BOX CAMERA HOUSING
User Manual
SHB-D-9000H

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHB-D-9000H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wisenet SHB-D-9000H

Summary of Contents for Wisenet SHB-D-9000H

  • Page 1 BOX CAMERA HOUSING User Manual SHB-D-9000H...
  • Page 2 BOX CAMERA HOUSING User Manual v1.1 7-2020 Copyright ©2020 Hanwha Techwin America, All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
  • Page 3 Hanwha Techwin America Technical Support (877) 213-1222...

  • Page 4: Product Overview

    Introduction PRODUCT OVERVIEW y This camera housing is designed to install the TNB-9000 camera and compatible lenses for use in indoor and outdoor locations securely to protect it from external conditions. The included IP67 rated power supply is integrated in to the wall mount arm and accepts a wide range of input voltages.

  • Page 5: Contents Of Box

    Contents of Box A. Enclosure/housing B. Wall mount arm C. Outdoor power supply (Can be mounted inside wall mount arm) D. Power supply mounting screws and washers E. Camera mounting bolts and washers F. Cable management sleeve inside wall mount arm G.
  • Page 6 Loosen 2 screws on the top back side of the Loosen the lockable latch on the back side of the housing. housing. Slowly open the top hatch and be careful not to let Remove the 4 screws on the camera mounting it drop.
  • Page 7 Note: If your lens needs room to zoom in and out, make sure you align the max zoom position with the front of the camera mounting plate. Carefully flip the camera and plate upside to keep Align the front of the lens with the front of the position of camera on mounting plate.
  • Page 8 Close the hatch to the housing and secure it with Remove cable gland nut to provide power, network, the lockable latch. Flip housing upside down. or other cables needed in the housing. Carefully remove cable gland rubber cable With the smaller Allen wrench (provided) loose the sealer with a screw drive so as not to damage it.
  • Page 9 With the larger Allen wrench (provided) remove the Run necessary cables (power, network, etc...) bolt on the bottom of the arm that allows it to be through arm and arm knuckle. opened. See Appendix A if mounting a power supply inside the arm.
  • Page 10 Pass the cable end through the cable gland port on Before mounting the other side of the arm knuckle the housing. Carefully insert the cable gland seal to the housing, completely hand tighten the cable and then very loosely screw on the cable gland nut. glands.
  • Page 11 Open the lid to the housing. Locate the power Insert the red cable into the red side of the 12V cable from the cable gland port and the 12V power power connector. Tighten with a small flat screw connector. driver. Repeat for black cable. Connect the network and power cable to the Place the humidity removal pack (included) near camera.
  • Page 12 -----> For proper closure please follow these steps. Use the latch to pull the lid down. Once latch is pulled down in this position. Use a This will ensure proper seal. screwdriver to tighten the two top fasteners.
  • Page 13 Above is a properly sealed lid.

  • Page 14: Appendix A: Mounting Power Supply Inside Arm

    Appendix A: Mounting Power Supply Inside Arm Open arm and push cable (the end with the Position the power supply in the arm so that the single black and single red cable) through the holes for the screws align. knuckle arm hole. Find 4 Philips head screws and tightening Push the other end of the power supply cable washers (included).
  • Page 15 * You can find applicable models with accessory selector www.hanwha-security.com/en/products/accessory-selector/ * The lastest product information / specification can be found at hanwhasecurity.com * Design and specifications are subject to change without notice. * Wisenet is the proprietary brand of Hanwha Techwin formerly known as Samsung Techwin.
  • Page 16 Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwhasecurity.com...
