Summary of Contents for Bluetti B80
- Page 1 Portable Power Station User Manual Please Read This Manual Before Use And Follow Its Guidance. Keep This Manual For Future Reference.
- Page 2 Warning 1. Charge the unit before first use. 2. Do not use solar panels with open circuit voltage higher than 28V. Solar input voltage range for the unit is DC 12V~28V. 3. Charge the unit when the SoC drops below 5%. If the SoC drops to 0, power off the unit and charge it for at least 30mins before restarting.
- Page 3 Thank You! Thank you for making BLUETTI a part of your family. From the very beginning, BLUETTI has tried to stay true to a sustainable future through green energy storage solutions for both indoor and outdoor use while delivering an exceptional eco-friendly experience for our homes and our world.
-
Page 4: Table Of Contents
Contents Safety Instructions General Safety Handling Storage and Usage What’s In The Box Product Overview Diagram Specifications Operating Instructions Buttons Power indicator Charging Discharging Appendix FAQs Abbreviations FCC Warning Important Instructions... -
Page 5: Safety Instructions
The Safety Requirements provided herein are for illustrative purposes that include but are not limited to those listed in this manual. Actual operation shall comply with all applicable safety standards. If you have any questions, feel free to contact BLUETTI support or your local BLUETTI dealers. 1.1. General Safety •... - Page 6 Do not move the unit during operation as the vibrations and shocks associated with movement may cause damage to the internal hardware. • In case of malfunction, turn off the unit immediately and contact BLUETTI support or your local BLUETTI dealers if this manual cannot adequately explain the malfunction to you.
-
Page 7: Handling
It is recommended to charge the unit via an AC source. If charging via solar energy, ensure that your solar system provides an output of more than 100W. BLUETTI shall not be liable for any equipment damage caused by the violation of above instructions. -
Page 8: What's In The Box
2. What’s In The Box Standard Packaging Item Picture Qty. Expansion Battery Battery Expansion Cable (800mm) User Manual Warranty Card Quality Certificate JUST POWER ON... - Page 9 Optional (Available on official BLUETTI website) Item Picture TYPE-C Cable (5A/100W, 2m) Car Charging Cable (16AWG, 720mm) Solar Charging Cable (16AWG, 1500mm) Extended Battery Expansion Cable （1830mm） Power Bank Output Cable （14AWG、720mm） 200W Charger JUST POWER ON...
-
Page 10: Product Overview
3. Product Overview 3.1 Diagram The BLUETTI B80 can be used with AC60 as an external expansion battery, or as a DC power station to run your devices independently. It offers up to 120W output with 3 DC ports - USB-A, USB-C and car cigarette lighter port, perfect for your phone, laptop, car fridge, and more. -
Page 11: Specifications
3.2 Specifications Model General Battery Capacity 806Wh Cell Type LiFePO4 Charging Temperature C～40 C/32°F~104°F Discharging Temperature C～40 C/-4°F～104°F Storage Temperature C～40 C/-4°F～104°F Working Humidity 10%～90% Weight About 9.9kg/21.83lbs Dimensions (L*W*H) 290mm×207mm×204mm/11.42in×8.15in×8.03in DC Output Cigarette Lighter Port 12VDC/10A USB-A 5VDC/3A; 9VDC/2A; 12VDC/1.5A USB-C (Type-C) 5/9/12/15/20VDC, 3A;... -
Page 12: Operating Instructions
4.1 Buttons B80 has a power button and a DC output button. • Press the power button to start up B80. Press and hold for more than 2 seconds to turn it off. • Press the DC power button to turn on/off the DC output (cigarette lighter and USB output). - Page 13 Connect the B80 to vehicle’s 12V cigarette lighter port via the car charging cable. Warning: Cigarette lighter must be completely plugged in, otherwise it may cause safety risks. 4.3.4. Adapter Charging The B80 can be charged via adapter. Please make sure the output voltage of adapter is between 12V~28VDC. JUST POWER ON...
-
Page 14: Discharging
5s, and it can recharge the power station directly. Note: In Power Bank mode, the B80 delivers a voltage of up to 25VDC. Please check the DC input voltage of your BLUETTI power station for compatibility. - Page 15 Note: 1)Load power and operation time are measured in watts and hours. 2)DoD refers to depth of discharge. B80 works at 90% DoD for longer battery life. η is the conversion efficiency of the inverter, which is 90% for B80.
-
Page 16: Appendix
Please evaluate the total constant load of your devices. If it doesn't exceed the Max. output power of B80 (120W), you can use this power station to run your devices. Note: Some devices with built-in motor/compressor may start at 2-4 times the rated power, which can easily overload the B80. -
Page 17: Fcc Warning
5.3 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1)This device may not cause harmful interference 2)This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 18 tion, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
-
Page 19: Important Instructions
5.4 Important Instructions INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS， SAVE THESE INSTRUCTIONS WARNING – When using this product, basic precautions should always be followed, including the following: a)Read all the instructions before using the product. b)To reduce the risk of injury, close supervision is necessary when the product is used near children. - Page 20 2)NEVER smoke or allow a spark or flame in vicinity of battery or engine. 3)Be extra cautious to reduce risk of dropping a metal tool onto battery.It might spark or short-circuit battery or other electrical part that may cause explosion. l)When charging the internal battery, work in a well ventilated area and do notrestrict ventilation in any way.
- Page 21 CONSIGNES DE SÉCURITÉ IMPORTANTES AVERTISSEMENT: lors de l’utilisation de ce produit, les précautions de base doivent toujours être respectées, y compris le Les éléments suivants: A)lire toutes les instructions avant d’utiliser le produit. B)pour réduire le risque de blessure, une surveillance étroite est nécessaire lorsque le produit est utilisé...
- Page 22 L)lors du chargement de la batterie interne, travailler dans une zone bienventilée et ne pas restreindre la ventilation. M)dans des conditions abusives, le liquide peut être éjecté de la batterie;Évitezle contact.En cas de contact accidentel, rincer à l’eau.Si le liquide entre encontact avec les yeux, consulter un médecin.Le liquide éjecté...
- Page 23 SHENZHEN POWEROAK NEWENER CO., LTD. Add: F19, BLD No.1, Kaidaer, Tongsha Rd No.168, Xili Street, Nanshan, Shenzhen, China USA Agent Company name: BLUETTI POWEROAK INC Address: 6185 S VALLEY VIEW BLVD STE D LAS VEGAS NEVADA 89118 United States FRN: 0033559824...
