- Page 1 In-ceiling Housing Installation Manual SHD-3000F2...
- Page 2 TABLE OF CONTENTS Overview What’s Included Installation Instructions Installation (indoor type) Product Specifications 2_ SHD-3000F2...
- Page 3 This In-CEILING HOUSING is a mounting ADAPTOR that is designed to mount the smart dome camera in built-in style on a double-layer ceiling. WHAT’S INCLUDED HOUSING SAFETY BRACKET (1EA) SAFETY WIRE (1SET) In-ceiling Housing Installation Manual SHD-3000F2 outdoor type (3EA) TEMPLATE (1EA) INSTALLATION MANUAL indoor type (2EA) SHD-3000F2 _3...
- Page 4 Place TEMPLATE A onto the CEILING BOARD to which you will attach the ceiling mount ADAPTOR and drill a hole of Ø165mm in diameter. See the figure below for the hole shape. Ø165mm Ø 천장 보드 CEILING BOARD 형판 TEMPLATE 4_ SHD-3000F2...
- Page 5 Refer to the installation manual of the camera that you want to install, and prepare necessary cables for camera connection. HOUSING 하우징 CEILING 천장 HOUSING 하우징 Hole 홀 External Cable 외부케이블 SHD-3000F2 _5...
- Page 6 Ensure that the HOUSING is firmly secured to the CEILING BOARD. BRACKET 브라켓 BRACKET 브라켓 HOUSING 하우징 BRACKET 브라켓 BRACKET 브라켓 <A> <B> <A상태> <B상태> SCREW 스크류 시계방향으로 회전 Turn clockwise 5. Remove the dome cover from the camera 6_ SHD-3000F2...
- Page 7 ※ When attaching the camera to the mount, check the arrow directions in the figure below before proceeding. CEILING 천장 HOUSING 하우징 7. install the cover onto the HOUSING. A ssemble the network cable through the hole on the bottom part of the housing. SHD-3000F2 _7...
- Page 8 PRODUCT SPECIFICATIONS Item Specifications D194 X H102 Dimension (mm) 350g Weight -10℃ ~ 50℃ Temperature Material Color Ivory...
