  • Page 1 BOX CAMERA HOUSING User Manual SHB-4300HP...
  • Page 2 BOX CAMERA HOUSING User Manual Copyright ©2016 Hanwha Techwin Co., Ltd. All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.

  • Page 3: Safety Instructions

    Safety Instructions The safety instructions below are prepared to avoid physical or monetary damage from an accident, so please read carefully and follow them.  Do not install the product in a place that contains salt or produces the sulphurous gas. ...
  • Page 4 Contents Product Overview INTRODUCTION Features Installation INSTALLATION Installing the Camera and Bracket Specifications SPECIFICATIONS 10 Dimension 4_ contents...
  • Page 5 Introduction PRODUCT OVERVIEW  This CAMERA-HOUSING is designed to install the outdoor CCTV camera securely to protect it from the external conditions. FEATURES  This product is a 16” camera housing that is designed to guarantee that the outdoor CCTV camera is installed securely for stable operation. ...
  • Page 6 Installation INSTALLATION Wiring Diagram RJ45 Terminal Layout Terminal Layout Input Output Tx+ + Power2_A Tx- + Power2_A Rx+ + Power2_B Power1_A POE POWER + Power1_A POE POWER + Rx- + Power2_B Power1_B POE POWER - Power1_B POE POWER - 6_ Installation...
  • Page 7 INSTALLING THE CAMERA AND BRACKET  Use 5mm wrench, open the housing top part.Remove the camera plate, Install the camera on the camera plate and screw up.Check the lens and focus and Close the housing top part and screw up tightly. ...
  • Page 8 Specifications SPECIFICATIONS SHB-4300HP Purpose Outdoor Housing Product Name Box Camera Housing Features PoE function, Dustproof, Waterproof, IP66 Material Aluminium Die-Casting ADC 12 Use Condition -35°C ~ +50°C Weight 2.5kg (without Bracket) Input Power DC12V(Min30W) & PoE Power(IEEE802.3at) Output Power Defroster...
  • Page 9 SHB-4300HP Functional Relation Chart Temperature (°C)  The specification for this product may change without prior notice for product improvement. English_9...
  • Page 10 Specifications DIMENSION  Body Unit: mm  Front  Mount Base 10_ Specifications...
  • Page 11 MEMO...
