Operation, Parts
Magnum ProLTS17 & 19
Electric Airless Sprayers
Not approved for use in explosive atmospheres or hazardous locations.
For portable airless spraying of architectural paints and coatings.
Models: ProLTS17, ProLTS19
3000 psi (207 bar, 20.7 MPa) Maximum Working Pressure
See page 3 for additional model information.
Important Safety Instructions
Read all warnings and instructions in this manual and related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Related Manuals
Gun – 312830 (SG3)
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
Pump – 3A3172
3A3242C
ti27115a
EN
