Instruction manual
0
Instruction Manual Electrobloc EBL 225
Electrobloc EBL 225
Type no. 911.570
Table of contents
1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3
Description and appropriate use . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4
Suitable accessories (not supplied) . . . . . . . . . . . . . . . . . . . . . . . . 5
5
Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
8
Shutting down the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
9
Changing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
10
Technical faults, possible causes and remedies . . . . . . . . . . . . . . 9
11
Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
12
Block diagram - for specialist workshop only . . . . . . . . . . . . . . . . 12
13
Fault report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Situation: 14.06.2005
Advertisement
Table of Contents
Related Manuals for Schaudt EBL 225
Summary of Contents for Schaudt EBL 225
-
Page 1: Table Of Contents
Fault report......... . 13 © 2005 Schaudt GmbH, Elektrotechnik & Apparatebau, Daimlerstraße 5, 88677 Markdorf, Germany, Phone +49 7544 9577-0, Telefax +49 7544 9577-29, www.schaudt-gmbh.de SDT-0058-00EN Situation: 14.06.2005... -
Page 2: Introduction
Never make any modifications to the Electrobloc. The electrical connection may only be established by qualified person- nel and must be carried out according to the Schaudt installation instructions. Connection work is to be carried out in tensionless condition only. - Page 3 12 hours with an 80 Ah battery and 24 hours with a 160 Ah battery. Do not operate the Schaudt solar charge regulator without a battery. This might damage the solar charge regulator or any connected consumers. If the battery is going to be changed or removed, take off the positive lead "+ Solar Module"...
-
Page 4: Description And Appropriate Use
Instruction Manual Electrobloc EBL 225 Description and appropriate use The Electrobloc EBL 225 is designed as a main power distributor for motorhomes. It is a permanent installation. The Electrobloc is for charging batteries and supplying 12 V appliances with power. -
Page 5: Suitable Accessories (Not Supplied)
Control and switch panel DT 220, LT 500 Auxiliary charging unit Schaudt battery charging unit type LAS... with up to 18 A charge current Additional 2-pin charging cable, lengths supplied on request Solar charge regulator Schaudt solar charge regulator type LR... for solar modules with a total cur- rent of 14 A incl. - Page 6 Instruction Manual Electrobloc EBL 225 Only press the step switch briefly. The PolySwitch fuse may otherwise trig- ger and interrupt the circuit. „ Before putting the unit into Make sure the living area battery is connected. service for the first time „...
-
Page 7: Maintenance
Instruction Manual Electrobloc EBL 225 Additional functions 7KLV UHOD\ VXSSOLHV WKH $(6FRPSUHVVRU UHIULJHUDWRU ZLWK SRZHU IURP WKH Automatic switch function VWDUWHU EDWWHU\ ZKHQ WKH YHKLFOH HQJLQH LV UXQQLQJ DQG WKH ' FRQQHFWLRQ LV for AES/compressor OLYH An AES/compressor refrigerator is powered by the living area battery refrigerator when the vehicle engine is switched off. -
Page 8: Shutting Down The System
Only use the Electrobloc for connecting the 12 V power supply to 6-cell lead gel or lead acid batteries. Do not operate the Schaudt solar charge regulator without a battery. This might damage the solar charge regulator or any connected consumers. If the battery is going to be changed or removed, take off the positive lead "+ Solar Module"... -
Page 9: Technical Faults, Possible Causes And Remedies
If this is not possible, e.g. if you are abroad, you can have the Electrobloc repaired at a specialist workshop. Inexpert repairs invalidate the guarantee for the Electrobloc and Schaudt GmbH takes no liability for any resulting damage. Fault... - Page 10 Instruction Manual Electrobloc EBL 225 Fault Possible cause Remedy Living area battery is not Defective alternator Have the alternator charged during mobile checked operation (battery voltage No voltage at D+ input Have the fuse and wiring below 13.0 V) checked...
-
Page 11: Customer Service
Instruction Manual Electrobloc EBL 225 Customer service Customer service address Schaudt GmbH, Elektrotechnik & Apparatebau Daimlerstraße 5 88677 Markdorf Germany Phone: +49 7544 9577-16 Email: kundendienst@schaudt-gmbh.de Opening hours Mon to Thu 8 to 12 a.m., 1 to 4 p.m. 8 to 12 a.m. -
Page 12: Block Diagram - For Specialist Workshop Only
G67Ã2Ãyv‰vtÃh…rhÃih‡‡r…’ 15-4 Ã6vtÃyvtu‡ T7Ã2Ƈh…‡r…Ãih‡‡r…’ 13-6 ÃCrh‡r… 15-6 8‚rp‡rqÃrth‡v‰rÂyrÂsÈ€ƒ 7,5A 13-3 Tv‡puvtƇhtr ÃQˆ€ƒ 13-1 ÃGvtu‡Ã 14-2 ÃGvtu‡Ã! 14-1 ÃTƒh…r 7,5A 13-2 ÃGvtu‡Ã" 16-3 ÃT‡rƒ 8v…pˆv‡Ãi‚h…qÃFQGÃ@7GÃ!!$ Q‚y’Tv‡pu U’ƒrÂÃ&& %$ SDT00275 Fig. 2 Block diagram of Electrobloc EBL 225 Situation: 14.06.2005 SDT-0058-00EN... -
Page 13: Fault Report
Instruction Manual Electrobloc EBL 225 Fault report In the event of damage, please return the defective device together with the completed fault report. Device type: EBL 225 Type no.: 911.570 There is the following defect: (please tick) Battery not being charged... - Page 14 Instruction Manual Electrobloc EBL 225 Situation: 14.06.2005 SDT-0058-00EN...
