- Page 1 ASSEMBLY INSTRUCTIONS UltraHD® Workcenter LED work light included (Model No. 20276B, 20277B) Graphite Granite 48 in W X 24 in D X 65.5 in H (1.21 m x 60.9 cm x 1.66 m) Reference page 8 for special care and maintenance of stainless steel SC200416...
-
Page 2: Parts List
PARTS LIST Please check the parts carefully according to the parts list. If you are missing any parts, please call our customer service department (please see page 9.) Drawer Top Cantilever Shelf Parts Parts Qty. Qty. STAINLESS STEEL TOP #20-5 DRAWER BACK PANEL TOP PEGBOARD PANEL DRAWER FRONT PANEL SUPPORT PLATE... - Page 3 PARTS LIST Please check the parts carefully according to the parts list. If you are missing any parts, please call our customer service department (please see page 9.) #104 #100 #103 #101 #107 #105 #106 M8X20 pcs #27-B Parts Qty. Parts Qty.
- Page 4 UltraHD® Workcenter (Model No. 20276B, 20277B) *NOTE: We recommend TWO people to assemble the workbench. TIP: A magnetic screwdriver is included for your convenience. If a power screwdriver is used, keep on a low torque setting. Step 1. Install (#5-B) Leg Piece. Open the package, and put the parts aside.
- Page 5 UltraHD® Workcenter (Model No. 20276B, 20277B) *NOTE: We recommend TWO people to assemble the workbench. Step 4. Install (#49) Pegboard Long Support Bar. Attach (#49) Pegboard Long Support Bar to the back of the workbench, line up the screw holes, use (#40) Screw E with (#27-B) Washer to tighten.
- Page 6 UltraHD® Workcenter (Model No. 20276B, 20277B) *NOTE: We recommend TWO people to assemble the workbench. Step 8. Install (#20-3 & #20-4) Left & Right Drawer Side Panels and (#20-5) Drawer Back Panel. #20-3 Attach (#20-3 & #20-4) Left & Right Drawer Side Panels and Back #20-5 (#20-5) Drawer Back Panel to the (#19-2) Drawer Base...
- Page 7 UltraHD® Workcenter (Model No. 20276B, 20277B) *NOTE: We recommend TWO people to assemble the workbench. Step 11. Insert Drawer Pull out the drawer sliders to full length, then attach and fit the Drawer to the inner track of the sliders and slide drawers in. NOTE: Make sure to remove the rubber guards on the hooks of the inner track before fitting the...
- Page 8 UltraHD® Workcenter (Model No. 20276B, 20277B) *NOTE: We recommend TWO people to assemble the workbench. Install (#20-7) Drawer Divider Step 13. Insert Drawer Divider into the drawer. The solid wall of the divider should be facing the desired slot position. Slide the divider towards the slot, then push down into the slots.
- Page 9 UltraHD® Workcenter (Model No. 20276B, 20277B) *NOTE: We recommend TWO people to assemble the workbench. Step 16. Place (#100), (#101), (#103), (#104), (#105), (#106), (#107) Hooks to Pegboard as you desire. [!] CAUTION: Potential Shock or Fire Hazard. This unit is not intended for use in wet or potentially wet locations, such as showers, saunas, under or near fishtanks, sinks, etc.
-
Page 10: Contact Information
If you are missing any parts, have any questions, or need additional assistance in assembly, please contact our bilingual (English and Spanish) customer service department at: Seville Classics, Inc. 19401 Harborgate Way Torrance, CA 90501 USA Telephone: (800) 323-5565 within USA... - Page 11 UltraHD® Line UltraHD® 4-Drawer Rolling Cabinet UltraHD® 6-Foot Height Adjustable Workbench Model No. 20205 (Granite) Model No. 20292 (Granite) UltraHD® Wall Cabinet with Open Shelf UltraHD® 2-Door Rolling Workbench Model No. 20230 (Granite) Model No. 20262 (Granite) Model No. 20140 (Graphite) Model No.
