Contents Safety instructions Safety instructions ..............2 Important safety instructions! Explanation of displays and buttons ........3 Always observe the following instructions. General information ..............4 Designated use ................4 Risk of injury by electric shock. Warning! Installation/Connection VarioTec ..........5 • All terminal connections to a 230 V network must Connection as a drive controller ..........5 be made by an authorised electrician.
Explanation of displays and buttons General information / Designated use Manual/Automatic Explanation of displays General information UP button sliding switch The VarioTec device operates your roller shutters/sun STOP button Manual/Automatic Alarm signal protection systems on the basis of manual or external control UP button Auto sliding switch...
Installation / Connection Installation Installation 3. Replace the protective caps on the power supply unit. 4. Secure the power supply unit in the box. 5. Insert the operating device into the frame and plug it into the power supply unit. Connection as a group controller Note: The encoding switch located on the back of the VarioTec device can be used to select group or drive control.
Explanation of functions Explanation of functions Factory settings Reset button: Press the Reset button (with a ballpoint pen or similar object) Encoding switch factory setting to delete the intermediate position and the ventilation/reverse position. 1. Lower position Alarm signal function ON. POS ∇: 2.
Function menu/Explanation of functions Programming menu Drive controller: Programming If the VarioTec device is being used as a drive controller, the drive is directly connected to the VarioTec device, in which case Programming the intermediate position external signals are converted into control commands. Encoding switch 2 must be set to the lower position.
Programming Technical data / Cleaning / Troubleshooting Adjustment to intermediate position Technical data The shutter/curtain/blind can only be moved into the intermediate Nominal voltage 230-240 V AC / 50-60 Hz position from the upper end limit position. Switched current 5 A /250 V AC for cos j = 1 1.
Page 8
EC Declaration of conformity Declaration of conformity elero GmbH hereby declares that the radio system type VarioTec is in compliance with directive 2014/53/EU. The com- plete text of the EU declaration of conformity is available at the follo -wing adress: www.elero.com/downloads/ 14 | EN EN | 15...
