Specifications

Display
Status indicators
Frequency Range
Datalogger Sampling Rate
Memory Card
Data Hold
Memory Recall
Display update rate
Data Output
Operating Temperature
Operating Humidity
Auto Power OFF
Power Supply
Power Consumption
Weight
Dimensions
Electrical Specifications
Function
Acceleration
Velocity
Displacement
Above specification tests under the environment RF Field Strength less than 3 V/M & frequency less
than 30 MHz only and 23±0.5°C
Backlit LCD; LCD size: 52 x 38mm (2 x 1.5")
Over-range audible beep and low battery display icon
10Hz to 1kHz
AUTO LOGGING: From 1 to 3600 seconds.
MANUAL LOGGING: Set the sampling rate to '0' seconds
SD memory card; 1G to 16GB size
Freeze the displayed reading
Record and Recall the Maximum and Minimum readings
Approx. 1 second
RS-232 / USB PC computer interface
0 to 50°C (32 to 122°F)
85% R.H. max.
After 10 minutes of inactivity (can be disabled)
Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
Normal operation (backlight and datalogger OFF): approx. 5mAdc
With backlight OFF and datalogging ON: approx. 25mAdc
With backlight ON add approx. 12mAdc
343g (0.75 lbs.) w/ batteries; 241g (0.53 lbs.) w/o batteries
Meter: 182 x 73 x 47.5mm (7.1 x 2.9 x 1.9")
Vibration sensor: round 16mm (0.63") diameter, 37mm (1.46")
length
Unit Range
2
m/s 0.5 to 199.9 m/s
g 0.05 to 20.39 G
2
ft/s 2 to 656 ft/s
Calibration Point: 50 m/S^2 ( 160 Hz )
mm/s 0.5 to 199.9 mm/s
cm/s 0.05 to 19.99 cm/s
inch/s 0.02 to 7.87 inch/s
Calibration Point: 50 mm/s ( 160 Hz )
mm 0.003 to 1.999 mm
inch 0.078 inch
Calibration Point: 0.141 mm ( 160 Hz )
2
2
10
Accuracy
± ( 5%rdg + 2 d )
@ 80 and 160Hz
± ( 5%rdg + 2 d )
@ 80 and 160Hz
± ( 5%rdg + 2 d )
@ 80 and 160Hz
