Linear M13-631 Manual

WIRELESS KEYLESS ENTRY
The Wireless Keyless Entry System offers you the convenience of opening and
closing your garage door by entering your own 4-digit Personal Identification Number
(PIN) via the keypad. The WKE can be programmed wireless to control up to 4 garage
door operators that each work on a different code, or to control one garage door
operator with up to 4 different PINs. You can also program it to allow a temporary PIN
of your choice to be stored, to provide temporary access to authorized visitors or service
persons. Check the box content to familiarize yourself with parts shown in Fig.1 and 2.
Other Features Include:
Wireless Installation, Wireless Programming, Low Battery Indication, One-Button-to-Close
Operation, Backlit Keypad, Code Security, Anti-Tampering, and Weather-Resistant Design.
PROGRAM PIN AND TRANSFER TRANSMITTER CODE
1
Install batteries provided, see Fig. 2.
Press and hold button
for at least 3 seconds to
activate programming mode,
LED's light up for 10
seconds.
4
Press and release the ENTER
button.
LED's and keypad buttons
will light up for 2 seconds
signaling programming
is completed.
CHANGE AN EXISTING PIN
1
Press button for at least
3 seconds, LED's will flash
slowly. Release button.
For more information, please visit www.devancocanada.com or call toll free at 855-931-3334
MODEL M13-631
•
To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door:
•
•
•
•
2
Hold transmitter very close
to keypad buttons
Press and hold transmitter
button you use to open and
close your garage door.
Release transmitter
button when LED's on
keypad flash.
5
Test WKE by entering
the PIN, then press
ENTER
button.
2
Enter the programmed PIN
that you want to change.
Press the ENTER button.
LED's will flash rapidly.
Install Wireless Keyless Entry System within sight of the garage door, out of reach of
children at a minimum height of 5 feet (1.5m) and away from ALL moving parts of the door.
ALWAYS keep remote controls out of reach of children. NEVER permit children to
operate, or play with remote controls.
Activate gate or door ONLY when it can be seen clearly, is properly adjusted, and
there are no obstructions to door travel.
ALWAYS keep gate or garage door in sight until completely closed. NEVER permit
anyone to cross path of moving gate or door.
3
and
NOTE: To program the
WKE to more than one
garage door operator
(maximum 4), repeat the
steps above using a new
PIN for each additional
garage door operator.
3
Enter the new 4-digit PIN of
your choice # # # # then
press the ENTER
LED's and keypad light up
for 2 seconds.
Enter a 4-digit personal
identification number
(PIN) of your choice # # # #.
4
To test WKE, enter the new PIN
then press the ENTER button.
The garage door opener
button.
will activate.
Limited
LW
Warranty
1 Year
