Instruction manual
0
Instruction Manual Power Supply Unit CSV 300
CSV 300
CSV 300 2B10
CSV 300 2B13
CSV 300-3
Table of contents
1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3
Description and appropriate use . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4
Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7
Shutting down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
8
Technical faults, possible causes and remedies . . . . . . . . . . . . . . 6
9
Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
10
11
Block diagram - for specialist workshop only . . . . . . . . . . . . . . . . . 8
12
Fault report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Situation: 25.11.2009
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schaudt CSV 300
Summary of Contents for Schaudt CSV 300
-
Page 1: Table Of Contents
Fault report......... . . 9 © 2009 Schaudt GmbH, Elektrotechnik & Apparatebau, Planckstraße 8, 88677 Markdorf, Germany, Phone +49 7544 9577-0, Telefax +49 7544 9577-29, www.schaudt-gmbh.de 805.031 BA / EN... -
Page 2: Introduction
Never make any modifications to the power supply unit. ▲ The electrical connection may only be established by qualified person- nel and must be carried out according to the Schaudt installation instructions. ▲ Connection work is to be carried out in tensionless condition only. -
Page 3: Description And Appropriate Use
Description and appropriate use The power supply unit CSV 300 is designed for permanent installation in car- avans. The power supply unit powers 12 V devices such as fans, submersible pumps and lamps, while the caravan is connected to the 230 V mains. - Page 4 The power supply unit is designed for use in caravans with no living area bat- tery of their own and can therefore not be used for charging batteries. Fig. 1 Power supply unit CSV 300, CSV 300 2B10, CSV 300 2B13 and CSV 300-3 1 Negative 12 V outputs, circuits 1 to 5...
-
Page 5: Electrical Data
Instruction Manual Power Supply Unit CSV 300 12 V output circuits If the power supply unit is only powered with 12 V by the starter battery of the towing vehicle without any connection to the 230 V mains, the following 12 V... -
Page 6: Maintenance
If this is not possible, e.g. if you are abroad, you can have the power supply unit repaired at a specialist workshop. Inexpert repairs invalidate the guarantee for the power supply unit and Schaudt GmbH takes no liability for any resulting damage. Fault Possible cause... -
Page 7: Customer Service
When the product service life is over, dispose of the device in accordance with the applicable regulations. EG Conformity Declaration Schaudt GmbH hereby confirms that the CSV 400-1 A caravan power supply design complies with the relevant regulations. This declaration is based on: Type approval of "Kraftfahrt-Bundesamt"... -
Page 8: Block Diagram - For Specialist Workshop Only
Block diagram supply unit CSV 300, CSV 300 2B10, CSV 300 2B13 and CSV 300-3 1 Double circuit breaker (CSV 300 2B10: 10 A, CSV 300 2B13: 13 A) 2 Jumper: A22 - A24: Circuit 5/awning light supplied only by mains... -
Page 9: Fault Report
Instruction Manual Power Supply Unit CSV 300 Fault report In the event of damage, please return the defective device together with the completed fault report. Device type: CSV 300 CSV 300 2B10 CSV 300 2B13 CSV 300-3 Type no.: 905.030 905.031... - Page 10 Instruction Manual Power Supply Unit CSV 300 Situation: 25.11.2009 805.031 BA / EN...
