Model UT56: OPERATING MANUAL
Contents
B. Specifications
Introduction
UT56 is one type of UNI-T brand new UT50 series
Multimeters with 4 1/2 digits, which has steady
function and is a highly reliable hand-held measuring
instrument. The Meter uses large scale of integrated
circuit with double integrated A/D converter as its
core and has full range overload protection. The
Meter can measure DC current, AC current, DC
Voltage, AC Voltage, Resistance, Capacitance,
Diode, Transistor, Frequency and Continuity Beeper,
which is an ideal measuring tool for users.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the UT56 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UNI-T UT56

Summary of Contents for UNI-T UT56

  • Page 1: Table Of Contents

    F. Using Holster G. Using Strap Introduction UT56 is one type of UNI-T brand new UT50 series Multimeters with 4 1/2 digits, which has steady function and is a highly reliable hand-held measuring instrument. The Meter uses large scale of integrated circuit with double integrated A/D converter as its core and has full range overload protection.
  • Page 2 Model UT56: OPERATING MANUAL Safety Rules l Use the Meter only as specified in this manual, otherwise the protection provided by the Meter may be impaired. l Do not operate the Meter before the cabinet has been closed and screwed safely as terminal can carry voltage.
  • Page 3 Model UT56: OPERATING MANUAL l Replace the battery as soon as the battery indicator appears. With a low battery, " " the Meter might produce false readings that can lead to electric shock and personal injury. l Turn off the Meter once finished measuring.

  • Page 4: Your Meters Feature

    Model UT56: OPERATING MANUAL A. Your Meters Feature “ ” “ ”...
  • Page 6 Model UT56: OPERATING MANUAL B-3 Direct Current Current (DC Current) Range Resolution Accuracy 0.1 V (0.5% +5) 20mA (0.8% +5) 200mA 10 V (2% +10) Overload protection: Below 200mA with 0.3 A/250V Fused. No fuse protection on 20A. Max current input: 20A (above 10A for 15 seconds maximum).
  • Page 7 Model UT56: OPERATING MANUAL B-5 Resistance Range Resolution Accuracy (0.5% +10) 0.01 (0.3% +3) (0.3% +1) 200K (0.5% +1) [5.0%(-1000) +10] 200M Overload protection: All ranges are 250VDC or AC RMS. Caution: 1) At 200M range, test lead is short circuit, the...
  • Page 8 Model UT56: OPERATING MANUAL 2-7 Frequency Range Resolution Accuracy 20kH z 1H z (1.5% +5) Input sensitivity: <200mVrms, Max. input scope 30Vrms. Overload protection: 250Vrms. 2-8 Diode and Continuity Beeper Range Remark Measuring Condition Forward DC Current abt Display Diode...

  • Page 9: Making Measurements

    Model UT56: OPERATING MANUAL C. Making Measurements Caution: (1) If there is no display or is shown on the “ ” LCD when the Meter is switched on, replace the battery ASAP. (2) Never exceed the maximum input voltage or current limits shown besides the input jacks “...
  • Page 10 Model UT56: OPERATING MANUAL C-1 Measuring DC Voltage “ ” 1. Connect the black test lead to COM jack and “ ” red test lead to V jack. “ ” 2. Set the rotary switch to V 3. Connect the test leads across with the object to be measured.
  • Page 11 Model UT56: OPERATING MANUAL C-3 Measuring DC Current “ ” 1. Connect the black test lead to COM jack . When measuring below 200mA, connect the “ ” red test lead to mA jack. When measuring 20A or below, connect the red test lead to “...
  • Page 12 Model UT56: OPERATING MANUAL C-5 Measuring Resistance “ ” 1. Connect the black test lead to COM jack and red test lead jack. “ ” 2. Set rotary switch to “ ” 3. Connect the test leads across with the object to be measured.
  • Page 13 Model UT56: OPERATING MANUAL 3) Stabilizing reading takes some time when measuring high capacitance. Unit : 1pF=10 F, 1nF = 10 C-7 Measuring Frequency “ ” 1. Connect red test lead to Hz jack and black “ ” test lead to COM jack.

  • Page 14: Maintenance

    Model UT56: OPERATING MANUAL C-10 Auto-Power Off function 1. Meter equips with auto-power off function. It will be in a sleep condition when it has worked for 30 minutes. Power will be automatically cut off. 2. Press the on/off switch two times to power up again.

  • Page 15: Using Holster

    Model UT56: OPERATING MANUAL F. Using Holster Three different ways to use holster: 1. Set holster parallel on the table, do not open the tilt stand (see diagram 1) 2. Set holster in a small angle on the table, tilt it up by the first part of tilt stand (see diagram 2) 3.
  • Page 16 Model UT56: OPERATING MANUAL ~ END ~ * The manual is subject to changes without separate notice. *...
  • Page 17 Model UT56: OPERATING MANUAL Manufacturer: UNI-TREND TECHNOLOGY(DONG GUAN)LIMITED Address: Dong Fang Da Dao, Bei Shan Dong Fang Industrial Development District, Hu Men Town, Dong Guan City, Guang Dong Province, China Headquarters: Uni-Trend International Limited Address: Rm901, 9/F, Nanyang Plaza 57 Hung To Road...
