Unpack the Tube.

1
Unscrew the cap at the
top of the instrument.
Connect the antenna.

Connect your In-Situ instrument to a communication device.

2
Plug one end of a
Rugged Twist-Lock Cable
into a Wireless TROLL
Com.
Page 1

Tube 300S Overview

Monitor remote locations with the Tube 300S and your AquaTROLL, Level TROLL,
or Rugged TROLL instrument. The Tube can send data to HydroVu, In-Situ's
data-management software, or to your own FTP server.

Getting Started

Remove the solar panel
by pulling straight off.
Plug the battery into the
board.
Connect the other end of
the cable to your In-Situ
instrument (Aqua TROLL,
Level TROLL, Rugged
TROLL).
970-498-1500
Tube 300S Quickstart Guide
Unscrew the ring from
the Tube.
Slide the solar panel
back into place.
www.in-situ.com
Pull on the threaded
stud to remove the
interior of the Tube.
Plug the solar panel into
the battery terminals
and replace the cap.
2019-02-27 | 0062560

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tube 300S and is the answer not in the manual?

Questions and answers

Related Manuals for In-situ Tube 300S

Summary of Contents for In-situ Tube 300S

  • Page 1 Tube 300S Quickstart Guide Tube 300S Overview Monitor remote locations with the Tube 300S and your AquaTROLL, Level TROLL, or Rugged TROLL instrument. The Tube can send data to HydroVu, In-Situ’s data-management software, or to your own FTP server. Getting Started Unpack the Tube.
  • Page 2 Connect the other end of Download the ANT Tool TROLL Com and attach the top end of the Tube. the setup cable to your software from www.in- the cable to the Tube. situ.com and install. Page 2 970-498-1500 www.in-situ.com 2019-02-27 | 0062560...
  • Page 3 A value of 1 reading. means every reading. Click Write frequency Select the significant Select Functional mode Click the Test tab. and options. Close the digits to be included in and test. the data. window. Page 3 970-498-1500 www.in-situ.com 2019-02-27 | 0062560...
  • Page 4 Click Stop Device, and then click Start Device. Learn more. Your Tube 300S is ready for deployment after configuration with the ANT Tool. Visit the In-Situ Online Knowl- edge Base at help.in-situ.com for more information about working with the Tube 300S. For a complete video walkthrough of the Tube and HydroVu setup process, see In-Situ’s YouTube channel.
