Your Aqua TROLL 700 ships with all sensors installed except for pH/ORP or ISE sensors. If your
instrument does not include pH/ORP or ISE sensors, all six sensors are installed by the factory.
All sensors are factory calibrated and do not need to be recalibrated unless required by site procedures.
1 Install the RDO Cap (RDO sensor only).
Remove the restrictor.
Install the RDO cap on
the sensor.
Information subject to change without notice. In-Situ, In-Situ logo, "Water Simplified", VuLink, RDO, RuggedCable, TROLL,
BaroTROLL, HydroVu, VuSitu, Baro Merge, and Win-Situ are trademarks or registered trademarks of In-Situ Inc. ©2023. All
rights reserved. This product may be covered by patents identified at www.in-situ.com/patents
Aqua TROLL 700 Quickstart Guide
Box Contents
1. Instructions
2. Instrument with sensors and wiper or wiper plug installed
3. Hex Wrench
4. Screwdriver
5. RDO Sensor Cap (if RDO Sensor is included)
2
6. pH/ORP or ISE Sensors (if selected)
7. Accessories
7 8
8. pH maintenance kit (if pH/ORP or ISE sensors are included)
Getting Started
Use included hex wrench
to loosen set screw on
RDO sensor.
Insert RDO sensor in
instrument sensor port.
Use the small hole at the
bottom of the sensor to
lever the sensor out.
Tighten screw at base of
sensor with hex wrench.
Do not overtighten.
Remove the dust cover
from the RDO sensor.
