- Page 1 BOX CAMERA HOUSING User Manual SHB-4301HP...
- Page 2 BOX CAMERA HOUSING User Manual Copyright ©2018 Hanwha Techwin Co., Ltd. All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
- Page 3 Safety Instructions The safety instructions below are prepared to avoid physical or monetary damage from an accident, so please read carefully and follow them. y Do not install the product in a place that contains salt or produces the sulphurous gas. y Do not insert metal objects or inflammable substances inside.
-
Page 4: Table Of Contents
Contents INTRODUCTION Product Overview Features INSTALLATION Installation Installing the Camera and Bracket SPECIFICATIONS Specifications 10 Dimension 4_ contents... -
Page 5: Product Overview
Introduction PRODUCT OVERVIEW y This CAMERA-HOUSING is designed to install the outdoor CCTV camera securely to protect it from the external conditions. FEATURES y This product is a 16” camera housing that is designed to guarantee that the outdoor CCTV camera is installed securely for stable operation. y Firm and secure with the semi-permanent material, it is designed to be in harmony with the surrounding environment and to help the CCTV camera operate stably regardless of the dirt that may accumulate in the installation site and the weather condition. -
Page 6: Installation
Installation INSTALLATION Wiring Diagram RJ45 Terminal Layout Terminal Layout Input Output Tx+ + Power2_A Tx- + Power2_A Rx+ + Power2_B Power1_A POE POWER + Power1_A POE POWER + Rx- + Power2_B Power1_B POE POWER - Power1_B POE POWER - 6_ Installation... -
Page 7: Installing The Camera And Bracket
INSTALLING THE CAMERA AND BRACKET y Use 5mm wrench, open the housing top part.Remove the camera plate, Install the camera on the camera plate and screw up.Check the lens and focus and Close the housing top part and screw up tightly. y Use 5mm wrench, Install the bracket on the camera mount part and screw up tightly English_7... -
Page 8: Specifications
Specifications SPECIFICATIONS SHB-4301HP Purpose Outdoor Housing Product Name Box Camera Housing Features PoE function, Dustproof, Waterproof, IP66 Material Aluminium Die-Casting ADC 12 Use Condition -35°C ~ +50°C Weight 2.5kg (without Bracket) Input Power DC12V(Min30W) & PoE Power(IEEE802.3at) Output Power Defroster... - Page 9 SHB-4301HP Functional Relation Chart Temperature (°C) The specification for this product may change without prior notice for product improvement. The UTP cable is UTP (unshielded twisted pair) indoor cable and should not be used outdoors but STP (shielded twisted pair) is recommended for installation outdoors. If the UTP cable is used outdoors, problems can occur with the product such as an abnormal voltage being applied to the cable due to lightning.
-
Page 10: Dimension
Specifications DIMENSION y Body Unit: mm y Front y Mount Base 10_ Specifications... - Page 11 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
