- Page 1 In-ceiling Housing Installation Manual SHD-3000F1...
-
Page 2: Table Of Contents
Table Of COnTenTS Overview What’s Included Installation Instructions Installation (indoor type) Installation (outdoor type) Product Specifications 2_ SHD-3000F1... -
Page 3: What's Included
InCluded HOUSING SAFETY BRACKET (1EA) SAFETY WIRE (1SET) outdoor type (3EA) Lower bracket (exclusively for TEMPLATE (1EA) indoor dome cameras) (1EA) indoor type (2EA) In-ceiling Housing Installation Manual SHD-3000F1 INSTALLATION MANUAL SHD-3000F1 _3... -
Page 4: Installation Instructions
Remove the round filling (“C”) from the tEMpLAtE. ❶ Place TeMPlaTe A onto the CeIlInG bOard to which you will attach the ceiling mount ADAPTOR and drill a hole of Ø198mm in diameter. See the figure below for the hole shape. CEILING BOARD TEMPLATE 4_ SHD-3000F1... - Page 5 3. To connect to the camera, insert the external cable through the side hole on the housing to the inside of the housing as shown in the figure. Refer to the installation manual of the camera that you want to install, and prepare necessary cables for camera connection. HOUSING CEILING HOUSING Hole External Cable SHD-3000F1 _5...
- Page 6 Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET BRACKET HOUSING BRACKET BRACKET <A> <B> SCREW Turn clockwise 5. Combine the dome camera and the bracket using two screws. Lower bracket is exclusively for indoor use. 6_ SHD-3000F1...
- Page 7 6. Insert the bracket where the camera is mounted into the housing and fix it by turning it in the lOCK direction. When the installation is completed, remove both PROTECTIVE TAPE and PRETOECTIVE COVER from the lens. 천장 CEILING HOUSING 하우징 7. Attach the COver to the hOuSInG. 하우징 HOUSING 커버 Cover SHD-3000F1 _7...
-
Page 8: Installation (Outdoor Type)
Hook and fix the other end of SafeTY wIre onto the hOuSInG as shown below: Nut (N1) ANCHOR BOLT Safety BRACKET Nut (N2,N3) SAFETY WIRE ANCHOR BOLT CEILING CEILING HOUSING The ANCHOR BOLTs and nuts are optional and not included in the product package. 8_ SHD-3000F1... - Page 9 SCREWs (x2) clockwise to fix the HOUSING on the CEILING. (The braCKeT will be positioned from <A> to <B> as shown.) Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET BRACKET HOUSING BRACKET BRACKET <A> <B> SCREW Turn clockwise SHD-3000F1 _9...
- Page 10 If waterproofing in the connected cable jacket is poor, it may cause leaks. Make sure you tape it tight and thoroughly. The butyl rubber tape for waterproofing can extend at least twice as long as the original length. 10_ SHD-3000F1...
- Page 11 When attaching the camera to the mount, check the arrow directions in the figure below before proceeding. 7. Remove the dome cover from the camera, and install the cover onto the HOUSING. CEILING HOUSING HOUSING Assemble the network cable through the Cover hole on the bottom part of the housing. SHD-3000F1 _11...
-
Page 12: Product Specifications
PrOduCT SPeCIfICaTIOnS Item Specifications Dimension (mm) D224 X H106.9 Weight 490g Temperature -10°C ~ 50°C Material Color Ivory 12_ SHD-3000F1... - Page 13 MEMO SHD-3000F1 _13...
- Page 14 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
