- Page 1 TNB-9000 Housing User Manual SHB-9000H...
-
Page 2: Safety Information
Safety Instructions SAFETY INFORMATION The safety instructions below are prepared to avoid physical or monetary damage from an accident, so please read carefully and follow them. ~ Do not install the product in a place that contains salt or produces the sulphurous gas. ~ Do not insert metal objects or inflammable substances inside. -
Page 3: Precautions Before Installation
~ When mounting the SHB-9000H Housing to a wall, please use the dedicated bracket, SBB-900. ※ If you have to use any bracket other than this, please use the standard screw (1/4-20X1/2) to join the housing and bracket. -
Page 4: Product Overview
Introduction PRODUCT OVERVIEW ~ SHB-9000H Housing is designed to protect TNB-9000 camera from external environment. COMPONENTS AND ACCESSORIES Check if the following items are included in the product package. Appearance Item Name Quantity Remarks User Manual Screw (1/4-20 X 3/8), Length(9.5 mm) -
Page 5: Optional Lens
INCLUDED MOUNTING ACCESSORIES This mount is NOT included in SHB-9000H/KDO model, please check the product label. ※ OPTIONAL LENS The following lenses compatible with TNB-9000 are separately sold. Item Name Model Name Canon 24mm f1.4L, Auto-Iris Canon 35mm f1.4L, Auto-Iris Canon 50mm f1.4, Auto-Iris... -
Page 6: Component Names And Functions
Introduction ※ This device must be installed by a skilled person, not by an ordinary person. COMPONENT NAMES AND FUNCTIONS Sun shield Cover Fuses(2EA) : Ratings (3 A, 250 V) DC 12V connection adapter Terminal for power supply connection Fixing latch Please use a lock hook of which thickness is no more ※... -
Page 7: Installing The Camera
Installation INSTALLING THE CAMERA TNB-9000 Camera tray Spring washer Spring washer Screw (1/4-20 x 3/8) Screw (1/4-20 x 3/4) English_7... -
Page 8: Installation
Installation INSTALLING THE BRACKET Sun shield Housing Flat Washer Spring Washer Screw (1/4-20 X 1/2) SBB-900 SBB-900 Bracket mounted to the Housing is separately sold. ※ 8_ Installation... - Page 9 HOW TO CONNECT THE POWER SUPPLY AND NETWORK(ALL REGIONS EXCEPT THE US AND CANADA) The camera is designed to connect the cable to the port (compressive fitting) on the bottom side at the rear of the housing. Unfasten the nut of the compressive fitting at the rear of the housing and insert the power cable and the network cable from the outside of the housing inside of it according to the size of each hole.
- Page 10 Installation HOW TO CONNECT THE POWER SUPPLY AND NETWORK(THE US AND CANADA ONLY.) The camera is designed to connect the cable to the port (compressive fitting) on the bottom side at the rear of the housing. Unfasten the nut of the compressive fitting at the rear of the housing and insert the power cable and the network cable from the outside of the housing inside of it according to the size of each hole.
-
Page 11: Specifications
Specifications DIMENSION unit: mm... - Page 12 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwhasecurity.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
