Installation/Operator Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion and to prevent property
damage, personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Clear the room, building or area of
all occupants.
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
ES3131
AVERTISSEMENT: Assurez-vous de
bien suivre les instructions données dans
cette notice pour réduire au minimum le
risque d'incendie ou d'explosion ou pour
éviter tout dommage matériel, toute
blessure ou la mort.
—Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
—QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareils.
Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
Évacuez la pièce, le bâtiment ou la
zone.
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
—L'installation et l'entretien doivent être
assurés par un installateur ou un
service d'entretien qualifié ou par le
fournisseur de gaz.
American Dryer Corporation
Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
88 Currant Road
Fall River MA 02720-4781 USA
e-mail: techsupport@amdry.com
www.adclaundry.com
ADC Part No. 113280 -3
Advertisement
Table of Contents
Related Manuals for ADC ES3131
Summary of Contents for ADC ES3131
- Page 1 American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 USA Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447 e-mail: techsupport@amdry.com www.adclaundry.com ADC Part No. 113280 -3...
- Page 2 Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory, you can FAX your order to ADC at +1 (508) 678-9447 or telephone your order directly to the ADC Parts Department at +1 (508) 678-9000. Please specify the dryer model number and serial number in addition to the description and part number, so that your order is processed accurately and promptly.
-
Page 3: Table Of Contents
WARNING In the State of Massachusetts, the following installation instructions apply: Proposition 65 Installations and repairs must be performed Use of this product could expose you to substances by a qualified or licensed contractor, plumber, from fuel combustion that contain chemicals or gasfitter qualified or licensed by the State known to the State of California to cause cancer, of Massachusetts. -
Page 4: Safety Precautions
Safety Precautions ____________________ WARNING WARNING Do not use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured For your safety, the information in this manual must rubber materials. Drying in a heated tumbler may be followed to minimize the risk of fire or explosion damage plastics or rubber and also may be a fire and to prevent property damage, personal injury, or hazard. - Page 5 WARNING WARNING You must disconnect and lockout the electric supply This appliance must only operate with the gas type and the gas supply or the steam supply before any indicated on the dryer’s data plate. If the appliance covers or guards are removed from the machine to is converted (gas type is changed), a data plate allow access for cleaning, adjusting, installation, or amendment must be obtained from American Dryer...
-
Page 6: Specifications
Specifications _____________________________________________________________________ 13.61 kg MAXIMUM CAPACITY 30 lb (DRY WEIGHT) PER POCKET TUMBLER DIAMETER 30” 76.20 cm 68.58 cm TUMBLER DEPTH 27” 312.62 L TUMBLER VOLUME 11.04 cu ft PER POCKET TUMBLER/DRIVE MOTOR 1/4 hp 0.19 kW PER POCKET BLOWER/FAN MOTOR 1/2 hp 0.37 kW PER POCKET... - Page 7 Specifications _____________________________________________________________________ NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. 113280 - 3 www.adclaundry.com...
-
Page 8: Installation Procedures
Installation Procedures ______________ Unpacking / Setting Up _______________ Installation should be performed by competent professional Remove protective shipping material (i.e., plastic wrap and in accordance with local, state, and country codes. In the optional shipping box) from the dryer. absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- IMPORTANT: Dryer must be transported and handled in an LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA... -
Page 9: Fresh Air Supply Requirements
Fresh Air Supply Requirements ______ Exhaust Requirements _______________ This appliance may only be installed in a room that meets Exhaust ductwork should be designed and installed by a the appropriate ventilation requirements specified in the qualified professional. Improperly sized ductwork will create national installation regulations. - Page 10 Outside Ductwork Protection The length of the ductwork from the dryer to the outside exhaust outlet, must not exceed 12 feet (3.66 meters). The To protect the outside end of the horizontal ductwork from minimum diameter of this ductwork must be at least 8-inches the weather, a 90°...
-
Page 11: Electrical Information
The illustration below shows the minimum cross-sectional NOTE: The use of aluminum wire will void the warranty. area for multiple dryer round or square venting. These figures An individual ground circuit must be provided to each must be increased if the main duct run from the last dryer to pocket, do not daisy chain. - Page 12 Electrical Service Specifications Grounding Gas and Steam Models Only A ground (earth) connection must be provided and installed in accordance with local, state, and national regulations or ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET) codes of the country of origin. In the absence of these codes, grounding must conform to applicable requirements of the IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME.
-
Page 13: Gas Information
208-240V Application without Neutral 3-Phase (3ø) Wiring Connections / Hookup CAUTION: The dryer must be grounded. A ground Gas Information ______________________ lug has been provided for this purpose. It is your responsibility to have all plumbing connections, Input connection wiring must be sized properly to handle the materials, and workmanship conform to local and state dryer’s current draw. - Page 14 CE and Australian Dryers The dryer must be connected to the type of heat/gas indicated on the data label and pressure must be confirmed. If this There are 2 N.P.T. to B.S.P.T. adaptors included with each information does not agree with the type of gas available, do dryer, which must be installed to the gas inlets.
- Page 15 Heat Input / Gas Consumption / Orifice (Injector) Data (For AGA [Australian] Models Only)** Gas Specifications for AGA Approved Dryers Supply *Gross Burner *Orifice Orifice Size Pressure Heat Input Pressure (Injector) Type Quantity MJ/h 1.7-3.2 58.03 3.988 0.69 Natural Propane 2.75 58.03 2.184...
-
Page 16: Converting From One Family Of Gas To Another
Connect the union and the three electrical plugs. another. Repeat these steps for the other burner. Conversion from Natural Gas Affix L.P. Conversion Label (ADC P/N 114515) to the dryer’s to Propane or Butane Gas data label. Complete L.P. Kit Conversion Confirmation Label (ADC P/N The following conversion allows the dryer to be operated with 114083) and affix this label as close as possible to the dryer’s... - Page 17 If the screw (under vent cap). Remove spring under screw appliance is converted (gas type changed), a data and replace with spring from kit (ADC P/N 140415). plate amendment must be obtained from American Replace regulator adjustment screw.
-
Page 18: Gas Pressure Testing
Gas Pressure Testing _________________ Steam Information ____________________ For proper operation, the gas pressure must be correct, It is your responsibility to have all plumbing connections made consistent and maintained at the gas pressure rates shown by a qualified professional to ensure that the steam plumbing on page 14. -
Page 19: Water Information
Steam Requirements – High Pressure IMPORTANT: Flexible hoses/couplings must be used. Coil failure due to hard plumbing connections will void the Inlet ---------- 1/2” N.P.T. supply line connection warranty. 1 at top manifold Return ------- 1/2” N.P.T. return line connection Water Information _____________________ 1 at bottom manifold Before You Start... -
Page 20: Preparation For Operation / Start-Up
Preoperational Test ___________________ Optional Manual Bypass Provisions are made in the dryer’s fire suppression system All dryers are thoroughly tested and inspected before leaving for the installation of an optional manual bypass. The the factory. However, a preoperational test should be connections for the manual bypass are made at the “cross”... -
Page 21: Preoperational Instructions
Preoperational Instructions __________ Service / Parts Information ___________ IMPORTANT: For more detailed information regarding the Service microprocessor controller (computer), refer to the microprocessor user’s manual included with the dryer. Service must be performed by a qualified trained technician. If service is required, contact the reseller from whom the Coin Models equipment was purchased. -
Page 22: Routine Maintenance
Shipping charges are not the responsibility of ADC. All returns WARNING should be “prepaid” to the factory. Any “C.O.D.” or “COLLECT” returns will not be accepted. -
Page 23: Adjustments
Data Label Information _______________ Standard Label When contacting ADC, the information on the data label is required to ensure proper service/parts assistance. The data label is located at the upper left rear of the dryer behind the back guard. -
Page 24: Programming
Programming _________________________ Event Codes Defined: Top Pocket / Bottom E1 / E4: While attempting to turn on the burner, no burner return Enter Service Mode by Inserting Key and Turning Clockwise signal was received within RADIANT SENSOR COOL DOWN Main Service Mode window will appear and offer 5 selections: TIME. - Page 25 NOTES __________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ 113280 - 3 www.adclaundry.com...
- Page 26 ADC Part No. 113280 3 - 11/26/14...
