ADC AD-758DV Parts Manual

Adc dryer parts manual
Hide thumbs Also See for AD-758DV:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
AD-758DV
Parts Manual
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
111600JCARRITA/calbert
ADC Part No. 450433

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-758DV and is the answer not in the manual?

Questions and answers

Related Manuals for ADC AD-758DV

Summary of Contents for ADC AD-758DV

  • Page 1 AD-758DV Parts Manual American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com 111600JCARRITA/calbert ADC Part No. 450433...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

  • Page 3: Table Of Contents

    OPL Control Door Assembly For Models Mfd. as of July 1, 2002 ... 2 Coin Control Door Assembly For Models Mfd. as of July 1, 2002 ... 3 Control Door Assembly For Models Mfd. prior to July 1, 2002 ... 4 Phase 5 OPL Microprocessor Control Panel Assembly ...

  • Page 4: Opl Control Door Assembly

    102601 102502 150321 154011 American Dryer Corporation Description ADC Logo with Tape Double Sided Tape Kit White Control Door Assembly (includes illus. nos. 2 and 3) Ivory Control Door Assembly (includes illus. nos. 2 and 3) Coral Blue Control Door Assembly (includes illus.

  • Page 5: Coin Control Door Assembly

    High Security Lock Assembly 160104 Key ONLY 160016 Lock Cam ONLY 881053 ADC Logo with Tape 883621 White Control Door Assembly with Black Trim (includes illus. nos. 4 through 7) 883619 Ivory Control Door with Black Trim (includes illus. nos. 4 through 7)

  • Page 6: Control Door Assembly

    Special Dummy Lock ONLY (for non-coin models Only) MK-100 Key ONLY Lock Cam ONLY ADC Logo with Tape Double Sided Tape Kit White High Security Control Door Assembly Less Lock (includes illus. nos. 4 and 5) Almond “B” High Security Control Door Assembly Less Lock (includes illus.

  • Page 7: Phase 5 Opl Microprocessor Control Panel Assembly

    Phase 5 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 OPL English Keyboard Label Assembly 112276 OPL Stick-On Labels (English Only)...Not Illustrated 112275 3-Language OPL Stick-On Labels...Not Illustrated (Spanish, Italian, and Hebrew) 112277 3-Language OPL Stick-On Labels...Not Illustrated (English, Spanish, and Hebrew) 112278 5-Language OPL Stick-On Labels...Not Illustrated...

  • Page 8: Phase 5 Coin Microprocessor Control Panel Assembly

    Phase 5 Coin Microprocessor Control Panel Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
  • Page 9 Phase 5 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112526 Coin Keyboard Label Assembly 883537 Phase 5 Coin Control Panel Assembly (includes illus. nos. 1, 2, and 4 through 6) (for models mfd. as of June 25, 2002) 883538 Phase 5 Coin Control Panel Assembly with Battery Option (includes illus.

  • Page 10: Dual Timer "Tap Touch" Controls

    Illus. No. Part No. Qty. 124030 124025 824175 122301 131932 120730 151000 882903 850392 153010 152000 150207 150110 112563 124104 124105 American Dryer Corporation Dual Timer “Tap Touch” Controls Description 15 Minute Timer - 24 VAC 60 Minute Timer - 24 VAC Red Pilot Light - 24 VAC “Tap Touch”...

  • Page 11: Coin And Opl Control Box Assembly

    Coin and OPL Control Box Assembly Illus. No. Part No. Qty. Description 132002 Transformer (for mechanical steam damper models - 208 VAC and higher Only) 150300 #10-16 x 1/2” Hex Washer TEK Screw 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 131931 Steam Valve Relay - 24 VAC (for mechanical steam damper models Only)

  • Page 12: Coin Vault Assembly

    Illus. No. Part No. Qty. 802112 802117 160028 875061 160105* 802020 802019 125915 802018 152014 102502 102601 102603 Specify key number when ordering. American Dryer Corporation Description Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 6) Microprocessor Coin Vault ONLY Cam for 1/4 Turn Lock ONLY 1/4 Turn Lock with Key and Cam 1/4 Turn Mer-Pel Key ONLY...

  • Page 13: Front Panel Assembly

    Front Panel Assembly Illus. No. Part No. Qty. Description 882905 White Front Panel Assembly (includes illus. nos. 1, 5, and 6) 882901 Coral Blue Front Panel Assembly (includes illus. nos. 1, 5, and 6) 882902 Ivory Front Panel Assembly (includes illus. nos. 1, 5, and 6) 150313 #10-16 x 1/2”...

  • Page 15: Main Door "Steel" Assembly

    Main Door “Steel” Assembly Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170731 Black Glass Adhesive (10.3 oz. cartridge) 881152 Black Top Hinge Block Assembly (includes illus.

  • Page 16: Main Door Switch Assembly

    Illus. No. Part No. Qty. 150006 152013 153010 137005 122636 881211 881153 150301 American Dryer Corporation Description #6-32 x 7/8” Phillips Pan Head Machine Screw #6-32 Hex Nut #6 Star Washer Door Switch Flag Terminal Black Main Door Switch Housing ONLY Black Main Door Switch Housing Complete (includes illus.

  • Page 17: Basket (Tumbler)/Support Assemblies

    Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 800708 Basket (tumbler) ONLY without Felt Collar 800857 Stainless Steel Basket (tumbler) ONLY without Felt Collar 800816 Basket (tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 800873 Stainless Steel Basket (tumbler) and Support Assembly Complete (includes illus.

  • Page 18: Lint Drawer/Lint Drawer Switch Assembly

    Illus. No. Part No. Qty. 882871 882920 882919 117605 122116 122605 122701 122801 818087 304136 150301 122700 122604 American Dryer Corporation Lint Drawer/Lint Drawer Switch Assembly Description Lint Drawer Assembly (white) (includes illus. nos. 1 and 2) Lint Drawer Assembly (coral blue) (includes illus.

  • Page 19: Idler Bearing Assembly

    Idler Bearing Assembly Illus. No. Part No. Qty. Description 100108 5L-680 V-Belt (basket [tumbler] to idler) For Both Reversing and Non-Reversing Models 101140 14” x 3” Compound Pulley 100194 4L-720 V-Belt (idler to motor) For Non-Reversing Models ONLY 100109 4L-650 V-Belt (idler to motor) For Reversing Models ONLY 154301 5/16-18 x 1”...

  • Page 21: Basket (Tumbler) Bearing Assembly

    Basket (Tumbler) Bearing Assembly Illus. No. Part No. Qty. Description 880220 1-3/4” Flange Bearing 153025 9/16” Lock Washer 152050 9/16-12 Hex Nut 883258 Pillow Block Bearing Assembly Complete (includes illus. nos. 4 through 17, 23 and 24) 882545 Pillow Block Bearing Assembly Complete with Rotational Sensor (includes illus.

  • Page 22: Non-Reversing Motor Mount Assembly

    Illus. No. Part No. Qty. 100194 100701 101133 101130 150501 153002 153001 100073 181050 100069 100068 American Dryer Corporation Non-Reversing Motor Mount Assembly Description 4L-720 V-Belt (idler to motor) 3/16” x 3/16” x 1” Key 5/8” x 2-1/4” Motor Pulley (60 Hz Only) 5/8”...
  • Page 23 Non-Reversing Motor Mount Assembly (continued...) Illus. No. Part No. Qty. Description 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool 137030 8-Pin Housing Connector 152004 5/16-18 Hex Nut 153002 5/16” Lock Washer 153001 5/16” Flat Washer 117604 Neoprene Sponge Tape (sold by the foot) 154000 5/16-18 Tinnerman Nut 850018...

  • Page 24: Reversing T.e.f.c. Motor Mount Assembly

    Reversing T.E.F.C. Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 25: Reversing T.e.f.c. Motor Mount Assembly

    Reversing T.E.F.C. Motor Mount Assembly Illus. No. Part No. Qty. Description 100109 4L-650 V-Belt (to idler assembly) 100701 3/16” x 3/16” x 1” Key 101130 5/8” x 2-1/2” Motor Pulley (50 Hz Only) 101133 5/8” x 2-1/4” Motor Pulley (60 Hz Only) 120200 3/8”...

  • Page 26: Sensor Bracket Assemblies

    Sensor Bracket Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 27: Sensor Bracket Assemblies

    Sensor Bracket Assemblies Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225° Automatic Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Female Terminal 122701 Socket Terminal ONLY 112801...

  • Page 28: Direct Spark Ignition (Dsi) Burner Assembly

    1/2” 24 VAC Redundant (natural gas) Gas Valve 1/2” 24 VAC Direct Spark Ignition (DSI) Liquid Propane (L.P.) Gas Valve Assembly AD-758DV Liquid Propane (L.P.) Conversion Kit #30 Burner Orifice (natural gas) ONLY #49 Burner Orifice (liquid propane [L.P.] gas) ONLY...

  • Page 29: Direct Spark Ignition (Dsi) Burner Assembly

    Direct Spark Ignition (DSI) Burner Assembly Illus. No. Part No. Qty. Description 150103 #8-32 x 1/2” Pan Head Machine Screw 151001 #8-32 Pal Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 809309 Ignitor Probe Assembly with 19” Leads 150309 #10-16 x 1/2”...

  • Page 30: Electric Oven Assembly

    Electric Oven Assembly ELECTRIC OVEN (REAR VIEW) American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...

  • Page 31: Electric Oven Assembly

    Electric Oven Assembly Illus. No. Part No. Qty. Description 803005 Large Electric Oven Box ONLY --------* Electric Oven Assembly Complete --------* Electric Element 150300 #10-16 x 1/2” Hex Washer TEK Screw 802800 Sail Switch Box with Bracket and Cover ONLY 802801 Sail Switch Box Assembly Complete (includes illus.

  • Page 33: Air-Operated Steam Damper Assembly

    Air-Operated Steam Damper Assembly Illus. No. Part No. Qty. Description 165009 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 803415 Steam Damper Assembly (includes illus. nos. 7, 10, and 11) 153007 1/4”...

  • Page 34: Single-Phase (1Ø) Motor, Electric Relay Panel Assembly

    Single-Phase (1ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. 151000 150300 150008 120716 322817 882662 882663 818395 882652 882653 818396 136008 1 or 2 136049 136057 150301 150297 152004 121010 153002 132459 121300 American Dryer Corporation Description #6-32 Pal Nut #10-16 x 1/2”...

  • Page 35: 3-Phase (3Ø) Motor, Electric Relay Panel Assembly

    3-Phase (3ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 151000 #6-32 Pal Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120701 4-Position Terminal Block (for models mfd. with 3ø motors) 120716 2-Position Terminal Block (for models mfd.

  • Page 36: 460-480 Vac 3-Phase (3Ø) Motor, Electric Relay Panel Assembly

    460-480 VAC 3-Phase (3ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. 150009 120701 830208 824161 135501 120768 150301 150297 152004 121010 153002 132459 322817 883332 830262 151000 120765 121300 141403 American Dryer Corporation Description #6-32 x 1-1/2” Phillips Pan Head Machine Screw 4-Position Terminal Block Transformer Assembly (460 VAC) for Micro Models ONLY Transformer Assembly (460 VAC) for Non-Micro Models ONLY...

  • Page 37: Reversing Electric Relay Panel Assembly

    Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120701 4-Position Terminal Block 132458 3-Pole Reversing Contactor 882653 Transformer Assembly - 208-240 Volt for Gas and Steam Models ONLY 825428 Transformer Assembly - 208-240 Volt for Electric Heated Models ONLY 882654...

  • Page 38: 460-480 Vac Reversing Electric Relay Panel Assembly

    460-480 VAC Reversing Electric Relay Panel Assembly Illus. No. Part No. Qty. 132458 150297 121010 152004 153002 132459 150300 830208 824161 120765 322817 883327 824133 151000 150009 120701 135501 120768 112068 121300 141403 American Dryer Corporation Description 24 VAC Reversing Contactor #10 x 1/2”...

  • Page 39: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 319203 Sail Switch Mounting Bracket 319202 Sail Switch Damper (flat) 319201 Sail Switch Box Cover 802800 Sail Switch Box 154004 Twin Speed Nut 154002 1/8” Push On Fastener 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 150303 #4 x 3/4”...

  • Page 40: Outer Top/Back Guard Assemblies

    Illus. No. Part No. Qty. 322809 150301 323738 314510 150301 150300 312527 314518 150301 103500 There is no outer top or top back guard on steam models. American Dryer Corporation Outer Top/Back Guard Assemblies Description Back Electrical Box Cover #8-18 x 7/16” Phillips Pan Head TEK Screw Top Back Guard (for gas models Only) Top Back Guard (for electric models Only) #8-18 x 7/16”...
  • Page 41 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 * When ordering oven assembly complete, specify 3 wire or 4 wire when applicable, as well as if dryer has microprocessor or non-microprocessor controls. .

  • Page 42: Microprocessor Coin Acceptors Listing

    NOTE: Coin acceptors listed include optical switch. Replacement optic switch for Hanke acceptors is Part No. 881143. Replacement optic switch for Greenwald acceptors is Part No. 137056. ADC Part No. Nation 883363 United States 882689 United States 125100 U.S. and Canada...

  • Page 43: Additional Parts Available

    Additional Parts Available Part No. Description 112280 “Clean Lint Screen” Label 114001 “CAUTION - Exhaust/Lint Screen” Label 112533 “Phase 5 Coin Program Location Summary” Label 112534 “Phase 5 OPL Program Location Summary” Label 114006 “WARNING - Fire Hazards” Label 114094 “MOP HEAD WARNING”...
  • Page 44 ADC 450433 5 - 04/15/04-1...
