- Page 1 In-Ceiling Plenum Housing Installation Manual SHD-3000F5...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Overview ................................What’s Included ..............................Installation Instructions ............................ How to install ............................... Product Specifications ........................... 2_ SHD-3000F5... -
Page 3: Overview
This In-CEILING HOUSING is a mounting ADAPTOR that is designed to mount PNM-9000VQ in built-in style on a double-layer ceiling. The housing is Plenum rated when properly installed. WHAT’S INCLUDED HOUSING SAFETY BRACKET (1EA) SAFETY WIRE (1SET) In-ceiling Housing Installation Manual SHD-3000F5 TEMPLATE (1EA) INSTALLATION MANUAL SHD-3000F5 _3... -
Page 4: Installation Instructions
Remove the round fi lling (“C”) from the TEMPLATE. ➋ Place TEMPLATE A onto the CEILING BOARD to which you will attach the ceiling mount ADAPTOR and drill a hole of Ø326mm in diameter. See the fi gure below for the hole shape. CEILING BOARD TEMPLATE 4_ SHD-3000F5... - Page 5 2. Remove the CAP and NUT that fi t to the size of the HOLE you are going to use. 3. Remove the Dome Cover and Mounting Plate according to the Disassembling section in the PNM-9000VQ manual. 4. Join the MOUNTING PLATE to the Housing using the SCREWS shipped with PNM-9000VQ. SCREW MOUNTING PLATE SHD-3000F5 _5...
- Page 6 After fi xing the SAFETY WIRE to the HOUSING, tighten the screw in the SAFETY RING to the end. 6. In the case that a pipe is to be connected to the External Cable hole, the pipe must be inserted within the depth of 15mm or less. Less than 15mm 6_ SHD-3000F5...
- Page 7 HOUSING on the CEILING. (The BRACKET will be positioned from <A> to <B> as shown.) Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET BRACKET SAFETY WIRE BRACKET HOUSING BRACKET <A> <B> SCREW Turn clockwise SHD-3000F5 _7...
- Page 8 Disassembling in the PNM-9000VQ manual. HOUSING Cover 10. Align and attach the COVER to the HOUSING following the arrow, and push it hard so that four Hook & Loop Fasteners are fi rmly attached to it. Hook & Loop Fasteners 8_ SHD-3000F5...
- Page 9 COVER to fi x it to the HOUSING. Since Hook & Loop Fasteners are lightly attached to the surface, they can easily be detached. Therefore, the screws need to be tightened immediately after attaching the Hook & Loop Fasteners. SHD-3000F5 _9...
-
Page 10: Product Specifications
PRODUCT SPECIFICATIONS Item Specifi cations Dimension (mm) Ø352 X H109 2550g (5.62 lbs) Weight -10°C ~ 55°C (14°F ~ 131°F) Temperature Aluminum, Plenum rated Material Color White (Cover) Unit : mm (Inches) 10_ SHD-3000F5... - Page 11 MEMO...
