SETTING UP YOUR WI-FI ExTENDER
2.0/ SETTING UP YOUR WI-FI ExTENDER
Note: Using a wired backhaul, the Wi-Fi Extender can be placed
at a location distant from the Verizon Router, and positioned for
optimum coverage. Using Wi-Fi backhaul, performance can be
slower and the distance from the Router will be determined by
the reach of Wi-Fi from the Verizon Router, the materials in the
home, and neighboring Wi-Fi traffic. Wi-Fi backhaul is effective and
convenient for Wi-Fi configuration, but based on Wi-Fi interference
characteristics, does not perform as well as a wired connection.
2.0a/ WIRED INSTALLATION
A. Connect the Verizon Router to a coax outlet. (If the coax
outlet is already in use, use the coax splitter included in the
box.)
B. Connect the Wi-Fi Extender to a coax outlet - ideally in an
area with spotty Wi-Fi coverage.
C. Connect the power cords to the Router and Extender then
to an electrical outlet.
