Optix Series
LCD Monitor
Optix MAG342CQR (3DB6)
Optix MAG342CQRV (3DB6)
MAG342CQPV (3DB6)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Optix MAG342CQR and is the answer not in the manual?

Questions and answers

Håkan Johansson
January 26, 2025

Can not reach the OSD menu, option buttons does not work. Power on starts monitor and and select DP monitor automatically. Cannot select HDMI monitor, This has been like this since purchase. No monitor buttons work

1 comments:
Mr. Anderson
February 10, 2025

The option buttons on the MSI Optix MAG342CQR monitor may not be working due to several possible reasons:

1. Button Lock Feature: The buttons might be locked. Check if there is a button lock feature enabled in the settings and disable it if necessary.

2. Power or Connection Issue: Ensure the monitor is properly powered on and connected to the PC.

3. Firmware or Software Issue: Restart the monitor and check if the issue persists. Updating firmware might help.

4. Physical Damage or Dirt: Inspect the buttons for any physical damage, debris, or dirt that may be obstructing their function.

5. OSD Settings Reset: If possible, reset the monitor settings to default via the control button.

If the issue continues, consider contacting MSI technical support.

This answer is automatically generated

Summary of Contents for MSI Optix MAG342CQR

  • Page 1 Optix Series LCD Monitor Optix MAG342CQR (3DB6) Optix MAG342CQRV (3DB6) MAG342CQPV (3DB6)
  • Page 2: Table Of Contents

    Contents Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Technical Support ���������������������������������������������������������������������������������������������������iii Safety Instructions ���������������������������������������������������������������������������������������������������iv CE Conformity ���������������������������������������������������������������������������������������������������������vi FCC-B Radio Frequency Interference Statement ���������������������������������������������������vi WEEE Statement ���������������������������������������������������������������������������������������������������vii Chemical Substances Information �������������������������������������������������������������������������vii RoHS Statement ����������������������������������������������������������������������������������������������������vii Getting Started �������������������������������������������������������������������������������1-1 Package Contents ������������������������������������������������������������������������������������������������ 1-2 Installing the Monitor Stand ����������������������������������������������������������������������������������...
  • Page 3: Copyright And Trademarks Notice

    Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be trademarks of their respective owners� No warranty as to accuracy or completeness is expressed or implied�...
  • Page 4: Safety Instructions

    Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the device or user’s manual should be noted� ◙ Refer servicing to qualified personnel only. Keep the User’s Guide that comes with the package for future reference� To prevent fire or shock hazard, keep this device away from humidity and high temperature�...
  • Page 5 Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper disposal, take-back, recycling, and disassembly of MSI products�...
  • Page 6: Ce Conformity

    1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp� 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com...
  • Page 7: Weee Statement

    Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
  • Page 9: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity� IMPORTANT • The illustrations are for reference only� Your monitor may vary in appearance� •...
  • Page 10: Package Contents

    Package Contents 1� Monitor 2� Stand 3� Stand Base with Screw 4� Stand Screws x4 5� Power Adapter & Power Cord 6� HDMI Cable (Optional) 7� DisplayPort Cable (Optional) 8� Quick Start Guide 9� Warranty Card 10� Registration Card * Contact your place of purchase or local distributor if any of the items is damaged or missing�...
  • Page 11: Installing The Monitor Stand

    Getting Started Installing the Monitor Stand IMPORTANT Place the monitor on a soft, protected surface to avoid scratching the display panel� The holes for installing the stand can be also used for wall mount� Please contact your dealer for proper wall mount kit� 1�...
  • Page 12: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities� IMPORTANT • Avoid touching the display panel when adjusting the monitor� • The reserved pivot 5° is designed for adjusting the level imbalance of some tables� 90mm...
  • Page 13: Monitor Overview

    Getting Started Monitor Overview...
  • Page 14 Menu Key Select Key Select Key Enter Key Power Button LED Indicator White: On Orange: Standby HDMI 1�4 Port (Optional) HDMI 2�0 Port (Optional) DisplayPort 1�2 (Optional) DisplayPort 1�4 (Optional) Headphone Jack Power Jack Kensington Lock...
  • Page 15: Connecting The Monitor To Pc

    Getting Started Connecting the Monitor to PC 1� Turn off your computer. 2� Connect the HDMI/DisplayPort cable from the monitor to your computer� 3� Assemble the monitor power adapter & power cord�(Figure A) 4� Connect the power adapter to the monitor power jack�(Figure B) 5�...
  • Page 17: Osd Setup

    OSD Setup This chapter provides you with essential information on OSD Setup� IMPORTANT All information is subject to change without prior notice�...
  • Page 18: Osd Key

    OSD Key The monitor comes with a set of OSD Key that helps to control the On-Screen Display (OSD) menu�...
  • Page 19 OSD Setup Without entering OSD menu, you can use these OSD keys as hot keys for quick seetings� OSD Key Function Basic Operations Game Mode ■ Press button to enter this setting� ■ Press button to select� ■ Press button to confirm and exit. Screen Assistance ■...
  • Page 20: Osd Setup Menu

    OSD Setup Menu Press button to launch the On-Screen Display (OSD) main menu� In OSD screen, buttons to tune the desired function to suit your personal preferences� These OSD keys operations are as follows� OSD Key Basic Operations ■ Exiting the current menu ■...
  • Page 21 OSD Setup Optix MAG342CQR Optix MAG342CQRV/ MAG342CQPV h Gaming 1st Level Menu 2nd/3rd Level Menu Description Game Mode User User mode� First person shooting game mode� Racing Racing game mode� Strategic game mode� RPG game mode�...
  • Page 22 1st Level Menu 2nd/3rd Level Menu Description Night Vision ■ This function optimizes background brightness and is recommended for FPS Normal games� Strong Strongest A�I� Response Time Normal ■ Users can adjust Response Time in any Mode� Fast Fastest Anti Motion Blur ■...
  • Page 23 OSD Setup 1st Level Menu 2nd/3rd Level Menu Description Adaptive-Sync ■ Adaptive-Sync prevents screen tearing� (OFF) ■ DisplayPort or HDMI default is OFF and can be adjusted ON/OFF in any mode, (ON) any resolution, any input source and any screen refresh rate� ■...
  • Page 24 h Image 1st Level Menu 2nd/3rd Level Menu Description Brightness 0-100 ■ Users can adjust Brightness in User, RTS, RPG and Reader mode� Contrast 0-100 ■ Users can adjust Contrast in any Mode� Sharpness ■ Users can adjust Sharpness in any Mode� ■...
  • Page 25 OSD Setup h PIP/PBP 1st Level Menu 2nd/3rd Level Menu Description ■ PIP (Picture in Picture) allows users to simultaneously display multiple video Source sources on one screen� One program is HDMI1 displayed on the full screen at the same HDMI2 time as one or more other programs are displayed in inset windows�...
  • Page 26 h Setting 1st Level Menu 2nd Level Menu Description Language 繁體中文 ■ Language factory default is English� ■ Users have to press the Middle Button to confirm English and apply the Language setting� Français ■ Language is an independent setting� Users’ own Deutsch language setting will override the factory default�...
  • Page 27: Appendix

    Appendix IMPORTANT All information is subject to change without prior notice�...
  • Page 28: Specifications

    Specifications Optix MAG342CQRV (3DB6) Model Optix MAG342CQR (3DB6) MAG342CQPV (3DB6) Size 34 inch Curvature 1500R Panel Type Resolution 3440x1440 @144hz 3440x1440 @100hz Aspect Ratio 21:9 Brightness (nits) 300 nits (typ�) 250 nits (typ�) Contrast Ratio 4000:1 (typ�) 3000:1 (typ�) Refresh Rate...
  • Page 29 Appendix Optix MAG342CQRV (3DB6) Model Optix MAG342CQR (3DB6) MAG342CQPV (3DB6) VESA Mounting ■ Plate Type: 75 x 75 mm ■ Screw Type: M4 x 10 mm ▶ Thread Diameter: 7 mm ▶ Thread Pitch: 7�9 mm ▶ Thread Length: 35 mm Dimension (W x H x D) 808�6 x 270�0 x 514�2 mm...
  • Page 30: Preset Display Modes

    Preset Display Modes Standard Resolution Optix MAG342CQR (3DB6) HDMI1 HDMI2 640x480 @60Hz 640x480 @75Hz Dos-Mode 720x400 @70Hz 720x480 @60Hz 720x576 @50Hz SVGA 800x600 @60Hz 800x600 @72Hz 800x600 @75Hz XVGA 1024x768 @60Hz 1024x768 @75Hz SXVGA 1280x720 @50Hz 1280x1024 @60Hz 1280x1024 @75Hz...
  • Page 31 Appendix Standard Resolution Optix MAG342CQRV (3DB6) MAG342CQPV (3DB6) HDMI1 HDMI2 640x480 @60Hz 640x480 @75Hz Dos-Mode 720x400 @70Hz 720x480 @60Hz 720x576 @50Hz SVGA 800x600 @60Hz 800x600 @72Hz 800x600 @75Hz XVGA 1024x768 @60Hz 1024x768 @75Hz SXVGA 1280x720 @50Hz 1280x1024 @60Hz 1280x1024 @75Hz 1280x1024 @100Hz WXGA+ 1440x900 @60Hz...
  • Page 32: Troubleshooting

    Troubleshooting The power LED is off. ■ Press the monitor power button again� ■ Check if the monitor power cable is properly connected� No image� ■ Check if the computer graphics card is properly installed� ■ Check if the computer and monitor are connected to electrical outlets and are turned on�...
