INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Model:
WARNING!
Risk Of Fire!
Do not install glass doors on this appliance.
Glass doors could cause overheating
of adjacent structures.
Outdoor Lifestyles by Hearth & Home Technologies Inc. • Courtyard Owner's Manual • 4150-900 Rev. B • 05/23
Owner's Manual
Care and Operation
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
•
Shut off gas to the appliance.
•
Extinguish any open flame.
•
If odor continues, leave the area immediately.
•
After leaving the area, call your gas supplier or fire
department.
•
Failure to follow these instructions could result in fire
or explosion, which could cause property damage,
personal injury, or death.
WARNING
Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING: For outdoor use only.
Installation and service must be performed by a qual-
ified installer, service agency, or the gas supplier.
WARNING:
Improper installation, adjust-
ment, alteration, service or maintenance can cause
injury or property damage. Read the installation,
operating and maintenance instructions thoroughly
before installing or servicing this equipment.
WARNING:
If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or
loss of life.
1
