Chapter 9 9-21 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. BOWEN HERVEY BAY McDermott Holden Whitaker Holden 98 Herbert Street 96 Torquay Road P: (07) 4786 1430 Fax: (07) 4786 2903 P: (07) 4128 1722 BUNDABERG INGHAM Ross Gray Holden Devietti Holden...
Page 138 Chapter 9 9-22 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. NAMBOUR WARWICK Kallenbach Motors Deighton Motors Pty Ltd 139 Howard Street Grafton Street P: (07) 5441 3099 Fax: (07) 5441 3105 P: (07) 4661 2266 Fax: (07) 4661 1275 NANANGO N.T.
Page 139 Chapter 9 9-23 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. THEBARTON KIMBA Metro Holden R.J. Flavel Mechanical Repairs 1 Port Road 30 High Street P: (08) 8354 9555 Fax: (08) 8443 6855 P: (08) 8627 2555 Fax: (08) 8627 2044 VALLEY VIEW...
Page 140 Chapter 9 9-24 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. ROXBY DOWNS MORLEY Hayes Augusta Motors Metro Motors Holden 10 Gosse Street 212 Walter Road West P: (08) 8671 0100 Fax: (08) 8671 0950 P: (08) 9449 3522 Fax: (08) 9449 3596...
Page 141 Chapter 9 9-25 AFTER SALES AUSTRALIAN HOLDEN DEALERS cont. CARNARVON MERREDIN North West Autos Carson’s of Merredin 175 Robinson Street 112 Barrack Street P: (08) 9941 1159 Fax: (08) 9941 1363 P: (08) 9041 1444 Fax: (08) 9041 1765 COLLIE...
Page 142 Chapter 9 9-26 AFTER SALES NEW ZEALAND HOLDEN DEALERS GISBORNE Auckland Metropolitan Enterprise Cars (1992) Limited HENDERSON 323 Gladstone Street West City Holden P: (06) 867 8368 Fax: (06) 867 1280 435 Great North Road HAMILTON P: (09) 836 0097 Fax: (09) 837 5291...
Page 143 Chapter 9 9-27 AFTER SALES NEW ZEALAND HOLDEN DEALERS cont. NELSON TAURANGA Nelson Bays Holden Ebbett Tauranga 2 Selwyn Place Cnr. Wharf Street & Cameron Road P: (03) 545 7222 Fax: (03) 545 6057 P: (07) 578 2843 Fax: (07) 578 6044...
Page 144 Chapter 9 9-28 AFTER SALES...
Page 145: Loading
Loading Page 10-2 Loading the car 10-3 Towing...
Page 146 Roof rack loads For safety reasons and to avoid damaging the roof, only the roof rack approved by Holden for your car, should be used. The maximum allowable roof load is 100 kg (including the weight of the roof rack).
Page 147 Chapter 10 10-3 LOADING TOWING Your Barina is designed as a passenger car. It is not designed or intended to be used to tow a trailer or caravan. Towing may affect handling, durability and economy.
Page 148 Chapter 10 10-4 LOADING...
Page 149: Cleaning
Cleaning Page INTERIOR CLEANING 11-2 Upholstery 11-2 Vinyl (P.V.C.) fabrics 11-3 Cloth fabrics 11-3 Carpet 11-3 Seat belts 11-3 Interior glass EXTERIOR CLEANING 11-4 Paint inspection 11-4 Washing 11-5 Grease, oil & tar spots 11-6 Polishing 11-6 Wheels 11-7 Exterior glass 11-8 Cleaning products...
Page 150 Should dirt accumulate and become embedded in the material pattern, the following procedure is recommended. 1. Using lukewarm water and soap, or Holden Velour Fabric and Vinyl Cleaner, work up thick suds on a piece of cheesecloth, and apply to the surface. A soft bristle brush can be used to remove stubborn stains or dirt embedded in the grain of the material.
Page 151 Do not bleach or dye seat belts since this may severely weaken them. Cleaning interior glass The interior glass area of the car should be cleaned using Holden Glass Cleaner with a clean soft cloth. Care must be taken when cleaning inside the rear window so as not to damage the demister.
Page 152 Chapter 11 11-4 CLEANING CARING FOR PAINT To help preserve that shiny new car finish, special attention should be given to correctly treating those conditions that can damage the paint. Road bloom: If, over a long period of time, oils, dirt, exhaust and other pollutants are allowed to build up, they may combine to affect the paint finish.
Page 153 P.V.C. coating should be checked and if necessary, restored to perfect condition. Commercial bitumen and rubber materials can damage P.V.C. coating. Have all work on the underbody performed by a Holden Dealer, as it requires knowledge of the specified materials and experience concerning their application.
Page 154 Alloy wheels (if fitted) To preserve the original appearance of alloy wheels, keep them clean and free from build up of road dirt. Holden Wheel Cleaner can be used for cleaning alloy wheels. Do not use abrasive cleaners on alloy wheels.
Page 155 The blades can be cleaned by lifting them off the windscreen and cleaning with Holden Optikleen and a clean cloth.
Page 156 Chapter 11 11-8 CLEANING CLEANING PRODUCTS HOLDEN PART SIZE DESCRIPTION USAGE NUMBER 92141386 500 ml Polymer glaze Seals in a deep, lustrous glazed finish. polish Long life protection from oxidation, salt and weather damage. M38424 400 g Velour fabric and Cleans and deodorises velour, most...
Page 157: Servicing
Servicing Page 12-2 Service intervals 12-3 Service light 12-4 Extreme operating conditions 12-6 Maintenance schedule 12-8 Service times 12-9 Service coupons...
Page 158 SERVICING SERVICE INTERVALS When it comes to service, remember that your Holden Dealer has the trained personnel and specialised equipment to correctly service your vehicle. Your Dealer invites you to return for all your service needs both during and after the warranty period.
Page 159 Chapter 12 12-3 SERVICING SERVICE LIGHT A small window in the speedometer is used for the odometer, tripmeter and the service reminder. The service reminder will show "InSP" (inspection required) for a few seconds when the ignition is turned ON if the car is within 500 km or one week of the next service.
Page 160 If at any time it is considered that the above items or other items should be more frequently serviced due to the type of operation or before a long trip, discuss the situation with the service manager of your Holden Dealer. Change automatic transmission fluid @ 60,000 km...
Page 161 Chapter 12 12-5 SERVICING EXTREME OPERATING CONDITIONS SPECIAL SERVICE FOR EXTREME SPECIAL SERVICE FOR EXTREME OPERATING CONDITIONS OPERATING CONDITIONS Date ....km ......Date ....km ......Items performed: ......... Items performed: ................................................................................. Servicing Servicing Dealer ..........
Page 162 Chapter 12 12-6 SERVICING MAINTENANCE SCHEDULE 1.5 15 30 45 60 75 90 105 120 135 150 165 180 Use odometer reading x 1,000 km or years, whichever 1/12 1 2 9 10 11 12 occurs first or years SERVICE ITEMS COOLANT - check level, check coolant %1/12 1 2 11 12 COOLANT - replace...
Page 163 Chapter 12 12-7 SERVICING MAINTENANCE SCHEDULE cont. 1.5 15 30 45 60 75 90 105 120 135 150 165 180 Use odometer reading x 1,000 km or years, whichever 1/12 1 2 9 10 11 12 occurs first or years SERVICE ITEMS HEADLIGHT ADJUSTMENT - check 10 11 12...
Page 164 The repair or replacement of any part found faulty during a service check and not covered by Holden Warranty will be added to the charges. Where any deficiencies are noted, such items should be reported to the owner/ operator so that the extra work required can be authorised.
Page 165 Chapter 12 12-9 SERVICING 1,500km or 1 month INSPECTION Holden invites the new owner of this car to return to the selling Dealer for a free service inspection at 1,500 km. Owner’s Mrs..............Name Miss. Other.... Address ..................Town ..................
Page 166 Chapter 12 12-10 SERVICING q COOLANT - check fluid level, check coolant % q ENGINE OIL - check level q WASHER - check fluid level q BRAKE AND CLUTCH FLUID - check fluid level q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q BODY/UNDERBODY - check corrosion protection...
Page 167 Chapter 12 12-11 SERVICING I authorise performance of the services 15,000 km specified on the rear of this coupon. I understand I will be charged for the following 1 year hours of labour: SERVICE COUPON • 1.1 hours Also, that there will be a charge for all lubricants, filters and parts used as a result of checks and additional services performed as requested.
Page 168 Chapter 12 12-12 SERVICING q COOLANT - replace coolant q DRIVE BELTS - check q ENGINE OIL AND FILTER - replace q LEAKAGE - visual check of engine and trans. q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level and blade condition q DOOR HINGES, DOOR STOP, BONNET LOCK,...
Page 169 Chapter 12 12-13 SERVICING I authorise performance of the services 30,000 km specified on the rear of this coupon. I understand I will be charged for the following 2 years hours of labour: SERVICE COUPON • 1.6 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 170 Chapter 12 12-14 SERVICING q COOLANT - check level, check coolant % q POLLEN FILTER (if fitted) - replace q DRIVE BELTS - check q FUEL FILTER - replace q ENGINE OIL AND FILTER - replace q AUTO TRANS - check fluid level. q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check...
Page 171 Chapter 12 12-15 SERVICING I authorise performance of the services 45,000 km specified on the rear of this coupon. I understand I will be charged for the following 3 years hours of labour: SERVICE COUPON • 1.5 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 172 Chapter 12 12-16 SERVICING q COOLANT - check level, check coolant % q DRIVE BELTS - check q ENGINE OIL AND FILTER - replace q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level and blade condition q DOOR HINGES, DOOR STOP, BONNET LOCK,...
Page 173 Chapter 12 12-17 SERVICING I authorise performance of the services 60,000 km specified on the rear of this coupon. I understand I will be charged for the following 4 years hours of labour: SERVICE COUPON • 3.2 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 174 Chapter 12 12-18 SERVICING q COOLANT - check level, check coolant % q POLLEN FILTER (if fitted) - replace q DRIVE BELTS - check q ENGINE TOOTHED BELT and TENSIONER ASSEMBLY - replace; IDLER PULLEYS inspect q AIR CLEANER paper element - replace q SPARK PLUGS - replace q FUEL FILTER - replace q ENGINE OIL AND FILTER - replace...
Page 175 Chapter 12 12-19 SERVICING I authorise performance of the services 75,000 km specified on the rear of this coupon. I understand I will be charged for the following 5 years hours of labour: SERVICE COUPON • 1.8 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 176 Chapter 12 12-20 SERVICING q COOLANT - replace q DRIVE BELTS - check q ENGINE OIL AND FILTER - replace q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level and blade condition q DOOR HINGES, DOOR STOP, BONNET LOCK,...
Page 177 Chapter 12 12-21 SERVICING I authorise performance of the services 90,000 km specified on the rear of this coupon. I understand I will be charged for the following 6 years hours of labour: SERVICE COUPON • 1.6 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 178 Chapter 12 12-22 SERVICING q COOLANT - check level, check coolant % q POLLEN FILTER (if fitted) - replace q DRIVE BELTS - check q FUEL FILTER - replace q ENGINE OIL AND FILTER - replace q AUTO TRANS - check fluid level. q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check...
Page 179 Chapter 12 12-23 SERVICING I authorise performance of the services 105,000 km specified on the rear of this coupon. I understand I will be charged for the following 7 years hours of labour: SERVICE COUPON • 1.5 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 180 Chapter 12 12-24 SERVICING q COOLANT - check level, check coolant % q DRIVE BELTS - check q ENGINE OIL AND FILTER - replace q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level and blade condition q DOOR HINGES, DOOR STOP, BONNET LOCK,...
Page 181 Chapter 12 12-25 SERVICING I authorise performance of the services 120,000 km specified on the rear of this coupon. I understand I will be charged for the following 8 years hours of labour: SERVICE COUPON • 3.2 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 182 Chapter 12 12-26 SERVICING q COOLANT - check level, check coolant % q POLLEN FILTER (if fitted) - replace q DRIVE BELTS - check q ENGINE TOOTHED BELT, TENSIONER ASSEMBLY AND IDLER PULLEYS- replace q AIR CLEANER paper element - replace q SPARK PLUGS - replace q FUEL FILTER - replace q ENGINE OIL AND FILTER - replace...
Page 183 Chapter 12 12-27 SERVICING I authorise performance of the services 135,000 km specified on the rear of this coupon. I understand I will be charged for the following 9 years hours of labour: SERVICE COUPON • 1.5 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 184 Chapter 12 12-28 SERVICING q COOLANT - check level, check coolant % q DRIVE BELTS - check q ENGINE OIL AND FILTER - replace q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level and blade condition q DOOR HINGES, DOOR STOP, BONNET LOCK,...
Page 185 Chapter 12 12-29 SERVICING I authorise performance of the services 150,000 km specified on the rear of this coupon. I understand I will be charged for the following 10 years hours of labour: SERVICE COUPON • 1.9 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 186 Chapter 12 12-30 SERVICING q COOLANT - replace q POLLEN FILTER (if fitted) - replace q DRIVE BELTS - check q FUEL FILTER - replace q ENGINE OIL AND FILTER - replace q AUTO TRANS - check fluid level. q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level...
Page 187 Chapter 12 12-31 SERVICING I authorise performance of the services 165,000 km specified on the rear of this coupon. I understand I will be charged for the following 11 years hours of labour: SERVICE COUPON • 1.5 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 188 Chapter 12 12-32 SERVICING q COOLANT - check level, check coolant % q DRIVE BELTS - check q ENGINE OIL AND FILTER - replace q LEAKAGE - visual check of engine and trans q LIGHTS, MONITORING, SIGNAL EQUIPMENT AND PARK BRAKE ADJUSTMENT - check q WINDSCREEN WIPE/WASH system - check fluid level and blade condition q DOOR HINGES, DOOR STOP, BONNET LOCK,...
Page 189 Chapter 12 12-33 SERVICING I authorise performance of the services 180,000 km specified on the rear of this coupon. I understand I will be charged for the following 12 years hours of labour: SERVICE COUPON • 3.2 hours labour • add 0.2 hours if brake/clutch fluid changed Also, that there will be a charge for all lubricants, filters and parts used as a result...
Page 190 Chapter 12 12-34 SERVICING q COOLANT - check level, check coolant % q POLLEN FILTER (if fitted) - replace q DRIVE BELTS - check q ENGINE TOOTHED BELT and TENSIONER ASSEMBLY - replace; IDLER PULLEYS - inspect q AIR CLEANER paper element - replace q SPARK PLUGS - replace q FUEL FILTER - replace q ENGINE OIL AND FILTER - replace...
Page 191 Fluid level ......... 7-5 Fluid capacity/type ....8-3 Date ..........1-18 Operation ......... 4-4 Deadlocking ........ 2-4 Sports/economy drive ....4-4 Dealers (Authorised Holden) ... 9-12 Starting-off aid ......4-5 Demister ........1-16 Dimensions ........ 8-3 Dimmer (instrument lighting) ..1-5 Battery Dipping (headlights) ....
Page 192 Height adjust seat belts ..... 3-7 High beam indicator light ... 1-7 First aid ........6-3 Holden Dealers ......9-12 Flashers Holden Customer Assistance .. 9-10 Hazard warning ...... 1-10 Hood .......... 1-19 Turn signal ......1-10 Horn ..........1-3 Flat battery .........
Page 193 INDEX cont. Loading information ....10-2 Paintwork cleaning ....11-4 Locks Park brake lever ......3-10 Bonnet ........1-19 Parking ........4-3 Door .......... 2-2 Petrol ........... 5-3 Fuel filler ........5-3 Plates ........... 8-4 Ignition ........1-20 Polishing ........11-6 Tailgate ........
Page 194 INDEX cont. Serial number ......8-4 Tray, floor ........3-15 Service ........12-1 Trip meter ........1-4 Service light ....... 12-3 Turn signal Snow chains ....... 4-8 Bulb replacement ....6-19 Operation ....... 1-10 Spare wheel ........ 6-4 Tyres Specifications ......8-1 Speedometer ......
