Summary of Contents for HOLDEN WN Series

  • Page 1 WN CAPRICE OWNER’S HANDBOOK...
  • Page 2 GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden) Change of name, address or ownership If you drive a pre-owned Holden, have moved house or changed any of your details, we’d like to hear from you! Holden uses your details to keep your vehicle’s factory provided Roadside Assistance and Warranty details up to date.
  • Page 3: Table Of Contents

    Contents Introduction ..... . 2 In Brief ......5 Keys, Doors, and Windows .
  • Page 4: Introduction

    Introduction Introduction...
  • Page 5 Introduction Introduction Directional data, e.g. left or right, Warning or front or back, always relate to This Owner's Handbook provides the direction of travel. you with all the necessary Text marked Warning word mark and information to enable you to drive provides information on risk of logo are registered trademarks your vehicle safely and efficiently.
  • Page 6 Introduction NOTES...
  • Page 7: In Brief

    In Brief In Brief Initial Drive Door Locks Information Initial Drive Information Remote Keyless Entry Remote Keyless Entry (RKE) (RKE) System System ......5 Door Locks .
  • Page 8: Seat Adjustment

    In Brief Seat Adjustment Head Restraint Adjustment The vehicle has the following levers and switches for seat adjustment. Warning The head restraint is a safety feature. The centre of the head restraint should be at eye level, never at neck level. Lift the head restraint up to raise it.
  • Page 9: Seat Belts

    In Brief Seat Belts To adjust horizontally, pull the The vehicle has adjustable rear front head restraint forwards and head restraints, these can be engage in one of three positions. removed. Pull the metal tongue across your To return to its rearmost position, body into the buckle, until it clicks See Head Restraints 0 36.
  • Page 10: Mirror Adjustment

    In Brief Mirror Adjustment Exterior mirrors Steering Wheel Adjustment Power mirrors Automatic dimming rear view mirror Warning Do not attempt to adjust the steering wheel while driving. L: Left side mirror selected The vehicle has an automatic R: Right side mirror selected dimming rear view mirror.
  • Page 11 In Brief 4. Ensure the steering wheel is locked in position before driving. See Steering Wheel Controls 0 65.
  • Page 12: Instrument Panel Overview

    In Brief Instrument Panel Overview...
  • Page 13: Interior Lighting

    In Brief 1. Vents. See Adjustable Air Headlamp High/Low-Beam 24. 12 volt power socket. See Changer 0 93. Power Outlets 0 68. Vents 0 183. 2. Glovebox 0 57. Driver Information Centre (DIC) 25. Shift lever. See Transmission 0 79. Display 0 190.
  • Page 14: Exterior Lighting

    In Brief Exterior Lighting High/low beam Turn signals High beam: Push lever Left: Lever up : Off Low beam: Push the lever forward Right: Lever down AUTO: Automatic headlamps again See Exterior Lamp Controls 0 93. : Park lamps Headlamp flash: Pull lever See Turn and Lane-Change Signals : Headlamps The high beam lamps can be...
  • Page 15: Horn

    In Brief Hazard warning flasher Horn Washer and Wiper Systems Press to turn the hazard warning Press flasher on and off when the ignition Mist: Wipers cycle while the lever is is in any position. held up See Hazard Warning Flashers 0 95. OFF: Off INT: Intermittent wipe LO: Slow...
  • Page 16: Climate Controls

    In Brief See Washer Fluid 0 235. Transmission Parking 1. Apply the park brake. Automatic transmission Climate Controls 2. Select position P. 3. Shut all windows. 4. Turn the ignition off and remove the key from the vehicle. 5. Press on the key to lock all doors and to arm the alarm system.
  • Page 17 In Brief Check that the warning The electronic key must be indicators illuminate when inside the vehicle. turning the ignition on. Press the brake pedal and move See Driving Environment 0 185. the shift lever to P or N. See Starting the Engine 0 189. Press the ENGINE START/ STOP button.
  • Page 18: Keys, Doors, And Windows

    Keys, Doors, and Windows Keys, Doors, and Interior Mirrors Keys and Locks Automatic Dimming Rear View Windows Mirror ......30 Keys Windows Power Windows .
  • Page 19 Foldaway key blade If the vehicle's key is lost, inform a Press then press and hold Holden Dealer immediately so the for remote vehicle start. See vehicle can be reprogrammed and Remote Vehicle Start 0 22. will no longer recognise the Panic/vehicle locate button missing key.
  • Page 20 If a third key is made, the third If you are still having trouble, out of sight. key becomes memory one and contact a Holden Dealer. the other two keys become Metallic window tint reduces the If pressing the key buttons does identical memory two keys.
  • Page 21: Infocard

    If the passenger's door is open If a key is lost, a replacement can Remote Keyless Entry when is pressed, all doors lock. be ordered through any Holden Dealer by quoting the key code (RKE) System Operation Pressing arms the vehicle alarm.
  • Page 22 Keys, Doors, and Windows The vehicle can be customised to Pressing the lock/unlock button will (Unlock) : Press to unlock the always unlock all doors on the first cause all doors to lock if any of the driver's door or all doors. See lock/unlock button press.
  • Page 23 Keys, Doors, and Windows Passive locking Caution This feature allows for selecting whether the doors automatically lock It is recommended the RKE during normal vehicle exit. When transmitter is kept on your person the vehicle is turned off and all at all times.
  • Page 24: Remote Vehicle Start

    Keys, Doors, and Windows 1. Push the button on the Remote Vehicle Start turn signal lamps flashing transmitter to extend the key confirms the request to remote Remote start allows the engine to blade. start the vehicle has been be started from outside the vehicle. received.
  • Page 25: Door Locks

    Keys, Doors, and Windows For example, if the engine has been The vehicle is unlocked. Danger (Continued) running for five minutes, and the The bonnet is not closed. remote start is extended, the engine door is locked, the handle The hazard warning flashers will run for a total of 20 minutes.
  • Page 26 Keys, Doors, and Windows There are several ways to lock and Note doors press a second time. unlock the vehicle. This will not arm or disarm the alarm See Remote door unlock under system. Vehicle Personalisation 0 89. From the outside: If the vehicle is unlocked using the All doors will lock with one Press...
  • Page 27: Door Open Reminder

    P (Park), see doors. closed. Power door locks under Vehicle If any problems occur, contact a A door is unlocked when the Personalisation 0 89. Holden Dealer. lock snib is up.
  • Page 28: Safety Locks

    Keys, Doors, and Windows Safety Locks Doors Warning Child safety rear door locks Boot For safety, always check the lock is operating correctly (after setting) by trying to open the door Warning from inside the vehicle. To prevent dangerous exhaust fumes entering the vehicle, close the boot when the engine is running.
  • Page 29 Keys, Doors, and Windows Key button Boot release button Note The boot release button is disabled when all doors are locked, the alarm is enabled or the vehicle is moving at greater than 3 km/h. If the boot is not closed properly when the vehicle is locked, the horn will sound twice.
  • Page 30: Vehicle Security

    Keys, Doors, and Windows 1. Press the lock button (located Vehicle Security Start the engine. at the top centre of the middle The alarm automatically disarms. seat) all the way down to Vehicle Alarm System unlock the seatback. Immobiliser Operation This vehicle has an anti-theft alarm 2.
  • Page 31: Exterior Mirrors

    Keys, Doors, and Windows The system has one or more Do not leave the transmitter that Exterior Mirrors transmitters matched to an disarms or deactivates the immobiliser control unit in your theft-deterrent system, in the Power Mirrors vehicle. Only a correctly matched vehicle.
  • Page 32: Heated Mirrors

    Keys, Doors, and Windows To deactivate, refer to Reverse Tilt Interior Mirrors Warning Mirror. See Vehicle Personalisation 0 89. Automatic Dimming Rear The passenger side mirror is convex shaped, to provide a View Mirror wider view. Objects in this mirror are closer than they appear.
  • Page 33: Windows

    Keys, Doors, and Windows Sun visor mirrors Windows if any door is opened within 45 seconds from the ignition key being turned off, the windows Power Windows remain operational for 45 seconds. Warning Take care when operating the power windows. Risk of injury, particularly to children.
  • Page 34 Keys, Doors, and Windows automatically with safety function. Safety function on front Child safety system for rear To stop movement, operate the windows windows switch once more in the same If the window glass encounters direction. resistance above the middle of the Operation of rear windows window during automatic closing, it is immediately stopped and opened...
  • Page 35: Roof

    Keys, Doors, and Windows warning message is displayed in the When released, they fold up against Roof Driver Information Centre. See the roof. Vehicle Messages 0 83. Sunroof Warning Activate the window electronics as The vehicle has a sunroof. follows: Do not hold onto assist grips 1.
  • Page 36 Keys, Doors, and Windows Opening the sunroof Auto-close function Press to close the tilted sunroof. Release when the When the ignition is turned off, the Press partially to open the sunroof is closed or in the sunroof closes automatically after sunroof.
  • Page 37 Keys, Doors, and Windows Cleaning and maintenance Caution The tinted glass panel on the sunroof is heat and UV resistant. Ensure that due care is taken and that the directions below are followed when cleaning. Regularly clean the glass, flocked seal and roof flanges with a moist, soft cloth.
  • Page 38: Seats And Restraints

    Seats and Restraints Seats and Curtain Airbag System ..49 Head Restraints What Will You See after an Restraints Airbag Inflates? ....49 Warning Airbag System Check .
  • Page 39 Seats and Restraints Lift the head restraint up to To adjust horizontally, pull the The vehicle has adjustable rear raise it. front head restraint forwards and head restraints, these can be engage in one of three positions. removed. See Child Restraint Push the locking button and Systems 0 52.
  • Page 40: Front Seats

    Seats and Restraints Front Seats Power Seat Adjustment Seat Position Warning Do not adjust the driver's seat Warning when the vehicle is moving as the seat could move suddenly To avoid reducing the causing the driver to lose control. effectiveness of seat belts, seatbacks should only be upright or at most semi-reclined when the Warning...
  • Page 41 Seats and Restraints Recline Up/down Tilt Adjust the seatback by tilting the Raise or lower the seat by moving Tilt the seat up at the front by tilting vertical switch forwards or the horizontal switch up or down. the front of the horizontal switch up. backwards.
  • Page 42: Memory Seats

    Seats and Restraints 4. Immediately press and hold 1 until two beeps sound. 5. Repeat Steps 1 4 for a second driver using button 2. To store exit positions for when you get out of the vehicle, repeat Steps 1 4 using (Exit) to store your positions.
  • Page 43: Heated Front Seats

    To stop the recall movement, press If the memory position is still not one of the memory, power mirror or one of the memory, power mirror, recalling, see your Holden dealer for or power seat controls. power seat controls. service.
  • Page 44: Rear Seats

    Seats and Restraints Remote start heated seats Rear Seats The vehicle has heated seats that can be automatically turned on Warning during a remote start, when the temperature outside is below Do not press the release button approximately 10 degrees. They are on the top of the seatback while cancelled when the ignition is the vehicle is moving.
  • Page 45: Rear Seat Armrest

    Seats and Restraints Rear Seat Armrest Seat Belts How to Wear Seat Belts Properly Warning Seat belts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or 1.
  • Page 46: Three-Point Seat Belt

    Seats and Restraints Three-Point Seat Belt 5. Settle the belt at the hip. Warning (Continued) 6. Run your hand under the sash Fitting from hip to shoulder. Belts should not be worn with straps twisted. The belt should fit comfortably. Any extra belt length retracts Each belt assembly must only be automatically.
  • Page 47: Seat Belt Use During

    Seats and Restraints locks immediately on fast braking, Shoulder height adjust Warning impact with a solid object or any quick movement by the wearer. For your safety, do not adjust the If the shoulder portion of a rear seat seat belt shoulder height while belt is pulled out all the way, the driving.
  • Page 48: Replacing Seat Belt System Parts After A Crash

    Seats and Restraints Airbag System Warning (Continued) Warning (Continued) Airbags and child restraints particularly battery acid. Cleaning The child could be seriously may safely be carried out using injured if the airbag inflates, as mild soap and water. The belt the child's head would be very should be replaced if webbing close to the inflating airbag.
  • Page 49: Front Airbag System

    Seats and Restraints Warning (Continued) Warning Airbags inflate with great force. The horn pad must not be If you are too close to an inflating covered with adhesive or any airbag it may cause injury. Seat other material. belts help keep you in position for The driver should adjust the seat airbag inflation in the event of a as far rearward as possible while...
  • Page 50: Side Airbag System

    Seats and Restraints Side Airbag System Warning Do not fit unauthorised seat covers as they may impair the deployment of the Side Impact Airbags (SIAB). Do not position your body or any object (including pillows) between front seats and doors. Do not lean on, or sleep against, the door.
  • Page 51: Curtain Airbag System

    Seats and Restraints Curtain Airbag System Warning Do not position your body or any object (including pillows) in the area in which the airbag inflates. There must be no objects in the area in which the airbag inflates. Refer to the illustration. Use the hooks above the doors only to hang up light articles of clothing.
  • Page 52: Airbag System Check

    It is recommended that this work be and provided there is battery The SRS may not function carried out by a Holden Dealer or power), the following will occur: correctly in the event of an approved repairer. The engine will switch off.
  • Page 53: Child Restraints

    Seats and Restraints Child Restraints They are able to stay seated like Young Children this for the entire trip. Older Children Infants and Young Children Infants Forward facing child seats are for use when the child is able to sit and easily hold their head upright.
  • Page 54: Child Restraint Systems

    Booster seats are for when children outgrow a typical forward facing Holden strongly recommends that child seat, but are still too small for you refer to your specific State or three point seat belts.
  • Page 55 Seats and Restraints 5. Lift the head restraint up When engaged, this feature Warning and out. prevents the seat belt from being loosened without releasing the 6. Store the head restraint in a Always ensure that the seat belt buckle. safe location.
  • Page 56: Where To Put The Restraint

    If unsure about installing a child restricting the seating of children restraint anchor fitting, please in the front passenger seat. In contact an approved restraint fitting station or a Holden Dealer. most jurisdictions, children under 4 years should not be seated in (Continued)
  • Page 57: Isofix Child Restraint

    Unscrew the cover plug. Fasten vehicle-approved ISOFIX 8. Front of vehicle child restraint systems to the Some generic fittings come with a ISOFIX mounting brackets. selection of spacers. Holden child restraint fitting A 10 mm spacer is required. 1. Unscrew the cover plug.
  • Page 58 Seats and Restraints Note Ensure that the seat belt buckles are placed out of the way of the child seat. ISOFIX mounting brackets are indicated by the label on the seatback. In addition to the ISOFIX mounting, fasten the top-tether strap(s) to the top tether anchorage points.
  • Page 59: Storage

    Storage Storage Storage Cupholders Compartments Cupholders are designed for holding standard size soft drink cans, small Storage Compartments size bottles and cups with lids. Glovebox Glovebox ..... . 57 Larger bottles may be stored in the Cupholders .
  • Page 60: Front Storage

    Storage The rubber cupholder lining can be Front Storage Armrest Storage removed for cleaning. Rear armrest Rear cupholders The front storage compartment is located below the climate control The vehicle has a rear armrest with panel on the instrument panel. Cupholders may be located in the a built-in storage compartment.
  • Page 61: Rear Storage

    Storage Rear Storage Centre Console Storage Additional Storage Features Seatback Pockets Convenience Net Warning Avoid eye injury. Do not overstretch. Always keep face and body out of recoil path. Do not use when there are visible signs of wear or damage. The maximum load for the A storage area is located under the convenience net is 15 kg single...
  • Page 62: Roof Rack System

    Storage Roof Rack System Roof Rack Distribute the load evenly and secure tightly with straps. When carrying loads on the roof rack, avoid hard braking, abrupt swerving or sharp steering. Roof rack loads alter the handling of a vehicle. Attach four corner loops (1) to the The net can be opened and objects Warning top two hooks on the vehicle (two...
  • Page 63 Storage Information on Warning (Continued) Loading the Vehicle restrained from rolling around, Heavy Accessories and where possible, placed in the load area of the vehicle. Place heavy objects in the boot as far forward as possible. It is recommended that if gas cylinders are frequently Movement of heavy objects in transported, that a purpose-built...
  • Page 64: Instruments And Controls

    Instruments and Controls Instruments and Malfunction Indicator Lamp ..73 Vehicle Messages Service Vehicle Soon Light ..74 Vehicle Messages ... . . 83 Controls Brake System Warning Light .
  • Page 65: Instrument Panel Overview

    Instruments and Controls Instrument Panel Overview...
  • Page 66 Instruments and Controls 1. Vents. See Adjustable Air Headlamp High/Low-Beam 24. 12 volt power socket. See Changer 0 93. Power Outlets 0 68. Vents 0 183. 2. Glovebox 0 57. Driver Information Centre (DIC) 25. Shift lever. See Transmission 0 79. Display 0 190.
  • Page 67: Controls

    Instruments and Controls Controls 3. To lock, move the lever up. (Rotary Control) : Turn Ensure the steering wheel is thumbwheel to select locked in position before Steering Wheel preset radio stations. driving. Adjustment Turn thumbwheel to select Steering Wheel Controls the next or previous favourite radio Warning station, CD track, DVD track/chapter...
  • Page 68: Horn

    Instruments and Controls Windscreen Wiper/ (Forward collision alert) : (Cancel) : Press to disengage Press the button to set the alert cruise control without erasing the Washer timing to far, medium, near or off. set speed from memory. The button press shows the current Horn control setting on the HUD.
  • Page 69 Instruments and Controls INT: Intermittent wipe Rain sensing Caution (Continued) LO: Slow The vehicle has rain sensing windscreen wipers. To prevent damage to the wiper HI: Fast blades, make sure that the A sensor near the top centre of the : Pull to wash the windscreen.
  • Page 70: Clock

    Instruments and Controls Rotate the collar down for higher Note Caution sensitivity. Any device connected to a power socket must not exceed a current Rotate the collar up for less A car bra or an accessory that draw of 10 amps. sensitivity.
  • Page 71 Instruments and Controls A power socket is located in front of The rear power socket is located in the shift lever and inside the centre the boot on the passenger side. console. It operates when the ignition is turned on or off. Rear power socket Caution Do not use the rear power socket...
  • Page 72: Warning Lights, Gauges, And Indicators

    Instruments and Controls Warning Lights, Gauges, and Indicators...
  • Page 73: Instrument Cluster

    Instruments and Controls Instrument Cluster Odometer Fuel Gauge The odometer shows how far the vehicle has been driven in kilometres. Trip Odometer The trip odometer can show how far the vehicle has been driven since the trip odometer was last reset. The trip odometer is accessed and reset through the Driver Information Centre (DIC).
  • Page 74: Seat Belt Reminders

    Instruments and Controls prevents false readings due to fuel If the vehicle has been operated A chime sounds when the seat belt movement when cornering. If the under normal driving conditions, pull is unbuckled and vehicle speed is vehicle is idling on a gradient for an off the road, stop the vehicle, and above 22 km/h.
  • Page 75: Airbag Readiness Light

    Instruments and Controls The front passenger seat belt Airbag Readiness Light Charging System Light reminder light and chime may turn This light shows if there is an This light comes on briefly when on if an object is put on the seat such as a briefcase, handbag, electrical problem with the airbag the ignition is turned on, but the...
  • Page 76: Service Vehicle Soon Light

    Instruments and Controls could damage the emission control Service Vehicle Soon Caution system on the vehicle. Diagnosis Light and service might be required. If the vehicle is continually driven If the light comes on, a To prevent more serious damage to with this light on, the emission condition exists that may require the the vehicle:...
  • Page 77: Electric Parking Brake Light

    Instruments and Controls Electric Parking Brake If this light comes on, there is a Warning (Continued) problem with a system on the Light vehicle that is causing the parking warning light on can lead to a brake system to work at a reduced This light should come on crash.
  • Page 78: Lane Departure Warning (Ldw)

    If it does the system is turned on, contact a not, have the vehicle serviced by Holden dealer. your dealer. If the system is working The forward collision alert comes on See Traction Control System (TCS) normally, the light then turns off.
  • Page 79: Electronic Stability Control

    Instruments and Controls If it does not, have the vehicle This light comes on when the ESC possible, and inflate the tyres to the serviced by your dealer. If the system is turned off. When the ESC pressure value shown on the tyre system is working normally, the is off, the TCS is also off, and wheel placard.
  • Page 80: Low Fuel Warning Light

    Instruments and Controls the indicator light turns off. If it does Cruise Control Light If the light illuminates when the not come on, have the vehicle engine is running: The cruise control light serviced by your dealer. Stop the vehicle as soon as it is Illuminates white whenever the If the light stays on and the engine safe to do so.
  • Page 81: Information Displays

    Instruments and Controls Information Displays Trip/Fuel Menu Items Press MENU on the turn signal Driver Information lever until Trip/Fuel Menu is displayed. Use to scroll through Centre (DIC) the following possible menu items: The Driver Information Centre (DIC) Digital Speedometer displays information about the vehicle.
  • Page 82 Instruments and Controls odometer can be reset to zero by Instantaneous Fuel Consumption Vehicle Information Menu Items pressing SET/CLR while the trip The instantaneous fuel consumption Press MENU on the turn signal odometer display is showing. display shows the current fuel lever until Vehicle Information menu Fuel Range economy in litres per 100 kilometres...
  • Page 83: Head-Up Display (Hud)

    Instruments and Controls Speed Warning The Economy Trend Statistic Tachometer display shows the fuel economy for This display is used to set the Turn Signal Indicators the last 50 km. Each bar in the vehicle speed at which the speed High-Beam Indicator Symbol graph represents 5 km.
  • Page 84 Instruments and Controls To adjust the HUD image so that items are properly displayed: 1. Adjust the driver seat to a comfortable position. 2. Start the engine. 3. Adjust the HUD controls. Page two displays: The display at the top of page four shows the gear shift timing.
  • Page 85: Vehicle Messages

    Instruments and Controls If the HUD Image Is Not Clear Vehicle Messages the vehicle that may be noticed. At the point that features are disabled, Is the HUD image too bright? DIC messages display when the this message displays. Turn off Are the windscreen and HUD status of the vehicle has changed unnecessary accessories to allow...
  • Page 86: Cruise Control Messages

    Instruments and Controls SERVICE BRAKE ASSIST Cruise Control Messages RIGHT REAR DOOR OPEN This message may be displayed This message will display when the CRUISE SET TO XXX when there is a problem with the passenger side rear door is open. This message displays when the brake boost assist system.
  • Page 87: Engine Oil Messages

    Instruments and Controls If this message continues to appear, is serviced. See the Service and to your destination. The have the system repaired by your Warranty Booklet for more performance may be reduced the dealer as soon as possible to avoid information.
  • Page 88: Lamp Messages

    Instruments and Controls REPLACE BATTERY IN AUTOMATIC LIGHT Object Detection System REMOTE KEY CONTROL OFF Messages This message displays when the This message is displayed when the PARK ASSIST OFF battery in the Remote Keyless Entry automatic light control has been (RKE) transmitter needs to be turned off.
  • Page 89: Security Messages

    Instruments and Controls SERVICE ESP SERVICE POWER STEERING Starting the Vehicle Messages This message displays if there is a This message displays if there is a problem with the Electronic Stability problem with the power steering TURN STEERING WHEEL TURN Control (ESC) system.
  • Page 90: Transmission Messages

    Instruments and Controls Transmission Messages to too low or too high of a gear. See Vehicle Reminder Active Select (A/S) Mode under Messages SPORT MODE ON / SPORT Shift Lever 0 191 for more MODE OFF information. ICE POSSIBLE DRIVE WITH CARE These messages display when the SHIFT TO PARK...
  • Page 91: Vehicle Personalisation

    Instruments and Controls Vehicle 3. Press the centre of the TUNE/ Power Door Locks MENU switch to select the Remote Lock/Unlock/Start Personalisation highlighted menu item. The Return to Factory Settings? ignition must be in the ON The infotainment system controls position.
  • Page 92 Instruments and Controls Chime Volume will remain the same, no matter Press BACK to confirm the which key was used to enter and selection and move back to the This allows the selection of the start the vehicle. last menu. chime volume level.
  • Page 93 Instruments and Controls Press the TUNE/MENU switch when Auto Door Unlock Off. Press BACK to confirm the Park Assist is highlighted. Turn the selection and move back to the This allows selection of which of the switch to select Off, On or On with last menu.
  • Page 94 Instruments and Controls Remote Left in Veh. Reminder Press the TUNE/MENU switch when Press the TUNE/MENU switch when Remote Door Unlock is highlighted. Passive Door Lock is highlighted to Remote Unlock Feedback Turn the switch to select All Doors select On or Off. Press BACK to This allows selection of what type of or Driver Door Only.
  • Page 95: Lighting

    Lighting Lighting Exterior Lighting (Park lamps) : Turns on the park, tail and rear number plate lamps. Exterior Lamp Controls Exterior Lighting (Headlamps) : Turns on the Exterior Lamp Controls ..93 headlamps and all park lamps. Headlamp High/Low-Beam (Fog lamps) : Turns on the fog Changer .
  • Page 96: Daytime Running

    Lighting The high beam indicator Note There is a light sensor located on top of the instrument panel. Do not If the lamp control switch is turned lamp illuminates on the cover the sensor. Otherwise the instrument panel. , the DRL will turn off. headlamps will come on when they The DRL will turn on in night time To return to low beam:...
  • Page 97: Hazard Warning Flashers

    Lighting Hazard Warning Flashers Turn and Lane-Change Warning (Continued) Signals In situations such as this, set the lamp switch to , otherwise your safety and that of other road users could be endangered. Lights On with Wipers If the windscreen wipers are activated in daylight with the engine on, and the exterior lamp control is in AUTO, the headlamps, park...
  • Page 98: Fog Lamps

    Lighting A green arrow on the instrument Interior Lighting Load Compartment panel flashes when the lamps Lamps are in operation. Instrument Panel Boot lamp Illumination Control Fog Lamps The lamp illuminates when the boot In very heavy fog, vision may be is opened and switches off when improved by having the park closed.
  • Page 99: Reading Lamps

    Lighting Reading Lamps Rear reading lamps (Door activated): The lamp automatically switches on when Front reading lamps a door is opened, the vehicle is unlocked or the ignition is turned off. The lamp dims to off after all doors are closed. Switching the ignition on dims the lamps off immediately (unless a door remains open).
  • Page 100: Sun Visor Lamps

    Lighting Sun Visor Lamps Lighting Features Activation, deactivation and duration of lighting of this function can be Lamps are located at either side of changed. See Exit Lighting under Entry Lighting the mirror. Vehicle Personalisation 0 89. The lamps turn on and off To facilitate retrieving the vehicle Battery Power Protection automatically when the cover is...
  • Page 101: Infotainment System

    Infotainment System Infotainment Navigation Introduction Using the Navigation System System ..... . 141 General information Maps ......145 Do the following before driving: Navigation Symbols .
  • Page 102 Infotainment System ® iPod is a registered trademark Danger (Continued) Caution of Apple Inc. ® Pandora is a registered cause a crash resulting in injury Do not place beverages close to trademark of Pandora or death to yourself or others. the audio system.
  • Page 103: Theft-Deterrent Feature

    The TMC service should not be Limitation of liability Overview relied upon for journeys that are Neither GM Holden nor the provider The infotainment system is time critical because, on occasions, of the TMC will be liable to you or to...
  • Page 104 Infotainment System Radio with Navigation Infotainment Control Buttons The buttons on the faceplate are used to start primary functions while using the infotainment system. SRCE (Source) : Press to change the audio source to AM, FM, CD, USB or Bluetooth Audio. HOME : Press to go to the Home Page.
  • Page 105 Infotainment System If a destination has already been preset Favourite Pages can be Turn to highlight a feature within entered, press to access the changed by pressing the Config a menu. Press the centre of the Route Menu. See Destination button on the Home Page, then TUNE/MENU switch to activate 0 147.
  • Page 106: Using The System

    Infotainment System Some audio functions can be Using the System Home : Press/touch to go back to controlled through the steering the Home Page. The infotainment system is wheel controls. Fav : Press/touch to display a page controlled by touching the screen, (Push to Talk) : Press to of stored (favourite) AM or FM using the switches and pressing the...
  • Page 107 Infotainment System will be displayed. The maximum number of buttons on Home Page 1 is eight. 4. Touch Done. To move screen buttons: 1. Touch Menu. Touch the Now Playing screen Touch the Destination screen button button to display the active source to display the Destination Entry 2.
  • Page 108 Infotainment System Touch the Pandora screen button to display the Pandora home page and streams personalised radio stations based on artists, songs, genres, and comedians. See Pandora Internet Radio 0 113. Touch the Config screen button to Touch the FM screen button to display the Config main page.
  • Page 109 Infotainment System Touch the Quick Info screen button to access available information on Audio playing. See Quick Info under Radio Reception 0 113. Cleaning High Gloss Surfaces and Vehicle Information and Touch the USB screen button to Touch the Bluetooth screen Radio Displays display the USB main page and play button to display the Bluetooth...
  • Page 110: Operation

    Infotainment System Operation Menu System Selecting a Menu Option Controls Controls The TUNE/MENU switch and The infotainment system is operated BACK are used to navigate the by using the buttons, switches, menu system. menus shown on the display and steering wheel controls. TUNE/MENU: Turning the System On or Off Press to:...
  • Page 111 Infotainment System Activating a Setting 2. Press the TUNE/MENU switch Press BACK to go back to the to confirm the setting. Tone Settings menu. Turning a Function On or Off Adjusting the Fader and Balance 1. Touch the Tone screen button on the Home page.
  • Page 112: Radio

    Infotainment System System Settings 1. Touch the Config screen button Radio on the Home page. Configuring the Number of AM-FM Radio 2. Select Radio Settings. Favourite Pages 3. Select Auto Volume. To configure the number of available Playing the Radio favourite pages: 4.
  • Page 113 Infotainment System The radio can be turned off at any Treble: Touch + or to change Seeking a station time by pressing the power button. the level. Press SEEK or SEEK EQ: Press or Rotate the TUNE/ search for a station. MENU switch to cycle through the preset EQ options.
  • Page 114: Radio Data System (Rds)

    Infotainment System few seconds, a beep is heard Recalling a preset station and the new preset information To recall a preset station from a displays on that screen button. favourites page, do one of the 2. Repeat for each preset. following: Touch the Fav screen button at Mixed-Band Presets...
  • Page 115: Radio Reception

    Infotainment System information is available. It is automatically works to reduce Quick Info possible that a radio station could interference, some static can occur, broadcast incorrect information that especially around tall buildings or causes the radio features to work hills, causing the sound to fade in improperly.
  • Page 116 Infotainment System Create stations using the Pandora Launching Pandora If nothing happens when the website or smartphone application, available Pandora screen button is ® ® Connect the iPhone , iPad touched, download the latest then use (thumbs up) or ® or iPod touch to the USB port, Pandora application and retry.
  • Page 117 Infotainment System Pandora has a menu system with Press and say Tune Press and say Tune the following: Pandora. Pandora. Shuffle : Select to play the stations If nothing happens when the If nothing happens when the in random order. available Pandora screen button is available Pandora screen button is touched, download the latest...
  • Page 118 Infotainment System on this station again. This helps Pandora Skip Limit Check that the latest version of Pandora choose which song should Pandora is installed. Pandora limits the number of skips not play on this station. This feature allowed on their service. When the Check that there is an active is only available on user created account logged into Pandora.
  • Page 119: Stitcher Internet Radio

    Infotainment System Thumbs Up or Thumbs Down The battery saver and task No Stations Found : Logged in but Error manager applications on the no stations have been created. phone can cause Pandora to Touch OK to continue. If there is an error trying to rate a function incorrectly.
  • Page 120 Infotainment System ® an account, download the Bluetooth . See USB 0 126 or If nothing happens when the application from the Android Bluetooth 0 168. For first-time use, available Stitcher screen button is Market or iTunes Store, or go to set up the stations before touched, download the latest www.stitcher.com.
  • Page 121 Infotainment System 2. Use one of the following to Stitcher Menus Stitcher Station Categories : launch: Displays categories by topic. Select the application on When a category then sub-category the device. is selected, the radio will start playing the first program in that Select Stitcher on the sub-category.
  • Page 122 Infotainment System Stitcher Troubleshooting For Android devices, check (Thumbs Down) : When that the device is paired with the touched, Stitcher changes to the Unable to Connect Device to ® vehicle and that the Bluetooth next show. This helps Stitcher Vehicle icon on the display is provide a personalised listening...
  • Page 123: Audio Players

    Infotainment System ® ® If any iPhone , iPod touch Paused or Audio Paused : Audio Players ® or iPad is connected to Playback is paused on the radio or ® Bluetooth and the dock on device. Press or play on the CD Player connector, go to the Airplay icon device.
  • Page 124 Infotainment System Do not apply labels to discs. The Playing an Audio CD less than five seconds, it seeks labels could get caught in the to the previous track. If longer player. than five seconds, the current track starts from the beginning. Insert only one disc at a time.
  • Page 125: Cd/Dvd Player

    Infotainment System The disc is very hot. Try the disc To avoid damage to the CD/DVD Press to eject a disc from the player: again when the temperature CD/DVD player. If the disc is not returns to normal. removed within a short period of Do not use scratched or time, it is automatically pulled back The road is very rough.
  • Page 126: Mp3

    Infotainment System If the controls are not currently (Play/Pause) : Use to pause or displayed on the screen; touch the resume play. Playing an MP3 CD screen. : Use to move forwards from the To play an MP3 CD, follow the same Error Messages current position.
  • Page 127 Infotainment System MP3 Music Menu Albums : Touch to view the albums compressed audio file. The empty on the disc. Select the album to folder(s) are not displayed or Touch the Menu screen button while view a list of all songs on the album. numbered.
  • Page 128: Usb

    Infotainment System Unprotected WMA and thousands of other famous artist nicknames as voice Unprotected AAC Playing From a USB commands to access music. See ® Gracenote Voice Recognition 0 161. A USB mass storage or Certified ® Windows Vista /Media Transfer Normalisation: If equipped, Gracenote technology embedded Protocol (MTP) device can be...
  • Page 129 Infotainment System 3. Touch Normalisation to turn on Use the touch screen or voice USB MP3 player and USB drives recognition to create a More Like or off. The USB MP3 players and USB This Playlist. See Voice Cover Art: The Gracenote drives connected must comply Recognition Commands in Voice embedded database contains cover...
  • Page 130 Infotainment System Connect the USB and it begins While the USB source is active, use USB menu to play. the following to operate USB The following are available through function: Touch the USB screen button on the USB Menu: the Home Page. TUNE/MENU Switch : Rotate to Shuffle: Touch to play the tracks scroll through the track list.
  • Page 131 Infotainment System ® 2. Select a playlist to view the list Songs: When connecting an iPod of all songs in that playlist. which firmware from other 1. Touch to display a list of all providers is installed. 3. Select a song from the list to songs on the USB.
  • Page 132 Infotainment System ® iPod menu 2. The radio will show Playlist 2. Select an album name to view Creation Succeeded and a list of all songs on the album continue playing the or select All Songs to view all ® current song.
  • Page 133: Bluetooth Audio

    Infotainment System Podcasts: Album , Play Song , or Play 2. Touch Vehicle Settings. Genre . See Voice Recognition 1. Touch to view the podcasts on 3. Touch Return to Factory 0 161. ® the iPod Settings. ® ® ® iPhone , iPod touch and iPad...
  • Page 134 Infotainment System ® 2. Music can be launched by Bluetooth Audio Menu Some phones support sending ® doing one of the following: Bluetooth music information to Touch the Menu screen button and display on the infotainment system. Touch the Bluetooth Audio the following may display: When the infotainment system screen button on the...
  • Page 135: Rear Seat Infotainment

    Infotainment System Rear Seat range of above 20°C and below 60°C. Heat or cool the vehicle until Infotainment it is within the operating range. Global Off Rear Seat Entertainment To turn off the RSE system screens (RSE) System and features: The vehicle has a DVD Rear Seat 1.
  • Page 136 Infotainment System Headphones channel 1/2 switch, and a volume (Left) and R (Right) symbols are on control. Turn the headphones off the outside bottom edge of the ear when not in use. cup and should be worn appropriately. Push the On/Off button to turn on the headphones.
  • Page 137 Infotainment System Remove the batteries if the Power for auxiliary devices is not 4. A fourth time to change the headphones are not going to be supplied by the infotainment system. source of both video screens to used for a long period. the DVD player.
  • Page 138 Infotainment System The front seat passengers can listen Push the video screen down into its Video Screen Input Jack to audio from the A/V jacks through locked position when it is not in use, the vehicle speakers by selecting the screen turns off automatically. Rear AUX as the source on the Only the left RSE seatback console infotainment system.
  • Page 139 Infotainment System Remote Control If a CD, DVD, or MP3 disc is in the (Title) : Press to return to the infotainment system slot, the remote main menu of the DVD. This control button can be used to turn function could vary for each disc. on the video screen display and (Main Menu) : Press to access start the disc.
  • Page 140 Infotainment System button might not work when the (Play/Pause) : Press to start (Clear) (If Available) : Press this DVD is playing the copyright playing a DVD. Press to pause a button within three seconds after information or the previews. DVD while it is playing.
  • Page 141 Infotainment System Troubleshooting Chart Problem Recommended Action No power. The ignition might not be turned on. The picture does not fill the screen. Check the display mode settings in There are black borders on the top the setup menu by pressing the and bottom or on both sides or it display menu button on the remote looks stretched out.
  • Page 142 Infotainment System Troubleshooting Chart (cont'd) Problem Recommended Action The auxiliary source is running but Check that the RSE video screen is there is no picture or sound. in the auxiliary source mode by pressing the AUX button on the remote control. Check the auxiliary input connections at both devices.
  • Page 143: Using The Navigation

    Infotainment System DVD Display Error Messages Cleaning the RSE Seatback Navigation Console The video screen may display one Using the Navigation of the following error messages: Use only a clean cloth dampened with clean water to clean the RSE System Disc Load/Eject Error or seatback console surface.
  • Page 144 Infotainment System The touch screen buttons Touch Heading Indicator to display available are: the Map View. There are three indicator settings: 2D North Up: Displays North at the top of the map screen regardless of the direction the vehicle is travelling. 2D Heading Up: Displays the direction the vehicle is travelling.
  • Page 145 Infotainment System of full and split views. Some views All Traffic Events: Select to view POIs Along Route are only selectable when route all reported traffic events while Select to display a search list of guidance is active. on or off a planned route. POIs that lie along or near the route Traffic Events on Route: Select to the destination.
  • Page 146 Infotainment System Switch Route Time/Destination Map Scales Scroll Features Touch to customise the Arrival/ Travel time and Waypoint/ Destination information displayed in the main map screen. Current Position Info Touch to display a split screen showing detailed information about To scroll within the map, touch the vehicle position.
  • Page 147: Maps

    Infotainment System Detailed Areas Road network attributes are contained in the map database for detailed areas. Attributes include information such as street names, street addresses and turn Touch the cycling arrows located at The vehicle symbol indicates the restrictions. A detailed area includes the top of the map screen to toggle current position and heading all major highways, service roads...
  • Page 148 Infotainment System A waypoint is a stopover destination This symbol indicates that the map point added to the planned route. view is North up: North up displays North at the top of the map screen The estimated time and distance to regardless of the direction the the destination are displayed.
  • Page 149: Destination

    Infotainment System may not always be accurate due to Destinations, Address Book and My changes since the map data was Home may be greyed out if no created. Always follow the posted destination was previously entered speed limit on the road. or saved.
  • Page 150 Infotainment System Address Entry City/Suburb : Enter a city/ information, then displays it on the Destination Confirmation suburb name. screen. Street : Enter a street name. House # : Enter a valid address number. Junction : Enter a street name that intersects with the selected street.
  • Page 151 Infotainment System 4. Select a few of the characters Select a destination from the or spell the name in full, by Previous Destination List. Up to 15 using the alpha keyboard. points that have been previously entered can be recalled. If the list is 5.
  • Page 152 Infotainment System 4. The system displays the 2. On the Destination options Name, Address, Confirmation screen, Number, Icon and Done. Touch select Edit. Done to save the destination. 3. The system displays the 5. To customise the address book options Name, Address, entry, select Name, Address, Number, Icon and Delete.
  • Page 153 Infotainment System Favourite Routes Selecting a Favourite Route: 1. Touch the Home Page Destination screen button to 1. Touch the Home Page display the Favourite Routes Destination screen button to screen button. Touch this display the Favourite Routes button to display the list of screen button.
  • Page 154 Infotainment System (Address Entry, POI Entry, etc.). The scroll symbol will be Save as Home : Touch to save the Select Save as Home from the centred on the map. displayed destination as your home Destination Confirmation screen. destination. The home destination 3.
  • Page 155 Infotainment System Eco : This calculates the most Menu with Route Guidance fuel-efficient route based on speed Active and distance. Under the Route Options menu, there are route preferences that by default are all enabled. A checkmark placed next to each preference indicates this.
  • Page 156: Configure Menu

    Infotainment System To save a destination list as a Voice Prompt favourite route, select Save as Select Voice Prompt to view options Favourite Route. to disable or manage navigation voice prompts and traffic alert Turn List prompts. Detour Select Detour to display the route detour options.
  • Page 157 Infotainment System Touch the Config button on the Voice Prompt Traffic settings Home Page to enter the setup menu. Rotate the TUNE/MENU switch or touch the scroll bar until the Navigation Settings option displays. Select this feature to make changes to Voice Prompt, Traffic Settings, Guidance Alert, Driver Alert, Delete Saved Destinations, Bread Crumbs and Route...
  • Page 158 Infotainment System Sort by Road Name: Touch to User Defined: Touch to define Traffic conditions display traffic events in the individual types of icons that The following traffic condition icons alphabetical road name order. are displayed for traffic flow and may display: traffic conditions.
  • Page 159 Infotainment System Select to enable the guidance alert pop-up to be viewed on the map or on the main screens such as audio, phone, etc. A appears to indicate the guidance alert mode is on. Driver Alerts Alert Road Condition Select either Manual or Automatic Station Selection mode to choose a radio station that broadcasts Traffic...
  • Page 160 Infotainment System Delete Saved Destinations Use Specified Location : Select to start the simulation from a specified location. Once the starting position for the simulation is selected, select Navigation and the Map display will be in Simulation mode. SIM is displayed on the map.
  • Page 161: Global Positioning

    Infotainment System To exit from Simulation mode, return Signals are obstructed by tall If a tunnel runs parallel to a buildings, trees, large trucks, to the Navigation Settings menu, surface road. select Route Simulation, then select or a tunnel. The vehicle has been transferred Cancel Route Simulation.
  • Page 162: Problems With Route

    Infotainment System The 12-volt battery is Automatic rerouting might produced. The map data is updated disconnected for several days. display a route returning to the periodically, provided that the map set waypoint if heading for a information has changed. The vehicle is driving in heavy destination without passing traffic where driving is at low To check for the availability of...
  • Page 163: Voice Recognition

    Infotainment System Voice Recognition When the system does not Press twice on the steering recognise the command, the wheel to skip the voice prompt Voice recognition allows for system says pardon. messages. hands-free operation of the If experiencing difficulty with the Cancelling Voice Recognition infotainment system features.
  • Page 164 Infotainment System When using navigation Phone : Use this command to learn Tune AM (frequency) or Tune FM commands, take the time to about how to dial, pair a device, (frequency) : Instructs the system become familiar with the or delete a device. to go to the specific station.
  • Page 165 Infotainment System Redial or Redial Last Number : Play Song (song title) : Instructs Search Folder (folder name) : Instructs the system to dial the last the system to play a specific song. Instructs the system to show a list of phone number called.
  • Page 166 Infotainment System Settings Commands No, Nope, Na, No way, Wrong, 3. Clearly speak one of the Incorrect, Negative, Not really, No commands in this section. Verbose (set) on (mode), Verbose I said, No I Did Not, No I Do Not : The following commands only apply (set) off (mode) : Instructs the These can be used to say No.
  • Page 167: Personalisation

    Infotainment System with that contact can become a Where Am I?, My Location, Personalisation or Current Position : Instructs the route. If the system cannot resolve The Configuration Menu is used to the address, an error displays. system to give the current position adjust features and preferences, of the vehicle.
  • Page 168 Infotainment System MENU switch to highlight the 12hr/24hr Format : Touch to select settings where background noise is desired option and then press 12 hour or 24 hour time format. typically louder than the sound the centre of the switch to system volume.
  • Page 169 Infotainment System Display Settings Display Off : Touch to turn off the Vehicle Settings display. The display will return when Touch the Config button on the See Vehicle Personalisation 0 89. any buttons are pressed or the Home Page, then select Display screen is touched.
  • Page 170: Bluetooth Phone/Devices

    Infotainment System ® Bluetooth Phone/ Bluetooth Controls When using voice recognition: The system may not recognise Devices Use the buttons on the infotainment voice commands if there is too system and the steering wheel to ® much background noise. operate the Bluetooth system.
  • Page 171 Infotainment System Pairing with Infotainment If multiple paired mobile phones phone to enter the PIN are within range of the system, provided in Step 4, or to Controls the radio will connect to the first confirm the six-digit code ® A Bluetooth -enabled mobile phone phone in the list or to the phone...
  • Page 172 Infotainment System 4. Select Device List. 5. Select the new phone to PIN or confirming the six-digit connect to and follow the passcode. The PIN is used in Deleting a Paired Phone/Device screen prompts. Step 4. 1. Touch Config on the Home 4.
  • Page 173 Infotainment System Deleting a Paired Phone The Call Lists menu allows access 1. Press . The system to the phone numbers from the responds Please Say a If the phone name to delete is Incoming Calls, Outgoing Calls, and Command, followed by a tone. unknown, see Listing All Paired Missed Calls menus on the mobile and Connected Phones.
  • Page 174 Infotainment System 3. Select the Incoming Calls, Using the Infotainment Controls Press to answer an Outgoing Calls, or Missed incoming call when another call Rotate TUNE/MENU to Answer or Calls list. is active. The original call is Decline and press TUNE/MENU or placed on hold.
  • Page 175: Text Messaging

    Infotainment System 3. After the call has been placed, Transferring a Call Dual Tone Multi-Frequency rotate TUNE/MENU and (DTMF) Tones Audio can be transferred between choose Merge Calls. ® ® the Bluetooth system and the The in-vehicle Bluetooth system 4. To add more callers to the mobile phone.
  • Page 176 Infotainment System The text messaging feature can also 3. View the message. The be initiated via voice recognition. message view screen is not available while the vehicle is in Using Text Messaging motion. Touch Listen to hear the message through the audio system.
  • Page 177 Infotainment System Replying to Text Messages Incoming Text Messages Touch Dismiss to close the pop-up incoming message screen. Text Messaging Settings 1. Select the desired message A pop-up screen is displayed when from the display of predefined there is an incoming text message. messages to send as the reply.
  • Page 178: Hands-Free Phone

    Infotainment System Touch Manage Predefined various voice features. For 4. Say Dial or Call . Messages to create a user additional information, say Help Once connected, the person called defined message that can be while in a voice recognition menu. will be heard through the audio used later to reply to a text speakers.
  • Page 179 Infotainment System back the digit it heard followed on how to delete this information, by a tone. After the last digit see Deleting a Paired Phone/ has been entered, say Dial. Device. If an unwanted number is repeated back, say Clear to clear the last number.
  • Page 180: Climate Controls

    Climate Controls Climate Controls Climate Control 3. Windscreen demister button 4. Face mode button Systems 5. Fan speed and on/off knob Climate Control Systems Air Conditioning System 6. Bi-level mode button Air Conditioning System ..178 The climate control panel is located 7.
  • Page 181 Climate Controls Turning the temperature control Enter Dual-Zone mode by adjusting Leave the system in automatic knob clockwise past 29°C, will the passenger side temperature operation to: show HI (hottest). control knob when in Turn the air conditioning on Single-Zone mode. Turning the temperature control and off.
  • Page 182 Climate Controls Note outer instrument panel vents, Note windscreen and side window When manually adjusting the The AUTO icons on the demist vents. fan speed, the system will infotainment display are not revert to semi-automatic displayed when the system is Floor and windscreen demist operation.
  • Page 183 Climate Controls Air conditioning cannot be AUTO is displayed turned off in demist mode. when the system is Press to switch the system automatically controlling the Air conditioning may switch off/on. mixture of fresh and off during heavy acceleration, When the system is off, only the recirculated air for optimal towing or when there is rear window demister and...
  • Page 184 Climate Controls Automatic transmission Sensors To prevent false temperature readings, the displayed If the vehicle is stopped for a long The automatic climate control uses temperature will not update at time in hot weather with the engine sensors to maintain temperatures: low vehicle speeds.
  • Page 185 Climate Controls Air Vents The instrument panel and console vents can be adjusted up or down and left or right to allow directional Adjustable Air Vents air flow. The vents have shut-off doors to adjust the air volume. For example, air flow at the centre vents can be reduced to enhance air flow at the rear seat vents.
  • Page 186 A passenger compartment air filter may be fitted to filter contaminants such as pollen and dust from entering the vehicle. This can be fitted by a Holden Dealer. See the Service and Warranty Booklet for the maintenance schedule. Air Conditioning Regular...
  • Page 187: Driving And Operating

    Driving and Operating Driving and Electronic Stability Driving Information Control (ESC) ....198 Operating Driving Environment Cruise Control Cruise Control ....199 Before entering the vehicle Driving Information Object Detection Systems...
  • Page 188: Starting And Operating

    Have Operating wear and early replacement of the steering repaired as soon as brakes. possible by a Holden Dealer. New vehicle running-in It is recommended that the new Mobile phones and CB radios vehicle be driven for at least...
  • Page 189: Ignition Positions

    Driving and Operating Replace tyres when tread wear Ignition Positions Warning indicators are visible. See Tread Depth 0 257. Warning Portable gas cylinders can leak, Regularly check tyres are creating a risk of fire or explosion. properly inflated. See Tyre Do not switch the engine off while As a precaution, ensure adequate Pressure 0 254.
  • Page 190 Driving and Operating ON/RUN/START Driver Information Centre (DIC). If the vehicle cannot be pulled over, See Transmission Messages 0 88 and must be shut off while driving, Stopping the Engine/OFF for more information. When the press and hold the ENGINE START/ The transmitter must be in the vehicle is shifted into P (Park), the STOP button for longer than...
  • Page 191: Starting The Engine

    Driving and Operating See Starting the Engine 0 189 for Note The instruments and audio systems will operate as they do in ON/RUN, more information. The ignition will OFF is when the ENGINE START/ then remain in ON/RUN. but the vehicle will not be able to be STOP button is not illuminated.
  • Page 192: Retained Accessory

    Driving and Operating normal operating temperature. Automatic 5. Press the button on the key, Premature engine wear or or press the lock/unlock button Transmission damage may result. on a front door handle to lock all doors and arm the alarm Retained Accessory system.
  • Page 193: Shift Lever

    Driving and Operating Shift Lever D : Used for general driving. The Caution (Continued) transmission automatically selects the appropriate gear according to Do not press the accelerator the current load and driving pedal with the brakes applied in conditions. any gear except position P or N. +/- : For sport shift mode, move the This will overheat the shift lever to position D then push to...
  • Page 194 Driving and Operating Sport Shift Mode Do not move the shift lever to + Caution or , otherwise A/S mode will be enabled. Do not use the accelerator pedal 3. To return to normal shift mode, to hold the vehicle stationary on move the shift lever right, to an uphill gradient.
  • Page 195 Driving and Operating It can also provide engine-braking After changing the gear and While in A/S mode, 2nd or 3rd by selecting the appropriate lower releasing the shift lever, it returns to gear starts can be selected from gear on a steep downhill grade. the centre position on the left side of a standing start.
  • Page 196: Antilock Brake

    Note: The vehicle's brake system noise of the regulation process. remains operational, but without System (ABS) ABS assistance. Have a Holden The initial self-check may also be The ABS: Dealer check the system as soon audible.
  • Page 197: Brake Assist

    Driving and Operating if the ignition is off. To avoid If the EPB is applied while the Warning draining the battery, do not operate vehicle is in motion, a chime will the EPB too often without the sound, and the DIC message Driving while is on may cause engine running.
  • Page 198: Hill Start Assist (Hsa)

    Driving and Operating stability system hydraulic brake Hill Start Assist (HSA) Ride Control Systems control module increases brake The HSA system assists in pressure at each corner of the Traction Control preventing rollback when driving off, vehicle until the ABS activates. while on an incline.
  • Page 199 Driving and Operating When the light is on solid, the Caution (Continued) system will not limit wheel spin. Adjust your driving accordingly. ESC and/or SERVICE TRACTION CONTROL messages The Traction Control System is automatically enabled whenever the are displayed, the differential vehicle is started.
  • Page 200: Electronic Stability

    Driving and Operating Electronic Stability problem with the vehicle. The conditions, the system should system should initialise before the always be left on. But, ESC can be Control (ESC) vehicle reaches 40 km/h. turned off if needed. The vehicle has an Electronic If the system fails to turn on or If the vehicle is in cruise control Stability Control (ESC) system...
  • Page 201: Cruise Control

    Driving and Operating When the ESC system is turned off, Cruise Control Warning light and the warning light will both be on to warn the driver Do not use the cruise control that both traction control and ESC when road or driving conditions are disabled.
  • Page 202 Driving and Operating Vehicle speed can be Cruise control automatically Warning (Continued) increased by pressing the deactivates when: accelerator pedal. When the Vehicle speed is below Release the accelerator pedal accelerator pedal is released, approximately 30 km/h. when the speed returns to the set the previously stored speed is speed.
  • Page 203: Object Detection Systems

    Driving and Operating Object Detection not respond. The indicator may Warning disappear on curves, highway exit Systems ramps, hills, or due to poor visibility. FCA is a warning system and The FCA system will not detect does not apply the brakes. When Forward Collision Alert another vehicle ahead until it is approaching a slower-moving or...
  • Page 204 Driving and Operating Collision Alert Selecting the Gap Setting timing. The range of selectable alert timing may not be appropriate for all drivers and driving conditions. Unnecessary Alerts FCA may sometimes set unnecessary alerts to turning vehicles, vehicles in other lanes, objects that are not vehicles, When your vehicle approaches or shadows.
  • Page 205: Parking Assist

    Driving and Operating Parking Assist The Parking Assist (PA) system is Warning (Continued) able to detect obstacles in front of and behind the vehicle when disruptive reflections from an moving forward and reversing. object's surface. Such objects The PA consists of sensors on the may not be detected.
  • Page 206 Driving and Operating When an object is detected: If an object enters the range, the sector will illuminate green. A warning tone sounds. When the distance decreases, As the distance decreases, the additional sectors will illuminate repetition rate of the tone and the colour will change to increases.
  • Page 207 When a forward gear is selected Flashes when the button is after reverse, the front and rear pressed. sensors will remain operational until Contact a Holden Dealer. the vehicle's speed exceeds 15 km/h. Objects attached to the vehicle If a forward gear is selected, only...
  • Page 208: Side Blind Zone

    3.5 m. Note cyclists or animals. Failure to use This zone starts at each side mirror This adjustment is for Holden proper care when changing lanes and goes back approximately 5 m. approved tow bars fitted by a...
  • Page 209 Driving and Operating How the System Works SBZA displays may come on when the Vehicle" under Exterior Care a passed vehicle remains in or 0 273. If the DIC still displays the The SBZA symbol lights up in the drops back into the detection zone. SIDE DETECTION SYSTEM side mirrors when the system UNAVAILABLE message after...
  • Page 210: Rear Vision Camera (Rvc)

    Cleaning damage in the area of the camera Warning (boot lid), it may become Never rely solely on the rear misaligned. Contact a Holden vision camera when reversing the Dealer. vehicle. Always keep the camera lens free There is a blind spot that cannot from dirt, snow or ice.
  • Page 211 Driving and Operating 9. Select reverse gear. Default Display Selection Warning The default display Park Assist or Rear View Camera may be Do not use abrasive cleaners or selected: scouring pads as they could scratch the lens, impairing the 1. Turn the ignition on. systems performance.
  • Page 212: Lane Departure Warning (Ldw)

    The LDW system is an aid to help camera lens. Contact a Holden damage, injury, or death could the vehicle stay in the driving Dealer.
  • Page 213 Driving and Operating When the vehicle crosses a The camera sensor may be detected lane marking, the LDW blocked by dirt, snow or ice. indicator will flash and three beeps The windscreen may be will sound. LDW will not warn if the damaged.
  • Page 214: Driver Assistance Systems

    Driving and Operating LDW warnings may occasionally Driver Assistance Parallel space length vehicle length plus 1.1 m up to 20.0 m occur due to tar marks, shadows, Systems cracks in the road, or other road Minimum perpendicular space imperfections. This is normal system width vehicle width plus 1.0 m Advanced Parking Assist...
  • Page 215 Driving and Operating Press and hold for 2 seconds Perpendicular search 0.7 m The APA will automatically control the steering and display to initiate a perpendicular to 1.5 m is recommended for parking space search. A beep optimum detection messages on the DIC with the will be heard.
  • Page 216 This may system functionality. be due to kerbs at a If a Genuine Holden Always manoeuvre the vehicle reclined angle or leaves in Accessory roo bar is fitted, slowly to allow yourself sufficient...
  • Page 217: Fuel

    Fuel is extremely flammable and EXHAUST WARNING of the vehicle is damaged. highly explosive. CARBON MONOXIDE Take the vehicle to a Holden Always switch off the engine of POISONING Dealer if you think the vehicle the vehicle and any mobile...
  • Page 218: Recommended Fuel

    The use of fuel additives damage to the vehicle and that are not recommended by personal injury. Recommended Fuel Holden may affect your New The use of fuel containing more Vehicle Voluntary Warranty to the Unleaded petrol than 10% ethanol may also affect...
  • Page 219: Filling The Tank

    Driving and Operating Purchasing your fuel from a 2. Push on the rear edge of the reputable fuel retailer may reduce fuel filler flap located on the the risk of purchasing fuel which right side of the vehicle. contains abnormal fuel properties. 3.
  • Page 220: Trailer Towing

    When towing a trailer: equipment which should be used. purpose trailer. Do not drive with the Holden will not accept liability for Towing boot open. defects occurring in towing Handling, durability and economy Fully open the instrument...
  • Page 221 Ensure the weight of the packed have affected the specifications or trailer is not greater than the towing quality of the vehicle. See Towing capacity of the Holden approved and loading equipment later in this tow bar package fitted to the section.
  • Page 222 Towing and loading equipment Tow load Mandatory equipment Recommended equipment Up to 1,200 kg Holden 1,200 kg rated tow bar Holden trailer wiring harness Brakes on the trailer if the aggregate trailer mass (ATM) is more than 750 kg Between 1,201 kg...
  • Page 223 *Electric brake controller provision is aiding brake performance. This also 2. Adjust superlift inflation provided in the Holden Genuine enables more load to be carried in pressure so the bottom edges Accessory Trailer Wiring Harness.
  • Page 224 Driving and Operating Ensure superlift shock absorbers At highway speeds it is Warning are adjusted correctly. See recommended that the cruise Superlift shock absorbers control be used. Cruise control At no time may the total front or previously in this section. prevents the transmission from rear axle load exceed the unnecessarily changing gears,...
  • Page 225: Trailer Sway Control (Tsc)

    Driving and Operating bar tongue. See Adjustment for Trailer Sway Conversions and a towbar under Parking Assist Control (TSC) Add-Ons 0 203. If the system detects trailer sway Trailer brakes Add-On Electrical movements, engine power is Trailer brakes are mandatory on reduced and the vehicle/trailer Equipment trailers with an aggregate trailer...
  • Page 226 Driving and Operating The Holden Genuine Accessories are an exception, however they should be removed in high load and high temperature conditions. Caution In high load and high temperature applications (e.g. towing) no objects should be fitted over the upper or lower air intake at the front of the vehicle, as this could affect cooling.
  • Page 227: Vehicle Care

    Wheels and Tyres General Information Tyre Pressure ....254 Where specified, use only Holden Tyre Pressure Monitor genuine parts and accessories. System ..... . 255...
  • Page 228 Avoid long engine warm ups. They It is recommended that servicing be converter and closed loop are unnecessary and waste fuel. carried out by an authorised Holden mixture control system. Dealer who will maintain the Avoid long engine idling. It is recommended that service and...
  • Page 229: Vehicle Checks

    Vehicle Care Riding the brake Vehicle Checks Do not rest your foot on the brake Bonnet pedal when you do not intend to brake. Opening Air conditioning Switch off the air conditioning when not required, however, once every 2 weeks, with the engine running, switch the air conditioning on for 5 to 10 minutes to lubricate the seals (even in winter).
  • Page 230: Overview

    Vehicle Care Engine Compartment Overview Warning If while driving you notice that the bonnet has not been properly closed, pull the vehicle over to the side of the road at the earliest possible moment and close the bonnet correctly. Note If the wiring of the bonnet switch is damaged or tampered with, it will be detected by the vehicle...
  • Page 231: Engine Oil

    Vehicle Care Engine Oil This may raise the oil level creating a false reading on the engine oil dipstick. Danger For example, in a vehicle that has Engine oil is an irritant and if accumulated 1,500 km of short distance or intermittent city ingested can cause illness or operation and has consumed a death.
  • Page 232: Engine Coolant

    Scalding fluid and steam can Vehicle Voluntary Warranty, to the 1. Rotate the engine oil filler cap be blown out under pressure extent that Holden considers the anticlockwise and remove. non-recommended fluid to have which could cause serious burns.
  • Page 233 Vehicle Care 3. When the engine is cold, the 1. Mix a solution of Holden coolant level should be at or coolant and clean fresh water. above the minimum mark (2). 2. Add coolant into the coolant When the engine is warm, the...
  • Page 234: Engine Overheating

    Vehicle Care Coolant helps the cooling Engine Overheating Danger system in hot weather by increasing the boiling point. Caution Do not open the bonnet if you can Coolant protects against freezing see or hear steam or coolant down to 37 °C, provided the Immediate action is required if the escaping from the engine specified concentration is...
  • Page 235 Vehicle Care 2. Ensure the shift lever is in P or 4. If you do not find anything neutral and apply the park wrong, check the engine brake. coolant level. See Engine Coolant 0 230. 3. Exit the vehicle and listen to check that the cooling fan is 5.
  • Page 236 Vehicle Care 3. Cover the cap with a thick cloth and rotate slowly anticlockwise to remove. Caution Do not spill coolant on the vehicle's exterior surfaces as it can damage the paintwork. If you do, wash it off immediately. 4. As well as adding coolant to the coolant reservoir, add coolant directly through the radiator cap opening until full.
  • Page 237: Washer Fluid

    Wait 30 seconds and top up if If the coolant requires regular the level drops. topping up, contact a Holden Dealer. 9. Replace the radiator cap. Note 10. Turn the ignition off.
  • Page 238: Brake Fluid

    5. Secure the cap and clean up quickly absorb moisture. any spilt fluid. Adding brake fluid If the brake fluid requires regular Use heavy duty brake fluid. See topping up, contact a Holden Dealer Recommended Fluids and immediately. Lubricants 0 279. 1. Turn the ignition off.
  • Page 239: Battery

    (EPM) system may not operate features are adjusted. See correctly. Personal identity keys under Keys 0 16. For replacement, refer to a Holden Dealer or authorised repairer.
  • Page 240: Bulb Replacement

    Clean stained bulbs with the vehicle. Condensation occurs methylated spirits. when there is a temperature Bulbs to be changed by a Holden difference between the inside and Dealer outside of the lamp allowing a fine Brake/tail lamps (LED type) mist on the inside surface of the lamp lens.
  • Page 241: Headlamps

    It is strongly recommended that the 2. Park lamps (W5W bulb) Place a clean rag over the high and low beam bulbs are opening of the coolant 3. Headlamp wiring connector replaced by a Holden Dealer, as reservoir. they operate at high voltage.
  • Page 242: Front Turn Signal Lamps

    Vehicle Care Park lamps 6. Install components removed in 5. Insert the new bulb and install Step 1. the bulb holder following the Front park lamps guide tab. Ensure that the 7. Check lamp operation. same colour bulb is used. 1.
  • Page 243 2. Raise the spare wheel cover Note and attach the T-piece to the The stop/tail bulb is an LED and is boot lid. See Tyre Changing only replaceable by a Holden 0 265. Dealer. 3. Unscrew and remove the four convenience net retaining screws securing the plastic boot trim.
  • Page 244: Number Plate Lamp

    Vehicle Care Rear turn signal and reverse Ensure that the same colour 2. Pull the lamp assembly bulb is used. downwards. lamps 5. Install the bulb holder into the lamp. 6. Install the components removed in Step 1. 7. Check lamp operation. Number Plate Lamp (W5W bulb) 1.
  • Page 245: Interior Lamps

    Vehicle Care 8. Check lamp operation. 2. From the rear side, remove the Glovebox lamp, door courtesy lamps bulb holder from the lamp Interior Lamps housing by rotating the bulb (5W bulb) holder anticlockwise. Rear dome/reading lamps Note (W5W bulb) Do not remove the lens from the lamp assembly.
  • Page 246: Electrical System

    Vehicle Care Electrical System Colour Rating (amps) Warning (Continued) Fuses involving the electrical system or Blue the replacement of high current fuses or relays carried out by a Yellow Warning Dealer. Natural Turn off the ignition and any Green electrical equipment before Fuses and relays changing a fuse.
  • Page 247 Vehicle Care To refit, replace the cover and Fuse and relay index rotate the catch clockwise to secure.
  • Page 248 Vehicle Care The vehicle may not be equipped DECKLID PASSIVE ENTRY with all of the fuses and relays FLASHING LAMPS PASSIVE shown. / EDI MODULE START-BATT 1 Fuses AUXILIARY MEMORY SEAT BATTERY MODULE DRIVER FRONT / LH REAR AMPLIFIER WINDOW PASSENGER EMER / VEH FRONT / RH...
  • Page 249 Vehicle Care Note ENGINE TRAILER Relays R1, R2, R3 and R5 are PCB CONTROL MODULE mounted relays and are not MODULE replaceable. Relays AUXILIARY BOOT RELEASE Cabin fuse panel GAUGES ACCESSORY RETAINED ACCESSORY POWER BATTERY VOLTAGE SENSING RETAINED ACCESSORY POWER TAILGATE MOTOR 30A LOGISTICS MODE REAR...
  • Page 250 Vehicle Care Refitting fuse panel cover 1. Insert the rear edge of the fuse panel cover under the door seal. 2. Locate the hooks on the cover into the end of the instrument panel. 3. Rotate and push the cover back into position.
  • Page 251 Vehicle Care Cabin fuse and relay index AIRBAG / AOS CB26 - The vehicle may not be equipped INSTRUMENT BODY CONTROL with all of the fuses and relays CLUSTER MODULE 8 shown. HVAC CONTROL BLOWER FAN Fuses MODULE ACCESSORIES BODY CONTROL RAIN SENSOR BODY CONTROL MODULE 1...
  • Page 252 Vehicle Care Engine compartment fuse panel 1. Main fuse/relay box Remove the clip-on cover to access. Ensure the cover is replaced securely.
  • Page 253 Vehicle Care Engine compartment fuse and ABS VALVES FOG LAMPS relay index IGNITION-IP The vehicle may not be equipped / BODY with all of the fuses and relays FUEL SYSTEM shown. HEATED FRONT CONTROL SEATS HEATED MODULE MIRRORS IGNITION REAR DEMISTER FRONT 7.5A ESCL...
  • Page 254 Vehicle Care Relays RH HID HORN DRIVING LAMPS HEADLAMP Note HEADLAMP WASHER LH & RH HI BEAM Relays R3, R4, R12, R13 and R20 HEADLAMP REAR WASHER PUMP are PCB mounted relays and are HORN not replaceable. FRONT WASHER PUMP ENGINE REAR DEMISTER COOLING FAN...
  • Page 255: Vehicle Tools

    Vehicle Care Vehicle Tools Spare wheel Tools Tools Tyre repair kit The vehicle may have an emergency tyre sealant and air compressor kit in place of the jack, tools and spare tyre. 1. Jack The vehicle may have a spare wheel, which is located in a 2.
  • Page 256: Wheels And Tyres

    Vehicle Care Wheels and Tyres The front tyre pressures are shown Check pressures when the vehicle has been stationary for in the left column and the rear tyre pressures are shown in the right over 3 hours. If tyre pressures Tyre Pressure column.
  • Page 257: Tyre Pressure Monitor

    Vehicle Care Low profile sports tyres indicated on the tyre placard, you The TPMS includes a malfunction should determine the correct tyre indicator to warn if the system is not Low profile tyres are expected to inflation pressure for those tyres.) operating properly.
  • Page 258: Tyre Pressure Monitor

    Vehicle Care See Tyre Pressure Monitor inflation pressure. Using the DIC, it Caution Operation 0 256 for additional may be possible to view the tyre information. pressure levels. For additional Tyre sealant materials are not all information and details about the the same.
  • Page 259: Tread Depth

    Vehicle Care one minute and then stays on for Replacement tyres or wheels do if equipped, should go off at the next the remainder of the ignition cycle. not match the original equipment ignition cycle. The sensors are A DIC warning message may also tyres or wheels.
  • Page 260: Tyre Rotation

    Vehicle Care show as plain bars across the Tyre Rotation New tyres should be fitted in pairs to tread pattern at regular intervals the front. If replacing only one tyre, It is recommended that you rotate around the tyre. pair it on the same axle with the tyres at every scheduled least worn of the other three.
  • Page 261: Wheel Alignment And Tyre

    Take the vehicle to a Holden Dealer and tyres may affect the New to have the tyre repaired or replaced Vehicle Voluntary Warranty as well Tyre Chains as soon as possible.
  • Page 262 Do not connect to the power assembly. socket yet. Replacement tyre sealant canisters 5. Unscrew the tyre valve cap are available from a Holden Dealer. 1. On/off switch anticlockwise and remove. 2. Air pressure gauge Temporary puncture repair 6. Attach the sealant-air delivery 3.
  • Page 263 13. Switch the compressor off to 11. Check the air pressure get an accurate reading. Contact a Holden Dealer. gauge (2). The pressure gauge (2) reads If there is no pressure reading slightly high while the...
  • Page 264 This is a temporary puncture repair. 20. Drive the vehicle immediately Take the vehicle to a Holden Dealer for at least 8 km to distribute to have the tyre repaired or replaced the sealant evenly within as soon as possible.
  • Page 265 Vehicle Care Inflating tyres without sealant Do not jam the 12 volt power If there is no pressure reading connection cable in the door, while the compressor is boot/tailgate or window. running, check for leaks at the connection between the hose 5.
  • Page 266 2. Pull the air-only delivery 6. Dispose of the tyre sealant manoeuvres or a collision. hose (4) from the tyre sealant canister at a Holden Dealer or canister. in accordance with local or 3. Unwrap the sealant-air delivery State codes and practices.
  • Page 267: Tyre Changing

    Vehicle Care To install a new tyre sealant Tyre Changing Warning (Continued) canister: Warning Use the jack only for lifting the vehicle when changing wheels. All passengers must be out of the Do not get under a vehicle that is vehicle when it is being jacked.
  • Page 268 Vehicle Care 3. Switch the hazard warning flashers on. 4. Turn the ignition off and remove the key from the vehicle. 5. Place the shift lever in P. 9. Lift the cover by attaching the 11. The vehicle may have a T-piece/hook to the boot lid.
  • Page 269 Vehicle Care Ensure that the jack is not tilted Caution and the base is resting squarely on the ground. Ensure that the wheel wrench is fully unfolded. Warning Failure to position the jack as described could cause the vehicle to slip off the jack. Do not get under a vehicle that is supported by a jack.
  • Page 270 Vehicle Care 26. With the wheel on the ground, use the extended or unfolded wheel wrench to tighten the wheel nuts in the sequence shown. 19. Rotate the wheel wrench 27. Replace the tools, container clockwise. and flat tyre in the boot. 20.
  • Page 271 Vehicle Care Trolley jack or vehicle hoist Warning (Continued) torque in the sequence shown (refer to Step 26), as wheel nuts which have not been tightened properly could eventually allow the wheel to come off while the vehicle is moving. 1.
  • Page 272: Jump Starting

    If you are still unsure about jump system may not work Do not attempt jump starting starting, Holden strongly correctly. Refer to your directly from the battery. recommends for your safety and Dealer for battery that of the vehicle that you seek the replacement.
  • Page 273 Vehicle Care These posts are to be used instead 2. Apply the park brakes. Warning (Continued) of a direct connection to a battery. 3. Place the shift lever in P. The positive jump start connection If a permanently connected 4. Turn the ignition switch off. post is covered by a red cap.
  • Page 274: Towing The Vehicle

    Vehicle Care 8. Connect one end of the BLACK Note Towing the Vehicle jumper lead to the negative Refit the red protective cap to terminal (3) of the charged the positive jump start Warning battery. connection post following removal of the jumper leads. 9.
  • Page 275: Appearance Care

    Bird droppings, dead insects, resin, Have the door hinges of all doors Attachment locations pollen and the like should be greased by a Holden Dealer. An oval shaped slot (1) is provided cleaned off immediately, as they underneath the front of the vehicle.
  • Page 276 Never use abrasive cleaners to exist in the engine bay or boot and clean glass. Air intakes on the underside of the vehicle. Refer to a Holden Dealer for Clear debris from the air intakes, windscreen washer additive. between the bonnet and windscreen Warning...
  • Page 277: Interior Care

    Warning Do not use abrasive cleaners. Have more extensive damage or Many cleaning products are toxic, Door drain holes rust areas repaired by your Holden flammable or may damage the Dealer. interior. When cleaning the interior, avoid volatile cleaners Caution...
  • Page 278: Floor Mats

    Vehicle Care Leather Leather has an elasticity and Warning (Continued) may stretch. This is a natural Clean regularly using a leather characteristic of leather. revitaliser or mild detergent. cleaners and always follow the cleaning product manufacturer's Apply revitaliser using a lint free Caution recommendations.
  • Page 279 Make sure the floor mat does not interfere with the accelerator or brake pedal. Original equipment and Genuine Holden Accessory floor mats are designed for your vehicle. If the floor mats need replacing, it is recommended that Holden approved floor mats be purchased.
  • Page 280: Service And Maintenance

    Service and Maintenance Service and General Information Maintenance Service Information In order to ensure economical and safe vehicle operation and to General Information maintain the value of your vehicle, it Service Information ... 278 is of vital importance that all Recommended Fluids, maintenance work is carried out at...
  • Page 281 LN3 600 cold cranking amps (CCA), 120 minutes reserve capacity. Warning Use only a manufacturer recommended battery with a ventilation system. Use of other batteries may affect the electric power management system and allow explosive gases into the vehicle cabin. Refer to a Holden Dealer or authorised repairer.
  • Page 282: Technical Data

    Technical Data Technical Data Vehicle Identification Vehicle Identification Vehicle Identification Number (VIN) Vehicle Identification Number (VIN) ....280 Identification Plate ... . 281 Vehicle Data Engine Data .
  • Page 283: Identification Plate

    Technical Data Identification Plate Compliance label This label shows the vehicle make, model series, date of manufacture, Vehicle Identification Number (VIN), Cooling system/air conditioning combination, air conditioning, paint approved seating capacity and label number, engine, transmission, axle approval number. ratio options, suspension options Label (1) shows the warnings for the (where applicable) and build date.
  • Page 284 Technical Data Engine number location The engine number is located at the rear of the engine on the passenger side. The engine number can be viewed from the top, using a mirror, after the engine cover has been removed.
  • Page 285: Vehicle Data

    Minimum Regular unleaded 91 Recommended Premium unleaded 95 Ethanol compatibility *For further information see Recommended Fuel 0 216. Air conditioning specifications Refrigerant type R-134A Refrigerant charge 480 g +/- 20 g Compressor oil type Polyalkylene glycol (Holden part no. 90510419)
  • Page 286: Vehicle Weight

    Technical Data Note Warning The carrying capacity assumes that no accessories are fitted. The air conditioning system If accessories are fitted, the should be serviced by qualified carrying capacity must be personnel only. Improper service decreased accordingly. See methods may cause personal Additional Weights 0 285.
  • Page 287: Additional Weights

    Additional Weights If the vehicle is fitted with Genuine A. Vehicle carrying capacity Example loading guide Holden Accessory 20 inch wheels (example 450 kg) and Holden recommended tyres, the B. Subtract occupant weight maximum rear axle load is 1,300 kg.
  • Page 288: Vehicle Dimensions

    Technical Data Vehicle Dimensions Dimensions (mm) Length Width Width Height Wheel Front Rear Front Rear excl. incl. base overhang overhang track track mirrors mirrors Caprice 5160 1898 2099 1470 3009 1281 1593 1608 The above figures are based on the design dimensions. Capacities and Specifications Engine type 6.2L Generation IV V8...
  • Page 289: Tyre Pressure

    Technical Data Tyre Pressure Caprice Wheel size and Recommended pressure Tyre size profile Normal load Maximum load Spare Front Rear Front Rear 245/40 R19 XL 98W 19 x 8.5 J...
  • Page 290: Customer Information

    Holden Customer Care Holden Customer Care Office Customer Information At Holden, we want you to be Should you wish to speak to a Owner Assistance ... . 288 completely satisfied with your Holden representative, you are ownership experience.
  • Page 291 Most of this information will be This number provides access to found on the Vehicle Identification New Zealand Roadside Assistance You can also write to Holden at the Certificate, located inside the front as well as New Zealand address below: cover of the Service/Warranty Customer Care.
  • Page 292: Index

    Index Index Antilock Brake System (ABS) . . . 194 Warning Light ....75 Accessory Power ....190 Appearance Care Add-On Electrical Equipment .
  • Page 293 Index Battery (cont'd) Compressor Kit, Tyre Voltage and Charging Sealant ......259 Camera, Rear Vision ... 208 Messages .
  • Page 294 Index Displays Engine Forward Collision Alert Automatic Transmission ..190 Check and Service Engine (FCA) System ....201 Dome Lamps ....96 Soon Light .
  • Page 295 Index Gauges (cont'd) Horn ......13, 66 Warning Lights and How to Wear Seat Belts Jump Starting ....270 Indicators .
  • Page 296 Index Light Lights (cont'd) Messages (cont'd) Electronic Stability Control Tyre Pressure ....77 Engine Oil ..... . 85 Load Compartment Lamps .
  • Page 297 Index Owner Assistance ....288 Navigation Radio Destination ....147 Personalisation .
  • Page 298 Index Replacing Airbag System ..50 Seats Starting the Engine ... . . 189 Replacing Seat Belt System Head Restraints ....36 Starting the Vehicle Messages .
  • Page 299 Index Tyre Pressure ....287 Vehicle (cont'd) Tyres Remote Start ....22 Tachometer .
  • Page 300 Index Weights Additional ..... 285 Vehicle ..... . . 284 Wheels Alignment and Tyre Balance .

This manual is also suitable for:

Wn caprice

Table of Contents
