Perlick TOBIN ELLIS SIGNATURE Series Installation & Operation Manual page 4

PERLICK SIGNATURE SERIES MOBILE BARS
Installation & Operation Manual
Tobin Ellis Limited Edition Signature Series Residential Mobile Bar
MODEL NOS.
DIMENSIONS:
EXTERIOR (mm)
DIMENSIONS:
SHIPPING (mm)
PERLICK BAR EQUIPMENT
ELECTRICAL
LED BARTENDER
TASK LIGHTING
WATER HEATER
WATER PUMP
GRAY WATER/ICE MELT TANK
(PRE-PLUMBED)
POTABLE WATER TANK
(PRE-PLUMBED)
Tobin Ellis Signature Series Limited Edition Residential
Mobile Bars feature Toffee Crocodile exterior with
Vanilla Sugar engineered solid surface top.
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
RMB-001
Length
Width
Height
Weight (lbs)
Length
Width
Height
Weight (lbs)
Ice Chest TS30IC with Sliding Cover
Insulated Bottle Well
Drainboard
Hand Sink
SRC-CL left curved (1 ea.)
Speed Rail SRC-CR right curved (1 ea.)
SRC-S18 18" straight (1 ea.)
Voltage
Frequency
Phase
Amperage
Connection
Cord Length
Color Temperature
Lumen Output
Temperature Range
Tank Volume
Recovery time @ 60°^
Max Flow
Switch Off Pressure
Capacity
Capacity
RMB-001
70" (1778)
34-1/2" (877)
43-3/4" (1112)
351 lbs. (159 kg)
75" (1905)
40" (1016)
70" (1778)
451 lbs. (205 kg)
TSC12IBW
TSCS12 (2 ea.)
N/A
120V AC
60 Hz
Single
0.4 A
NEMA 5-15P
12ft
4000K
1200 LM
N/A
N/A
N/A
N/A
N/A
(2) 2.5gal
N/A
Toffee Crocodile Vanilla Sugar
4
