Process CPU
User's Manual
(Hardware Design,
Maintenance and Inspection)
Mitsubishi Programmable
Logic Controller
Q12PHCPU
Q25PHCPU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELSEC- Q Q12PHCPU and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi MELSEC- Q Q12PHCPU

Summary of Contents for Mitsubishi MELSEC- Q Q12PHCPU

  • Page 1 Process CPU User's Manual (Hardware Design, Maintenance and Inspection) Mitsubishi Programmable Logic Controller Q12PHCPU Q25PHCPU...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using.) When using Mitsubishi equipment, thoroughly read this manual and the associated manuals introduced in this manual. Also pay careful attention to safety and handle the module properly. These SAFETY PRECAUTIONS classify the safety precautions into two categories: "DANGER" and "CAUTION".
  • Page 3 [DESIGN PRECAUTIONS] DANGER When overcurrent which exceeds the rating or caused by short-circuited load flows in the output module for a long time, it may cause smoke or fire. To prevent this, configure an external safety circuit, such as fuse. Build a circuit that turns on the external power supply when the PLC main module power is turned on.
  • Page 4 [INSTALLATION PRECAUTIONS] CAUTION Use the PLC in an environment that meets the general specifications contained in this manual. Using this PLC in an environment outside the range of the general specifications could result in electric shock, fire, erroneous operation, and damage to or deterioration of the product. Hold down the module loading lever at the module bottom, and securely insert the module fixing latch into the fixing hole in the base unit.
  • Page 5 [WIRING PRECAUTIONS] CAUTION Be sure to ground the FG terminals and LG terminals to the protective ground conductor. Not doing so could result in electric shock or erroneous operation. When wiring in the PLC, be sure that it is done correctly by checking the product's rated voltage and the terminal layout.
  • Page 6 [STARTUP AND MAINTENANCE PRECAUTIONS] DANGER The online operations conducted for the CPU module being operated, connecting the peripheral device (especially, when changing data or operation status), shall be conducted after the manual has been carefully read and a sufficient check of safety has been conducted. Operation mistakes could cause damage or problems with of the module.

  • Page 7: Revisions

    This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 8: Table Of Contents

    INTRODUCTION Thank you for choosing the Mitsubishi MELSEC-Q Series of General Purpose Programmable Controllers. Please read this manual carefully so that equipment is used to its optimum. CONTENTS SAFETY PRECAUTIONS ..........................A- 1 REVISIONS ..............................A- 6 CONTENTS ..............................A- 7 About Manuals ..............................A-17 How to Use This Manual ..........................A-18...
  • Page 9 6.5 I/O Number Allocation ..........................6- 6 6.6 Guideline for Use of Extension Base Units (Q5 B) ................6- 7 7 MEMORY CARD AND BATTERY 7- 1 to 7- 6 7.1 Memory Card Specifications ........................7- 1 7.2 Battery Specifications (For CPU Module and SRAM Card)..............7- 2 7.3 Handling the Memory Card ........................
  • Page 10 10.3.2 Battery replacement procedure ....................10- 7 11 TROUBLESHOOTING 11- 1 to 11-89 11.1 Troubleshooting Basics ........................11- 1 11.2 Troubleshooting..........................11- 2 11.2.1 Troubleshooting flowchart......................11- 2 11.2.2 Flowchart for when the "MODE" LED is not turned on .............. 11- 3 11.2.3 Flowchart for when the "MODE"...

  • Page 11: Contents

    (Related manual) ....................Process CPU User's Manual (Function Explanation, Program Fundamentals) CONTENTS 1 OVERVIEW 1.1 Features 1.2 Programs 1.3 Convenient Programming Devices and Instructions 2 SYSTEM CONFIGURATION FOR SINGLE CPU SYSTEM 2.1 System Configuration 2.2 Precaution on System configuration 2.3 Confirming the Serial Number and Function Versions 3 PERFORMANCE SPECIFICATION 4 SEQUENCE PROGRAM CONFIGURATION &...
  • Page 12 4.8.4 Real numbers (floating decimal point data) 4.9 Character String Data 5 ASSIGNMENT OF I/O NUMBERS 5.1 Relationship Between the Number of Stages and Slots of the Extension Base Unit 5.2 Installing Extension Base Units and Setting the Number of Stages 5.3 Base Unit Assignment (Base Mode) 5.4 What are I/O Numbers? 5.5 Concept of I/O Number Assignment...
  • Page 13 7.6 Remote Operation 7.6.1 Remote RUN/STOP 7.6.2 Remote PAUSE 7.6.3 Remote RESET 7.6.4 Remote latch clear 7.6.5 Relationship of the remote operation and Process CPU RUN/STOP switch 7.7 Changing the Input Response Speed of the Q Series Compatible Module (I/O Response Time) 7.7.1 Selecting the response time of the input module 7.7.2 Selecting the response time of the high speed input module 7.7.3 Selecting the response time of the interrupt module...
  • Page 14 8 COMMUNICATION WITH INTELLIGENT FUNCTION MODULE/SPECIAL FUNCTION MODULE 8.1 Communication Between Process CPU and Q-series Intelligent Function Modules 8.1.1 Initial setting and automatic refresh setting using GX Configurator 8.1.2 Communication using device initial value 8.1.3 Communication using FROM/TO instruction 8.1.4 Communication using the intelligent function module device 8.1.5 Communication using the instructions dedicated for intelligent function modules 8.2 Request from Intelligent Function Module to Process CPU 8.2.1 Interrupt from the intelligent function module...
  • Page 15 10.5 Intelligent Function Module Devices (U \G ) 10.6 Index Registers (Z) 10.6.1 Switching between scan execution type programs and low speed execution type programs 10.6.2 Switching between scan/low speed execution programs and interrupt/fixed scan execution type programs 10.7 File Registers (R) 10.7.1 File register capacity 10.7.2 Differences in memory card access method by memory card type 10.7.3 Registering the file registers...
  • Page 16 13 OUTLINE OF MULTIPLE CPU SYSTEMS 13.1 Features 13.2 Outline of Multiple CPU Systems 13.3 Differences with Single CPU Systems 14 SYSTEM CONFIGURATION OF MULTIPLE CPU SYSTEMS 14.1 System Configuration 14.2 Precautions For Multiple CPU System Configuration 14.2.1 CPU module mounting positions 14.2.2 Precautions when using Q series I/O modules and intelligent function modules 14.2.3 Modules that have mounting restrictions 14.2.4 Compatible GX Developers and GX Configurators...
  • Page 17 18 PROCESSING TIME FOR MULTIPLE CPU SYSTEM PROCESS CPUs 18.1 Concept behind QCPU Scanning Time 18.2 Factor to Prolong the Scan Time 19 STARTING UP THE MULTIPLE CPU SYSTEM 19.1 Flow-chart for Starting Up the Multiple CPU System 19.2 Setting Up the Multiple CPU System Parameters (Multiple CPU Settings, Control PLC Settings) 19.2.1 System configuration 19.2.2 Creating new systems 19.2.3 Using existing preset multiple CPU settings and I/O allocations...

  • Page 18: About Manuals

    About Manuals The following manuals are related to this product. Referring to this list, please request the necessary manuals. Related Manuals Manual Number Manual Name (Model Code) Process CPU User's Manual (Function Explanation, Program Fundamentals) SH-080315E This manual explains the functions, programming methods, devices and so on necessary to create (13JR56) programs with the Process CPU.

  • Page 19: How To Use This Manual

    How to Use This Manual This manual is prepared for users to understand the hardware specifications of those modules such as the CPU modules, power supply modules, and base units, maintenance and inspections of the system, and troubleshooting required when you use MELSEC-Q series PLCs. The manual is classified roughly into three sections as shown below.

  • Page 20: About The Generic Terms And Abbreviations

    Process CPU General name for Q12PHCPU, and Q25PHCPU modules. Q Series Abbreviation for Mitsubishi MELSEC-Q Series Programmable Logic Controller. Abbreviation for small types of Mitsubishi MELSEC-A Series Programmable Logic AnS Series Controller. GX Developer General name for GX Developer Version 7.10L or later.

  • Page 21: Overview

    1 OVERVIEW MELSEC-Q 1 OVERVIEW This User's Manual describes the hardware specifications and handling methods of the Process CPU. The Manual also describes those items related to the specifications of the power supply module, main base unit, extension base unit, extension cable, memory card and battery.

  • Page 22: Features

    1 OVERVIEW MELSEC-Q 1.1 Features Process CPU has the following new features: (1) 52 instructions added as process control instructions 52 additional instructions are capable of high-level process control. (2) 2-degree-of-freedom PID control system The 2-degree-of-freedom PID control system adopted enables optimum response to both set value variation and disturbance variation.
  • Page 23 1 OVERVIEW MELSEC-Q (7) Controllable multiple I/O points Process CPUs support 4096 points (X/Y0 to FFF) as the number of actual I/O points capable of getting access to the I/O module installed on the base unit. They also support 8192 points max. (X/YO to 1FFF) as the number of I/O devices which can be used in the remote I/O stations such as MELSECNET/H remote I/O NET and CC-Link data link.
  • Page 24 1 OVERVIEW MELSEC-Q (11) Saved space by a reduction in size The installation space for Q series has been reduced by approx. 60 % of the space for AnS series. Comparison of installation space 1SX10 1SY50 1SX41 1SY41 1SX81 1SY81 1SX42 1SY42 98mm...
  • Page 25 1 OVERVIEW MELSEC-Q (14) Data can be written automatically to standard ROM You need not use GX Developer to write parameters/programs on a memory card to the standard ROM of the Process CPU. When the standard ROM is used to perform ROM operation, you can load a memory card into the Process CPU and write parameters/programs on the memory card to the standard ROM.

  • Page 26: System Configuration For Single Cpu System

    2.1 System Configuration The outline of the equipment configuration, configuration with peripheral devices, and system configuration in the Process CPU system is described below. (1) Equipment configuration MITSUBISHI MITSUBISHI LITHIUM BATTERY Memory card Battery...
  • Page 27 2 SYSTEM CONFIGURATION FOR SINGLE CPU SYSTEM MELSEC-Q (2) Configuration of peripheral devices MITSUBISHI Memory card Process CPU USB cable 1 (Q2MEM-1MBS,Q2MEM-2MBS, (Q12PHCPU,Q25PHCPU) (To be procured yourself) Q2MEM-2MBF,Q2MEM-4MBF, Q2MEM-8MBA,Q2MEM-16MBA, Q2MEM-32MBA) RS-232 cable (QC30R2) Personal Computer PC card adapter (GX Developer Version 7.10L...
  • Page 28 2 SYSTEM CONFIGURATION FOR SINGLE CPU SYSTEM MELSEC-Q (3) Outline of system configuration Main base unit(Q312B) Power supply module 0 1 2 3 4 5 6 7 8 9 10 11 Slot No. Extension cable Extension base unit(Q612B) Power supply module The figure shows the configuration 1st extension stage...

  • Page 29: Precaution On System Configuration

    2 SYSTEM CONFIGURATION FOR SINGLE CPU SYSTEM MELSEC-Q 2.2 Precaution on System Configuration This section describes hardware and software packages compatible with Process CPU. (1) Hardware (a) The Process CPU can be used with the MELSEC-Q series I/O and intelligent function modules.

  • Page 30: Confirming The Serial Number And Function Version

    2 SYSTEM CONFIGURATION FOR SINGLE CPU SYSTEM MELSEC-Q 2.3 Confirming the Serial Number and Function Version The CPU module serial No. can be confirmed on the rated plate and GX Developer's system monitor. (1) Confirming the serial No. on the rated plate The serial No.

  • Page 31: General Specifications

    3 GENERAL SPECIFICATIONS MELSEC-Q 3 GENERAL SPECIFICATIONS Performance specification of PLC is as follows: Item Specifications Operating ambient 0 to 55°C temperature Storage ambient -25 to 75°C temperature Operating ambient 5 to 95%RH, non-condensing humidity Storage ambient 5 to 95%RH, non-condensing humidity Frequency Acceleration...
  • Page 32 3 GENERAL SPECIFICATIONS MELSEC-Q MEMO 3 - 2 3 - 2...

  • Page 33: Hardware Specification Of The Cpu Module

    4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q 4 HARDWARE SPECIFICATION OF THE CPU MODULE 4.1 Performance Specification The table below shows the performance specifications of the CPU module. Performance Specifications Model Item Remark Q12PHCPU Q25PHCPU —— Control method Repetitive operation of stored program Direct I/O is possible by I/O control mode Refresh mode...
  • Page 34 4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q Performance Specifications (continued) Model Item Remark Q12PHCPU Q25PHCPU Number of devices Number of I/O devices points 8192 points (X/Y0 to 1FFF) usable on program Number of points Number of occupied I/O points 4096 points (X/Y0 to FFF) accesible to actual I/O modules...
  • Page 35 4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q Performance Specifications (continued) Model Item Remark Q12PHCPU Q25PHCPU Special link relay [SB] 2048 points (SB0 to 7FF) Special link register [SW] 2048 points (SW0 to 7FF) Step relay [S] 8192 points (S0 to 8191) Index register [Z] 16 points (Z0 to 15) 4096 points (P0 to 4095), set parameter values to select usable range...

  • Page 36: Part Names And Settings

    4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q 4.2 Part Names and Settings This section explains the part names and settings of the module. Front face With front cover open Q25PHCPU MODE MODE ERR. ERR. USER USER BAT. BAT. BOOT BOOT ON SW STOP RUN...
  • Page 37 4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q Name Application 1) Module fixing hook Hook used to fix the module to the base unit. (Single-motion installation) Indicates the mode of the CPU module. 2) "Mode" LED ON (green) : Q mode Flicker (green) : Enforced ON/OFF for external I/O registered Indicates the operating status of the CPU module.
  • Page 38 4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q Name Application 9) Memory card EJECT button Used to eject the memory card from the CPU module. Memory card loading Connector used to load the memory card to the CPU module. connector Connector for connection with USB-compatible peripheral device.

  • Page 39: Switch Operation After Writing In Program

    4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q 4.3 Switch Operation After Writing in Program When writing a program into the CPU module, do not turn off the system protect set switch SW1 in advance (When the switch is turned off, the system will not be protected).

  • Page 40: Latch Clear Operation

    4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q 4.4 Latch Clear Operation To perform latch clear, operate the RESET/L.CLR switch in the following procedure. 1) RUN/STOP switch : STOP 2) RESET/L.CLR switch : Move the switch to L.CLR several times until the USER LED flickers.
  • Page 41 4 HARDWARE SPECIFICATION OF THE CPU MODULE MELSEC-Q Operations with CPU module (automatic write to standard ROM) Switch OFF the power supply to the PLC. Mount the memory card that contains the parameters and programs to be booted onto the CPU module. Set the parameter's valid drive in the mounted memory card with the CPU module's dip switches.

  • Page 42: Online Module Change

    4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q 4.6 Online Module Change Online module change is a function to change the Q Series module mounted on the main or extension base unit during control of the PLC system. If a module fails during control, it can be changed to the same type module by using this function.
  • Page 43 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q (c) Base unit that enables online module change 1) For an online module change, use the main base and Q6 B extension base. The module installed on the main base or Q6 B extension base is not available for online change.
  • Page 44 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q (2) Restrictions during online module change The following operations fail an online module change. One CPU module gets the online module change orders from multipe GX Developer at the same time. (Requests from multiple GX Developers are made of one CPU module for an online module change.) Parameters are written to the CPU module during an online module change.
  • Page 45 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q (3) Special relays and special registers related to online module change Indication for online module change is stored into the special relays (SM235, SM236) and special register (SD235). By monitoring SM235, SM236 and SD235, shows the status for online module change.
  • Page 46 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q (4) Online module change procedure The online module change procedure for an I/O module is explained here. Please refer to the intelligent function module’s manual about its online module change procedure. POINT It is recommended to turn OFF the output (Y) from the output or I/O mixed module before its on line change.
  • Page 47 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q Double-click the module to be changed online to display the Online module change screen. (The following table indicates the status of communication with the module changed online when the following screen is being displayed.) Executed/ Target Module, Item Not Executed...
  • Page 48 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q Disconnect the external wiring and dismount the module. Refer to Section 9.3.3 for module dismounting. Mount a new module to the same slot and connect the external wiring. Refer to Section 9.3.3 for module mounting. After mounting the module, click the "Execution"...
  • Page 49 4 HARDWARE SPECIFICATIONS OF CPU MODULE MELSEC-Q The "Online module change completed" screen appears. (The following table indicates the status of communication with the module changed onlinely, when the following screen is displayed.) Executed/ Target Module, Item Not Executed Input module refresh Executed Output module refresh Executed...

  • Page 50: Power Supply Module

    5 POWER SUPPLY MODULE MELSEC-Q 5 POWER SUPPLY MODULE 5.1 Specification 5.1.1 Power supply module specifications This section gives the specifications of the power supply modules. Performance Specifications Item Q61P-A1 Q61P-A2 Q62P Q63P Base loading position Power supply module loading slot Applicable base unit Q3 B, Q6 B +10%...
  • Page 51 5 POWER SUPPLY MODULE MELSEC-Q Power Supply Module Specifications (Continued) Performance Specifications Item Q64P Base loading position Power supply module loading slot Applicable base unit Q3 B, Q6 B +10% 100 to 120VAC/200 to 240VAC -15% Input power supply (85V to 132VAC/170 to 264VAC) Input frequency 50/60Hz ±5% Input voltage distortion factor...
  • Page 52 5 POWER SUPPLY MODULE MELSEC-Q POINTS 1 : Overcurrent protection The overcurrent protection device shuts off the 5 V, 24 VDC circuit and stops the system if the current flowing in the circuit exceeds the specified value. The LED of the power supply module is unlit or lit dimly upon a voltage drop. If this device is activated, switch the input power supply off and eliminate the cause such as insufficient current capacity or short.

  • Page 53: Selecting The Power Supply Module

    5 POWER SUPPLY MODULE MELSEC-Q 5.1.2 Selecting the power supply module The power supply module is selected according to the total of current consumption of the base units, I/O modules and intelligent function module, supplied by its power supply module. For the internal current consumption of 5 VDC of the base unit, see Chapter 6.

  • Page 54: Precaution When Connecting The Uninterruptive Power Supply

    5 POWER SUPPLY MODULE MELSEC-Q (b) Ideas for reducing voltage drops The following methods are effective to reduce voltage drops at the extension cables. 1) Changing the module loading positions Load large current consumption modules on the main base unit. Load small current consumption modules on the extension base unit.

  • Page 55: Names Of Parts And Settings

    5 POWER SUPPLY MODULE MELSEC-Q 5.2 Names of Parts and Settings The names of the parts of each power supply module are described below. (1) Q61P-A1, Q61P-A2, Q62P, Q63P, Q64P Q61P-A2 POWER POWER INPUT INPUT 200-240VAC 100-120VAC 50/60Hz 105VA 50/60Hz 105VA OUTPUT 5VDC 6A OUTPUT 5VDC 6A ERR.
  • Page 56 5 POWER SUPPLY MODULE MELSEC-Q Name Application POWER LED 5VDC power indicator LED 1) Turned ON when the whole system operates normally. 2) Turned OFF (opened) when a stop error occurs in the CPU module. ERR terminals 3) In a multiple CPU system configuration, turned OFF when a stop error occurs in any of the CPU modules.
  • Page 57 5 POWER SUPPLY MODULE MELSEC-Q MEMO 5 - 8 5 - 8...

  • Page 58: Base Unit And Extension Cable

    6 BASE UNIT AND EXTENSION CABLE MELSEC-Q 6 BASE UNIT AND EXTENSION CABLE This section describes the specifications of the extension cables for the base units (main base unit and extension base unit) used in the PLC system and the specification standards of the extension base unit. 6.1 Base Unit Specification Table (1) Main base unit specifications Type...

  • Page 59: Extension Cable Specification Table

    6 BASE UNIT AND EXTENSION CABLE MELSEC-Q (3) Extension base unit specifications Type Q63B Q65B Q68B Q612B Item Number of I/O modules installed Possibility of Extendable extension Applicable module Q series modules 5 VDC internal current 0.121A 0.105A 0.110A 0.114A consumption Mounting hole size M4 screw hole or...

  • Page 60: Parts Names Of Base Unit

    6 BASE UNIT AND EXTENSION CABLE MELSEC-Q 6.3 Parts Names of Base Unit The names of the parts of the base unit are described below. (1) Main base unit(Q33B, Q35B, Q38B, Q312B) POWER I/00 I/01 I/02 I/03 I/04 I/05 I/06 I/07 I/08 I/09...
  • Page 61 6 BASE UNIT AND EXTENSION CABLE MELSEC-Q (2) Extension base unit (Q5 B, Q6 Q52B, Q55B I/O0 I/O1 I/O2 I/O3 I/O4 7) 4) Q63B, Q65B, Q68B, Q612B I/00 I/01 I/02 I/03 I/04 I/05 I/06 I/07 I/08 I/09 I/10 I/11 POWER Name Application Connectors for sending and receiving signals from the main base unit or the other...

  • Page 62: Setting The Extension Base Unit

    6 BASE UNIT AND EXTENSION CABLE MELSEC-Q 6.4 Setting the Extension Base Unit The number of stages setting method of each extension base unit to be used when extension base units are installed is described below. PIN1 Stage No. setting connector Setting of Stage Number for Extension Base Units Number Setting for Extension Stages 1st stage 2nd stage 3rd stage 4th stage 5th stage 6th stage 7th stage...

  • Page 63: I/O Number Allocation

    6 BASE UNIT AND EXTENSION CABLE MELSEC-Q 6.5 I/O Number Allocation The I/O numbers are automatically allocated in the system loading status. 10 11 12 extension stage 14 15 16 17 18 19 20 extension stage 22 23 24 25 extension stage In this system, 32-point modules are loaded on slots 0 to 25.

  • Page 64: Guideline For Use Of Extension Base Units (Q5 B)

    6 BASE UNIT AND EXTENSION CABLE MELSEC-Q 6.6 Guideline for Use of Extension Base Units (Q5 B) Since the Q5 B is supplied with 5VDC from the power supply module on the main base unit, a voltage drop occurs at extension cables. Improper I/O may be provided if the specified voltage (4.75VDC or higher) is not supplied to the "IN"...
  • Page 65 6 BASE UNIT AND EXTENSION CABLE MELSEC-Q List for Calculating Voltage Drops Occurring at Extension Cables in System Consisting of Extensions 1 to 7 Q5 B Sum Total of Voltage Voltage Drop at Extension Cable on Corresponding Extension Unit Loading Drops to "IN"...
  • Page 66 6 BASE UNIT AND EXTENSION CABLE MELSEC-Q List for Calculating Voltage Drops Occurring at Extension Cables when connecting Q6 B between Q3 B and Q5 B Voltage drop caused by extension Position of extension base unit cable from the main base unit to the Q6 B Q5 B Q5 B IN connector (V)
  • Page 67 6 BASE UNIT AND EXTENSION CABLE MELSEC-Q POINT When connecting GOT by extension cable that is 13.2 m (43.31ft) or longer, the bus extension connector box A9GT-QCNB is required. Since the A9GT-QCNB is supplied with 5VDC from the power supply module loaded on the main base unit, 29mA must be added to "Im"...

  • Page 68: Memory Card And Battery

    7 MEMORY CARD AND BATTERY MELSEC-Q 7 MEMORY CARD AND BATTERY This section describes the specifications and handling of the memory card and battery which can be used on the Process CPU. The memory card is necessary for sampling tracing. The memory card is also used to handle file registers of more than the number of points that can be stored in the standard RAM.

  • Page 69: Battery Specifications (For Cpu Module And Sram Card)

    7 MEMORY CARD AND BATTERY MELSEC-Q 7.2 Battery Specifications (For CPU Module and SRAM Card) (1) For CPU module Type Q6BAT Item Manganese dioxide lithium primary Classification battery Initial voltage 3.0V Nominal current 1800mAh Storage life 10 years (room temperature) Total power interrupt Refer to Section 10.3.1.

  • Page 70: Handling The Memory Card

    7 MEMORY CARD AND BATTERY MELSEC-Q 7.3 Handling the Memory Card (1) Formatting of memory card Any SRAM or ATA card used on the Process CPU must have been formatted Since the SRAM or ATA card purchased is not yet formatted, format it using GX Developer before use.

  • Page 71: The Names Of The Parts Of The Memory Card

    7 MEMORY CARD AND BATTERY MELSEC-Q 7.4 The Names of The Parts of The Memory Card The names of the parts of the memory card are described below. Write-protected ON "LOCK" direction "RELEASE" direction Name Descriptions 1) Connector section Connector section connected to the CPU module Used to set the lithium battery for data backup of the SRAM memory 2) Battery holder (SRAM card only)

  • Page 72: Memory Card Loading/Unloading Procedures

    7 MEMORY CARD AND BATTERY MELSEC-Q 7.5 Memory Card Loading/Unloading Procedures (1) To install the memory card Install the memory card into the CPU module, while paying attention to the orientation of the memory card. Insert the memory card securely into the connector until the height of the memory card reaches that of the memory card EJECT button.

  • Page 73: Installation Of Battery (For Cpu Module And Memory Card)

    7 MEMORY CARD AND BATTERY MELSEC-Q 7.6 Installation of Battery (For CPU Module and Memory Card) (1) The battery for the CPU module is shipped with its connector disconnected. Connect the connector as follows. Refer to Section 10.3 for the service life of the battery and how to replace the battery.

  • Page 74: Emc And Low Voltage Directive

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8 EMC AND LOW VOLTAGE DIRECTIVE For the products sold in European countries, the conformance to the EMC Directive, which is one of the European Directive, has been a legal obligation since 1996. Also, conformance to the Low Voltage Directive, another European Directive, has been a legal obligation since 1997.

  • Page 75: Installation Instructions For Emc Directive

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8.1.2 Installation instructions for EMC Directive The PLC is open equipment and must be installed within a control cabinet for use. This not only ensures safety but also ensures effective shielding of PLC-generated electromagnetic noise.

  • Page 76: Cables

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8.1.3 Cables The cables extracted from the control panel contain a high frequency noise component. On the outside of the control panel, therefore, they serve as antennas to emit noise. To prevent noise emission, use shielded cable for the cables which are connected to the I/O modules and intelligent function modules and may be extracted to the outside of the control panel.
  • Page 77 8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q (2) MELSECNET/H module Always use a double-shielded coaxial cable (MITSUBISHI CABLE INDUSTRIES, LTD.: 5C-2V-CCY) for the coaxial cables MELSECNET/H module. Radiated noise in the range of 30MHz or higher can be suppressed by use of the double- shielded coaxial cables.

  • Page 78: Power Supply Module

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8.1.4 Power supply module Always ground the LG and FG terminals after short-circuiting them. 8.1.5 Others (1) Ferrite core A ferrite core has the effect of reducing radiated noise in the 30MHz to 100MHz band.

  • Page 79: Requirement To Conform To The Low Voltage Directive

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8.2 Requirement to Conform to the Low Voltage Directive The Low Voltage Directive requires each device that operates with the power supply ranging from 50 to 1000VAC and 75 to 1500VDC to satisfy the safety requirements. In Sections 8.2.1 to 8.2.6, cautions on installation and wiring of the MELSEC-Q series PLC to conform to the Low Voltage Directive are described.

  • Page 80: Power Supply

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8.2.3 Power supply The insulation specification of the power supply module was designed assuming installation category II. Be sure to use the installation category II power supply to the PLC. The installation category indicates the durability level against surge voltage generated by a thunderbolt.

  • Page 81: Grounding

    8 EMC AND LOW VOLTAGE DIRECTIVE MELSEC-Q 8.2.5 Grounding There are the following two different grounding terminals. Use either grounding terminal in an earthed status. Protective grounding : Maintains the safety of the PLC and improves the noise resistance. Functional grounding : Improves the noise resistance.

  • Page 82: Loading And Installation

    9 LOADING AND INSTALLATION MELSEC-Q 9 LOADING AND INSTALLATION In order to increase the reliability of the system and exploit the maximum performance of its functions, this section describes the methods and precautions for the mounting and installation of the system. 9.1 General Safety Requirements Install a safety circuit external to the PLC that keeps the entire DANGER...
  • Page 83 9 LOADING AND INSTALLATION MELSEC-Q When connecting a peripheral device to the CPU module or connecting DANGER a personal computer or the like to the special function module to exercise control (data change) on the running PLC, configure up an interlock circuit in the sequence program to ensure that the whole system will always operate safely.
  • Page 84 9 LOADING AND INSTALLATION MELSEC-Q (1) System design circuit example (when not using ERR contact of power supply module) POWER SUPPLY FOR AC FOR AC/DC POWER SUPPLY Input switched TRANSFORMER TRANSFORMER when power TRANSFORMER supply FUSE FUSE established. FUSE CPU MODULE CPU MODULE SM52 POWER...
  • Page 85 9 LOADING AND INSTALLATION MELSEC-Q (2) System design circuit example (when using ERR contact of power supply module) POWER SUPPLY FOR AC/DC TRANSFORMER TRANSFORMER Input switched FUSE FUSE when power supply CPU MODULE established. SM52 POWER SUPPLY RUN/STOP circuit (-) (+) interlocked with SM403 FUSE...
  • Page 86 Though Mitsubishi PLCs are manufactured under strict quality control, they may cause failure or abnormal operations due to unspecific reasons. To prevent the abnormal operation of the whole system, machine breakdown, and accidents, fail-safe circuitry against failure of the PLC must be constructed outside the PLC.

  • Page 87: Calculating Heat Generation By Plc

    9 LOADING AND INSTALLATION MELSEC-Q 9.2 Calculating Heat Generation by PLC The ambient temperature inside the board storing the PLC must be suppressed to a PLC usable ambient temperature of 55°C. For the design of radiation from the storing board, it is necessary to know the average power consumption (heating value) of the devices and instruments stored in the board.
  • Page 88 9 LOADING AND INSTALLATION MELSEC-Q (6) Power consumption of the power supply section of the intelligent function module 5 + I 24 + I 100 (W) 100V The total of the power consumption values calculated for each block becomes the power consumption of the overall sequencer system. W = W From this overall power consumption (W), calculate the heating value and a rise in ambient temperature inside the board.
  • Page 89 9 LOADING AND INSTALLATION MELSEC-Q (f) Average power consumption due to voltage drop in the output section of the output module = 0 (W) (g) Average power consumption of the input section of the input module = 0.004 1 = 3.07 (W) (h) Power consumption of the power supply section of the intelligent function module = 0 (W)

  • Page 90: Module Installation

    9 LOADING AND INSTALLATION MELSEC-Q 9.3 Module Installation 9.3.1 Precaution on installation Use the PLC in an environment that meets the general specifications CAUTION contained in this manual. Using this PLC in an environment outside the range of the general specifications could result in electric shock, fire, erroneous operation, and damage to or deterioration of the product.
  • Page 91 9 LOADING AND INSTALLATION MELSEC-Q (6) Install the main base unit (by screwing) in the following procedure. 1) Fit the two base unit top mounting screws into the enclosure. Panel 2) Place the right-hand side notch of the base unit onto the right-hand side screw. Panel 3) Place the left-hand side pear-shaped hole onto the left-hand side screw.
  • Page 92 9 LOADING AND INSTALLATION MELSEC-Q (7) Note the following points when mounting a DIN rail. Mounting a DIN rail needs special adaptors (optional), which are to be user- prepared. (a) Applicable adaptor types For Q38B, Q312B, Q68B, Q612B : Q6DIN1 For Q35B, Q65B : Q6DIN2 For Q33B, Q52B, Q55B, Q63B...

  • Page 93: Instructions For Mounting The Base Unit

    9 LOADING AND INSTALLATION MELSEC-Q 9.3.2 Instructions for mounting the base unit When mounting the PLC to an enclosure or the like, fully consider its operability, maintainability and environmental resistance. (1) Module mounting position For enhanced ventilation and ease of module replacement, leave the following clearances between the module top/bottom and structure/parts.
  • Page 94 9 LOADING AND INSTALLATION MELSEC-Q (2) Module mounting orientation (a) Since the PLC generates heat, it should be mounted on a well ventilated location in the orientation shown below. (b) Do not mount it in either of the orientations shown below. Vertical Flat (3) Installation surface...

  • Page 95: Installation And Removal Of Module

    9 LOADING AND INSTALLATION MELSEC-Q 9.3.3 Installation and removal of module This section explains how to install and remove a power supply, CPU, I/O, intelligent function or another module to and from the base unit. (1) Installation and removal of the module from Q3 B, ,Q5 B and Q6 B The installation and removal of the module from Q3 B/Q6 B base unit are described below.
  • Page 96 9 LOADING AND INSTALLATION MELSEC-Q (b) Removal from Q3 B, Q5 B and Q6 B Base unit Hold the module with both hands, and push the hook on the top of the module with a finger until it stops. Module connector Module While pushing the hook, and...

  • Page 97: How To Set Stage Numbers For The Extension Base Unit

    9 LOADING AND INSTALLATION MELSEC-Q 9.4 How to Set Stage Numbers for the Extension Base Unit When using two or more extension base units, their stage numbers must be set with their stage number setting connectors. Extension 1 need not be set since the extension number is factory-set to 1.

  • Page 98: Connection And Disconnection Of Extension Cable

    9 LOADING AND INSTALLATION MELSEC-Q 9.5 Connection and Disconnection of Extension Cable (1) Instructions for handling an extension cable • Do not stamp an extension cable. • An extension cable must be connected to the base unit when the base cover has been installed.
  • Page 99 9 LOADING AND INSTALLATION MELSEC-Q (a) To connect an extension cable to the main base unit, remove the portion under the OUT characters on the base cover with a tool such as a flat-blade screwdriver (5.5 75, 6 100). This also applies to a case where an extension cable is connected to the OUT side connector of the extension base unit.
  • Page 100 9 LOADING AND INSTALLATION MELSEC-Q (3) Disconnection of extension cable When unplugging the extension cable, hold and pull the connector part of the extension cable after making sure that the fixing screws have been removed completely. 9 - 19 9 - 19...

  • Page 101: Wiring

    9 LOADING AND INSTALLATION MELSEC-Q 9.6 Wiring 9.6.1 The precautions on the wiring Completely turn off the external power supply when installing or DANGER placing wiring. Not completely turning off all power could result in electric shock or damage to the product. When turning on the power supply or operating the module after installation or wiring work, be sure that the module's terminal covers are correctly attached.
  • Page 102 9 LOADING AND INSTALLATION MELSEC-Q (b) Do not connect the 24VDC outputs of two or more power supply modules in parallel to supply power to one I/O module. Parallel connection will damage the power supply modules. 24VDC 24VDC 24VDC External power supply (c) 100VAC, 200VAC and 24VDC wires should be twisted as dense as possible.
  • Page 103 9 LOADING AND INSTALLATION MELSEC-Q (2) Wiring of I/O equipment (a) Insulation-sleeved crimping terminals cannot be used with the terminal block. It is recommended to cover the wire connections of the crimping terminals with mark or insulation tubes. (b) The wires used for connection to the terminal block should be 0.3 to 0.75mm in core and 2.8mm (0.11 inch) max.

  • Page 104: Connecting To The Power Supply Module

    9 LOADING AND INSTALLATION MELSEC-Q 9.6.2 Connecting to the power supply module The following diagram shows the wiring example of power lines, grounding lines, etc. to the main and extension base units. Main base unit 100/110VAC (Q38B) Q61P-A1 CPU module Fuse 24VDC INPUT...

  • Page 105: Maintenance And Inspection

    10 MAINTENANCE AND INSPECTION MELSEC-Q 10 MAINTENANCE AND INSPECTION Do not touch the terminals while power is on. DANGER Doing so could cause shock. Correctly connect the battery. Also, do not charge, disassemble, heat, place in fire, short circuit, or solder the battery. Mishandling of a battery can cause overheating or cracks which could result in injury and fires.

  • Page 106: Daily Inspection

    10 MAINTENANCE AND INSPECTION MELSEC-Q 10.1 Daily Inspection The items that must be inspected daily are listed below. Daily inspection Item Inspection Item Inspection Judgment Criteria Remedy Check that fixing screws The screws and cover must be installed Further tighten the Installation of base unit are not loose and the securely.

  • Page 107: Periodic Inspection

    10 MAINTENANCE AND INSPECTION MELSEC-Q 10.2 Periodic Inspection The items that must be inspected one or two times every 6 months to 1 year are listed below. When the equipment is moved or modified, or layout of the wiring is changed, also perform this inspection.

  • Page 108: Battery Replacement

    10 MAINTENANCE AND INSPECTION MELSEC-Q 10.3 Battery Replacement When the voltage of the program and power interrupt hold-on function backup battery is lowered, the special relays SM51 and SM52 are energized. Even if these special relays are energized, the contents of the program and power interrupt hold-on function are not erased immediately.

  • Page 109: Battery Life

    10 MAINTENANCE AND INSPECTION MELSEC-Q 10.3.1 Battery life (1) CPU module battery (Q6BAT) life (a) The CPU module battery life is given below. Battery life Energization CPU Module After SM51 is energized Time Ratio Guaranteed value Value in actual use Type (Guaranteed time after (MIN)
  • Page 110 10 MAINTENANCE AND INSPECTION MELSEC-Q POINT Remember that the SRAM card consumes battery power even when the battery is connected to the CPU module and the power is turned ON. If the special relay SM51 (battery low latch) turns on, immediately replace the battery. If an alarm has not yet occurred, it is recommended to replace the battery periodically according to the conditions of use.

  • Page 111: Battery Replacement Procedure

    10 MAINTENANCE AND INSPECTION MELSEC-Q 10.3.2 Battery replacement procedure (1) CPU module battery replacement procedure When the CPU module battery has been exhausted, replace the battery with a new one according to the procedure shown below. The PLC power must be on for 10 minutes or longer before dismounting the battery.
  • Page 112 10 MAINTENANCE AND INSPECTION MELSEC-Q (2) SRAM card CPU module battery replacement procedure Replace the SRAM card battery in the following procedure. POINTS Replace the battery while paying attention to the following. (a) To back up the data, replace the SRAM card battery with the PLC power supply ON and the SRAM card installed.

  • Page 113: Troubleshooting

    11 TROUBLESHOOTING MELSEC-Q 11 TROUBLESHOOTING This section describes the various types of trouble that occur when the system is operated, and causes and remedies of these troubles. 11.1 Troubleshooting Basics In order to increase the reliability of the system, not only highly reliable devices are used but also the speedy startup of the system after the occurrence of trouble becomes an important factor.

  • Page 114: Troubleshooting

    11 TROUBLESHOOTING MELSEC-Q 11.2 Troubleshooting The trouble investigating methods, contents of troubles for the error codes, and remedies of the troubles are described below. 11.2.1 Troubleshooting flowchart The following shows the contents of the troubles classified into a variety of groups according to the types of events.

  • Page 115: Flowchart For When The "Mode" Led Is Not Turned On

    Hardware fault Check operations in the order starting from the minimum system. Completion If the module will not work, please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. 11 - 3 11 - 3...

  • Page 116: Flowchart For When The "Mode" Led Is Flickering

    Hardware fault Check operations in the order starting from the minimum system. Completion If the module will not work, please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. 11 - 4 11 - 4...

  • Page 117: Flowchart For When The "Power" Led Is Turned Off

    2) Turn OFF the input power and wait protection working? several minutes before turning it ON again. Can "POWER" LED be turned on? Please consult your local Mitsubishi service center or representative, explaining a detailed description Completion of the problem. 11 - 5...

  • Page 118: Flowchart For When The "Run" Led Is Turned Off

    For the Set the CPU module's RUN/STOP case of (2) switch to STOP and write END to address 0 with the GX Please consult your local Mitsubishi Developer. service center or representative, explaining a detailed description of the problem. Set the RUN/STOP switch to RUN and enter to the monitor "RUN"...

  • Page 119: When The "Run" Led Is Flickering

    Confirm details of error by Hardware fault GX Developer. (Refer to Section 11.3.) Set the RUN/STOP switch to STOP. Please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. Modify error details. (Refer to Section 11.3.) Reset by the RESET/L.

  • Page 120: When The "User" Led Is Turned On

    11 TROUBLESHOOTING MELSEC-Q 11.2.8 When the "USER" LED is turned on If the "USER" LED turns on, follow the steps described below. The "USER" LED turns on when an error is detected by the CHK instruction or the annunciator (F) turns on. If the "USER"...

  • Page 121: Flowchart For When The "Boot" Led Is Flickering

    Is the "BOOT" LED turned on? memory card to standard ROM Perform boot operation from standard ROM. CPU module hardware fault. Please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. 11 - 9...

  • Page 122: Flowchart For When Output Module Led Is Not Turned On

    Is the LED turned Output module hardware fault hardware fault. on when the output module is Consult your local system service, Please consult your local Mitsubishi changed for another output module, agency or branch office. service center or representative, which is then forcibly...

  • Page 123: Flowchart For When Output Load Of Output Module Does Not Turn On

    Check the load wire and load, and recover the power supply. Please consult your local Mitsubishi service center or representative, Change the output relay number and Confirm rush current when the load...

  • Page 124: Flowchart For When Unable To Read A Program

    RS-232 Can the CPU communicate with the GX Developer? Please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. Can the CPU communicate with GX Developer by...

  • Page 125: Flowchart For When Unable To Write A Program

    11 TROUBLESHOOTING MELSEC-Q 11.2.14 Flowchart for when unable to write a program The following shows the flowchart to be followed when programs cannot be written in the CPU module. Unable to write a program Is the DIP switch Turn the DIP switch SW1 (system SW1 set to OFF? protect) to OFF.
  • Page 126 11 TROUBLESHOOTING MELSEC-Q Format program memory. Is it able to write a program? Please consult your local Mitsubishi service center or representative, explaining a detailed description Completion of the problem. 11 - 14 11 - 14...

  • Page 127: Flowchart For When It Is Unable To Perform Boot Operation From Memory Card

    Write a file to the memory card. file stored in the memory card? Is it able to perform boot operation? Please consult your local Mitsubishi service center or representative, explaining a detailed description Completion of the problem. 11 - 15...

  • Page 128: Flowchart For When Unit Verify Err. Occurs

    Replace the CPU module. Error detection Proper operation Replace the applicable base unit. Error detection Hardware fault Please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. Completion 11 - 16 11 - 16...

  • Page 129: Flowchart For When Control Bus Err. Occurs

    Replace the CPU module. Error detection Proper operation Replace the applicable base unit. Error detection Hardware fault Please consult your local Mitsubishi service center or representative, explaining a detailed description of the problem. Completion 11 - 17 11 - 17...

  • Page 130: Error Code List

    11 TROUBLESHOOTING MELSEC-Q 11.3 Error Code List If a fault occurs when the PLC power supply is switched on or the stopped CPU module runs or during RUN, the High Performance model QCPU displays an error (on the LED) using the self-diagnosis function and stores the error information into the special relays SM and special registers SD.

  • Page 131: Error Code List

    11 TROUBLESHOOTING MELSEC-Q 11.3.2 Error code list The following information deals with error codes and the meanings, causes, and corrective measures of error messages. " " in the Corresponding CPU column indicates that the error is applied to Process CPU module. "Rem"...
  • Page 132 1310 An interruption has occurred although there is no interrupt module. so check the modules. Contact your nearest Mitsubishi representative and explain the problem with the defective module. 1 Characters in parentheses ( ) indicate the special register numbers where individual information is being stored.
  • Page 133 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code LED Status Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) Stop/ At power ON/At reset/ 1401 SP. UNIT DOWN Unit/module No. ———...
  • Page 134 • There was no response from the intelligent function module when The intelligent function module that was being accessed is 1403 the END instruction is executed. experiencing hardware problems. Contact your nearest Mitsubishi + Rem • An error is detected at the intelligent function module. representative.
  • Page 135 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual LED Status Operating Error Code Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) 2100 2103 SP. UNIT LAY ERR. Unit/module No. ——— Flicker Stop At power ON/At reset 2106...
  • Page 136 11 TROUBLESHOOTING MELSEC-Q Corres- Error Code Error Contents and Cause Corrective Action ponding (SD0) Slot loaded with the QI60 is set to other than the Inteli (intelligent Make setting again to match the parameter I/O assignment with the function module) or Interrupt (interrupt module) in the parameter I/O actual loading status.
  • Page 137 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code LED Status Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) Stop/ 2110 SP. UNIT ERROR Unit/module No. Program error location Off/On Flicker/On Continue...
  • Page 138 (2) The intelligent function module is experiencing hardware (2) There was no response form the intelligent function module. problems. Contact your nearest Mitsubishi representative. (1) Eliminate empty slots between the CPU modules. (Set empty CPU module locations in a multiple CPU system are either of the slots on the right side of the CPU modules.)
  • Page 139 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code LED Status Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) 2401 FILE SET ERROR File name Parameter number Flicker Stop At power ON/At reset 2410 Stop/...
  • Page 140 RAM or on the memory card. Contact your 3002 PLC file setting parameter, the specified file does not exist though nearest Mitsubishi representative. the file register capacity has been set. The automatic refresh range of the multiple CPU system exceeded Change the file register file for the one refresh-enabled in the whole the file register capacity.
  • Page 141 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code LED Status Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) 3100 3101 At power ON/Reset/ LINK PARA. ERROR File name Parameter number Flicker Stop...
  • Page 142 (4) If the error persists after the above items (1) to (3) are checked, type.) the hardware is faulty. Contact your nearest Mitsubishi representative and explain the symptom. • When the station number of the MELSECNET/H module is 0, the inter-PLC network parameter setting has been made.
  • Page 143 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code LED Status Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) When an END instruction is executed. 3301 At power ON/Reset/ SP.
  • Page 144 11 TROUBLESHOOTING MELSEC-Q Corres- Error Code Error Contents and Cause Corrective Action ponding (SD0) The refresh setting of the intelligent function module exceeded the Change the file register file for the one which allows refresh in the file register capacity. whole range.
  • Page 145 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code LED Status Error Messages Diagnostic Timing Information Information Statuses of (SD0) ERROR (SD5 to 15) (SD16 to 26) 4210 4211 CAN'T EXECUTE (P) Program error location ——— Flicker Stop When instruction is executed 4212...
  • Page 146 11 TROUBLESHOOTING MELSEC-Q Corres- Error Code Error Contents and Cause Corrective Action ponding (SD0) The CALL instruction is executed, but there is no subroutine at the 4210 specified pointer. Read the common error information at a GX Developer, check error step corresponding to its numerical value (program error location), 4211 There was no RET instruction in the executed sub-routine program.
  • Page 147 11 TROUBLESHOOTING MELSEC-Q Error Code List (Continued) Common Individual Operating Error Code Error Messages Information Information LED Status Statuses of Diagnostic Timing (SD0) (SD5 to 15) (SD16 to 26) 7000 Always MULT CPU DOWN Unit/module No. ——— Flicker Stop 7002 At power ON/Reset 7003 At power ON/Reset...
  • Page 148 11 TROUBLESHOOTING MELSEC-Q Corres- Error Code Error Contents and Cause Corrective Action ponding (SD0) (1) In a multiple CPU system, at PLC fault occurred at a station (1) Read the individual error information using GX Developer, check where "all station stop by stop error of PLC " was selected in the the error of the CPU resulting in CPU fault, and remove the operating mode.

  • Page 149: Canceling Of Errors

    11 TROUBLESHOOTING MELSEC-Q 11.4 Canceling of Errors The Process CPU can perform the cancel operation for errors only when the errors allow the CPU module to continue its operation. To cancel the errors, follow the steps shown below. 1) Eliminate the cause of the error. 2) Store the error code to be canceled in the special register SD50.

  • Page 150: I/O Module Troubleshooting

    11 TROUBLESHOOTING MELSEC-Q 11.5 I/O Module Troubleshooting This chapter explains possible problems with I/O circuits and their corrective actions. 11.5.1 Input circuit troubleshooting This section describes possible problems with input circuits and their corrective actions. Input Circuit Problems and Corrective Actions Condition Cause Corrective Action...
  • Page 151 11 TROUBLESHOOTING MELSEC-Q Input Circuit Problems and Corrective Actions (Continued) Condition Cause Corrective Action • Sneak path due to the use of two power • Use only one power supply. supplies. • Connect a sneak path prevention diode. (Figure below) Input signal does not Input module...
  • Page 152 11 TROUBLESHOOTING MELSEC-Q <Calculation example of Example 4> QX40 Leakage current If a switch with an LED display 2.33mA Input module is connected to QX40 and a 4.7k current of 2.33 mA is leaked. 24VDC Voltage V across the terminal and common base is: = 2.33[mA] 5.6[k ] = 13[V] (Ignore the voltage drop caused by the LED.) Because the condition for the OFF voltage ( 11 [V]) is not satisfied, the input does not turn off.

  • Page 153: Output Circuit Troubleshooting

    11 TROUBLESHOOTING MELSEC-Q 11.5.2 Output Circuit Troubleshooting This section explains trouble examples and troubleshooting methods in the output circuit. Output Circuit Troubleshooting Condition Cause Corrective Action • When load is half-wave rectified inside • Connect a resistor of several ten K to several (This is typical of some solenoids.) hundred K across the load.

  • Page 154: Special Relay List

    11 TROUBLESHOOTING MELSEC-Q 11.6 Special Relay List Special relays, SM, are internal relays whose applications are fixed in the PLC. For this reason, they cannot be used by sequence programs in the same way as the normal internal relays. However, they can be turned ON or OFF as needed in order to control the CPU module and remote I/O modules.
  • Page 155 11 TROUBLESHOOTING MELSEC-Q Special Relay List (1) Diagnostic Information Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) • ON if diagnosis results show error occurrence (Includes when an annunciator is ON, and when an error OFF : No error Diagnostic errors is detected with CHK instruction) S (Error)
  • Page 156 11 TROUBLESHOOTING MELSEC-Q Special Relay List (2) System information Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) LED off • When this relay goes from OFF to ON, the LEDs SM202 ON : LED off command corresponding to the individual bits at SD202 go off S (Status SM203 STOP contact STOP status...
  • Page 157 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) • Goes ON for standby network OFF : Operative network SM255 (If no designation has been made concerning active or S (Initial) ON : Standby network MELSECNET/H standby, active is assumed.)
  • Page 158 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) Selects the device status when the stopped CPU module SFC device clear OFF : Clear device SM326 is run after the sequence program or SFC program has mode ON : Preserves device been modified when the SFC program exists.
  • Page 159 11 TROUBLESHOOTING MELSEC-Q Special Relay List (3) System clocks/counters Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) SM400 Always ON • Normally is ON (Every END M9036 processing) SM401 Always OFF • Normally is OFF (Every END M9037 processing) •...
  • Page 160 11 TROUBLESHOOTING MELSEC-Q Special Relay List (4) Scan information Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) Low speed OFF : Completed or not exection type • Goes ON when low speed execution type program is SM510 executed (Every END program...
  • Page 161 11 TROUBLESHOOTING MELSEC-Q (6) Instruction-Related Special Relays Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) OFF : Carry OFF SM700 Carry flag • Carry flag used in application instruction (Instruction M9012 ON : Carry ON execution) Number of output •...
  • Page 162 11 TROUBLESHOOTING MELSEC-Q (7) Debug Corresponding Set by Applicable Number Name Meaning Explanation ACPU (When Set) OFF : Not ready S (Status SM800 Trace preparation • Switches ON when the trace preparation is completed. ON : Ready change) • Trace is started when this relay switches ON. OFF : Suspend SM801 Trace start •...
  • Page 163 11 TROUBLESHOOTING MELSEC-Q (9) A to Q/QnA conversion correspondences Special relays SM1000 to SM1255 are the relays which correspond to ACPU special relays M9000 to M9255 after A to Q/QnA conversion. All of these special relays are controlled by the system so that users cannot turn them ON/OFF in the program.
  • Page 164 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) ACPU Special Special Applicable Special Relay after Relay for Name Meaning Details Relay Conversion Modification • Turned on when battery voltage reduces to less than OFF : Normal M9006 SM1006 Battery low specified. Turned off when battery voltage becomes ON : Battery low normal.
  • Page 165 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) ACPU Special Special Applicable Special Relay after Relay for Name Meaning Details Relay Conversion Modification • Used as dummy contacts of initialization and application M9036 SM1036 Always ON instruction in sequence program. • SM1038 and SM1037 are turned on and off without regard to position of key switch on CPU module front.
  • Page 166 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) ACPU Special Special Applicable Special Relay after Relay for Name Meaning Details Relay Conversion Modification • Provides P, I set request after transfer of the other OFF : Other than when P, I set Sub program 3 P, program (for example subprogram when main program is M9061...
  • Page 167 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) ACPU Special Special Applicable Special Relay after Relay for Name Meaning Details Relay Conversion Modification • Set when consecutive transfer is not executed with Continuous OFF : When transition is consecutive transfer enabled. Reset when transfer of one M9104 SM1104 SM324...
  • Page 168 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) ACPU Special Special Applicable Special Relay after Relay for Name Meaning Details Relay Conversion Modification ZNRD instruction • Depends on whether or not the ZNRD (word device read) (LRDP instruction instruction has been received. OFF : Not accepted M9200 SM1200...
  • Page 169 11 TROUBLESHOOTING MELSEC-Q Special Relay List (Continued) ACPU Special Special Applicable Special Relay after Relay for Name Meaning Details Relay Conversion Modification Local station OFF : No errors Depends on whether or not a local station has detected an M9233 SM1233 error detect ON : Error detection...

  • Page 170: Special Register List

    11 TROUBLESHOOTING MELSEC-Q 11.7 Special Register List The special registers, SD, are internal registers with fixed applications in the PLC. For this reason, it is not possible to use these registers in sequence programs in the same way that normal registers are used. However, data can be written as needed in order to control the CPU modules and remote I/O modules.
  • Page 171 11 TROUBLESHOOTING MELSEC-Q Special Register List (1) Diagnostic Information Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) Diagnostic Diagnosis • Error codes for errors found by diagnosis are stored as BIN data. D9008 format S (Error) errors error code •...
  • Page 172 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) • Common information corresponding to the error codes (SD0) is stored here. • The following four types of information are stored here: Slot No.
  • Page 173 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) Time (value set) Meaning Number Time : 1 µs units (0 to 999 µs) Time : 1 ms units (0 to 65535 ms) SD10 SD11 (Vacant)
  • Page 174 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) • Individual information corresponding to error codes (SD0) is stored here. SD16 File name/Drive name (Example) File name= Number Meaning ABCDEFGH. IJK SD16 Drive B15 to B8 B7 to B0...
  • Page 175 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) Error code that • Stores error code that performs error reset SD50 Error reset +Rem performs error reset • All corresponding bits go ON when battery voltage drops. •...
  • Page 176 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) When F goes ON due to OUT F or SET F , the F numbers which SD64 D9125 go progressively ON from SD64 through SD79 are registered. F numbers turned OFF by RST F are deleted from SD64 to SD79, SD65 D9126...
  • Page 177 11 TROUBLESHOOTING MELSEC-Q Special Register List (2) System information Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) • The switch status of the remote I/O module is stored in the following format. B4 B3 S (Always) Remote Vacant Remote I/O module switch status Always 1: STOP...
  • Page 178 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) 0: Test not yet executed 1: During X Device test device test SD206 execution • Set when the device test mode is executed on GX Developer. (Request) 2: During Y type...
  • Page 179 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) SD220 • LED display ASCII data (16 characters) stored here. SD221 SD220 15th character from the right 16th character from the right SD222 SD221 13th character from the right...
  • Page 180 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) When Xn0 of the installed CC-Link goes ON, the bit corresponding to the station switches ON. When either Xn1 or XnF of the installed CC-Link switch OFF, the bit corresponding to the station switches ON.
  • Page 181 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) No. of modules SD340 • Indicates the number of modules installed on Ethernet. installed SD341 I/O No. • Ethernet I/O No. of the 1st module installed. Network SD342 •...
  • Page 182 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) Instruction reception status of channel 1 Not used Instruction reception status of channel 2 Instruction reception status of channel 3 Instruction reception Instruction reception status of channel 4 SD380 Instruction reception status of channel 5...
  • Page 183 11 TROUBLESHOOTING MELSEC-Q Special Register List (4) Scan information Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) Execution type of Execution • Program number of program currently being executed is S (Status SD500 program being program No. stored as BIN value.
  • Page 184 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) • Waiting time at the time of constant scan setting is stored Constant scan wait SD542 S (First into SD542, SD543. (Measurement is made in 100µs time (ms unit) Constant scan increments.)
  • Page 185 11 TROUBLESHOOTING MELSEC-Q Special Register List (5) Memory card Corresponding Set by Corresponding Number Name Meaning Explanation ACPU (When set) • Indicates memory card A model installed B8 B7 B4 B3 0< ----------- >0 Memory Memory S (Initial Drive 1 0: Does not exist SD600 card A...
  • Page 186 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) File register S (Status SD640 Drive number • Stores drive number being used by file register. drive change) SD641 • Stores file register file name (with extension) selected at parameters or by use of QDRSET instruction as ASCII code.
  • Page 187 11 TROUBLESHOOTING MELSEC-Q (6) Instruction-Related Registers Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) • During block operations, turning SM705 ON makes it possible to use SD705 the mask pattern being stored at SD705 (or at SD705 and SD706 if Mask pattern Mask pattern double words are being used) to operate on all data in the block with SD706...
  • Page 188 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) • Stores the mask patterns masked by the IMASK instruction as follows. l49 l48 SD781 SD781 Mask pattern S (During SD782 of IMASK Mask pattern execution) SD793...
  • Page 189 11 TROUBLESHOOTING MELSEC-Q (7) A to Q/QnA conversion correspondences ACPU special registers D9000 to D9255 correspond to the special registers SD1000 to SD1255 after A-series to the Q/QnA-series conversion. Since data are all set to these special registers on the system side, the user cannot turn them ON/OFF in a program.
  • Page 190 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) ACPU Special Special Corresponding Name Meaning Details Special Register after Register for Conversion Conversion Modification • If I/O modules, of which data are different from data entered, are detected when the power is turned on, the first I/O number of the lowest number unit among the detected units is stored in hexadecimal.
  • Page 191 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) ACPU Special Special Corresponding Special Register after Register for Name Meaning Details Conversion Conversion Modification • When operation error has occurred during execution of application instruction, the step number, at which Step number at the error has occurred, is stored in BIN code.
  • Page 192 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) ACPU Special Special Corresponding Special Register after Register for Name Meaning Details Conversion Conversion Modification • If scan time is larger than the content of SD526, the Maximum scan value is newly stored at each END. Namely, the D9019 SD1019 SD526...
  • Page 193 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) ACPU Special Special Corresponding Special Register after Register for Name Meaning Details Conversion Conversion Modification • When SM803 is turned ON/OFF by peripheral device to activate sampling trace STRA , STRAR , value For sampling Step or time during stored in SD1044 is used as sampling trace condition.
  • Page 194 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) ACPU Special Special Corresponding Special Register after Register for Name Meaning Details Conversion Conversion Modification • Sets the time check time of the data link instructions (ZNRD, ZNWR) for the MELSECNET/10. Register for •...
  • Page 195 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continued) ACPU Special Special Corresponding Name Meaning Details Special Register after Register for Conversion Conversion Modification • When one of F0 to 2047 is turned on by SET F 1 is added to the contents of SD63. When RST F or LEDR instruction is executed, 1 is subtracted from Annunciator the contents of SD63.
  • Page 196 11 TROUBLESHOOTING MELSEC-Q Special Register List (10) Special register list dedicated for QnA ACPU Special Special Corresponding Special Register after Register for Name Meaning Details Conversion Conversion Modification Stores the execution result of the ZNRD (word device read) instruction 0: Normal end 2: ZNRD instruction •...
  • Page 197 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continue) ACPU Special Special Corresponding Name Meaning Details Special Register after Register for Conversion Conversion Modification • Loopback in forward/reverse loops Master station 0: Forward loop, Station 2 Station 3 Station 1 Station n during data link 1: Reverse loop, during data link...
  • Page 198 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continue) ACPU Special Special Corresponding Name Meaning Details Special Register after Register for Conversion Conversion Modification Stores conditions Station numbers of local stations that have detected D9216 SD1216 for up to numbers errors are stored into corresponding data register bits as 1 to 16 indicated below.
  • Page 199 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continue) ACPU Special Special Corresponding Name Meaning Details Special Register after Register for Conversion Conversion Modification Stores conditions Stores the local or remote station number at which a D9232 SD1232 for up to numbers forward or reverse loop error has occurred 1 to 8 Device...
  • Page 200 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continue) ACPU Special Special Corresponding Name Meaning Details Special Register after Register for Conversion Conversion Modification Stores conditions Stores the local station number which is in STOP or PAUSE D9248 SD1248 for up to numbers 1 mode.
  • Page 201 11 TROUBLESHOOTING MELSEC-Q Special Register List (Continue) (12) I/O module verification Set by Corresponding Corresponding Number Name Meaning Explanation (When ACPU set) SD1400 • When the power is turned on, the module numbers of the I/O D9116 modules whose information differs from the registered I/O module SD1401 D9117 information are set in this register (in units of 16 points).

  • Page 202: Appendices

    APPENDICES MELSEC-Q APPENDICES APPENDIX 1 Error Code Return to Origin During General Data Processing The CPU module returns an error code to the general data processing request origin when an error occurs and there is a general data processing request form the peripheral equipment, intelligent function module, or network system.

  • Page 203: Appendix 1.2 Description Of The Errors Of The Error Codes (4000 H To 4Fff H )

    APPENDICES MELSEC-Q APPENDIX 1.2 Description of the errors of the error codes (4000 to 4FFF The error contents of the error codes (4000 to 4FFF ) detected by the CPU module and the messages displayed by the GX Developer are shown below. Error code Error Error description...
  • Page 204 APPENDICES MELSEC-Q Error code Error Error description Countermeasure (hexadecimal) item The specified drive memory does not exist or 4021 Check the specified drive memory status. there is an error. The file with the specified file name or file No. 4022 Check the specified file name and file No.
  • Page 205 APPENDICES MELSEC-Q Error code Error Error description Countermeasure (hexadecimal) item The request contents cannot be executed 4050 because the memory card write protect switch Turn off the memory card write protect switch. is on. Check the following and make it countermeasures. The specified device memory cannot be 4051 •...
  • Page 206 APPENDICES MELSEC-Q Error code Error Error description Countermeasure (hexadecimal) item 4084 The specified pointer P, I cannot be detected. Check the data to be searched. Pointer P, I cannot be specified because the Specify pointer P, I after registering the program to be 4085 program is not specified in the parameter.
  • Page 207 APPENDICES MELSEC-Q Error code Error Error description Countermeasure (hexadecimal) item 40A0 A block No. outside the range was specified. Check the setting contents and make a correction. A number of blzocks that exceeds the range 40A1 Check the number of settings and make a correction. was specified.
  • Page 208 APPENDICES MELSEC-Q Error code Error Error description Countermeasure (hexadecimal) item Make a request again after completion of the online An online module change is already being 4212 module change, or continue after changing the made for other equipment. connection path. The specified head I/O number differs from the When making a request, specify the head I/O number of 4213...

  • Page 209: Appendix 2 External Dimensions

    APPENDICES MELSEC-Q APPENDIX 2 External Dimensions APPENDIX 2.1 CPU module Q25PHCPU MODE ERR. USER BAT. BOOT PULL RS-232 89.3(3.52) 27.4(1.08) Unit: mm (inch) App - 8 App - 8...

  • Page 210: Appendix 2.2 Power Supply Module

    APPENDICES MELSEC-Q APPENDIX 2.2 Power supply module (1) Power Supply Module (Q61P-A1, Q61P-A2, Q62P, Q63P) Q61P-A1 POWER PULL 90(3.55) 55.2(2.17) Unit: mm (inch) (2) Power Supply Module (Q64P) Q64P POWER PULL 115 (4.53) 55.2 (2.17) Unit: mm (inch) App - 9 App - 9...

  • Page 211: Appendix 2.3 Main Base Unit

    APPENDICES MELSEC-Q APPENDIX 2.3 Main base unit (1) Main Base Unit (Q33B) 4-mounting screws (M4 14) I/O0 I/O1 I/O2 POWER (0.30) 44.1 ± 169±0.3(6.65 0.01) 15.5 (1.74) (0.61) 189(7.44) Unit: mm (inch) (2) Main Base Unit (Q35B) 4-mounting screws (M4 14) I/O0 I/O1 I/O2...
  • Page 212 APPENDICES MELSEC-Q (4) Main Base Unit (Q312B) 4-mounting screws (M4 14) I/00 I/01 I/02 I/03 I/04 I/05 I/06 I/07 I/08 I/09 I/10 I/11 POWER (0.30) 44.1 419±0.3(16.51±0.01) 15.5 (1.74) (0.61) 439(17.30) Unit: mm (inch) App - 11 App - 11...

  • Page 213: Appendix 2.4 Extension Base Unit

    APPENDICES MELSEC-Q APPENDIX 2.4 Extension base unit Unit: mm (inch) (1) Extension Base Unit (Q52B) 4-mounting screws (M4 14) I/O0 I/O1 (0.30) 44.1 83.5±0.3 15.5 (1.74) (3.29±0.01) (0.61) 106 (4.17) Unit: mm (inch) (2) Extension Base Unit (Q55B) 4-mounting screws (M4 14) I/O0 I/O1 I/O2...
  • Page 214 APPENDICES MELSEC-Q (4) Extension Base Unit (Q65B) 4-mounting screws (M4 14) I/O0 I/O1 I/O2 I/O3 I/O4 POWER (0.30) 44.1 222.5±0.3(8.77±0.01) 15.5 (1.74) (0.61) 245(9.65) Unit: mm (inch) (5) Extension Base Unit (Q68B) 4-mounting screws (M4 14) I/O0 I/O1 I/O2 I/O3 I/O4 I/O5 I/O6...

  • Page 215: Appendix 3 Comparison Between Process Cpu And High Performance Model Qcpu

    APPENDICES MELSEC-Q APPENDIX 3 Comparison Between Process CPU and High Performance model QCPU The comparison between the Process CPU and High Performance model QCPU is given below. APPENDIX 3.1 Function comparison Function Version and Serial Number of High Performance model QCPU Process Function Version A Function Version B...
  • Page 216 APPENDICES MELSEC-Q MEMO App - 15 App - 15...
  • Page 217 INDEX Cable ............6- 2 Allowable momentary power failure period ... 4- 3 Stage ............2- 3,6- 5 External dimensions CPU .............4- 3 Base unit Base unit............6- 1 Extension ........2- 3, 6- 5, 6- 6 Power supply module........5- 2 External dimensions diagram..App- 9 to App-12 Installation and removal of the module ........
  • Page 218 Base unit............6- 1 Battery ............7- 2 Performance ........... 4- 1 CPU .............4- 3 Power supply module Extension cable...........6- 2 External dimensions diagram....App- 8 Memory card ..........7- 1 Example of wiring ........9-26 Power supply module........5- 2 Installation..........9-14 Wiring Names of parts and settings ...... 5- 6 Extension cable...........2- 3 Heat generation...........9- 6 Specifications..........
  • Page 219 1. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be repaired at no cost via the dealer or Mitsubishi Service Company.
  • Page 220 Process CPU User's Manual (Hardware Design,Maintenance and Inspection) QNPHCPU-U-HH-E MODEL MODEL 13JR55 CODE SH(NA)-080314E-B(0210)MEE HEAD OFFICE : 1-8-12, OFFICE TOWER Z 14F HARUMI CHUO-KU 104-6212,JAPAN NAGOYA WORKS : 1-14 , YADA-MINAMI 5 , HIGASHI-KU, NAGOYA , JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.

This manual is also suitable for:

Melsec- q q25phcpu

Table of Contents
